Asus P8H67-M LE User manual

Motherboard
P8H67-M LE Series
P8H67-M LE
P8H67-M LX

ii
E6188
First Edition (V1)
December 2010
Copyright © 2010 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product may contain copyrighted software that is licensed under the General Public License (“GPL”)
and under the Lesser General Public License Version (“LGPL”). The GPL and LGPL licensed code in this
product is distributed without any warranty. Copies of these licenses are included in this product.
You may obtain the complete corresponding source code (as dened in the GPL) for the GPL Software,
and/or the complete corresponding source code of the LGPL Software (with the complete machine-
readable “work that uses the Library”) for a period of three years after our last shipment of the product
including the GPL Software and/or LGPL Software, which will be no earlier than December 1, 2011, either
(1) for free by downloading it from http://support.asus.com/download;
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source code
we would be much obliged if you give us a notication to the email address [email protected], stating the
product and describing the problem (please do NOT send large attachments such as source code archives
etc to this email address).

iii
Contents
Notices......................................................................................................... vi
Safety information ..................................................................................... vii
About this guide ........................................................................................ vii
P8H67-M LE Series specications summary ........................................... ix
Chapter 1: Product introduction
1.1 Before you proceed ..................................................................... 1-1
1.2 Motherboard overview................................................................. 1-2
1.2.1 Motherboard layout ......................................................... 1-2
1.2.2 Layout contents............................................................... 1-2
1.3 Central Processing Unit (CPU) ................................................... 1-3
1.4 System memory ........................................................................... 1-3
1.4.1 Overview ......................................................................... 1-3
1.4.2 Memory congurations.................................................... 1-4
1.5 Expansion slots............................................................................ 1-7
1.5.1 Installing an expansion card ........................................... 1-7
1.5.2 Conguring an expansion card ....................................... 1-7
1.5.3 PCI slot ........................................................................... 1-7
1.5.4 PCI Express x4 slot......................................................... 1-7
1.5.3 PCI Express x16 slot....................................................... 1-7
1.6 Jumpers ........................................................................................ 1-8
1.7 Connectors ................................................................................... 1-9
1.7.1 Rear panel connectors.................................................... 1-9
1.7.2 Internal connectors ........................................................1-11
1.8 Onboard switches...................................................................... 1-17
1.9 Onboard LEDs............................................................................ 1-18
1.10 Software support........................................................................ 1-19
1.10.1 Installing an operating system ...................................... 1-19
1.10.2 Support DVD information .............................................. 1-19
Chapter 2: BIOS information
2.1 Managing and updating your BIOS ............................................ 2-1
2.1.1 ASUS Update utility ........................................................ 2-1
2.1.2 ASUS CrashFree BIOS 3 utility ...................................... 2-2

iv
Contents
2.1.3 ASUS BIOS Updater....................................................... 2-3
2.2 BIOS setup program .................................................................... 2-6
2.3 Main menu .................................................................................... 2-9
2.3.1 System Language ........................................................ 2-10
2.3.2 System Date ................................................................ 2-10
2.3.3 System Time ................................................................. 2-10
2.3.4 Security ......................................................................... 2-10
2.4 Ai Tweaker menu........................................................................ 2-11
2.4.1 Memory Frequency ...................................................... 2-12
2.4.2 GPU Boost ................................................................... 2-12
2.4.3 DRAM Timing Control ................................................... 2-12
2.4.4 CPU Power Management ............................................. 2-12
2.4.5 DRAM Voltage ............................................................. 2-13
2.4.6 CPU Offset Mode Sign ................................................. 2-13
2.4.7 VCCIO Voltage
(for P8H67-M LE only)........................ 2-13
2.4.8 PCH Voltage ................................................................ 2-13
2.5 Advanced menu ......................................................................... 2-14
2.5.1 CPU Conguration ........................................................ 2-14
2.5.2 System Agent Conguration ......................................... 2-16
2.5.3 PCH Conguration ........................................................ 2-16
2.5.4 SATA Conguration ....................................................... 2-16
2.5.5 USB Conguration ........................................................ 2-17
2.5.6 Super IO Conguration
(for P8H67-M LX only) ............ 2-18
2.5.7 Onboard Devices Conguration.................................... 2-18
2.5.8 APM .............................................................................. 2-20
2.6 Monitor menu ............................................................................. 2-21
2.6.1 CPU Temperature / MB Temperature ........................... 2-21
2.6.2 CPU / Chassis Fan Speed ........................................... 2-21
2.6.3 CPU Q-Fan Control ...................................................... 2-21
2.6.4 Chassis Q-Fan Control ................................................ 2-22
2.6.5 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage .. 2-22
2.6.6 Anti Surge Support ....................................................... 2-22
2.7 Boot menu .................................................................................. 2-23
2.7.1 Bootup NumLock State ................................................. 2-23
2.7.2 Full Screen Logo .......................................................... 2-23

v
Contents
2.7.3 Option ROM Messages ................................................ 2-23
2.7.4 Setup Mode .................................................................. 2-23
2.7.5 Boot Option Priorities .................................................... 2-24
2.7.6 Boot Override................................................................ 2-24
2.8 Tools menu ................................................................................. 2-25
2.8.1 ASUS EZ Flash Utility ................................................... 2-25
2.8.2 ASUS O.C. Prole......................................................... 2-25
2.9 Exit menu.................................................................................... 2-26

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modications to this unit not
expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department
of Communications.
This class B digital apparatus complies with Canadian ICES-003.
DO NOT throw the motherboard in municipal waste. This product has been designed to
enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin
indicates that the product (electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol
of the crossed out wheeled bin indicates that the battery should not be placed in municipal
waste.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/REACH.htm.

vii
Safety information
Electrical safety
• To prevent electric shock hazard, disconnect the power cable from the electric outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure that all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
• Chapter 2: BIOS information
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.

viii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
NOTE: Tips and additional information to help you complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
Where to nd more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign means
that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
Example: <Ctrl>+<Alt>+<D>

ix
P8H67-M LE Series specications summary
(continued on the next page)
CPU LGA1155 socket for Intel®Second Generation Core™ i7 /
Core™ i5 / Core™ i3 Processors
Supports 32nm CPU
** Refer to www.asus.com for Intel®CPU support list.
Chipset Intel®H67 Express Chipset
Memory Dual-channel memory architecture
- 2 x 240-pin DIMM sockets support unbuffered non-ECC
DDR3 1333/1066MHz memory modules
- Supports up to 16GB system memory
* The maximum 32GB memory capacity can be supported with
DIMMs of 8GB (or above). ASUS will update the memory QVL
once the DIMMs are available in the market.
** Refer to www.asus.com for the Memory QVL (Qualied
Vendors Lists).
*** When you install a total memory of 4GB capacity
or more, Windows®32-bit operating system may only
recognize less than 3GB. We recommend a maximum
of 3GB system memory if you are using a Windows®
32-bit operating system.
Expansion slots 1 x PCI Express x16 slot
1 x PCI Express x4 slot
2 x PCI slots
Graphics Integrated graphics in Sandy Bridge CPU
- Supports HDMI with max.resolution up to 1920 x 1200
@60Hz (for P8H67-M LE only)
- Supports DVI with max. resolution up to 1920 x 1200
@60Hz
- Supports D-Sub with max. resolution up to 2048 x 1536
@75Hz
Storage Intel®H67 Express Chipset:
- 4 x Serial ATA 3Gb/s connectors
- 2 x Serial ATA 6Gb/s connectors
- Intel®Rapid Storage technology supports RAID 0, 1, 5,
and 10
LAN Realtek®8112L Gigabit LAN controller
Audio ALC887 8-channel High Denition Audio CODEC
USB For P8H67M LE:
- 2 x USB 3.0/2.0 ports (blue, at the back I/O)
- 12 x USB 2.0/1.1 ports (8 ports at mid-board, 4 ports at the
back panel)
For P8H67-M LX:
- 14 x USB 2.0/1.1 ports (8 ports at mid-board, 6 ports at the
back panel)

x
P8H67-M LE Series specications summary
ASUS Special
features
GPU Boost
MemOK!
Anti-Surge protection
ASUS CrashFree BIOS 3
ASUS MyLogo 2
ASUS Q-Fan2
Internal connectors 4 x USB 2.0/1.1 connectors support additional 8 USB 2.0/1.1 ports
1 x System panel connector
1 x S/PDIF Out connector (for P8H67-M LE only)
4 x SATA 3.0 Gb/s connectors
2 x SATA 6.0 Gb/s connectors
1 x Front panel audio connector
1 x CPU fan connector
1 x Chassis fan connector
1 x Speaker connector
1 x COM connector (for P8H67-M LX only)
1 X LPT connector (for P8H67-M LX only)
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
Rear panel ports 1 x PS/2 Keyboard port
1 x LAN (RJ-45) port
1 x VGA port
1 x HDMI port (for P8H67-M LE only)
6 x USB 2.0/1.1 ports (for P8H67-M LX only)
4 x USB 2.0/1.1 ports (for P8H67-M LE only)
2 x USB 3.0/2.0 ports (for P8H67-M LE only)
3 x Audio jacks
BIOS features 32 Mb Flash ROM, EFI BIOS, PnP, DMI v2.0, WfM2.0,
SMBIOS v2.6, ACPI v2 0a
Manageability WOL, PXE, WOR by PME, WOR by Ring
Accessories 1 x Serial ATA 3.0Gb/s cable
1 x Serial ATA 6.0 Gb/s cable
1 x I/O shield
1 x Support DVD
User Manual
Support DVD Drivers
ASUS PC Probe II
ASUS Update
Anti-virus software (OEM version)
Form factor MicroATX form factor: 9.6 in x 8.4 in (24.4 cm x 21.3 cm)
* Specications are subject to change without notice.

ASUS P8H67-M LE Series 1-1
Chapter 1
Product introduction
Thank you for buying an ASUS®P8H67-M LE Series motherboard!
Before you start installing the motherboard, and hardware devices on it, check the items in
your motherboard package. Refer to page x for the list of accessories.
1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due to
static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so may
cause severe damage to the motherboard, peripherals, or components.
If any of the items is damaged or missing, contact your retailer.

1-2 Chapter 1: Product introduction
P8H67-M LX
PCIEX16
PCI1
PCI2
PCIEX4_1
LPT
COM1
CLRTC
SPEAKER
AAFP
EATX12V
EATXPWR
CPU_FAN
CHA_FAN Lithium Cell
CMOS Power
Super
I/O
ALC
887
RTL
8112L
ASM
1442
32Mb
BIOS
Asmedia
ASM1083
SB_PWR
21.3cm(8.4in)
24.4cm(9.6in)
LGA1155
Intel®
H67
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module)
SATA3G_3 SATA3G_4
SATA3G_1 SATA3G_2
SATA6G_1 SATA6G_2
MemOK!
DRAM_LED
AUDIO
KB_USB56
LAN1_USB12
USB34
DVI_VGA
USB1314 USB1112 USB910 USB78
F_PANEL
21 43 2 5
6
7
8
9
10
1
11121315 1416
1.2.2 Layout contents
Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page
1. ATX power connectors (24-pin EATXPWR,
8-pin EATX12V)
1-11 9. SATA 3.0Gb/s / 6.0Gb/s connectors (7-pin
SATA3G1-4, 7-pin SATA6G1-2)
1-13
2. CPU and chassis fan connectors (4-pin
CPU_FAN, 3-pin CHA_FAN)
1-12 10. System panel connector (10-1 pin F_PANEL) 1-15
3. Intel®CPU socket 1-3 11. Speaker connector (4-pin SPEAKER) 1-14
4. DDR3 DIMM slots 1-3 12. Clear RTC RAM (3-pin CLRTC) 1-8
5. Serial port connector (10-1 pin COM1) 1-16 13. USB 2.0 connectors (10-1 pin USB78, USB910,
USB1112, USB1314)
1-16
6. LPT connector (26-1 pin LPT) 1-15 14. Standby power LED (SB_PWR) 1-18
7. MemOK! switch 1-17 15. Digital audio connector (4-1 pin SPDIF_OUT) 1-12
8. DARM LED (DRAM_LED) 1-18 16. Front panel audio connector (10-1 pin AAFP) 1-14
Place four screws into the holes indicated by circles to secure the motherboard to the
chassis. DO NOT overtighten the screws! Doing so can damage the motherboard.
Ensure that you install the motherboard into the chassis in the correct orientation. The edge
with external ports goes to the rear part of the chassis.
1.2 Motherboard overview
1.2.1 Motherboard layout

ASUS P8H67-M LE Series 1-3
1.3 Central Processing Unit (CPU)
This motherboard comes with a surface mount LGA1155 socket designed for the
Intel®second Generation Core™ i7 / Core™ i5 / Core™ i3 processors.
1.4 System memory
1.4.1 Overview
The motherboard comes with two Double Data Rate 3 (DDR3) Dual Inline Memory Modules
(DIMM) sockets.
A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched
differently to prevent installation on a DDR2 DIMM socket. DDR3 modules are developed for
better performance with less power consumption.
The gure illustrates the location of the DDR3 DIMM sockets:
P8H67-M LX
P8H67-M LX 240-pin DDR3 DIMM sockets
DIMM_A1 DIMM_B1
Channel Sockets
Channel A DIMM_A1
Channel B DIMM_B1
Ensure that all power cables are unplugged before installing the CPU.
• Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the
socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing,
or if you see any damage to the PnP cap/socket contacts/motherboard components.
ASUS will shoulder the cost of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. ASUS will process Return Merchandise
Authorization (RMA) requests only if the motherboard comes with the cap on the
LGA1155 socket.
• The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP
cap.

1-4 Chapter 1: Product introduction
1.4.2 Memory congurations
You may install 512MB, 1GB, 2GB, 4GB, and 8GB unbuffered non-ECC DDR3 DIMMs into
the DIMM sockets.
• We recommend that you install the memory modules from the blue slots for better
overclocking capability.
• Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.
• Due to the memory address limitation on 32-bit Windows®OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
- Use a maximum of 3GB system memory if you are using a 32-bit Windows®OS.
- Install a 64-bit Windows®OS when you want to install 4GB or more on the
motherboard.
• This motherboard does not support DIMMs made up of 512Mb (64MB) chips or less.
P8H67-M LE Series Motherboard Qualied Vendors Lists (QVL)
DDR3-1333 MHz capability
• The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value. To operate at the vendor-marked or at a
higher frequency, refer to section 2.4 Ai Tweaker menu for manual memory frequency
adjustment.
• For system stability, use a more efcient memory cooling system to support a full
memory load (2 DIMMs) or overclocking condition.
continued on the next page
Vendors Part No. Size SS/
DS
Chip
Brand Chip No. Timing Voltage
DIMM
Support
A* B*
A-Data AD31333001GOU 1GB SS A-Data AD30908C8D-151C E0906 - - • •
A-Data AD31333G001GOU 3GB(3x1GB) SS - - 8-8-8-24 1.65-1.85V • •
A-Data AD31333002GOU 2GB DS A-Data AD30908C8D-151C E0903 - - • •
A-Data AD31333G002GMU 2GB DS - - 8-8-8-24 1.65-1.85V •
Apacer 78.A1GC6.9L1 2GB DS APACER AM5D5808DEWSBG - - • •
Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808FEQSBG 9 - • •
CORSAIR CM3X1024-1333C9DHX 1GB SS - - 9-9-9-24 1.60V • •
CORSAIR CM3X1024-1333C9 1GB SS - - 9-9-9-24 1.60V • •
CORSAIR TR3X3G1333C9 G 3GB(3x1GB) SS - - 9-9-9-24 1.50V • •
CORSAIR TR3X3G1333C9 G 3GB(3x1GB) SS - - 9-9-9-24 1.50V •
CORSAIR TR3X3G1333C9 3GB(3x1GB) SS - - 9-9-9-24 1.50V • •
CORSAIR CM3X1024-1333C9DHX 1GB DS Corsair - - - •
CORSAIR CMD24GX3M6A1333C9(XMP) 24GB(6x4GB) DS - - 9-9-9-24 1.60V • •
CORSAIR CM3X2048-1333C9DHX 2GB DS - - - - •
CORSAIR TW3X4G1333C9 G 4GB(2x2GB) DS - - 9-9-9-24 1.50V •
CORSAIR CMX8GX3M4A1333C9 8GB(4x2GB) DS - - 9-9-9-24 1.50V • •
Crucial CT12864BA1339.8FF 1GB SS Micron 9FF22D9KPT 9 - • •
Crucial CT25664BA1339.16FF 2GB DS Micron 9KF27D9KPT 9 - • •
Crucial BL25664BN1337.16FF (XMP) 6GB(3x2GB) DS - - 7-7-7-24 1.65V • •
ELPIDA EBJ10UE8EDF0-DJ-F 1GB SS ELPIDA J1108EDSE-DJ-F - 1.35V(low
voltage) •
ELPIDA EBJ21UE8EDF0-DJ-F 2GB DS ELPIDA J1108EDSE-DJ-F - 1.35V(low
voltage) • •
G.SKILL F3-10600CL8D-2GBHK(XMP) 1GB SS G.SKILL - - - • •

ASUS P8H67-M LE Series 1-5
DDR3-1333 MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand Chip No. Timing Voltage
DIMM
Support
A* B*
G.SKILL F3-10666CL7T-3GBPK(XMP) 3GB(3x1GB) SS - - 7-7-7-18 1.5~1.6V • •
G.SKILL F3-10666CL9T-3GBNQ 3GB(3x1GB) SS - - 9-9-9-24 1.5~1.6V • •
G.SKILL F3-10600CL8D-4GBHK(XMP) 4GB(2x2GB) DS - - 8-8-8-21 1.5-1.6V • •
G.SKILL F3-10666CL8D-4GBECO(XMP) 4GB(2x2GB) DS - - 8-8-8-8-24 XMP 1.35V • •
G.SKILL F3-10666CL7T-6GBPK(XMP) 6GB(3x2GB) DS - - 7-7-7-18 1.5~1.6V • •
G.SKILL F3-10666CL7D-8GBRH(XMP) 8GB(2x4GB) DS - - 7-7-7-21 1.5V • •
G.SKILL F3-10666CL9D-8GBRL 8GB(2x4GB) DS - - 9-9-9-24 1.5V • •
GEIL GV32GB1333C9DC 2GB(2x1GB) DS - - 9-9-9-24 1.5V • •
GEIL GV34GB1333C7DC 2GB DS - - 7-7-7-24 1.5V •
GEIL GG34GB1333C9DC 4GB(2x2GB) DS GEIL GL1L128M88BA12N 9-9-9-24 1.3V(low
voltage) • •
GEIL GV34GB1333C9DC 4GB(2x2GB) DS - - 9-9-9-24 1.5V • •
Hynix HMT112U6TFR8A-H9 1GB SS HYNIX H5TC1G83TFRH9A - 1.35V(low
voltage) • •
HYNIX HMT325U6BFR8C-H9 2GB SS HYNIX H5TQ2G83BFRH9C - - • •
Hynix HMT125U6TFR8A-H9 2GB DS HYNIX H5TC1G83TFRH9A - 1.35V(low
voltage) • •
HYNIX HMT351U6BFR8C-H9 4GB DS HYNIX H5TQ2G83BFRH9C - - • •
KINGMAX FLFD45F-B8KL9 1GB SS KINGMAX KKB8FNWBFGNX-27A - - • •
KINGMAX FLFE85F-C8KM9-NAES 2GB SS KINGMAX KFC8FNMXF-BXX-15A - - • •
KINGMAX FLFE85F-B8KL9 2GB DS KINGMAX KKB8FNWBFGNX-26A - - • •
KINGMAX FLFF65F-C8KM9-NEES 4GB DS KINGMAX KFC8FNMXF-BXX-15A - - • •
Kingston KVR1333D3N9/1G 1GB SS ELPIDA J1108BDBG-DJ-F 9 1.5V • •
KINGSTON KVR1333D3N9/2G 2GB SS HYNIX H5TQ2G83AFRH9C 9 - • •
KINGSTON KVR1333D3N9/2G(low prole) 2GB DS ELPIDA J1108BDBG-DJ-F 9 1.5V • •
Kingston KVR1333D3N9/2G 2GB DS KTC D1288JPNDPLD9U 9 1.5V •
Kingston KVR1333D3N9/2G 2GB DS ELPIDA J1108BDSE-DJ-F 9 1.5V • •
Kingston KHX1333C7D3K2/4GX(XMP) 4GB(2x2GB) DS - - 7 1.65V • •
Kingston KHX1333C9D3UK2/4GX(XMP) 4GB(2x2GB) DS - - 9 XMP 1.25V • •
KINGSTON KVR1333D3N9/4G(low prole) 4GB DS HYNIX H5TQ2G83AFRH9C 9 1.5V • •
KINGSTON KVR1333D3N9/4G 4GB DS Hynix H5TQ2G83AFR - - • •
MICRON MT4JTF12864AZ-1G4D1 1GB SS MICRON D9LGQ - - • •
Micron MT8JTF12864AZ-1G4F1 1GB SS Micron 9FF22D9KPT 9 - • •
MICRON MT8JTF25664AZ-1G4D1 2GB SS MICRON D9LGK - - • •
Micron MT16JTF25664AZ-1G4F1 2GB DS Micron 9KF27D9KPT 9 - • •
MICRON MT16JTF51264AZ-1G4D1 4GB DS MICRON D9LGK - - • •
OCZ OCZ3F13334GK 4GB(2x2GB) DS - - 9-9-9-20 1.7V •
OCZ OCZ3G13334GK 4GB(2x2GB) DS - - 9-9-9-20 1.7V •
OCZ OCZ3G1333LV4GK 4GB(2x2GB) DS - - 9-9-9-20 1.65V •
OCZ OCZ3P1333LV4GK 4GB(2x2GB) DS - - 7-7-7-20 1.65V • •
OCZ OCZ3X13334GK(XMP) 4GB(2x2GB) DS - - 7-7-7-20 1.75V • •
OCZ OCZ3G1333LV6GK 6GB(3x2GB) DS - - 9-9-9-20 1.65V • •
OCZ OCZ3P1333LV6GK 6GB(3x2GB) DS - - 7-7-7-20 1.65V •
OCZ OCZ3X1333LV6GK(XMP) 6GB(3x2GB) DS - - 8-8-8-20 1.60V • •
OCZ OCZ3G1333LV8GK 8GB(2x4GB) DS - - 9-9-9-20 1.65V • •
OCZ OCZ3RPR1333C9LV8GK 8GB(2x4GB) DS - - 9-9-9-20 1.65V •
PSC AL7F8G73D-DG1 1GB SS PSC A3P1GF3DGF928M9B05 8-8-8-24 1.5V • •
PSC AL8F8G73D-DG1 2GB DS PSC A3P1GF3DGF928M9B05 8-8-8-24 1.5V • •
SAMSUNG M378B2873FHS-CH9 1GB SS SAMSUNG K4B1G0846F - - • •
SAMSUNG M378B5673FH0-CH9 2GB DS SAMSUNG K4B1G0846F - - • •
SAMSUNG M378B5273CH0-CH9 4GB DS SAMSUNG K4B2G0846C - - • •
Super Talent W1333UA1GH 1GB SS HYNIX H5TQ1G83TFR 9 - • •
Super Talent W1333X2GB8(XMP) 1GB SS - - - - • •
Super Talent W1333UB2GS 2GB DS Samsung K4B1G0846F 9 - • •
Super Talent W1333UB4GS 4GB DS Samsung K4B2G0846C - - • •
Super Talent W1333UX6GM 6GB(3x2GB) DS Micron 0BF27D9KPT 9-9-9-24 1.5V • •
Transcend TS256MLK64V3U 2GB DS Micron 9GF27D9KPT - - • •
Transcend TS256MLK64V3U 2GB DS Elpida J1108BDBG-DJ-F 9 - • •
