Asus P5KPL IN/SI User manual

Motherboard
P5KPL IN/SI

ii
Copyright © 2009 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E4648
First Edition V1
April 2009

iii
Contents
Notices.......................................................................................................... v
Safety information ...................................................................................... vi
About this guide ......................................................................................... vi
P5KPL IN/SI specications summary ..................................................... viii
Chapter 1 Product introduction
1.1 Before you proceed ..................................................................... 1-1
1.2 Motherboard overview................................................................. 1-2
1.2.1 Motherboard layout ......................................................... 1-2
1.2.2 Layout contents............................................................... 1-2
1.3 Central Processing Unit (CPU) ................................................... 1-3
1.4 System memory ........................................................................... 1-3
1.4.1 Overview ......................................................................... 1-3
1.4.2 Memory congurations.................................................... 1-3
1.5 Expansion slots............................................................................ 1-6
1.5.1 PCI slots.......................................................................... 1-6
1.5.2 PCI Express x16 slot....................................................... 1-6
1.6 Jumpers ........................................................................................ 1-6
1.7 Connectors ................................................................................... 1-8
1.7.1 Rear panel ports ............................................................. 1-8
1.7.2 Internal connectors ......................................................... 1-9
1.8 Software support........................................................................ 1-13
1.8.1 Installing an operating system ...................................... 1-13
1.8.2 Support CD information ................................................ 1-13
Chapter 2 BIOS information
2.1 Managing and updating your BIOS ............................................ 2-1
2.1.1 ASUS Update utility ........................................................ 2-1
2.1.2 ASUS EZ Flash 2 utility................................................... 2-2
2.1.3 ASUS CrashFree BIOS 3 utility ...................................... 2-3
2.2 BIOS setup program .................................................................... 2-4
2.3 Main menu .................................................................................... 2-4
2.3.1 System Time ................................................................... 2-4
2.3.2 System Date ................................................................... 2-4
2.3.3 SATA1-4 .......................................................................... 2-5

iv
Contents
2.3.4 Storage Conguration ..................................................... 2-5
2.3.5 System Information ......................................................... 2-6
2.4 Advanced menu ........................................................................... 2-6
2.4.1 CPU Conguration .......................................................... 2-6
2.4.2 Chipset............................................................................ 2-7
2.4.3 Onboard Devices Conguration...................................... 2-8
2.4.4 USB Conguration .......................................................... 2-8
2.4.5 PCI PnP .......................................................................... 2-9
2.5 Power menu.................................................................................. 2-9
2.5.1 Suspend Mode................................................................ 2-9
2.5.2 ACPI 2.0 Support ............................................................ 2-9
2.5.3 ACPI APIC Support......................................................... 2-9
2.5.4 APM Conguration........................................................ 2-10
2.5.5 Hardware Monitor ......................................................... 2-10
2.6 Boot menu .................................................................................. 2-11
2.6.1 Boot Device Priority .......................................................2-11
2.6.2 Boot Settings Conguration ...........................................2-11
2.6.3 Security ......................................................................... 2-12
2.7 Tools menu ................................................................................. 2-13
2.7.1 ASUS EZ Flash 2.......................................................... 2-13
2.7.2 AI NET 2........................................................................ 2-13
2.8 Exit menu.................................................................................... 2-14

v
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modications to this unit not
expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
This class B digital apparatus complies with Canadian ICES-003.
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://green.asus.com/english/REACH.htm.

vi
Safety information
Electrical safety
• To prevent electric shock hazard, disconnect the power cable from the electric outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure that all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets, and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a at and stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
• Chapter 2: BIOS setup
This chapter tells how to change system settings through the BIOS setup menus.
Detailed descriptions of the BIOS parameters are also provided.

vii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING:Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
NOTE: Tips and additional information to help you complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
Where to nd more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign means
that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
Example: <Ctrl>+<Alt>+<D>

viii
P5KPL IN/SI specications summary
(continued on the next page)
CPU LGA775 socket for Intel® Core™2 Quad/ Core™2
Extreme / Core™2 Duo / Celeron®Processors
Support Intel®45nm CPU
Intel®Hyper-Threading Technology ready
Supports Enhanced Intel SpeedStep®Technology (EIST)
(Refer to www.asus.com for Intel CPU support list)
Chipset Northbridge: Intel®G31
Southbridge: Intel®ICH7
Front Side Bus 1333 / 1066 / 800MHz
Memory Dual channel memory architecture
2 x 240-pin DIMM sockets supports unbuffered non-ECC
4GB 800/667 MHz DDR2 memory modules
* Refer to www.asus.com for memory QVL (Qualify Vendor
List)
Expansion Slots 1 x PCI Express x16 slot
5 x PCI slots
Storage Southbridge Intel®ICH7 supports:
- 4 x SATA 150/300 ports
LAN RTL8112-GR, PCIe GB LAN
Audio VT1705 6-CH high-Denition Audio CODEC
USB Max. 6 x USB1.1&2.0 ports (2 ports at mid-board, 4 ports at
back panel
ASUS Features ASUS CrashFree BIOS 3
ASUS Q-Fan
ASUS EZ Flash 2
ASUS AI NET2
ASUS MyLogo2
Rear panel 1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x COM port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
6-channel audio I/O port
Internal connectors 1 x High Denition front panel audio connector
1 x USB 2.0 connectors supports additional 2 USB ports
4 x Serial ATA connectors
1 x CPU fan connector
1 x CHA fan connector
1 x 24-pin EATXPWR 12 V power connector
1 x 4-pin ATX 12 V power connector
1 x System Panel connector

ix
P5KPL IN/SI specications summary
*Specications are subject to change without notice.
BIOS features 8 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0,
SM BIOS 2.5
Manageability WOL, PXE,RPL, WOR, PME Wake Up
Support CD contents Drivers
ASUS PC Probe II
ASUS Update utility
Accessories 1 x Serial ATA cable
I/O shield
User manual
Support CD
Form factor ATX form factor: 12 in x 7.0 in (30.48 cm x 17.8cm)

Thank you for buying an ASUS®P5KPL IN/SI motherboard!
Before you start installing the motherboard, and hardware devices on it, check the items in
your motherboard package. Refer to page ix for the list of accessories.
If any of the items is damaged or missing, contact your retailer.
1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Use a grounded wrist strap or touch a safely grounded object or a metal object, such
as the power supply case, before handling components to avoid damaging them due to
static electricity
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so may
cause severe damage to the motherboard, peripherals, or components.
Chapter 1
Product introduction
Onboard LED
This motherboard comes with a standby power LED that lights up to indicate that the system
is ON, in sleep mode, or in soft-off mode. This is a reminder that you must shut down
the system and unplug the power cable before removing or plugging in any motherboard
component. The illustration below shows the location of the onboard LED.
SB_PWR
ON
Standy Power Powered Off
OFF
P5KPL IN/SI
P5KPL IN/SI Onboard LED
1-1 ASUS P5KPL IN/SI

P5KPL IN/SI
PCIEX16
PCI2
PCI1
PCI4
PCI5
PCI3
USB56
AAFP
ICS
9LRS954A4GLF
ATX12V
CPU_FAN
CHA_FAN
Intel®
G31 B0
Lithium Cell
CMOS Power
IT8756E
VIA
VT1705
RTL
8112
8Mb
BIOS
17.8cm(7.0in)
LGA775
Intel®
ICH7
DDR2 DIMM_A1 (64bit, 240-pin module) DDR2 DIMM_B1 (64bit, 240-pin module)
SATA2
SATA4
SATA1
SATA3
CLRTC
USBPW1-4
KBPWR
USBPW5-8
SB_PWR
AUDIO
KBMS
LAN1_USB12
USB34
F_PANEL
EATXPWR
30.5cm(12in)
COM
1 32 4 5 6
2
3
8
7
9 41012 11
Place this side towards
the rear of the chassis.
Place six screws into the holes indicated by circles to secure the motherboard to the
chassis. DO NOT overtighten the screws! Doing so can damage the motherboard.
1.2.2 Layout contents
1.2 Motherboard overview
1.2.1 Motherboard layout
Ensure that you install the motherboard into the chassis in the correct orientation. The
edge with external ports goes to the rear part of the chassis.
Connectors/Jumpers/Slots Page Connectors/Jumpers/Slots Page
1. Keyboard/mouse power (3-pin KBPWR) 1-9 7. Serial ATA connectors (7-pin SATA1-4) 1-10
2. ATX power connectors (24-pin EATXPWR, 4-pin
ATX12V)
1-12 8. Clear RTC RAM (3-pin CLRTC) 1-8
3. CPU/Chassis fan connectors (4-pin CPU_FAN
and 3-pin CHA_FAN)
1-9 9. USB connectors (10-1 pin USB56) 1-11
4. USB device wake-up (3-pin USBPW1-4, 5-8) 1-7 10. System panel connector (10-1 pin PANEL) 1-7
5. LGA775 CPU socket 1-3 11. Onboard LED 1-13
6. DDR2 DIMM slots 1-3 12. Front panel audio connector (10-1 pin
AAFP)
1-12
Chapter 1: Product introduction 1-2

1.3 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA775 socket for Intel® Core™ 2 Extreme /
Core™ 2 Quad / Core™ 2 Duo / Celeron®Processors.
Channel Sockets
Channel A DIMM_A1
Channel B DIMM_B1
P5KPL IN/SI
P5KPL IN/SI 240-pin DDR2 DIMM sockets
DIMM_A1 DIMM_B1
1.4 System memory
1.4.1 Overview
The motherboard comes with two Double Data Rate 2 (DDR2) Dual Inline Memory Modules
(DIMM) sockets.
The gure illustrates the location of the DDR2 DIMM sockets:
• Ensure that all power cables are unplugged before installing the CPU.
• Upon purchase of the motherboard, make sure that the PnP cap is on the socket and
the socket contacts are not bent. Contact your retailer immediately if the PnP cap
is missing, or if you see any damage to the PnP cap/socket contacts/motherboard
components. ASUS will shoulder the cost of repair only if the damage is shipment/
transit-related.
• Keep the cap after installing the motherboard. ASUS will process Return Merchandise
Authorization (RMA) requests only if the motherboard comes with the cap on the
LGA775 socket.
• The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP
cap.
1.4.2 Memory congurations
You may install 512MB, 1GB, and 2GB unbuffered non-ECC DDR2 DIMMs into the DIMM
sockets.
1-3 ASUS P5KPL IN/SI

• You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel conguration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
• Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.
• Due to the memory address limitation on 32-bit Windows OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you install a 64-bit
Windows OS when having 4GB or more memory installed on the motherboard.
• The default memory operation frequency depends on its SPD. Under the default state,
some memory modules for overclocking may operate at a lower frequency than the
vendor-marked value.
• For system stability, use a more efcient cooling system to support a full memory load
(2 DIMMs) or overclocking conditions.
Qualied Vendors Lists (QVL)
DDR2 667 Qualied Vendors List
Size Vendor Part No. SS/
DS Chip Brand Chip NO.
DIMM support
A* B*
1024MB Apacer AU01GE667C5KBGC DS Apacer AM4B5708MIJS7E0627B • •
1024MB Corsair XMS2-5400 DS Corsair Heat-Sink Package • •
2048MB(2x1GB) G.SKILL F2-5400PHU2-2GBNT DS G.SKILL D2 64M8CCF 0815 C7173S • •
512MB Kingston KVR667D2N5/ 512(矮矮) SS Kingston D6408TR7CGL25U • •
1024MB PSC AL6E8E63J-6E1 DS PSC A3R12E3JFF717B9A01 • •
4096MB Samsung M378T5263AZ3-CE6 DS Samsung K4T2G084QA-HCE6 • •
Chapter 1: Product introduction 1-4

DDR2 800 Qualied Vendors List
Size Vendor Part No. SS/
DS Chip Brand Chip NO.
DIMM support
A* B*
2048MB A-Data AD2800002GMU DS Hynix Heat-Sink Package • •
512MB Apacer 78.91G91.9K5 SS Apacer AM4B5708JQJS8E0751C • •
1024MB Corsair CM2X1024-6400 DS Corsair Heat-Sink Package • •
4096MB(2x2GB) Crucial BL25664AL80A.16FE5(EPP) DS N/A Heat-Sink Package • •
512MB G.SKILL F2-6400CL5D-1GBNQ SS G.SKILL Heat-Sink Package
SN:8151030036642
• •
4096MB G.SKILL F2-6400CL6Q-16GMQ DS N/A Heat-Sink Package • •
2048MB GEIL GB24GB6400C5DC DS GEIL GL2L128M88BA25AB • •
2048MB kingmax KLDE88F-B8KB5 DS kingmax KKB8FFBXF-CFA-25U • •
2048MB(2x1GB) Kingston KHX6400D2K2/2G DS N/A Heat-Sink Package • •
2048MB Kingston KVR800D2N5/2G(矮矮) DS Kingston D1288TPFCGL25U • •
4096MB Kingston KVR800D2N6/4G DS Elpida E2108ABSE-8G-E • •
1024MB OCZ OCZ2VU8004GK DS OCZ Heat-Sink Package • •
2048MB PSC AL8E8G73F-8E1 DS PSC P3R1GE3FGF850MAC19 • •
2048MB Qimonda HYS64T256020EU-2.5-C2 DS Qimonda HY818T1G800C2F-2.5 • •
1024MB Samsung K4T1G084QQ-HCF7 SS Qimonda M378T2863QZS-CF7 • •
4096MB Samsung M378T5263AZ3-CF7 DS Samsung K4T2G084QA-HCF7 • •
1024MB Transcend JM800QLJ-1G DS Transcend TQ123YBF8 T0747 • •
1024MB VDATA M2XSSKG3147C1L1C5Z DS Samsung K4T51083QE • •
Visit the ASUS website at (www.asus.com) for the latest QVL.
SS - Single-sided / DS - Double - sided
DIMM support:
• A*: Supports one module inserted into any slot as Single-channel memory
conguration.
• B*: Supports one pair of modules inserted into the blue slots as one pair of
Dual-channel memory conguration.
1-5 ASUS P5KPL IN/SI

1.5 Expansion slots
In the future, you may need to install expansion cards. Refer to the technical documentation
that come with your expansion card for installation details.
Ensure to unplug the power cord before adding or removing expansion cards. Failure to do
so may cause you physical injury and damage motherboard components.
1.5.1 PCI slots
The PCI slot supports cards such as LAN cards, SCSI cards, USB cards, and other cards
that comply with the PCI specications.
1.5.2 PCI Express x16 slot
This motherboard supports PCI Express x1 network cards, SCSI cards, and other cards that
comply with the PCI Express specications.
1.6 Jumpers
1. USB device wake-up (3-pin USBPW1-4, USBPW5-8)
Set this to +5V to wake up the computer from S1 sleep mode (CPU stopped, DRAM
refreshed, system running in low power mode) using the connected USB devices. Set
to +5VSB to wake up from S3 and S4 sleep modes (no power to CPU, DRAM in slow
refresh, power supply in reduced power mode).
P5KPL IN/SI
P5KPL IN/SI USB Device Wake Up
21 2 3
+5V
(Default)
+5VSB
USBPW5-8
21
2 3
+5V +5VSB
(Default)
USBPW1-4
• The USB device wake-up feature requires a power supply that can provide 500mA on
the +5VSB lead for the USB port. Otherwise, the system would not power up.
• The total current consumed must NOT exceed the power supply capability (+5VSB)
whether under normal condition or in sleep mode.
Chapter 1: Product introduction 1-6

2. Clear RTC RAM (CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can
clear the CMOS memory of date, time, and system setup parameters by erasing
the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in
CMOS, which include system setup information such as system •words.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3
for about 5~10 seconds, then move the cap back to pins 1-2.
4. Reinstall the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-
enter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
P5KPL IN/SI
P5KPL IN/SI Clear RTC RAM
1 2
2 3
Normal
(Default)
Clear RTC
CLRTC
• If the steps above do not help, remove the onboard battery and move the jumper again
to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery.
• You do not need to clear the RTC when the system hangs due to overclocking. For
system failure due to overclocking, use the CPU Parameter Recall (C.P.R.) feature. Shut
down and reboot the system, then the BIOS automatically resets the parameter settings
to default values.
• Due to the chipset limitation, AC power off is required before you use the C.P.R.
function. You must turn off and on the power supply or unplug and plug the power cord
before rebooting the system.
1-7 ASUS P5KPL IN/SI

1.7 Connectors
1.7.1 Rear panel ports
3. Keyboard/mouse power (3-pin KBPWR)
This jumper allows you to enable or disable the keyboard/mouse and USB port 5-6
wake-up feature. When you set this jumper to pins 2-3 (+5VSB), you can wake up the
computer by pressing a key on the keyboard (the default is the Space Bar), clicking
the mouse, or using a USB device. This feature requires an ATX power supply that can
supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS. The
USBPW56 jumper is for the rear USB ports.
P5KPL IN/SI
P5KPL IN/SI
P5KPL IN/SI Keyboard Power Setting
21 2 3
+5V
(Default)
+5VSB
KBPWR
3 42
57 6
1
98
1. PS/2 mouse port (green). This port is for a PS/2 mouse.
2. LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub.
LAN port LED indications
SPEED
LED
ACT/LINK
LED
LAN port
Activity/Link LED Speed LED
Status Description Status Description
OFF No link OFF 10 Mbps connection
Yellow Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
Chapter 1: Product introduction 1-8

3. Line In port (light blue). This port connects to the tape, CD, DVD player, or other
audio sources.
4. Line Out port (lime). This port connects to a headphone or a speaker. In 4-channel
and 6-channel conguration, the function of this port becomes Front Speaker Out.
5. Microphone port (pink). This port connects to a microphone.
Refer to the audio conguration table below for the function of the audio ports in 2, 4, or
6-channel conguration.
Audio 2, 4, 6-channel conguration
6. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0 devices.
7. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0 devices.
8. COM port. This 9-pin COM1 port is for pointing devices or other serial devices.
9. PS/2 Keyboard port (purple). This port is for a PS/2 keyboard.
1.7.2 Internal connectors
1. ICH7 Serial ATA connectors (7-pin SATA1-4)
These connectors are for the Serial ATA signal cables for Serial ATA hard disk drives.
Connect the right-angle side of SATA
signal cable to SATA device. You may
also connect the right-angle side of
SATA cable to the onboard SATA port
to avoid mechanical conict with huge
graphics cards.
right angle side
P5KPL IN/SI
P5KPL IN/SI SATA connectors (ICH10R®)
SATA4
GND
RSATA_TXN4
RSATA_TXP4
GND
RSATA_RXN4
RSATA_RXP4
GND
GND
RSATA_TXN3
RSATA_TXP3
GND
RSATA_RXN3
RSATA_RXP3
GND
SATA3
SATA2
GND
RSATA_TXN2
RSATA_TXP2
GND
RSATA_RXN2
RSATA_RXP2
GND
GND
RSATA_TXN1
RSATA_TXP1
GND
RSATA_RXN1
RSATA_RXP1
GND
SATA1
Port Headset 2-channel 4-channel 6-channel
Light Blue Line In Rear Speaker Out Rear Speaker Out
Lime Line Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Bass/Center
1-9 ASUS P5KPL IN/SI

2. USB connectors (10-1 pin USB56)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system
chassis. These USB connectors comply with USB 2.0 specication that supports up to
480 Mbps connection speed.
P5KPL IN/SI
P5KPL IN/SI USB2.0 connectors
PIN 1
USB+5V USB_P6- USB_P6+ GND NC
USB+5V
USB_P5-
USB_P5+
GND
USB56
Never connect a 1394
cable to the USB
connectors. Doing so will
damage the motherboard!
The USB module cable
is purchased separately.
3. Front panel audio connector (10-1 pin AAFP)
This connector is for a chassis-mounted front panel audio I/O module that supports either
HD Audio or legacy AC’97 audio standard.
P5KPL IN/SI
P5KPL IN/SI Analog front panel connector
AAFP
PIN 1
GND PRESENCE# SENSE1_RETUR SENSE2_RETUR
PORT1 L
PORT1 R PORT2 R
SENSE_SEND
PORT1 L
HD-audio-compliant
pin definition
PIN 1
AGND NC NC NC
MIC2
MICPWR
Line out_R
NC
Line out_L
Legacy AC’97
compliant definition
• We recommend that you connect a high-denition front panel audio module to this
connector to avail of the motherboard’s high-denition audio capability.
• If you want to connect a high-denition front panel audio module to this connector, set
the Front Panel Type item in the BIOS setup to [HD Audio]; if you want to connect an
AC'97 front panel audio module to this connector, set the item to [AC97]. By default, this
connector is set to [HD Audio].
Chapter 1: Product introduction 1-10

4. CPU fan connector (4-pin CPU_FAN)
The fan connectors support cooling fans of 350 mA ~ 2000 mA (24 W max.) or a total
of 1 A ~ 7 A (84 W max.) at +12V. Connect the fan cables to the fan connectors on the
motherboard, ensuring that the black wire of each cable matches the ground pin of the
connector.
Do not forget to connect the fan cables to the fan connectors. Insufcient air ow inside the
system may damage the motherboard components. These are not jumpers! Do not place
jumper caps on the fan connectors!
Only the CPU_FAN
connector support the ASUS
Advanced Q-Fan feature.
CPU_FAN
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
P5KPL IN/SI
P5KPL IN/SI CPU fan connector
5. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)
These connectors are for ATX power supply plugs. The power supply plugs are
designed to t these connectors in only one orientation. Find the proper orientation and
push down rmly until the connectors completely t.
P5KPL IN/SI
P5KPL IN/SI ATX power connectors
EATXPWR
ATX12V
PIN 1
+12V DC +12V DC
GND GND
PIN 1
GND
+5 Volts
+5 Volts
+5 Volts
-5 Volts
GND
GND
GND
PSON#
GND
-12 Volts
+3 Volts
+3 Volts
+12 Volts
+12 Volts
+5V Standby
Power OK
GND
+5 Volts
GND
+5 Volts
GND
+3 Volts
+3 Volts
• For a fully congured system, we recommend that you use a power supply unit (PSU)
that complies with EATX 12 V Specication 2.0 (or later version) and provides a
minimum power of 400 W.
• Do not forget to connect the 4-pin ATX12V power plug. Otherwise, the system will not
boot.
• We recommended that you use a PSU with a higher power output when conguring a
system with more power-consuming devices. The system may become unstable or may
not boot up if the power is inadequate.
1-11 ASUS P5KPL IN/SI
