Asus PR-DLSW User manual

Motherboard
PR-DLSW
User Guide

ii
Checklist
Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FORA PARTICULAR PURPOSE.
IN NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGEATANY TIME
WITHOUT NOTICE,AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BYASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
E1089
First Edition
October 2002

iii
Features
Contents
FCC/CDC statements..................................................................... vi
Safety information ......................................................................... vii
About this guide............................................................................ viii
How this guide is organized ................................................ viii
Conventions used in this guide .............................................ix
Where to find more information .............................................ix
ASUS contact information ...............................................................x
PR-DLSW specifications summary ................................................xi
Chapter 1: Product introduction
1.1 Welcome! ........................................................................... 1-1
1.2 Package contents............................................................... 1-1
1.3 Special features.................................................................. 1-2
1.3.1 Product highlights .................................................. 1-2
1.3.2 Value-added solutions............................................ 1-4
1.4 Motherboard overview........................................................ 1-6
1.4.1 Major components ................................................. 1-6
1.4.2 Core specifications ................................................ 1-8
Chapter 2: Hardware information
2.1 Motherboard installation ..................................................... 2-1
2.1.1 Placement direction ............................................... 2-1
2.1.2 Screw holes ........................................................... 2-1
2.2 Motherboard layout ............................................................ 2-2
2.3 Before you proceed ............................................................ 2-3
2.4 Central Processing Unit (CPU)........................................... 2-4
2.4.1 Overview ................................................................ 2-4
2.4.2 Installing the CPU .................................................. 2-5
2.4.3 Installing the CPU heatsink and fan....................... 2-6
2.5 System memory ................................................................. 2-8
2.5.1 Overview ................................................................ 2-8
2.5.2 Memory Configurations.......................................... 2-9
2.5.3 Installing a DIMM ................................................. 2-10
2.5.4 Removing a DIMM ............................................... 2-10

iv
Safeguards
Contents
2.6 Expansion slots .................................................................2-11
2.6.1 Installing an expansion card .................................2-11
2.6.2 Configuring an expansion card .............................2-11
2.6.3 PCI slots .............................................................. 2-13
2.7 Switches and jumper ........................................................ 2-14
2.7.1 Switches .............................................................. 2-14
2.7.2 Jumper ................................................................. 2-14
2.8 Connectors ....................................................................... 2-17
Chapter 3: Powering up
3.1 Starting up for the first time ................................................ 3-1
3.2 Powering off the computer ................................................. 3-2
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS .................................... 4-1
4.1.1 Creating a bootable disk ........................................ 4-1
4.1.2 Updating the BIOS ................................................. 4-3
4.2 BIOS Setup program .......................................................... 4-5
4.2.1 BIOS menu bar ...................................................... 4-6
4.2.2 Legend bar............................................................. 4-6
4.3 Main Menu.......................................................................... 4-8
4.3.1 Primary and Secondary Master/Slave ................. 4-10
4.3.2 Keyboard Features .............................................. 4-14
4.4 Advanced Menu ............................................................... 4-15
4.4.1 Chip Configuration ............................................... 4-17
4.4.2 I/O Device Configuration...................................... 4-18
4.4.3 PCI Configuration ................................................ 4-20
4.5 Power Menu ..................................................................... 4-22
4.5.1 Power Up Control ................................................ 4-24
4.5.2 Hardware Monitor ................................................ 4-26
4.6 Boot Menu ........................................................................ 4-27
4.7 Server Menu..................................................................... 4-29
4.8 Exit Menu ......................................................................... 4-30

v
Contents
Chapter 5: OS Installation
5.1 Microsoft
®
Windows
®
NT Server 4.0................................... 5-1
5.1.1 LSI® SCSI Driver Installation................................. 5-1
5.1.2 Intel® 82551QM LAN Driver Installation................ 5-4
5.1.3 C-Media Audio Device Driver Installation .............. 5-8
5.2 Microsoft
®
Windows
®
2000 Server ..................................... 5-9
5.2.1 LSI
®
SCSI Driver Installation.................................. 5-9
5.2.2 Intel
®
82551QM LAN Driver Installation ............... 5-12
5.2.3 C-Media Audio Device Driver Installation ............ 5-15
5.2.4 Enabling ATA100 Feature in Windows® 2000 ..... 5-17
5.2.5 Enabling AGP Bridge Driver in
Windows® 2000................................................... 5-17
5.3 Microsoft
®
Windows
®
XP Professional.............................. 5-18
5.3.1 LSI SCSI Driver and Intel 82551QM LAN Driver
Installation............................................................ 5-18
5.3.2 C-Media Audio Device Driver Installation ............ 5-19
5.4 Novell
®
NetWare
®
Server.................................................. 5-20
5.4.1 LSI
®
SCSI Driver Installation................................ 5-20
5.4.2 Intel
®
82551QM LAN Driver Installation ............... 5-22
5.5 SUN Solaris 7 Server ....................................................... 5-24
5.5.1 LSI
®
SCSI Driver Installation................................ 5-24
5.5.2 Intel
®
82551QM LAN Driver Installation ............... 5-29
5.6 SCO Open Server 5.0.x ................................................... 5-30
5.6.1 LSI
®
SCSI Driver Installation................................ 5-30
5.6.2 Intel
®
82551QM LAN Driver Installation ............... 5-33
5.7 SCO UnixWare Server ..................................................... 5-34
5.7.1 LSI
®
SCSI Driver Installation................................ 5-34
5.7.2 Intel
®
82551QM LAN Driver Installation ............... 5-37
5.8 Linux RedHat 7.x.............................................................. 5-38
5.8.1 LSI SCSI Driver Installation ................................. 5-38
5.8.2 Intel 82551QM LAN Driver Installation ................ 5-38
5.8.3 C-Media Audio Device Driver Installation ............ 5-38

vi
FCC/CDC statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.

vii
Safety information
Electrical safety
•To prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.
•When adding or removing devices to or from the system, ensure that
the power cables for the devices are unplugged before the signal
cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.
•Before connecting or removing signal cables from the motherboard,
ensure that all power cables are unplugged.
•Seek professional assistance before using an adpater or extension
cord. These devices could interrupt the grounding circuit.
•Make sure that your power supply is set to the correct voltage in your
area. If you are not sure about the voltage of the electrical outlet you
are using, contact your local power company.
•If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
Operation safety
•Before installing the product and adding devices on it, carefully read all
the documentation that came with the package.
•Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
•To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
•Avoid dust, humidity, and temperature extremes. Do not place the
product in any area where it may become wet.
•Place the product on a stable surface.
•If you encounter technical problems with the product, contact a
qualified service technician or your retailer.

viii
About this guide
This user guide contains the information you need when installing the
ASUS PR-DLSW motherboard.
How this guide is organized
This manual contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the PR-DLSW motherboard. It
includes brief descriptions of the special attributes of the motherboard
and the new technology it supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to
perform when installing system components. It includes description of
the switches, jumpers, and connectors on the motherboard.
•Chapter 3: Powering up
This chapter describes the power up sequence and gives information
on the BIOS beep codes.
• Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS
Setup menus. Detailed descriptions of the BIOS parameters are also
provided.
• Chapter 5: OS Installation
This chapter tells how to install SCSI, LAN, and audio drivers for
various operating systems.

ix
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the
following symbols used throughout this manual.
Where to find more information
Refer to the following sources for additional information and for product
and software updates.
1. ASUS Websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. The ASUS websites are listed in the
ASUS Contact Information on page x.
2. Optional Documentation
Your product package may include optional documentation, such as
warranty flyers, that may have been added by your dealer. These
documents are not part of the standard package.
WARNING: Information to prevent injury to yourself when trying
to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a
task.
NOTE: Tips and additional information to aid in completing a task.

x
ASUS contact information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
General Tel: [phone]
General Fax: [phone]
General Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel): [phone] (English)
Support Fax: [phone]
Support Email: [email protected]
Web Site: www.asus.com.tw
Newsgroup: cscnews.asus.com.tw
ASUS COMPUTER INTERNATIONAL (America)
Address: 6737 Mowry Avenue, Mowry Business Center,
Building 2, Newark, CA 94560, USA
General Fax: [phone]
General Email: [email protected]
Technical Support
Support Fax: [phone]
General Support: [phone]
Web Site: www.asus.com
Support Email: [email protected]
ASUS COMPUTER GmbH (Europe)
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [email protected] (for marketing requests only)
Technical Support
Support Hotline: MB/Others: [phone]
Notebook (Tel): [phone]
Support Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
Web Site: www.asuscom.de

xi
PR-DLSW specifications summary
CPU
Chipsets
Front Side Bus (FSB)
Memory
Onboard LAN
Onboard SCSI
Onboard audio
Expansion slots
Rear panel I/O
Internal connectors
BIOS features
Support for Intel
®
Xeon™processor
On-die 256KB/512KB L2 cache
RCC Grand Champion Work Station (GCWS)
- Champion Memory and I/O Controller (CMIC-WS)
- Champion I/O Bridge 2X (CIOBX2)
- Champion I/O Bridge Graphics (CIOBG)
RCC Champion South Bridge 5.0 (CSB5)
400 MHz
6 x 184-pin DDR DIMM sockets
Supports PC2100/PC1600 registered ECC DDR DIMMs
Supports up to 12GB system memory using 2GB DIMMs
Intel
®
82551QM Fast Ethernet controller
LSI
®
53C1010R PCI SCSI controller
C-Media CMI8738/PCI-SX 4-channel audio controller
1 x AGP Pro 4x slot
4 x PCI 64-bit/133MHz 3V (PCI-X1 to PCI-X4)
1 x PCI 64-bit/66MHz 3V (PCI-X5)
1 x PCI 32-bit/33MHz 5V (PCI6)
1 x Parallel port
2 x Serial ports
1 x PS/2 keyboard port
1 x PS/2 mouse port
2 x USB 1.1 ports
1 x RJ-45 port (with LED)
Line In/Line Out/Microphone ports
2 x 68-pin Ultra-160 SCSI connectors
2 x ATA/100 IDE connectors
1 x Floppy disk connector
1 x USB 1.1 connector for two additional USB ports
CD/AUX/Modem audio connectors
CPU/Power/Chassis fan connectors
24-pin, 8-pin SSI power connectors
IDE LED/Power LED connectors
20-pin Front panel connector
Chassis intrusion, SMBus, WOL, and WOR connectors
4Mb Flash ROM,Award BIOS with ACPI, DMI, Green, PnP
features, and Enhanced Server BIOS features
(continued on the next page)

xii
PR-DLSW specifications summary
Form Factor
Support CD contents
Extended ATX form factor: 12 in x 13 in (30.5 cm x 33 cm)
Device drivers
Utilities
Contact information
* Specifications are subject to change without notice.

Chapter
This chapter describes the features of the
PR-DLSW motherboard. It includes brief
explanations of the special attributes of the
motherboard and the new technology it
supports.
Product introduction

ASUS PR-DLSW motherboard
Chapter summary
1.1 Welcome! ........................................................ 1-1
1.2 Package contents .......................................... 1-1
1.3 Special features ............................................. 1-2
1.4 Motherboard overview................................... 1-6

ASUS PR-DLSW motherboard user guide 1-1
. Welcome!
Thank you for buying the ASUS
®
PR-DLSW motherboard!
The ASUS
PR-DLSW motherboard delivers a host of new features and
latest technologies making it another standout in the long line of ASUS
quality server motherboards!
The PR-DLSW incorporates dual Intel
®
Xeon™processors in 603/604-pin
package coupled with the ServerWorks
®
Grand Champion Work Station
(GCWS) SystemSet to deliver a reliable and high performance dual-
processor server platform.
Before you start installing the motherboard, and hardware devices on it,
check the items in your package with the list below.
.2 Package contents
Check your PR-DLSW package for the following items.
ASUS PR-DLSW motherboard
Extended ATX form factor: 12 in x 13 in (30.5 cm x 33 cm)
ASUS PR-DLSW support CD
I/O shield
80-conductor ribbon cable for UltraDMA100/66/33 IDE drives
68-pin LVD SCSI cable for Ultra 160 SCSI devices
Ribbon cable for a 3.5-inch floppy drive
Bag of extra jumper caps
PR-DLSW User Guide
LSI SCSI Controller User’s Manual
If any of the above items is damaged or missing, contact your retailer.

1-2 Chapter 1: Product introduction
.3 Special features
1.3.1 Product highlights
Latest processor technology
The PR-DLSW motherboard supports the Intel
®
Xeon processor via dual
604-pin surface mount ZIF sockets. The processor features the Intel
®
NetBurst™micro-architecture that includes hyper-pipelined technology, a
rapid execution engine, a 400MHz system bus, and an execution trace cache
to offer a significant increase in performance. See page 2-4 for more
information.
DDR memory support
Employing the Double Data Rate (DDR) memory technology, the PR-
DLSW motherboard supports up to 12GB of system memory using
PC2100/1600 registered ECC DDR DIMMs. The ultra-fast 200MHz
memory bus doubles the speed of the PC100 SDRAM to deliver the
required bandwidth for the latest 3D graphics, multimedia, and Internet
applications. See page 2-10.
Dual-channel Ultra-160 SCSI
The LSI
®
53C1010R 64-bit/66MHz PCI SCSI controller is onboard to
support dual-channel Ultra-160 SCSI connectors that provide high-speed
data transfer interfaces.
Advanced 64-bit PCI-X slots
The 64-bit/133MHz PCI-X slots onboard maximizes I/O bandwidth for the
next generation 64-bit PCI-X cards that support 133MHz bus. The PCI-X
specification 1.0a allows full peer-to-peer transactions between PCI buses
and provides options for intelligent I/O and server management cards.
AGP Pro 4X slot
The motherboard comes with an Accelerated Graphics Port (AGP) Pro 4X
slot for 3.3V/1.5V AGP cards. The slot supports 1X, 2X, or 4X mode bus to
support high performance 3D graphics applications.
Onboard LAN
The motherboard comes with the Intel
®
82551QM Fast Ethernet controller
to fully support 10BASE-T and 100BASE-TX Ethernet networking.

ASUS PR-DLSW motherboard user guide 1-3
Onboard audio
The C-Media CMI8738/PCI-SX audio controller is onboard to provide
HTRF-based 3D positional audio (C3DX™) 4-channel audio output.
ATA/100 IDE support
The dual-channel bus master IDE connectors comply with the ATA/100
protocol and supports ATA/100, Multi-Word DMA Mode2, PIO modes 3 & 4
IDE devices such as ATAPI IDE CD-ROM, CD-R/RW, ZIP, and LS-120
drives.

1-4 Chapter 1: Product introduction
1.3.2 Value-added solutions
Temperature, fan, and voltage monitoring
The CPU temperature is monitored by the ASUS ASIC to prevent
overheating and damage. The system fan rotations per minute (RPM) is
monitored for timely failure detection. The system voltage levels are
monitored to ensure stable supply of current for critical components.
Dual function power switch
While the system is ON, pressing the power switch for less than 4 seconds
puts the system to sleep mode or to soft-off mode, depending on the BIOS
setting. Pressing the power switch for more than 4 seconds lets the
system enter the soft-off mode regardless of the BIOS setting.
Wake-Up support
The motherboard includes Wake-On-LAN, Wake-On-Ring, and BIOS
Wake-Up features.
ACPI ready
The Advanced Configuration power Interface (ACPI) provides more energy
saving features for operating systems that support OS Direct Power
Management (OSPM).
Concurrent PCI
This feature allows multiple PCI transfers from PCI master buses to the
memory and processor.
Chassis intrusion detection
With this feature, the chassis intrusion circuitry logs “chassis-open”events
into the system BIOS. The onboard battery supports the chassis intrusion
detection feature even when the normal power is removed.
Smart BIOS
The 4Mbit firmware gives an easy-to-use interface that provides more
control and protection to the motherboard. The BIOS has a boot block
write protection and HD/SCSI/MO/ZIP/CD/Floppy boot selection, and is
Year 2000 certified.

ASUS PR-DLSW motherboard user guide 1-5
Compliance
Both the BIOS and the hardware levels of the motherboard meet the
stringent requirements for SDG 2.0 certification. The new SDG 2.0
requirements for systems and components are based on the following
high-level goals: support for Plug-and-Play compatibility and power
management for configuring and managing all system components, 32-bit
device drivers, and installation procedures for Windows NT/2000/XP.
Color-coded connectors and descriptive icons make identification easy as
required by the PC ‘99 specification.

1-6 Chapter 1: Product introduction
.4 Motherboard overview
Before you install the PR-DLSW motherboard, familiarize yourself with its
physical configuration and available features to facilitate the motherboard
installation and future upgrades. A sufficient knowledge of the motherboard
specifications will also help you avoid mistakes that may damage the
board and its components.
1.4.1 Major components
The following are the major components of the PR-DLSW motherboard as
pointed out in the picture on page 1-7.
1. DDR DIMM sockets
2. ServerWorks
®
Champion I/O
Bridge Graphics (CIOBG)
3. ATX power connector
4. ServerWorks
®
Grand Champion
WS North Bridge (CMIC-WS)
5. DIP switches (5-switch)
6. IDE connectors
7. 604-pin CPU sockets
8. 8-pin 12V SSI power connector
9. Floppy disk connector
10. Ultra-160 SCSI connectors
11. LSI
®
53C1010R SCSI controller
12. Flash ROM
13. DIP switches (8-switch)
14. ServerWorks
®
Champion I/O
Bridge (CIOBX2)
15. ServerWorks
®
Champion South
Bridge (CSB5)
16. ASUS ASIC
17. Audio controller
18. PCI-X slots (PCI-X1 to PCI-X5)
PCI slot (PCI6)
19. Intel
®
82551QM Fast Ethernet
controller
20. AGP Pro 4X slot
21. LPC super I/O controller
22. PS/2 mouse port
23. RJ-45 port
24. Parallel port
25. Microphone port
26. Line In port
27. Line Out port
28. Serial ports
29. USB ports 1 and 2
30. Keyboard port
See page 1-8 for the specifications of each component. Refer to
Chapter 2 for detailed information on the components.
