Asus VW226 Series User manual

VW226Series
LCD Monitor
User Guide

ii
E3379
First Edition V1
January 2010
Copyright © 2010 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.

iii
Contents
Notices......................................................................................................... iv
Safety information ...................................................................................... vi
Care & Cleaning ........................................................................................ vii
Chapter 1: Product introduction
1.1 Welcome! .................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Monitor introduction .................................................................... 1-2
1.3.1 Front view ....................................................................... 1-2
1.3.2 Back view........................................................................ 1-3
Chapter 2: Setup
2.1 Assembling the monitor base..................................................... 2-1
2.2 Adjusting the monitor.................................................................. 2-1
2.3 Detaching the arm/base (for VESA wall mount)........................ 2-2
2.4 Connecting the cables................................................................. 2-3
2.5 Turning on the monitor................................................................ 2-3
Chapter 3: General instruction
3.1 OSD (On-Screen Display) menu ................................................ 3-1
3.1.1 How to reconfigure.......................................................... 3-1
3.1.2 OSD Function Introduction.............................................. 3-1
3.2 5RGEKſECVKQPUUWOOCT[.............................................................. 3-4
3.3 Troubleshooting (FAQ)................................................................ 3-8
3.4 Supported operating modes ....................................................... 3-9

iv
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modifications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
As an Energy Star
®Partner, our company has determined that this product meets
the Energy Star®guidelines for energy efficiency.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

v
TCO Development
Congratulations!
The display you have just purchased carries the
TCO’03 Displays label. This means that your
display is designed, manufactured and tested
according to some of the strictest quality and
environmental requirements in the world. This
makes for a high performance product, designed
with the user in focus that also minimizes the
impact on our natural environment.
Some of the features of the TCO’03 Display requirements:
Ergonomics
• Good visual ergonomics and image quality in order to improve the working
environment for the user and to reduce sight and strain problems. Important
parameters are luminance, contrast, resolution, reflectance, colour rendition
and image stability.
Energy
• Energy-saving mode after a certain time – beneficial both for the user and the
environment
• Electrical safety
Emissions
• Electromagnetic fields
• Noise emissions
Ecology
• The product must be prepared for recycling and the manufacturer must have a
certified environmental management system such as EMAS or ISO 14 001
• Restrictions on
- chlorinated and brominated flame retardants and polymers
- heavy metals such as cadmium, mercury and lead.
The requirements included in this label have been developed by TCO
Development in cooperation with scientists, experts, users as well as
manufacturers all over the world. Since the end of the 1980s TCO has been
involved in influencing the development of IT equipment in a more user-friendly
direction. Our labelling system started with displays in 1992 and is now requested
by users and IT-manufacturers all over the world.
For more information, please visit www.tcodevelopment.com

vi
Safety information
This symbol of the crossed out wheeled bin indicates that the product (electrical,
electronic equipment, and mercury-containing button cell battery) should not
be placed in municipal waste. Please check local regulations for disposal of
electronic products.
• Before setting up the monitor, carefully read all the documentation that came
with the package.
• To prevent fire or shock hazard, never expose the monitor to rain or moisture.
• Never try to open the monitor cabinet. The dangerous high voltages inside the
monitor may result in serious physical injury.
• If the power supply is broken, do not try to fix it by yourself. Contact a qualified
service technician or your retailer.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or over a
radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source indicated
on the label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power
standard.
• Do not overload power strips and extention cords. Overloading can result in
fire or electric shock.
• Avoid dust, humidity, and temperature extremes. Do not place the monitor in
any area where it may become wet. Place the monitor on a stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a long period
of time. This will protect the monitor from damage due to power surges.
• Never push objects or spill liquid of any kind into the slots on the monitor
cabinet.
• To ensure satisfactory operation, use the monitor only with UL listed
computers which have appropriate configured receptacles marked between
100-240V AC.
• If you encounter technical problems with the monitor, contact a qualified
service technician or your retailer.

vii
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the cables
and power cord. Follow the correct lifting techniques when positioning the
monitor. When lifting or carrying the monitor, grasp the edges of the monitor.
Do not lift the display by the stand or the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor
surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed
with a cloth dampened with mild cleaner.
• Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended
for use with the LCD. Never spray cleaner directly on the screen, as it may drip
inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• The screen may flicker during the initial use due to the nature of the fluorescent
light. Turn off the Power Switch and turn it on again to make sure that the
flicker disappears.
• You may find slightly uneven brightness on the screen depending on the
desktop pattern you use.
• When the same image is displayed for hours, an afterimage of the previous
screen may remain after switching the image. The screen will recover slowly or
you can turn off the Power Switch for hours.
• When the screen becomes black or flashes, or cannot work anymore, contact
your dealer or service center to fix it. Do not repair the screen by yourself!
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying
to complete a task.
IMPORTANT: Information that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.

viii 9JGTGVQſPFOQTGKPHQTOCVKQPRefer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Your product package may include optional documentation that may have
been added by your dealer. These documents are not part of the standard
package.

1-1ASUS VW226Series LCD Monitor
1.1 Welcome!
Thank you for purchasing the ASUS
®VW226Series LCD monitor!
The latest widescreen LCD monitor from ASUS provides a crisper, broader, and
brighter display, plus a host of features that enhance your viewing experience.
With these features, you can enjoy the convenience and delightful visual
experience that the VW226Series brings you!
1.2 Package contents
Check your VW226Series LCD monitor package for the following items:
LCD monitor
Quick start guide
1 x Power cord
1 x VGA cable
1 x DVI cable (VW226T / VW226N only)
1 x Audio cable (VW226T / VW226S only)
If any of the above items is damaged or missing, contact your retailer
immediately.

1-2 Chapter 1: Product introduction
1.3 Monitor introduction
1.3.1 Front view
Base
1. Button:
• Use this hotkey to switch from five video preset modes (Game
Mode, Night View Mode, Scenery Mode, Standard Mode, Theater Mode)t View Mode, Scenery Mode, Standard Mode, Theater Mode)Mode, Scenery Mode, Standard Mode, Theater Mode)
with SPLENDID™ Video Enhancement Technology.
• Exit the OSD menu or go back to the previous menu as the OSD menu
is active.
• Automatically adjust the image to its optimized position, clock, and phase
by pressing this button for 2-4 seconds (for VGA mode only).
2. Button:
• Press this button to decrease the value of the function selected or move
left/up to the previous function.
• This is also a hotkey for Volume adjustment or Contrast adjustment
depending on the monitor models.
3. MENU Button:
• Press this button to enter/select the icon (function) highlighted while the
OSD is activated.
4. Button:
• Press this button to increase the value of the function selected or move
right/down to the next function.
• This is also a hotkey for Brightness adjustment.
1 2 3 4 5

1-3
ASUS VW226Series LCD Monitor
1.3.2 Back view
5. Power button/power indicator
• Press this button to turn the monitor on/off
• The color definition of the power indicator is as the below table.
1. Audio-in port. This port connects PC audio source by the bundled audio
cable. (VW226T / VW226S only)
2. AC-IN port. This port connects the power connector from the bundled power
cord.
3. DVI port. This 24-pin port is for PC (Personal Computer) DVI-D digital signal
connection. (VW226T / VW226N only)
4. VGA port. This 15-pin port is for PC VGA connection.
Rear connectors
Status Description
Blue ON
Amber Standby mode
OFF OFF
Stereo
speaker
Rear connectors
Stereo
speaker
Screw holes for
VESA Wall Mount
The VESA wall mount kit (100 mm x 100 mm) is purchased separately.
12 3 4

1-4 Chapter 1: Product introduction

2-1ASUS VW226Series LCD Monitor
2.1 Assembling the monitor base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Connect the base with the arm according to the below drawing. A click shows
that the base has been connected successfully.
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
2.2 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
v<RXFDQDGMXVWWKHPRQLWRUVDQJOHIURPWRIt is normal that the monitor slightly shakes while you adjust the the viewing
angle. aaa

2-2 Chapter 2: Setup
2.3 Detaching the arm/base
(for VESA wall mount)
The detachable arm/base of the VW226Series LCD monitor is specially designed
for VESA wall mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the rubbers in the four screw holes (Figure 1).
3. Use a screwdriver to remove the two screws on the arm (Figure 1), then slide
out the arm/base to detach it from the monitor (Figure 2).
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
Arm/base
Rubbers in the
screw holes
Two screws
Figure 1 Figure 2

2-3
ASUS VW226Series LCD Monitor
2.4 Connecting the cables
1. Connect the cables as the following instructions:
•To connect the audio cable: connect one end of the audio cable to the
monitor’s Audio-in port, the other end to the computer's audio-out port.
•To connect the power cord: connect one end of the power cord securely to
the monitor’s AC input port, the other end to a power outlet.
•To connect the VGA/DVI cable:
a. Plug the VGA/DVI connector to the LCD monitor’s VGA/DVI port.
b. Connect the other end of the VGA/ DVI cable to your computer’s VGA/
DVI port.
c. Tighten the two screws to secure the VGA/DVI connector.
2.5 Turning on the monitor
Gently press the power button . See page 1-2 for the location of the power
button. The power indicator lights up in blue to show that the monitor is ON.
When both the VGA and the DVI cables are connected, you can choose either
VGA mode or DVI mode from the Input Select item of the OSD functions.
2. Gather all the cables with the cable hook.
Cable hook

2-4 Chapter 2: Setup

3-1ASUS VW226Series LCD Monitor
3.1 OSD (On-Screen Display) menu
3.1.1 How to reconfigure
1. Press the MENU button to activate
the OSD menu.
2. Press
and to navigate through the functions. Highlight and activate
the desired function by pressing the MENU button. If the function selected
has a sub-menu, press and again to navigate through the sub-menu
functions. Highlight and activate the desired sub-menu function by pressing
the MENU button.
3. Press and to change the settings of the selected function.
4. To exit the OSD menu, press the button. Repeat step 2 and step 3 to
adjust any other function.
3.1.2 OSD Function Introduction
1. Spendid
This function contains five
sub-functions you can select
for your preference. Each mode has the
Reset selection, allowing you to maintain
your setting or return to the preset mode.
•Scenery Mode: best choice for scenery photo display with SPLENDID™
Video Enhancement.
•Standard Mode: best choice for document editing with SPLENDID™
Video Enhancement.
•Theater Mode: best choice for movie with SPLENDID™ Video
Enhancement.
•Game Mode: best choice for game playing with SPLENDID™ Video
Enhancement.
•Night View Mode: best choice for dark-scene game or movie with
SPLENDID™ Video Enhancement.
• In the Standard Mode, the Saturation and Sharpness functions are not
user-configurable.
• In the other modes, the sRGB function is not user-configurable.

3-2 Chapter 3: General Instruction
• Phase adjusts the phase of the pixel clock signal. With a wrong phase
adjustment, the screen shows horizontal disturbances.
• Clock (pixel frequency) controls the number of pixels scanned by one
horizontal sweep. If the frequency is not correct, the screen shows vertical
stripes and the image is not proportional.
3. Color
Select the image color you like
from this function.
•Color Temp.: contains five color modes including Cool, Normal,
Warm, sRGB, and User mode.
•Skin Tone: contains three color modes including Reddish, Natural,
and Yellowish.
In the User mode, colors of R (Red), G (Green), and B (Bluee) are user-
configurable; the adjusting range is from 0-100.
2. Image
You can adjust brightness, contrast,
sharpness, saturation,position (VGA
only), ASCR, and focus (VGA only) from
this main function.
•Brightness: the adjusting range is from 0 to 100. is a hotkey to
activate this function.
•Contrast: the adjusting range is from 0 to 100.
•ASCR: turns on/off the ASCR(ASUS Smart Contrast Ratio) function.
•Sharpness: the adjusting range is from 0 to 100.
•Saturation: the adjusting range is from 0 to 100.
•Position: adjusts the horizontal postition (H-Position) and the vertical
position (V-Position) of the image. The adjusting range is from 0 to 100.
•Focus: reduces Horizonal-line noise and Vertical-line noise of the image
by adjusting (Phase) and (Clock) separately. The adjusting range is from
0 to 100.

3-3
ASUS VW226Series LCD Monitor
4. Input Select
In this function, you can select
either VGA or DVI input source.
(Only for some models)
5. System Setup
Allow you to adjust the system.
•Volume: the adjusting range is from 0 to 100. is a hotkey to activate
this function.
•OSD Setup:
* Adjusts the horizontal postition (H-Position)/ the vertical positionAdjusts the horizontal postition (H-Position)/ the vertical positionAdjusts the horizontal postition (H-Position)/ the vertical position
(V-Position) of the OSD from 0 to 100.
* Adjusts the OSD timeout from 10 to 120.
* Enables or disables the DDC/CI function.
•Language: there are ten languages for your selection, including English,
German, Italian, French, Dutch, Spanish, Russian, Traditional Chinese,
Simplified Chinese, and Japanese.
•Aspect Control: adjusts the aspect ratio to “Full” or “4:3”.
•Information: shows the monitor information.
•Reset: “Yes” allows you to restore the default setting.

3-4 Chapter 3: General Instruction
6SHFL¿FDWLRQVVXPPDU\9:61Panel Type TFT LCD
Panel size 22" (16:10) wide screen
Max. Resolution WSXGA+ 1680 x 1050
Pixel pitch 0.282mm
Brightness (Typ.) 250cd/m2
Contrast Ratio (Typ.) 1000:1
Contrast Ratio (Max.)
50000:1 (with ASCR ON)
Viewing angle(H/V) CR>10 /160Display colors 16.7M
Response time 5ms
SPLENDID™ Video
Enhancement
Yes
SPLENDID™ selection 5 video preset modes (by hotkey)
Auto adjustment Yes (by hotkey)
Color temperature selection 5 color temperatures
Skin-Tone selection 3 skin-tones
Digital input DVI-D with HDCP
Analog input D-Sub
Colors Black
Power LED Blue (On)/ Amber (Standby)
VESA wall mount 100 x 100mm
Tilt -aKensington lock Yes
Voltage rating $&a9Power consumption
Power On : < 35W, Standby: < 1W, Power Off: <1W
Temperature (Operating) 0&aC
Temperature
(Non-operating)
-20&aC
Dimension (W x H x D)
513 mm x 405 mm x 210 mm (machine)
588 mm x 495 mm x 150 mm (package)
Weight (Esti.)
4.5 kg (Net) ; 6.3 kg (Gross)
Multi-languages 10 languages (English, German, Italian, French, Dutch,
Spanish, Russian, Traditional Chinese, Simplified
Chinese, Japanese)
Accessories VGA cable, DVI cable, power cord, quick start guide,
warranty card
Regulation approvals Energy Star®, CB, CE, Gost-R, CCC, UL, FCC, C-Tick,
BSMI, VCCI, TCO03, RoHS, WEEE, PSB, J-MOSS,
Windows Vista, TUV-GS, TUV-Ergo, Windows 7
5RGEKſECVKQPUCTGUWDLGEVVQEJCPIGYKVJQWVPQVKEG
