Asus P5B SE - Motherboard - ATX User manual

Motherboard
P5B SE

ii
E3381
Second Edition V2
September 2007
Copyright © 2007 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.

iii
Contents
Notices........................................................................................................ vii
Safety information .................................................................................... viii
About this guide ......................................................................................... ix
P5B SE specications summary............................................................... xi
Chapter 1: Product introduction
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2
1.3.1 Product highlights ........................................................... 1-2
1.3.2 ASUS AI Lifestyle features ............................................. 1-3
1.3.3 ASUS Special features ................................................... 1-5
Chapter 2: Hardware information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard overview................................................................. 2-2
2.2.1 Placement direction ........................................................ 2-2
2.2.2 Screw holes .................................................................... 2-2
2.2.3 Motherboard layout ......................................................... 2-3
2.2.4 Layout contents............................................................... 2-4
2.3 Central Processing Unit (CPU) ................................................... 2-6
2.3.1 Installing the CPU ........................................................... 2-7
2.3.2 Installing the heatsink and fan ........................................ 2-9
2.4 System memory ......................................................................... 2-13
2.4.1 Overview ....................................................................... 2-13
2.4.2 Memory configurations.................................................. 2-14
2.4.3 Installing a DIMM .......................................................... 2-18
2.4.4 Removing a DIMM ........................................................ 2-18
2.5 Expansion slots.......................................................................... 2-19
2.5.1 Installing an expansion card ......................................... 2-19
2.5.2 Configuring an expansion card ..................................... 2-19
2.5.3 Interrupt assignments ................................................... 2-20
2.5.4 PCI slots........................................................................ 2-21
2.5.5 PCI Express x1 slots..................................................... 2-21
2.5.6 PCI Express x16 slot..................................................... 2-21

iv
Contents
2.6 Jumpers ...................................................................................... 2-22
2.7 Connectors ................................................................................. 2-24
2.7.1 Rear panel connectors.................................................. 2-24
2.7.2 Internal connectors ....................................................... 2-26
Chapter 3: Powering up
3.1 Starting up for the rst time........................................................ 3-1
3.2 Powering off the computer.......................................................... 3-2
3.2.1 Using the OS shut down function.................................... 3-2
3.2.2 Using the dual function power switch.............................. 3-2
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS ............................................ 4-1
4.1.1 ASUS Update utility ........................................................ 4-1
4.1.2 Creating a bootable floppy disk....................................... 4-4
4.1.3 ASUS EZ Flash 2 utility................................................... 4-5
4.1.4 AFUDOS utility................................................................ 4-6
4.1.5 ASUS CrashFree BIOS 3 utility ...................................... 4-8
4.2 BIOS setup program .................................................................. 4-10
4.2.1 BIOS menu screen.........................................................4-11
4.2.2 Menu bar........................................................................4-11
4.2.3 Navigation keys..............................................................4-11
4.2.4 Menu items ................................................................... 4-12
4.2.5 Sub-menu items............................................................ 4-12
4.2.6 Configuration fields ....................................................... 4-12
4.2.7 Pop-up window ............................................................. 4-12
4.2.8 Scroll bar....................................................................... 4-12
4.2.9 General help ................................................................. 4-12
4.3 Main menu .................................................................................. 4-13
4.3.1 System Time ................................................................. 4-13
4.3.2 System Date ................................................................. 4-13
4.3.3 Legacy Diskette A ......................................................... 4-13
4.3.4 SATA 1, 2, 3, 4 .............................................................. 4-14
4.3.5 IDE Configuration.......................................................... 4-15
4.3.6 System Information ....................................................... 4-16

v
Contents
4.4 Advanced menu ......................................................................... 4-17
4.4.1 Jumperfree Configuration ............................................. 4-17
4.4.2 USB Configuration ........................................................ 4-19
4.4.3 CPU Configuration ........................................................ 4-20
4.4.4 Chipset.......................................................................... 4-21
4.4.5 Onboard Devices Configuration.................................... 4-24
4.4.6 PCI PnP ........................................................................ 4-25
4.5 Power menu................................................................................ 4-26
4.5.1 Suspend Mode.............................................................. 4-26
4.5.2 ACPI Version Features ................................................. 4-26
4.5.3 ACPI APIC Support....................................................... 4-26
4.5.4 APM Configuration........................................................ 4-27
4.5.5 Hardware Monitor ......................................................... 4-28
4.6 Boot menu .................................................................................. 4-29
4.6.1 Boot Device Priority ...................................................... 4-29
4.6.2 Removable Drives......................................................... 4-30
4.6.3 Boot Settings Configuration .......................................... 4-30
4.6.4 Security ......................................................................... 4-31
4.7 Tools menu ................................................................................. 4-33
4.7.1 ASUS EZ Flash 2.......................................................... 4-33
4.7.2 ASUS O.C. Profile......................................................... 4-34
4.8 Exit menu.................................................................................... 4-35
Chapter 5: Software support
5.1 Installing an operating system ................................................... 5-1
5.2 Support CD information .............................................................. 5-1
5.2.1 Running the support CD ................................................. 5-1
5.2.2 Drivers menu................................................................... 5-2
5.2.3 Utilities menu .................................................................. 5-3
5.2.4 Make Disk menu ............................................................. 5-5
5.2.5 Manuals menu ................................................................ 5-5
5.2.6 ASUS Contact information .............................................. 5-6
5.2.7 Other information ............................................................ 5-7
5.3 Software information ................................................................... 5-9
5.3.1 ASUS MyLogo™............................................................. 5-9
5.3.2 Audio configurations ......................................................5-11

vi
Contents
5.3.3 ASUS PC Probe II......................................................... 5-15
5.4 RAID congurations .................................................................. 5-21
5.4.1 RAID definitions ............................................................ 5-21
5.4.2 Installing Serial ATA hard disks ..................................... 5-21
5.4.3 JMicron®RAID Configuration........................................ 5-22
5.5 Creating a RAID driver disk....................................................... 5-30
5.5.1 Creating a RAID driver disk without entering the OS.... 5-30
5.5.2 Creating a RAID driver disk in Windows®...................... 5-30
Appendix: CPU features
A.1 Intel®EM64T..................................................................................A-1
A.2 Enhanced Intel SpeedStep®Technology (EIST) ........................A-1
A.2.1 System requirements ......................................................A-1
A.2.2 Using the EIST................................................................A-2
A.3 Intel®Hyper-Threading Technology ...........................................A-3

vii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modifications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

viii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. If possible, disconnect all power cables from the existing system
before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.
• Seek professional assistance before using an adpater or extension cord.
These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using,
contact your local power company.
• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all
the manuals that came with the package.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualified
service technician or your retailer.
This symbol of the crossed out wheeled bin indicates that the product (electrical,
electronic equipment and mercury-containing button cell battery) should not
be placed in municipal waste. Check local regulations for disposal of electronic
products.

ix
About this guide
This user guide contains the information you need when installing and configuring
the motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new
technology it supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to perform
when installing system components. It includes description of the switches,
jumpers, and connectors on the motherboard.
• Chapter 3: Powering up
This chapter describes the power up sequence and ways of shutting down
the system.
• Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
• Chapter 5: Software support
This chapter describes the contents of the support CD that comes with the
motherboard package.
• Appendix: CPU features
The Appendix describes the CPU features and technologies that the
motherboard supports.
Where to nd more information
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and
software products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty
flyers, that may have been added by your dealer. These documents are not
part of the standard package.

x
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the
Enter or Return key.
<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the
key names are connected with a plus sign (+).
Example: <Ctrl>+<Alt>+<D>
Command Means that you must type the command exactly as
shown.
Example: At the DOS prompt, type the command line:
afudos /i[lename]
afudos /iP5BSE.ROM
DANGER/WARNING: Information to prevent injury to yourself
when trying to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
NOTE: Tips and additional information to help you complete a
task.
IMPORTANT: Instructions that you MUST follow to complete a
task.

xi
P5B SE specications summary
(continued on the next page)
CPU LGA775 socket for Intel®Core™2 Quad/Core™2 Extreme/
Core™2 Duo/ Pentium®Extreme/ Pentium®D/
Pentium®4 processors
Compatible with Intel®05B/05A and 06 processors
Supports Intel® next generation 45nm Multi-Core CPU
* Refer to www.asus.com for Intel®CPU support list
Chipset Northbridge: Intel® P965 with Intel®Fast Memory Access
Southbridge: Intel®ICH8
System bus 1333*(overclocking)/1066/800/533 MHz
*The chipset officially supports the FSB up to 1066MHz.
Tuned by the ASUS exclusive technology, this
motherboard supports up to FSB 1333MHz. Refer to
www.asus.com for Intel®CPU support list
Memory Dual-channel memory architecture
- 4 x 240-pin DIMM sockets support unbuffered
non-ECC DDR2 800/667/533 MHz memory modules
- Supports up to 8 GB system memory
Expansion slots 1 x PCI Express™ x16 slot
2 x PCI Express™ x1 slots
3 x PCI slots
Storage Intel®ICH8 supports:
- 4 x SATA 3 Gb/s connectors
JMicron®JMB363 PATA and SATA controller supports:
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
- 1 x Internal SATA 3 Gb/s
- 1 x External SATA 3 Gb/s port on the rear
panel
- RAID 0, RAID 1, and JBOD configuration
(by 1 x External Serial ATA and 1 x Internal Serial
ATA)
LAN PCIeGigabit LAN controller
High Denition Audio Realtek®ALC662 6-channel CODEC
USB Supports up to 10 USB 2.0/1.1 ports (six at mid-board,
four on the rear panel)
ASUS special features ASUS Q-Fan
ASUS Q-Connector
ASUS O.C. Profile
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
MyLogo
ASUS Exclusive
Overclocking features
Stepless Frequency Selection (SFS) allows
- FSB tuning from 100MHz up to 500MHz at 1MHz
increment;
Overclocking protection:
- ASUS C.P.R. (CPU Parameter Recall)

xii
P5B SE specications summary
Rear panel 1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x Parallel port
1 x Serial port
1 x External Serial ATA port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
6-channel audio ports
Internal connectors 3 x USB 2.0 connectors support six additional USB 2.0 ports
1 x Floppy disk drive connector
1 x IDE connector for two devices
5 x Serial ATA connectors
1 x CPU / 1 x Chassis / 1 x Power fan connectors
1 x S/PDIF Out connector
Chassis intrusion connector
Front panel audio connector
CD audio in connector
24-pin ATX power connector
4-pin ATX 12 V power connector
System panel connector
BIOS features 8 Mb Flash ROM, AMI BIOS, PnP, DMI 2.0, WfM2.0,
SM BIOS 2.5, ACPI v3.0, ASUS EZ Flash 2, ASUS
CrashFree BIOS 3
Manageability WOL by PME, WOR by PME, PXE
Support CD contents Device drivers
ASUS PC Probe II
ASUS Update
Anti-virus software (OEM version)
Form factor ATX form factor: 12 in x 7.4 in (30.5 cm x 18.8 cm)
*Specications are subject to change without notice.

1
Product
introduction
This chapter describes the motherboard
features and the new technologies
it supports.

ASUS P5B SE
Chapter summary 1
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2

ASUS P5B SE 1-1
1.1 Welcome!
Thank you for buying an ASUS®P5B SE motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
If any of the above items is damaged or missing, contact your retailer.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS P5B SE
Cables 1 x Serial ATA power cable
2 x Serial ATA signal cables
1 x Ultra DMA 133/100/66 cable
1 x Floppy disk drive cable
Accessories I/O shield
1 x ASUS Q-connector kit (USB, system panel; Retail
version only)
Application CD ASUS motherboard support CD
ASUS Superb Software Library CD
Documentation User guide

1-2 Chapter 1: Product introduction
1.3 Special features
1.3.1 Product highlights
Green ASUS
This motherboard and its packaging comply with the European Union’s Restriction
on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision
of creating environment-friendly and recyclable products/packaging to safeguard
consumers’ health while minimizing the impact on the environment.
LGA775 Intel®Quad-core Processor Ready
This motherboard supports the latest powerful and energy efficient processors
from Intel. Intel®Quad-core is based on the Intel Core Microarchitecture process
technology that allows users to step up to new levels of gaming experience and
multi-tasking performance.
Combined with 1066/800 of front side bus (FSB), this motherboard guarantees
enhanced user experience in the digital home and office.
LGA775 Intel®Core™2 Processor Ready
This motherboard supports the latest Intel®Core™2 processor in the LGA775
package. With the new Intel®Core™ microarchitecture technology and
1333(O.C)/1066 / 800 MHz FSB, Intel®Core™2 processor is one of the most
powerful and energy efficient CPU in the world.
Intel P965 Chipset
The Intel®P965 Express Chipset is the latest chipset designed to support 8GB
of dual-channel DDR2 800/667/533 architecture, 1333(O.C)/1066/800/533 FSB
(Front Side Bus), PCI Express x16 graphics and multi-core CPU. It especially
includes the Intel® Fast Memory Access technology that significantly optimizes
the use of available memory bandwidth and reduces the latency of the memory
accesses.
DDR2 memory support
The motherboard supports DDR2 memory that features data transfer rates of
800/667/533 MHz to meet the higher bandwidth requirements of the latest
3D graphics, multimedia, and Internet applications. The dual-channel DDR2
architecture doubles the bandwidth of your system memory to boost system
performance, eliminating bottlenecks with peak bandwidths of up to 12.8 GB/s.
Without restriction to the memory size across the two channels, the motherboard
allows you to install DIMMs with different memory size and enjoy dual-channel
feature at the same time. See pages 2-13 to 2-17 for details.

ASUS P5B SE 1-3
Serial ATA 3 Gb/s technology and SATA on the go
This motherboard supports the next-generation hard drives based on the Serial
ATA (SATA) 3Gb/s storage specification, delivering enhanced scalability and
doubling the bus bandwidth for high-speed data retrieval and saves. The external
SATA port located at the back I/O provides smart setup and hot-plug functions.
Easily backup photos, videos and other entertainment contents to external devices.
See pages 2-25, 2-27, and 2-28 for details.
S/PDIF digital sound ready
This motherboard provides convenient connectivity to external home theater audio
systems via coaxial and optical S/PDIF-out (SONY-PHILIPS Digital Interface) jack.
It allows to transfer digital audio without converting to analog format and keeps the
best signal quality. See page 2-28 for details.
High Denition Audio
Enjoy high-end sound quality on your PC! The onboard 6-channel HD audio (High
Definition Audio, previously codenamed Azalia) CODEC enables high-quality 192
KHz/ 24-bit audio output and jack-sensing feature! With CODEC, 6-channel audio
ports, and S/PDIF interfaces, you can connect your computer to home theater
decoders to produce crystal-clear digital audio. See pages 2-24 and 4-23 for
details.
1.3.2 ASUS Special features
ASUS Q-Fan technology
The ASUS Q-Fan technology smartly adjusts the CPU fan speed according to the
system loading to ensure quiet, cool, and efficient operation. See pages 2-30 and
4-28 for details.
ASUS O.C. Prole
The motherboard features the ASUS O.C. Profile that allows users to conveniently
store or load multiple BIOS settings. The BIOS settings can be stored in the
CMOS or a separate file, giving users freedom to share and distribute their favorite
settings. See page 4-34 for details.
ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a
USB flash disk containing the BIOS file. See page 4-8 for details.

1-4 Chapter 1: Product introduction
ASUS Q-Connector
ASUS Q-Connector allows you to easily connect or disconnect the chassis front
panel cables to the motherboard. This unique module eliminates the trouble of
connecting the system panel cables one at a time and avoiding wrong cable
connections. See page 2-34 for details.
ASUS EZ Flash 2
EZ Flash 2 is a user-friendly BIOS update utility. Simply press the predefined
hotkey to launch the utility and update the BIOS without entering the OS. Update
your BIOS easily without preparing a bootable diskette or using an OS-based flash
utility. See pages 4-5 and 4-33 for details.
ASUS MyLogo™
ASUS My Logo is the new feature present in the motherboard that allows you to
personalize and add style to your system with customizable boot logos. See page
5-9 for details.
C.P.R. (CPU Parameter Recall)
The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the
BIOS default settings in case the system hangs due to overclocking. When the
system hangs due to overclocking, C.P.R. eliminates the need to open the system
chassis and clear the RTC data. Simply shut down and reboot the system, and the
BIOS automatically restores the CPU default setting for each parameter. See page
2-22 for details.

2
Hardware
information
This chapter lists the hardware setup
procedures that you have to perform
when installing system components. It
includes description of the jumpers and
connectors on the motherboard.

ASUS P5B SE
Chapter summary 2
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard overview................................................................. 2-2
2.3 Central Processing Unit (CPU) ................................................... 2-6
2.4 System memory ......................................................................... 2-13
2.5 Expansion slots.......................................................................... 2-19
2.6 Jumpers ...................................................................................... 2-22
2.7 Connectors ................................................................................. 2-24
