1
Chapter 1 the Introduction of AXE1600P
Overview of the AXE1600P
The Asterisk card is the telephony PCI-E card that supports up to sixteen FXO and FXS ports.
Using the analog card, open source Asterisk PBX and stand alone PC, users can create their
SOHO telephony solution which include all the sophisticated features of traditional PBX, and
extend features such as voicemail in IP PBX. The FXO and FXS modules are interchangeable to
suit various requirements.
Features
Analog card for Asterisk PBX
Support Asterisk PBX, zaptel and dahdi driver
Support up to 16 FXO/FXS analog port
Suitable for SOHO PBX / VoiceMail / IVR.
Caller ID and Call waiting Caller ID
Conference
Applications
IP PBX
IVR system
Traditional Calls/VoIP Calls Conference
Hardware requirement
500-Mhz Pentium III
64MB RAM
3.3V or 5V PCI-E 2.2 slot
PCI card dimension:
264mm (length) × 121mm (height)

AXE1600P User Manual
www.atcom.cn Email: [email protected]
2
Chapter 2 Hardware Introduction
Hardware Configuration
Motherboard: AXE1600P
Dual ports FXS module: AX-210S
Dual ports FXO module: AX-210X
One FXS port and one FXO port module: AX-210XS
Splitter: SP400
Users can use the combination of AX-210S, AX-210X, AX-210XS modules according to their
requirements. One AX-210S module supports two FXS ports, one AX-210X module supports two
FXO ports, One AX-210XS module supports one FXS port and one FXO port.
Attention: If users want to use FXS or FXO port, please plug the power cable for the card.
Warning: When the PC power is on, please do not plug or take down the card.
Figure 1: AXE1600P
Power Feeding Connection

AXE1600P User Manual
www.atcom.cn Email: [email protected]
3
Figure 5: SP400
Figure 2: AX-210S
Figure 3: AX-210X
Figure 4: AX-210XS

AXE1600P User Manual
www.atcom.cn Email: [email protected]
4
Chapter 3 Test Environment
Test Environment:
dahdi-linux-complete-2.6.2+2.6.2 (download from ATCOM website)
asterisk-1.8 (download from Digium website)
Centos6.0 (kernel version: 2.6.32-279.22.1.el6.i686)
AXE1600P

AXE1600P User Manual
www.atcom.cn Email: [email protected]
5
Chapter 4 Software Installation
1. Check the hardware messages
After inserting the card into the PCI-E slot and boot the server, please use the “lspci” command to
check the PCI bus compatibility. From the correct output, users can see the following line:
----------------------------------------------------------------------------------------------------------------------
05:04.0 Communication controller: Tiger Jet Network Inc. Tiger3XX Modem/ISDN interface
----------------------------------------------------------------------------------------------------------------------
The asterisk card will be found, if users can not get the message as the above, please power off the
server and try to use another PCI slot.
2. Installation the dependence packages
To install asterisk and dahdi, users need to install and update the following prerequisite
packages firstly.
[root@localhost src]# yum install update
[root@localhost src]# yum install -y bison bison-devel zlib zlib-devel openssl openssl-devel
gnutls-devel gcc gcc-c++ libxml2 libxml2-devel ncurses-devel sqlite sqlite-devel
3. Download the dahdi and asterisk packages
User could download dahdi-linux-complete, and asterisk packages into the system.
[root@localhost src]#
wget http://downloads.asterisk.org/pub/telephony/asterisk/asterisk-1.8-current.tar.gz
Attention:
Users need download dahdi package for axe1d card from ATCOM website. Users can get
the latest driver from the download center: http://www.atcom.cn/download.html.
For example:
Users can download the dahdi as the following link:
[root@localhost src]# wget
http://www.atcom.cn/cn/download/cards/ax1d/dahdi-linux-complete-2.6.1+2.6.1-1.2.tar.gz

AXE1600P User Manual
www.atcom.cn Email: [email protected]
6
4. Installation the dahdi and asterisk packages
Install dahdi-linux-complete
1) [root@localhost src]# tar -xvzf dahdi-linux-complete-xxx.tar.gz
2) [root@localhost dahdi-linux-complete-xxx+xxx]# make
3) [root@localhost dahdi-linux-complete-xxx+xxx]]# make install
4) [root@localhost dahdi-linux-complete-xxx+xxx]]# make config
Install asterisk
1) [root@localhost src]# tar -xvzf asterisk-xxx.tar.gz
2) [root@localhost asterisk-xxx]# ./configure
3) [root@localhost asterisk-xxx]# make
4) [root@localhost asterisk-xxx]# make install
5) [root@localhost asterisk-xxx]# make samples

AXE1600P User Manual
www.atcom.cn Email: [email protected]
7
Chapter 5 Software Configuration
1. Create the configuration information
Please use the “dahdi_genconf” command to configure the “/etc/dahdi/system.conf” file and
generate “/etc/asterisk/dahdi-channels.conf” file.
It will not show any information if the “dahdi_genconf ” command run successfully.
[root@localhost ~]# dahdi_genconf
After that, users will get the following configuration in the “/etc/asterisk/system.conf” file.
----------------------------------------------------------------------------------------------------------------
# Span 1: WCTDM/16 "Wildcard TDM400P REV E/F Board 17" (MASTER)
fxsks=1
echocanceller=mg2,1
fxsks=2
... ...
... ...
fxsks=15
echocanceller=mg2,15
fxsks=16
echocanceller=mg2,16
# Global data
loadzone = us (According to your country)
defaultzone = us (According to your country)
Users will get the configuration messages in the “/etc/asterisk/dahdi-channels.conf” file also.
----------------------------------------------------------------------------------------------------------------
; Span 1: WCTDM/16 "Wildcard TDM400P REV E/F Board 17" (MASTER)
;;; line="1 WCTDM/16/0 FXSKS"
signalling=fxs_ks
callerid=asreceived
group=0
context=from-pstn
channel => 1
callerid=
group=
context=default
;;; line="2 WCTDM/16/1 FXSKS"
signalling=fxs_ks
callerid=asreceived
group=0

AXE1600P User Manual
www.atcom.cn Email: [email protected]
8
context=from-pstn
channel => 2
callerid=
group=
context=default
... ...
... ...
;;; line="15 WCTDM/16/14 FXSKS (SWEC: MG2)"
signalling=fxs_ks
callerid=asreceived
group=0
context=from-pstn
channel => 15
callerid=
group=
context=default
;;; line="16 WCTDM/16/15 FXSKS (SWEC: MG2)"
signalling=fxs_ks
callerid=asreceived
group=0
context=from-pstn
channel => 16
callerid=
group=
context=default

AXE1600P User Manual
www.atcom.cn Email: [email protected]
9
2. Load the dahdi
Users can run the command “dahdi_cfg -vv” to load the dahdi in the CLI.
[root@localhost ~]# dahdi_cfg -vv
The right output of running dahdi_cfg -vv will like the following:
DAHDI Tools Version - 2.6.2
DAHDI Version: 2.6.2
Echo Canceller(s): MG2
Configuration
======================
Channel map:
Channel 01: FXS Kewlstart (Default) (Echo Canceler: mg2) (Slaves: 01)
Channel 02: FXS Kewlstart (Default) (Echo Canceler: mg2) (Slaves: 02)
... ...
... ...
Channel 15: FXS Kewlstart (Default) (Echo Canceler: mg2) (Slaves: 15)
Channel 16: FXS Kewlstart (Default) (Echo Canceler: mg2) (Slaves: 16)
16 channels to configure.
Setting echocan for channel 1 to mg2
Setting echocan for channel 2 to mg2
... ...
... ...
Setting echocan for channel 15 to mg2
Setting echocan for channel 16 to mg2

AXE1600P User Manual
www.atcom.cn Email: [email protected]
10
3. Please add the following command line in the end of chan_dahdi.conf file.
#include dahdi-channels.conf
4. Please run asterisk with the following command:
[root@localhost ~]# asterisk –vvgc
localhost *CLI> reload
5. Please run “dahdi show channels” command
The right output should like the following:
localhost *CLI> dahdi show channels
Chan Extension Context Language MOH Interpret Blocked State
pseudo default default In Service
1 from-pstn default In Service
2 from-pstn default In Service
3 from-pstn default In Service
... ...
... ...
14 from-pstn default In Service
15 from-pstn default In Service
16 from-pstn default In Service

AXE1600P User Manual
www.atcom.cn Email: [email protected]
11
Chapter 6 Reference
http://www.asteriskguru.com/
http://www.asterisk.org/downloads
http://www.atcom.cn/
