Asus VivoMini UN66 User manual

VivoMini UN66
User Manual

COPYRIGHT INFORMATION
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN
IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identication or
explanation and to the owners’ benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2016 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’part or other liability, you
are entitled to recover damages from ASUS. In each such instance, regardless of the basis
on which you are entitled to claim damages from ASUS, ASUS is liable for no more than
damages for bodily injury (including death) and damage to real property and tangible
personal property; or any other actual and direct damages resulted from omission or failure of
performing legal duties under this Warranty Statement, up to the listed contract price of each
product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in
contract, tort or infringement under this Warranty Statement.
This limit also applies to ASUS’suppliers and its reseller. It is the maximum for which ASUS, its
suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-
PARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS
OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC
CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS
SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at https://www.asus.com/support
Revised Edition V2
July 2016
E11837

VivoMini UN Series 3
Contents
About this document........................................................................................ 5
Conventions used in this manual ............................................................... 6
Typography......................................................................................................... 6
Package contents............................................................................................... 7
Chapter 1: Specications Summary
ASUS VivoMini UN66 Specications Summary......................................10
Chapter 2: Product Introduction
2.1 Motherboard Overview ...................................................................14
2.1.1 Before you proceed .....................................................................14
2.1.2 Motherboard layout....................................................................15
2.1.3 Motherboard dimensions .........................................................17
2.1.4 System memory............................................................................18
2.1.5 Internal connectors .....................................................................19
2.2 I/O connectors.....................................................................................25
Chapter 3: Upgrading your VivMini
3.1 Installing or upgrading memory modules................................28
3.2 Installing or upgrading the wireless card..................................30
3.3 Installing or upgrading the M.2 SSD ...........................................32
3.3.1 To install or upgrade a 2242 M.2 SSD....................................32
3.3.2 To install or upgrade a 2280 M.2 SSD....................................33
3.4 Installing 2.5” HDD or SSD...............................................................35
3.4.1 To install the HDD or SSD using the FFC SATA cable.......35
3.4.2 To install the HDD or SSD using the SATA cable................36
Chapter 4: BIOS Setup
4.1 Getting to know your BIOS .............................................................38
4.2 BIOS setup program..........................................................................38
4.3 Main Menu............................................................................................42

4 VivoMini UN Series
4.4 Advanced menu..................................................................................43
4.4.1 Trusted Computing .....................................................................43
4.4.2 CPU Conguration.......................................................................44
4.4.3 AMT Conguration ......................................................................45
4.4.4 PCH-FW Conguration ...............................................................46
4.4.5 PCH Storage Conguration ......................................................46
4.4.6 USB Conguration .......................................................................48
4.4.7 Onboard Devices Conguration.............................................49
4.4.8 APM Conguration ......................................................................50
4.4.9 Network Stack Conguration...................................................51
4.5 Monitor menu......................................................................................52
4.6 Boot menu ............................................................................................52
4.7 Tool menu .............................................................................................57
4.7.1 ASUS EZ Flash 3 Utility................................................................57
4.7.2 ASUS SPD Information................................................................57
4.8 Exit menu ..............................................................................................58
4.9 Updating BIOS.....................................................................................59
4.9.1 EZ Update........................................................................................59
4.9.2 ASUS EZ Flash 3 Utility................................................................60
4.9.3 ASUS CrashFree BIOS 3...............................................................63
Appendix
Safety information ...........................................................................................66
Regulatory notices...........................................................................................68
ASUS contact information ............................................................................73

VivoMini UN Series 5
About this document
This document provides information about the product
specications of your ASUS VivoMini UN66, organized through the
following chapters:
Chapter 1: Specications Summary
This chapter details the hardware and software features of your
VivoMini UN Series.
Chapter 2: Product Introduction
This chapter describes the features of the motherboard. It
includes description of the connectors, and I/O ports on the
motherboard.
Chapter 3: Upgrading your VivoMini
This chapter provides you with information on how to upgrade
and install the memory modules, storage drives, and wireless
card of your VivoMini.
Chapter 4: BIOS Setup
This chapter tells how to change system settings through
the BIOS Setup menus. Detailed descriptions of the BIOS
parameters are also provided.
Appendix
This section includes notices and safety statements of your
VivoMini UN Series.

6 VivoMini UN Series
Conventions used in this manual
To highlight key information in this manual, some text are presented
as follows:
IMPORTANT! This message contains vital information that must be followed
to complete a task.
NOTE: This message contains additional information and tips that can help
complete tasks.
WARNING! This message contains important information that must be
followed to keep you safe while performing certain tasks and prevent
damage to your VivoMini’s data and components.
Typography
Bold text Indicates a menu or an item to select.
Italic This indicates sections that you can refer
to in this manual.

VivoMini UN Series 7
Package contents
NOTE:
• *Actualproductspecicationsandpackagecontentsmayvary
depending on the model type, country, or region.
• **TheavailabilityandquantityoftheseitemsvarywithyourVivoMini
package.
• Ifthedeviceoranyofitscomponentsfailormalfunctionduringnormal
or proper use and it is still within the warranty period, bring the device
and the warranty card to you nearest ASUS Service Center.
Your VivoMini package contains the following items:
VivoMini
SATA cable FFC SATA cable
Powercable*
Technical documentations
ACpoweradapter*
DriverDVD**
M.2 screw pack

8 VivoMini UN Series

1
Specications Summary

10 VivoMini UN Series
Form factor
101.6 x 101.6 x 30 mm
Processor
Intel®6th generation Core™ i7-6500U Processor
Intel®6th generation Core™ i5-6200U Processor
Intel®6th generation Core™ i3-6100U Processor
Memory
2 x 260 pin SO-DIMM DDR4 2133 MHz (support up to
32GB)
Storage
1x SATA 6Gb/s connector
1x SATA 6Gb/s connector (FFC, Flat Flexible Cable)
Support 2.5” HDD or SSD
1x M.2 connector (support M.2 SSD 2242 or 2280)
Graphics
Integrated - Intel® HD Graphics 520
LAN
Realtek®8111H Gigabit (10/100/1000 Mb/s) LAN
Controller
WIFI + BT
1x M.2 connector (support M.2 2230 WIFI + Blutooth
Module)
Power
Supply
DC 19V, 3.42A, 65W Power Adapter
Expansion
Header
2 x Custom Solutions header (GPIO, I2C; DMIC, SMBus,
3.3/5V standby)
2 x Internal USB2.0 single port header
1 x CEC header
1 x Onboard power button
1 x Power LED
1 x SATA LED
1 x 2pin power connector(+19V, GND)
1 x COM port header
ASUS VivoMini UN66
Specications Summary
(continued on the next page)

VivoMini UN Series 11
Interface
(I/O)
Side I/O
1 x DC-in
2 x USB3.0
Front I/O
1 x Consumer IR sensor
2 x USB3.0 (with BC1.2 capability)
1 x Audio Jack (Mic in/Headphone out)
Rear I/O
1 x VGA
1 x HDMI
1 x LAN (RJ45) Port
ASUS AP
ASUS Business Manager
ASUS Hystream
ASUS Watchdog Timer
Media Streamer
Remote GO!
eManual
APRP
ASUS Remote Management Tool
ASUS EZ Installer
My Logo
ASUS WebStorage
Additional features
WinZip
Adobe Reader
(continued on the next page)

12 VivoMini UN Series
BIOS
ASUS CrashFree BIOS 3
ASUS DRAM SPD (Serial Presence Detect) memory
information
ASUS EZ Flash 3
Asset Tag Override
DMI2.0, WfM 2.0, SM BIOS 2.7, ACPI 3.0
F12 Print Screen
Last Modied Log
Multi-language BIOS
Quick Note
UEFI AMI BIOS, PnP
USB Boot device: FDD, ZIP, HDD, CDROM
Select Boot Device by function key F8 during POST
OS Support
Windows®10 Pro (64-bit)
Windows®10 (64-bit)
Windows® 7 Professional (64-bit/ 32-bit)
NOTE: Specications are subject to change without notice.

2
Product Introduction
Chapter 2: Product Introduction

14 VivoMini UN Series
2.1 Motherboard Overview
2.1.1 Before you proceed
Take note of the following precautions before you install
motherboard components or change any motherboard settings.
WARNING!
• Unplugthepowercordfromthewallsocketbeforetouchingany
component.
• Beforehandlingcomponents,useagroundedwriststraportoucha
safely grounded object or a metal object, such as the power supply case,
to avoid damaging them due to static electricity.
• HoldcomponentsbytheedgestoavoidtouchingtheICsonthem.
• Wheneveryouuninstallanycomponent,placeitonagrounded
antistatic pad or in the bag that came with the component.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpower
supply is switched o or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, or components.

VivoMini UN Series 15
2.1.2 Motherboard layout
Connectors and slots
1. Internal USB2.0 single port header
2. SATA 6Gb/s connector (FFC, Flat Flexible Cable)
3. 260 pin SO-DIMM DDR4 2133 MHz
4. SATA 6Gb/s connector & power connector
5. 2pin power connector(+19V, GND)
6. Custom Solutions header (3xGPIO, 2xI2C; DMIC, SMBus, 3.3/5V
standby)
7. COM port header
8. M.2 connector (support M.2 2230 WIFI + Blutooth Module)
9. M.2 connector (support M.2 SSD 2242 or 2280)
Bottom view

16 VivoMini UN Series
Connectors and slots
1. CPU fan connector
2. CEC header
Top view

VivoMini UN Series 17
Side view
Bottom view
2.1.3 Motherboard dimensions

18 VivoMini UN Series
2.1.4 System memory
The motherboard comes with two (2) Double Data Rate 4 (DDR4)
Small Outline Dual Inline Memory Modules (SODIMM) slots.

VivoMini UN Series 19
1. Internal USB2.0 single port header (4-pin USB2_5, USB2_6)
These connectors are for USB 2.0 ports. Connect the USB
module cable to any of these connectors. These USB connectors
comply with USB 2.0 specication that supports up to 480 Mbps
connection speed.
2.1.5 Internal connectors
2. COM port header (10-1 pin COM)
This connector is for the serial (COM) port. Connect the serial
port module cable to the connector.

20 VivoMini UN Series
3. 2pin power connector (2-pin AUX_PWR)
This power connector is used to power custom solutions. The
standby power is always on, even when the board is powered
o, and the presence of1.8V, 3.3V, and 5V standby power can be
monitored with pins.
NOTE: Ensure to use the bundled cable when connecting a hard disk drive to
this connector.
4. SATA 6Gb/s connector & power connector (7-pin SATA6G_1;
5-pin SATA_PWR1)
This connector connects to Serial ATA 6 Gb/s hard disk drives via
the Serial ATA 6 Gb/s signal and power cable.
