Atel AXIS V810A Installation guide

Passion for Innovation
Product Training
V810A
V1.3, January 4, 2023

CONFIDENTIAL –For Use Under NDA Only
WE ARE THE BIGGEST AND BEST IN QUALITY ODM. WE
WERE ESTABLISHED IN 2003 AND ARE ONE OUT OF 12
COMPANIES OF THE PUBLICLY TRADED STAR-NET
GROUP.
WE BUILD COMPLEX PRODUCTS THAT SOLVE
PROBLEMS, BRINGING SIMPLE SOLUTIONS.
ATEL OVERVIEW

CONFIDENTIAL –For Use Under NDA Only
The V810A AxisTM 1 Fixed Wireless Access Router
CELLULAR LTE Cat-4
4G LTE B2/4/5/12/13/14/66/71
3G B2/4/5
FEATURES Chipset: Qualcomm
4FF SIM
GPS
IPv4, IPv6
FOTA
ENVIRONMENTAL Operation Temperature: -10~60°
Storage Temperature: -20~80°
CONNECTIVITY Wi-Fi (Dual band Selectable)
802.11a/ac over 5GHz;
802.11b/g/n over 2.4GHz
LTE MIMO: 4x2
Speed: 150Mbps DL, 50Mbps UL
ADVANCED
NETWORKING
User Interface: Web GUI
Remote Management
Port Forwarding/Filtering
VPN Pass through
OpenVPN
IP Pass through
DHC
Static IP
BATTERY +
POWER
INFORMATION
USB Type-C Charger with
110-240V AC Input; 5V 2A DC Output
1800mAh, 3.7V Battery Backup with
up to 32 hours Standby Time and up
to 2 hours 40 minutes Usage Time
ANTENNA 2x Internal LTE Antennas
GNSS Antenna
WiFi Antenna
1x External LTE Antenna Port (Female
SMA Connector. External Antenna is
available as an add-on)
PHYSICAL Dimensions: 135 x 80 x 33 mm
Weight: 166g
(Internal Cellular Antenna; Does not
include External Cellular Antenna)
Mounting Slots for Secured Mount
DATA +
INTERFACE
PORTS
1x RJ45 Ethernet Port
SMA External Antenna Connector
Type-C USB Charge Port
DISPLAY 1.77” LCD, 128x160
Details: Battery Level, LTE Signal, WiFi
SECURITY Verizon Security Level 1 Approved
Secure Boot
Secure Firmware/software upgrade
Root of Trust & Unique device
identifier
NAT
MAC Settings
Admin Access
Content Filtering
CERTIFICATIONS
+ APPROVALS
Device Certifications: Verizon ODI,
Reach, FCC, PTCRB, RoHS, UL
V810 Series
ODI Certified

CONFIDENTIAL –For Use Under NDA Only
The V810A AxisTM 1 Diagram
1.
LCD Display
Displays Home, Device
Information, Hotspot login
information, and Online Portal
login information.
3.
Battery Port
This battery port is used to
connect to a Ni-MH
rechargeable battery pack (may
be sold separately).
2.
Power Button
Power the V810 on/off by
pressing and holding this
button. You can also short
press this button to wake up
the screen and toggle screens
to check device information
4.
Reset Button
Use a pin to push and hold this
button for 3 seconds for factory
reset.
5.
SIM Card Slot
Insert your 4FF SIM card into
this spring-loaded SIM slot. To
remove a SIM, press the edge
of the SIM inward and the SIM
would pop outward from the
SIM slot.
7.
Ethernet Port (RJ45)
Insert an ethernet cable to this
Port and plug the other end into
your computer for internet
access.
6.
Type-C Port
Use this port to connect the
USB-C cable to a wall adapter
for external power.
8.
Antenna Connector
Install an optional antenna (may
be sold separately) to increase
signal strength.

CONFIDENTIAL –For Use Under NDA Only
The V810A Set-Up Guide
1. Remove the V810 back cover.
2. Install the 4FF Nano SIM card into the spring-loaded SIM slot as the image
shows. To remove a SIM, press the edge of the SIM inward and the SIM
will pop outward from the SIM slot.
Install SIM Card
1. Remove battery cover.
2. Properly align and install the NiMH battery (with three pin sockets). Make
sure to align the pin sockets correctly.
3. Put the NiMH battery in place as shown below.
4. Replace the back cover of the V810 and make sure it’s aligned with the
bottom of the device.
Note: the NiMH Battery may be sold separately.
Installing a NiMH Battery

CONFIDENTIAL –For Use Under NDA Only
The V810A Set-Up Guide
To turn on your V810 press and hold the Power button.
To turn off your V810, press and hold the Power button until you see the screen turn of.
Turning your V810 On/Off
To increase signal strength, you can install an optional antenna.
1. Align the antenna with the antenna port and screw securely into place (in a clockwise direction).
2. Restart the V810 after the antenna is installed.
Note: Antenna may be sold separately. Using optional accessories (antenna and battery pack) by ATEL are recommended,
available at ATEL website, https://www.atel-usa.com/.
Optional Add-On’s: Install an Antenna

CONFIDENTIAL –For Use Under NDA Only
The V810A Set-Up Guide
The V810 provides 1 Ethernet port (RJ45). For internet access, plug
an ethernet cable to the Ethernet port of your V810 and connect it to
the Ethernet port of your computer.
Note: the computer and ethernet cable are not included.
Connect your Computer to the V810 Using the Ethernet Port
Your V810 Hotspot supports up to 15 Wi-Fi connected devices. To connect to the Hotspot Wi-Fi;
1. Locate your Network Name (SSID) / Password from your V810 LCD Display or device label under the battery holder.
2. Open the Wi-Fi Settings of your Wi-Fi capable devices.
3. Select the SSID of your V810 from the available network list.
4. When prompted, enter the password of your V810.
5. You are connected to the Internet.
Connecting to Your V810 Hotspot Wi-Fi

CONFIDENTIAL –For Use Under NDA Only
The V810A LCD Display Icons

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Options
The V810A Device Management Options
1. WebGUI: Local Device Management Web Interface
2. ARMS: Remote Management Portal
3. APP: Remote Management by Phone (IOS and Android)
Option 1 Example Option 3 ExampleOption 2 Example

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 1
Management Option Management Instructions
1WebGUI (Local Device
Management Web Portal)
1.
Connect your PC and V810 device using WiFi from the device, ethernet cable or USB-C cable.
2.
Using your Web Browser, visit 192.168.0.1
3. Log in to the WebGUI. Your Username is ‘admin’ and password can be found on the LCD display or on
the device label on the bottom of the device (under the battery cover).
4.
Once you’ve logged in, you can manage the device.
Dashboard Example:

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 2
Management Option Management Instructions
2ARMS (Remote Device
Management)
1.
Using a PC with Internet access (not necessarily the internet provided by the device which is being
managed), visit https://dm.a-tracs.com
2.
You can select ‘create account’, then register for a “General” account. You will need to provide your
email, a device IMEI and SN. The device shouldn’t have been managed by anyone else in ARMS or
the APP already. If you have already got your account registered through the APP, you can use the
same credentials to log in.
3.
You can register with an “Admin” account without the device information (note that you must have an
agreement ready with ATEL first.) Admin accounts can manage all the devices ATEL preload for you.
4.
The registered account can be used to log-in to ARMS and the APP.
5.
Log into your account. You can view your device there.
6.
Power on the device (make sure it connects to Internet).
7.
Once connected to the Internet, you can see your device is shown ‘online’ in the ARMS portal.
8.
You can manage your device now. You can use the menu button to refresh the status, delete the
device, configure the device, tag (name) it, give it an address, share the device management with
another person using his/her email, and import more devices either one by one or in batch.
9.
After sharing the device to another person’s email, he/she can use the default password Atras!234 to
log-in to manage the device. After log-in, he/she can change the password.

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 2
Device List Example
[e-mail]
[e-mail]

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 2
Dashboard Example
[e-mail]

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 2
Data Usage Example
[e-mail]

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 2
Settings Example
[e-mail]

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 3
Management Option Management Instructions
3
APP (Remote Device Management by
Phone)
1.
Using your iPhone, go to Apple Store. download ‘ATRACS Admin’ APP. Android APP can be
downloaded through the link on the ARMS Web portal https://dm.a-tracs.com
2.
You can click ‘Sign Up’, to register for a “General” account using a device IMEI and SN. This device
shouldn’t have been managed by anyone else in ARMS or APP already. If you already have an
account registered through ARMS, you can use the same credentials to log in.
3.
You can register with an “Admin” account without the device information (note that you must have an
agreement ready with ATEL first.) Admin accounts can manage all the devices ATEL preload for you.
4.
The registered account can be used to log-in to ARMS and the APP.
5.
Log into your account. You can view your device there.
6.
Power on the device (make sure it connects to Internet).
7.
Once connected to the Internet, you can see your device is shown ‘online’ in the ARMS portal.
8.
You can manage your device now. You can use the menu button to refresh the status, delete the
device, configure the device, tag (name) it, give it an address, share the device management with
another person using his/her email, and import more devices one by one.
9.
After sharing the device to another person’s email, he/she can use the default password Atras!234 to
log-in to manage the device. After log-in, he/she can change the password.

CONFIDENTIAL –For Use Under NDA Only
The V810A Device Management Option 3
Device List Example Device Info Example Device Settings Example

CONFIDENTIAL –For Use Under NDA Only
