Asus AX6100 Ai Mesh User manual

RENTAL EQUIPMENT SETUP GUIDE
Shipment Content:

2 x Protective Case
2 x Router with 4 embedded Antennas
2 x 9V Power Adapter


Quick Setup:
1. Your Asus AX6100 Mesh WiFi router     
system comes pre configured. They are also      
labeled for easy set-up, lets begin with the       
router labeled MAIN. 
2. Plug in the power adapter & a DHCP hard        
line from the venue onto the MAIN router’s       
WAN port. Press the power button on the       
side to turn on the router. Allow 3-5 minutes      
for the router to light up “white” when ready.        


-5G2, 5G1, 2.4G display the router is broadcasting       
WiFi.
-WAN (Internet), hardline connection established..
-Power LED, device is ready.
3. Lift all 4 antennas and position them      
upwards.
4. Plug in the power adapter into the router       
labeled MESH & power it on. It will connect        
automatically to the MAIN router. Allow 1-3     
minutes for the router to light up “white”       
when ready (WAN light will be off).
5. Lift the antennas and position them     
upwards. If you have more than one MESH       
unit in your order please repeat steps 4-5 for        
each one.



6. Connect your devices.

Connect your WIRED (e.g. Ethernet    
enabled Printer) Connect the ethernet    
cable to one of the LAN (1-4) ports in the         
back of the router. Plug the other end of the         
cable into the printer. The LAN LED on the        
router lights up  
when connected.

Connect your WIRELESS Devices (e.g.    
Tablet / PC) Open the camera app on your        
device and scan the QR-Code on the bottom       
of the router. Alternatively use the default      
SSID (Wireless Network Name) on the     
bottom of the router along with the      
password in your Important Documents    
Folder to connect wirelessly.

Via WPS (e.g. WPS enabled Printer)Press     
and Hold the WPS button on the side of the         
router until the Power light starts blinking      
fast. Then proceed to set the printer on       
WPS mode as per its setup document. Allow       
1-2 minutes to establish connection.
Please DO NOT press the Reset button on       
the back of the router this will cause the        
Mesh system to un-sync



Setup Video Guide: Contact our Support Team:
Scan this QR code www.choose2rent.com/help
with your phone [phone] Ext. 3 (USA)
camera for video. [phone] - 590 (Europe)

RENTAL EQUIPMENT SETUP GUIDE

Troubleshooting:
What if...
… the router does not power up?
Please check if the power plugs are plugged in tightly. Switch
On and Off again. Wait 3 mins.
… the WAN lights up Red? (MAIN)
The device is not getting an Internet connection, make sure
the hardline is on the WAN port. Ask if the hardline from the
venue has a splash screen or requires a MAC address.
… the LAN light is off?
No physical connection to printer or PC. Make sure the line is
properly plugged and the other unit is powered up. 
… the 2.4G light is off?

Your unit is pre-set to work only on the 5.0GHz wireless
connection.
...the 5G1 & 5G2 lights are off?
Your unit is not broadcasting any wireless connectivity.Please
check that your MAIN router has completely booted before
powering on the MESH units.
...the MESH unit has no internet connection?
Switch On and Off. If a problem persists your units might be
too far apart or there might be too much interference
between them.

