Asus Maximus V Extreme User manual

Motherboard
Maximus Extreme

ii
E3498
Second Edition V2
October 2007
Copyright © 2007 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii
Contents
Notices....................................................................................................... viii
Safety information ...................................................................................... ix
About this guide .......................................................................................... x
Maximus Extreme specications summary ............................................ xii
Chapter 1: Product introduction
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2
1.3.1 ROG intelligent Performance & Overclocking features .. 1-2
1.3.2 ROG unique features ..................................................... 1-4
1.3.3 Product highlights ........................................................... 1-7
Chapter 2: Hardware information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard overview................................................................. 2-5
2.2.1 Placement direction ........................................................ 2-5
2.2.2 Screw holes .................................................................... 2-5
2.2.3 Motherboard layout ......................................................... 2-6
2.2.4 Audio card layout ............................................................ 2-6
2.2.5 Layout contents............................................................... 2-7
2.3 Central Processing Unit (CPU) ................................................... 2-9
2.3.1 Installing the CPU ......................................................... 2-10
2.3.2 Installing the CPU heatsink and fan.............................. 2-12
2.3.3 Uninstalling the CPU heatsink and fan ......................... 2-14
2.4 System memory ......................................................................... 2-16
2.4.1 Overview ....................................................................... 2-16
2.4.2 Memory congurations.................................................. 2-17
2.4.3 Installing a DIMM .......................................................... 2-19
2.4.4 Removing a DIMM ........................................................ 2-19
2.5 Expansion slots.......................................................................... 2-20
2.5.1 Installing an expansion card ......................................... 2-20
2.5.2 Conguring an expansion card ..................................... 2-20
2.5.3 Interrupt assignments ................................................... 2-21
2.5.4 PCI slots........................................................................ 2-22
2.5.5 PCI Express x1 slots..................................................... 2-22

iv
Contents
2.5.6 PCI Express x16 slots................................................... 2-22
2.6 Slide switch ................................................................................ 2-23
2.7 EL I/O shield, LCD Poster and Audio card Installation........... 2-24
2.7.1 EL I/O shield and LCD Poster Installation..................... 2-24
2.7.2 Audio card Installation................................................... 2-25
2.8 Connectors ................................................................................. 2-26
2.8.1 Rear panel connectors.................................................. 2-26
2.8.2 Internal connectors ....................................................... 2-29
2.8.3 Onboard switches ......................................................... 2-40
2.8.4 Installing the optional fans ............................................ 2-41
2.8.5 Installing the DIY Pedestal............................................ 2-42
2.8.6 Installing Fusion Block System accessory .................... 2-43
Chapter 3: Powering up
3.1 Starting up for the rst time........................................................ 3-1
3.2 Turning off the computer............................................................. 3-2
3.2.1 Using the OS shut down function.................................... 3-2
3.2.2 Using the dual function power switch.............................. 3-2
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS ............................................ 4-1
4.1.1 ASUS Update utility ........................................................ 4-1
4.1.2 Creating a bootable oppy disk....................................... 4-4
4.1.3 ASUS EZ Flash 2 utility................................................... 4-5
4.1.4 AFUDOS utility................................................................ 4-6
4.1.5 ASUS CrashFree BIOS 3 utility ...................................... 4-8
4.2 BIOS setup program .................................................................... 4-9
4.2.1 BIOS menu screen........................................................ 4-10
4.2.2 Menu bar....................................................................... 4-10
4.2.3 Navigation keys............................................................. 4-10
4.2.4 Menu items ....................................................................4-11
4.2.5 Sub-menu items.............................................................4-11
4.2.6 Conguration elds ........................................................4-11
4.2.7 Pop-up window ..............................................................4-11
4.2.8 Scroll bar........................................................................4-11
4.2.9 General help ..................................................................4-11

v
Contents
4.3 Main menu .................................................................................. 4-12
4.3.1 System Time [xx:xx:xx] ................................................. 4-12
4.3.2 System Date [Day xx/xx/xxxx]....................................... 4-12
4.3.3 Legacy Diskette A [1.44M, 3.5 in.]................................. 4-12
4.3.4 Language [English] ....................................................... 4-12
4.3.5 SATA 1-6..........................................................................................4-13
4.3.6 SATA Conguration ....................................................... 4-14
4.3.7 AHCI Conguration ....................................................... 4-15
4.3.8 System Information ....................................................... 4-16
4.4 Extreme Tweaker menu ............................................................. 4-17
4.4.1 Congure System Performance Settings...................... 4-17
4.5 Advanced menu ......................................................................... 4-24
4.5.1 CPU Conguration ........................................................ 4-25
4.5.2 Chipset.......................................................................... 4-26
4.5.3 OnBoard Devices Conguration ................................... 4-27
4.5.4 USB Conguration ........................................................ 4-28
4.5.5 PCI PnP ........................................................................ 4-29
4.6 Power menu................................................................................ 4-30
4.6.1 Suspend Mode [Auto] ................................................... 4-30
4.6.2 Repost Video on S3 Resume [Disabled]....................... 4-30
4.6.3 ACPI 2.0 Support [Disabled] ......................................... 4-30
4.6.4 ACPI APIC Support [Enabled]....................................... 4-30
4.6.5 APM Conguration........................................................ 4-31
4.6.6 Hardware Monitor ......................................................... 4-32
4.7 Boot menu .................................................................................. 4-35
4.7.1 Boot Device Priority ...................................................... 4-35
4.7.2 Boot Settings Conguration .......................................... 4-36
4.7.3 Security ......................................................................... 4-37
4.8 Tools menu ................................................................................. 4-39
4.8.1 ASUS EZ Flash 2.......................................................... 4-39
4.8.2 ASUS O.C. Prole......................................................... 4-40
4.8.3 AI Net 2 ......................................................................... 4-41
4.9 Exit menu.................................................................................... 4-42
Chapter 5: Software support
5.1 Installing an operating system ..................................................... -1

vi
Contents
5.2 Support DVD information ............................................................ 5-1
5.2.1 Running the support DVD ............................................... 5-1
5.2.2 Drivers menu................................................................... 5-2
5.2.3 Utilities menu .................................................................. 5-3
5.2.4 Make Disk menu ............................................................. 5-5
5.2.5 Manual menu .................................................................. 5-6
5.2.6 Video menu..................................................................... 5-6
5.2.7 ASUS Contact information .............................................. 5-7
5.2.8 Other information ............................................................ 5-7
5.3 Software information ................................................................... 5-9
5.3.1 ASUS MyLogo 3™........................................................... 5-9
5.3.2 AI NET 2.........................................................................5-11
5.3.3 AI Audio 2 (SoundMAX® High Denition Audio utility)... 5-12
5.3.4 ASUS PC Probe II......................................................... 5-21
5.3.5 ASUS AI Suite............................................................... 5-27
5.3.6 ASUS EPU Utility—AI Gear 3 ....................................... 5-29
5.3.7 ASUS AI Nap ................................................................ 5-30
5.3.8 ASUS Q-Fan 2 .............................................................. 5-31
5.3.9 ASUS AI Booster........................................................... 5-32
5.3.10 CPU Level Up ............................................................... 5-33
5.4 RAID congurations .................................................................. 5-34
5.4.1 RAID denitions ............................................................ 5-34
5.4.2 Installing Serial ATA hard disks ..................................... 5-35
5.4.3 Intel® RAID congurations............................................. 5-35
5.4.4 JMicron® RAID Conguration........................................ 5-43
5.5 Creating a RAID driver disk....................................................... 5-51
5.5.1 Creating a RAID driver disk without entering the OS.... 5-51
5.5.2 Creating a RAID/SATA driver disk in Windows®............ 5-51
Chapter 6: ATI® CrossFire™ technology support
6.1 Overview ....................................................................................... 6-1
6.1.1 Requirements.................................................................. 6-1
6.1.2 Before you begin............................................................. 6-1
6.2 Installing CrossFire™ graphics cards ....................................... 6-2
6.3 Software information ................................................................... 6-5
6.3.1 Installing the device drivers............................................. 6-5

vii
6.3.2 Using the Catalyst™ Control Center............................... 6-7
Appendix: CPU features
A.1 Intel®EM64T..................................................................................A-1
A.2 Enhanced Intel SpeedStep®Technology (EIST) ........................A-1
A.2.1 System requirements ......................................................A-1
A.2.2 Using the EIST................................................................A-2
A.3 Intel®Hyper-Threading Technology ...........................................A-3
Using the Hyper-Threading Technology ........................................A-3
A.4 Debug Code Table........................................................................A-4

viii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

ix
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. If possible, disconnect all power cables from the existing system
before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.
• Seek professional assistance before using an adpater or extension cord.
These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using,
contact your local power company.
• If the power supply is broken, do not try to x it by yourself. Contact a
qualied service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all
the manuals that came with the package.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied
service technician or your retailer.
This symbol of the crossed out wheeled bin indicates that the product (electrical,
electronic equipment, and mercury-containing button cell battery) should not
be placed in municipal waste. Check local regulations for disposal of electronic
products.

x
About this guide
This user guide contains the information you need when installing and conguring
the motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new
technology it supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to perform
when installing system components. It includes description of the switches,
jumpers, and connectors on the motherboard.
• Chapter 3: Powering up
This chapter describes the power up sequence and ways of shutting down
the system.
• Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
• Chapter 5: Software support
This chapter describes the contents of the support CD that comes with the
motherboard package and the software.
• Chapter 6: ATI CrossFire™ support
This chapter describes the ATI CrossFire™ feature and shows the graphics
card installation procedures.
• Appendix: CPU features
The Appendix describes the CPU features and technologies that the
motherboard supports as well as the debug code table for the LCD Poster.
Where to nd more information
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and
software products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty
yers, that may have been added by your dealer. These documents are not
part of the standard package.

xi
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the
Enter or Return key.
<Key1+Key2+Key3> If you must press two or more keys simultaneously, the
key names are linked with a plus sign (+).
Example: <Ctrl+Alt+D>
Command Means that you must type the command exactly
as shown, then supply the required item or value
enclosed in brackets.
Example: At the DOS prompt, type the command line:
afudos /i[lename]
afudos /iMaximus-Extreme.ROM
DANGER/WARNING: Information to prevent injury to yourself
when trying to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
NOTE: Tips and additional information to help you complete a
task.
IMPORTANT: Instructions that you MUST follow to complete a
task.

xii
Maximus Extreme specications summary
CPU LGA775 socket for Intel®Core™2 Extreme /
Core™2 Quad/ Core™2 Duo / Pentium®Extreme /
Pentium®D / Pentium®4 Processors
Support Intel®next generation 45nm Multi-Core CPU
Compatible with Intel®06/05B/05A processors
* Refer to www.asus.com for Intel CPU support list
Chipset Intel®X38 / ICH9R with Intel®Fast Memory Access
Technology
System Bus 1600 / 1333 / 1066 / 800 MHz
Memory 4 x DIMM, max. 8GB,
DDR3 1800(O.C.)/1600(O.C.)/1333/1066 MHz,
non-ECC, un-buffered memory
Dual channel memory architecture
Expansion Slots 3 x PCIe Gfx slot, support dual PCIe2.0 x16 or
PCIe2.0 x16, dual x8
2 x PCIe x1, PCIex1_1 (black) is compatible with the
audio slot.)
2 x PCI 2.2
CrossFire™ Technology Support ATI CrossFire™ graphics cards
Storage Southbridge
- 6 x SATA 3.0 Gb/s ports
- Intel Matrix Storage Technology supports RAID 0, 1,
10, 5, and JBOD.
JMicron®JMB363 PATA and SATA controller
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
- 2 x External SATA 3.0 Gb/s port (SATA On-the-Go)
LAN Dual Gigabit LAN controllers, both featuring AI NET2
Teaming technology support
High Denition Audio SupremeFX II Audio Card
- ADI 1988B 8-channel High Denition Audio CODEC
- Noise Filter
Coaxial / Optical S/PDIF out ports at back I/O
IEEE 1394 2 x 1394a ports (1 port onboard; 1 port at back I/O)
USB 12 x USB 2.0/1.1 ports (6 ports at mid-board, 6 ports at
back panel)
(continued on the next page)

xiii
Maximus Extreme specications summary
ASUS ROG
Overclocking features
Crosslinx technology
Extreme Tweaker
Loadline Calibration
Intelligent overclocking tools:
- CPU level up
- AI NOS™ (Non-delay Overclocking System)
- AI Overclocking (intelligent CPU frequency tuner)
- AI Booster Utility
- O.C. Prole
Overclocking protection:
- COP EX (Component Overheat Protection -EX)
- Voltiminder LED
- ASUS C.P.R. (CPU Parameter Recall)
ASUS Special Features Fusion Block System
LCD Poster
EL I/O
Onboard Switches: Power / Reset / Clr CMOS
Q-Connector
Q-Fan Plus
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS MyLogo 3™
Back Panel I/O Ports 1 x PS/2 Keyboard (purple)
1 x Optical + 1 x Coaxial S/PDIF Out
2 x External SATA
2 x LAN (RJ45) port
6 x USB 2.0/1.1 ports
1 x IEEE1394a port
1 x Clr CMOS switch
Internal I/O Connectors 3 x USB 2.0 connectors support additional 6 USB 2.0
ports
1 x Floppy disk drive connector
1 x IDE connector for two devices
6 x SATA connectors
8 x Fan connectors (1 x CPU/ 1 x Power/ 3 x Chassis/
3 x Optional)
3 x Thermal sensor connectors
1 x IEEE1394a connector
1 x S/PDIF Out connector
1 x Chassis Intrusion connector
24-pin ATX Power connector
8-pin ATX 12V Power connector
1 x En/Dis-able Clr CMOS slide switch
1 x EL I/O Shield connector
(continued on the next page)

xiv
Maximus Extreme specications summary
BIOS Features 16 Mb AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.4,
ACPI 2.0a Multi-Language BIOS
Manageability WOL by PME, WOR by PME, Chassis Intrusion, PXE
Accessories Fusion Block System Accessory
DIY Pedestal
ASUS Optional Fan
3 in 1 ASUS Q-connector kit
UltraDMA 133/100/66 cable
Floppy disk drive cable
Serial ATA cables
Serial ATA power cables
2-port USB2.0 module + IEEE1394a module
EL I/O Shield
Thermal sensor cables
Cable ties
User's manual
Software The hottest 3D game: S.T.A.L.K.E.R
Support DVD:
Drivers
ASUS PC Probe II
ASUS Update
ASUS AI Suite
Futuremark®3DMark®06 Advanced Edition
Kaspersky Anti-Virus software
Form Factor ATX Form Factor, 12”x 10.6” (30.5cm x 26.9cm)
*Specications are subject to change without notice.

1
Product
introduction
This chapter describes the motherboard
features and the new technologies
it supports.

ASUS Maximus Extreme
Chapter summary 1
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2

ASUS Maximus Extreme 1-1
1.1 Welcome!
Thank you for buying an ASUS®Maximus Extreme motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
If any of the above items is damaged or missing, contact your retailer.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS Maximus Extreme
I/O modules USB 2.0 module + IEEE 1394a module
Cables Ultra DMA 133/100/66 cable
Floppy disk drive cable
Serial ATA cables
Serial ATA power cables
Thermal sensor cables
Accessories Fusion Block System Accessory
EL I /O shield
LCD Poster
ASUS Optional Fan
3-in-1 ASUS Q-Connector Kit
Cable ties
DIY Pedestal
DVD/CD ASUS motherboard support DVD
The hottest game: S.T.A.L.K.E.R
Documentation User guide

1-2 Chapter 1: Product Introduction
1.3 Special features
1.3.1 ROG intelligent Performance & Overclocking features
Crosslinx
Crosslinx is a unique technology utilizing a dedicated special graphics controller to
optimize PCIe allocation with x16, x8, x8 lanes. Such architecture eliminates the x4
bottleneck found on competing x16, x16, x4 solutions. Hence, the Crosslinx is able
to provide faster graphics performance.
Fusion Block System
The Fusion Block System is a more efcient thermal solution compared to
competing followers with complicated looks. It is a hybrid thermal design that
combines the ROG’s renowned heatpipe design with the additional ability to
connect to a water cooling system. By taking the entire integrated solution into
design considerations, the user can enjoy exceptional thermal improvement to
Northbridge, Southbridge, Crosslinx, and even VRM with a single connection. The
Fusion Block System is the most versatile, efcient, and advanced thermal system
there is on a motherboard.
Component Overheat Protection -EX (COP EX)
The COP EX allows overclockers to increase chipset voltages without the worries
of overheating. It can also be used to monitor and save an overheating GPU.
The COP EX allows more freedom and less constraint for maximum performance
achievement.
Frequency LED
Worried that no one knows when you’ve overclocked your system to the max? Let
the motherboard do the talking! The onboard Frequency LED highlights when your
system is under extreme overclocking or normal states � allowing you to show off
your O.C. skills.
Voltiminder LED
In the persuit of extreme performance, overvoltage adjustment is critical but risky.
Acting as the “red zone” of a tachometer, the Voltiminder LED displays the voltage
status for CPU, NB, SB, and Memory in a intuitive color-coded fashion. The
Voltiminder LED allows quick voltage monitoring for overclockers. See pages 2-1
to 2-3 for details.

ASUS Maximus Extreme 1-3
CPU Level Up
Enjoy up to 40% more performance! Overclock immediately with OC prole
presets. Much more than simple frequency settings, this prole gives gamers
comprehensive and detailed tuning to frequencies, voltagies, and even timings to
create a real professional level of overclocking conguration. See pages 4-17 and
5-33 for details.
2-Phase DDR3
With the embedded 2-Phase DDR3, this motherboard allows users to reach higher
memory frequencies and enjoy better performance. Compared with only one phase
solutions, this motherboard ensures longer power component lifespans and higher
overclockability due to cooler temperatures and better efciency.
3rd Generation 8 Phase Power Design
Longer Life & Higher Efciency!
With power efciency so important to operating temperatures, ASUS' 3rd
generation 8-phase VRM design leads the industry with its 95% power efciency.
High quality power components such as low RDS (on) MOSFETs for minimum
switching loss & lower temperatures, Ferrite core chokes with lower hysteresis
loss, and high quality Japanese-made conductive polymer capacitors all add up
to ensure longer component life and lower power loss - creating more energy
efciency.
Loadline Calibration
The Loadline calibration ensures stable and optimal CPU voltage when heavy
loading.
Extreme Tweaker
This feature allows you to ne tune the CPU/memory voltage and gradually
increase the memory Front Side Bus (FSB) and PCI Express frequency at 1MHz
increment to achieve maximum system performance.
AI Booster
The ASUS AI Booster allows you to overclock the CPU speed in Windows
environment without the hassle of booting the BIOS.

1-4 Chapter 1: Product Introduction
ASUS O.C. Prole
The motherboard features the ASUS O.C. Prole that allows users to conveniently
store or load multiple BIOS settings. The BIOS settings can be stored in the
CMOS or a separate le, giving users freedom to share and distribute their favorite
settings. See page 4-40 for details.
C.P.R. (CPU Parameter Recall)
The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the
BIOS default settings in case the system hangs due to overclocking. When the
system hangs due to overclocking, C.P.R. eliminates the need to open the system
chassis and clear the RTC data. Simply shut down and reboot the system, and the
BIOS automatically restores the CPU default setting for each parameter.
1.3.2 ROG unique features
Supreme FX II features
Supreme FX II extends all the features of the 1st generation and places a shielding
to enhancethe sound quality. It also lights up the model name with stylish LEDs.
Noise Filter
This feature detects repetitive and stationary noises (non-voice signals) like
computer fans, air conditioners, and other background noises then eliminates
it in the incoming audio stream while recording. See page 5-15 and 5-20 for
details.
LCD Poster
The LCD Poster uses an external panel to smartly display the error message of the
physical system during the Power-On Self Test (POST) to inform you the boot error
instead of the “code name.”
Onboard Switches
A power-on button, a reset button, and a clear CMOS button are onboard to
provide overclockers and gamers the convenience of ne-tuning performance
when working on a bare (open-case) system. Press the power-on button to wake
up the system, the reset button to reboot, and the clear CMOS button to clear
setup information when the system hangs due to overclocking. See page 2-40 for
details.
