AT&T Centillium MTA-1 User manual

AShut down your PC and set the power switch to your DSL modem to “off”
BUnplug your DSL modem
C Leave all equipment off for at least 5 minutes
ETHERNET
PORT
ETHERNET
POWER
OFF OFF
DSL
DSL JACK DSL MODEM PERSONAL COMPUTER
IMPORTANT! Shut down and unplug each device separately (i.e.,don’t simply shut off your powerstrip) !!
DSL JACK DSL MODEM PERSONAL COMPUTERWALL
OUTLET
TELEPHONE TELEPHONE ADAPTER (TA)
ethernet cable
(use existing cable)
ethernet cable
(use cable provided)
MTA-1TM Telephone Adapter
This will be referred to as the TA
in this guide.
Power Adapter
Using a power supply with a different
voltage rating will damage and void the
warranty of this product.
Telephone Cord (Grey)
You can use this to connect
your telephone to the TA
Ethernet Cable (Blue)
You can use this to connect your
TA to your computer or router.
CHECK YOUR PACKAGE CONTENTS
Step 1: Gather Information
Make sure you have the following information before you start your Telephone Adapter (TA) installation:
Step 3: Connect Equipment
R08 MTAQIG 1005
!IMPORTANT use your existing cable between
your DSL modem and TA and the blue
cable that came in this package between your
TA and your PC
Step 2: Shut Off All Equipment
APlug in DSL modem, turn on,
and wait until all lights go steady
A
BPlug in TA and wait 30 seconds CTurn on PC
B C
Step 4: Turn on Equipment in Order
IMPORTANT! You must turn on your equipment IN THE ORDER INDICATED for your service to work correctly !!
– If you are using a home router, please see the other side of this sheet
– If you have a cable modem, please see other sheet
– If you have static IP (and for a description of static IP) please see instructions on
page 20 of the accompanying MTA-1TM Telephone Adapter Install Guide
DSL phone cord
(leave as-is)
Step 5: Verify Your Connection
Step 6: Activate Your TA
You can now make calls by dialing the 10-digit
number from the phone connected to your TA and use
the advanced features on www.callvantage.att.com
If you are transferring your current phone number to AT&T CallVantage
Service, you will not be able to receive calls or place 911 Emergency
Dialing calls until your number is transferred. See your order confirmation
emails for additional details.
If you experience any problems with the service, please refer to
Troubleshooting, page 24 of the accompanying MTA-1TM Telephone
Adapter Install Guide.
Setup complete
AOpen your browser and
type in http://192.168.15.1
B Enter user in both the “User
name” and “Password”
fields, and click “OK”
A
COn the Function Overview
screen, click PPPoE
E Click “OK” to reboot
your TA. Once the reboot
is complete, you will be
returned to the Function
Overview screen.
DE
C
AT&T CallVantage Service
User ID
Your 10-digit AT&T CallVantage®
Service number (provided in your
order confirmation e-mail)
AT&T CallVantage Service
Password
You were provided or selected this
when you ordered the service; if you
forgot it go to www.callvantage.att.com
and click “Forgot your password?”
DSL Provider Username
(PPPoE Username)
You must get this from your DSL
provider
DSL Provider Password
(PPPoE Password)
You must get this from your DSL
provider
G
F
FVerify that the PWR, LAN,
and WAN lights on the front
of your TA are all steady
green (F) and you can
browse to a known website
(e.g. www.att.com) (G). If
you cannot browse, restart
your PC.
If you still cannot browse
after restarting your PC or
your PWR, LAN, and WAN
lights are not all steady
green, see Troubleshooting
on page 25-26 of the
accompanying MTA-1TM
Telephone Adapter Install
Guide.
A
B
AGo to www.callvantage.att.com
and login using your AT&T
CallVantage Service User ID
and password.
BClick the “Activate TA”
button.
CFollow the instructions on
the screen
B
DSelect “Yes” under Enable
PPPoE, enter your DSL
provider username
(PPPoE username) and
DSL provider password
(PPPoE password), and
select “Keepalive” under
Settings. Click “Save
PPPoE Configuration.”
Single PC connected directly to a DSL modem
®
Quick Install Guide
for the CentilliumTM MTA-1TM
Telephone Adapter

IMPORTANT! For alternate setup with TA behind the router, see page 18 of the accompanying MTA-1TM Telephone Adapter Install Guide. !!
Step 1: Gather Information
AT&T CallVantage Service
User ID
Your 10-digit AT&T CallVantage®
Service number (provided in your
order confirmation e-mail)
AT&T CallVantage Service
Password
You were provided or selected this
when you ordered the service; if you
forgot it go to www.callvantage.att.com
and click “Forgot your password?”
DSL Provider Username
(PPPoE Username)
You must get this from your DSL
provider
DSL Provider Password
(PPPoE Password)
You must get this from your DSL
provider
Home Router User Manual
The user manual you received
along with your home router. Many
manufacturers let you download this
from their website.
WAN/
UPLOAD
RESET
CONSOLE
PSTN
VoIP
12V 1A
ETHERNET
POWER
ETHERNET
PORT
ETHERNET
PORT
PORTS
RESET
WAN 12V –
LAN
ON ON
ON
ON
DSL VoIP1 VoIP2
IMPORTANT! Shut down and unplug each device separately (i.e., don’t simply shut off your powerstrip) !!
OFF
WAN/
UPLOAD
RESET
CONSOLE
PSTN
VoIP
12V 1A
ETHERNET
POWER
ETHERNET
PORT
OFF
ETHERNET
PORT
OFF
PORTS
RESET
WAN 12V –
VoIP1 VoIP2 LAN
OFF
DSL
DSL JACK DSL MODEM PERSONAL COMPUTER(S)WALL
OUTLET
TELEPHONE TELEPHONE ADAPTER (TA)
ethernet cable
(use existing cable)
ethernet cable
(use cable provided)
HOME ROUTERWALL
OUTLET
Make sure you have the following information before you start your Telephone Adapter (TA) installation:
Step 3: Connect Equipment
– If you do not have a home router, please see the other side of this sheet
– If you have a cable modem, please see other sheet
– If you have static IP (and for a description of static IP) please see instructions
on page 20 of the accompanying MTA-1TM Telephone Adapter Install Guide
!IMPORTANT use your existing cable between your
DSL modem and TA and the blue cable that came in
this package between your TA and your router
Step 2: Shut Off All Equipment
ETHERNET
PORT
ETHERNET
POWER
OFF
OFF
ETHERNET
PORT
OFF
OFF
WAN/
UPLOAD PORTS
DSL
DSL JACK DSL MODEM PERSONAL COMPUTER(S)ROUTER
DTurn on PC(s)
Step 4: Turn on Equipment in Order
IMPORTANT! You must turn on your equipment IN THE ORDER INDICATED for your service to work correctly !!
DSL modem with one or more PCs connected via a home router
®
AShut down your PCs and set the power switch to
your home router and DSL modem to “off”
BUnplug your DSL modem and router
CLeave all equipment off for at least 5 minutes
A B C D
APlug in DSL modem, turn on, and
wait until all lights go steady
BPlug in TA and wait 30 seconds CPlug in router, turn on,
and wait 30 seconds
DSL phone cord
(leave as-is)
Step 6: Verify Your Connection
Step 7: Activate Your TA Setup complete
AOpen your browser and
type in http://192.168.15.1
B Enter user in both the “User
name” and “Password”
fields, and click “OK”
A
COn the Function Overview
screen, click PPPoE
E Click “OK” to reboot
your TA. Once the reboot
is complete, you will be
returned to the Function
Overview screen.
DE
C
FWhen the reboot is
complete, IN THE
FOLLOWING ORDER:
unplug your router from
the power outlet and plug it
back in. Wait thirty seconds
and restart your PC.
AOpen a browser and type in the URL for your home
router control panel (the URL is found in your router
user manual)
BMake sure your router is configured to obtain IP
address automatically (for most routers, go to WAN
settings and set “obtain IP address automatically”;
this will put it into what is known as DHCP mode.
It may also be called “cable” or “Internet” mode.)
Please refer to your router’s user manual for
further detail.
Step 5: Configure Router
B
Sample: Your router’s control
panel may look different
H
DSelect “Yes” under Enable
PPPoE, enter your DSL pro-
vider username (PPPoE
username)and DSL provider
password(PPPoE password),
and select “Keepalive”
under Settings. Click “Save
PPPoE Configuration.”
GVerify that the PWR, LAN,
and WAN lights on the front
of your TA are all steady
green (G) and you can
browse to a known website
(e.g. www.att.com) (H). If
you cannot browse, restart
your PC.
If you still cannot browse
after restarting your PC or
your PWR, LAN, and WAN
lights are not all steady
green, see Troubleshooting
on pages 25-26 of the
accompanying MTA-1TM
Telephone Adapter Install
Guide.
G
A
B
AGo to www.callvantage.att.com
and login using your AT&T
CallVantage Service User ID
and password.
BClick the “Activate TA”
button.
CFollow the instructions on
the screen
B
MTA-1TM Telephone Adapter
This will be referred to as the TA
in this guide.
Power Adapter
Using a power supply with a different
voltage rating will damage and void the
warranty of this product.
Telephone Cord (Grey)
You can use this to connect
your telephone to the TA
Ethernet Cable (Blue)
You can use this to connect your
TA to your computer or router.
CHECK YOUR PACKAGE CONTENTS
You can now make calls by
dialing the 10-digit number from
the phone connected to your TA
and use the advanced features on
www.callvantage.att.com
Quick Install Guide
for the CentilliumTM MTA-1TM
Telephone Adapter
A
If you are transferring your current phone
number to AT&T CallVantage Service, you
will not be able to receive calls or place 911
Emergency Dialing calls until your number
is transferred. See your order confirmation
emails for additional details.
If you experience any problems with the
service, please refer to Troubleshooting, page
24 of the accompanying MTA-1TM Telephone
Adapter Install Guide.
