ATEN EC1000 User manual

EC1000
Energy Box with Real-!me
Power Monitoring
User Manual

EC1000 User Manual
ii
Compliance Statements
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC ules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
The device complies with Part 15 of the FCC ules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
Warning
Operation of this equipment in a residential environment could cause radio
interference.
Achtung
Der Gebrauch dieses Geräts in Wohnumgebung kann Funkstörungen
verursachen.
KCC Statement

EC1000 User Manual
iii
Industr Canada Statement
This Class A digital apparatus complies with Canadian ICES-003.
VCCI Statement
RoHS
This product is oHS compliant.

EC1000 User Manual
iv
User Information
Online Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual are subject
to change without prior notification by the manufacturer. The manufacturer makes no
representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties as to merchantability or fitness for any
particular purpose. Any of the manufacturer's software described in this manual is sold
or licensed as is. Should the programs prove defective following their purchase, the
buyer (and not the manufacturer, its distributor, or its dealer), assumes the entire cost of
all necessary servicing, repair and any incidental or consequential damages resulting
from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV interference
caused by unauthorized modifications to this device. It is the responsibility of the user
to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation of this
system if the correct operational voltage setting was not selected prior to operation.
PLEASE VE IFY THAT THE VOLTAGE SETTING IS CO ECT BEFO E USE.
International http://support.aten.com
International 886-2-8692-69 9
China 86-400-810-0-810
Japan 81-3- 61 - 811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
1-949-428-1111

EC1000 User Manual
v
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
eseller. Visit ATEN on the Web for a list of locations and telephone numbers:
Package Contents
Check to make sure that all the components are in working order. If you
encounter any problem, please contact your dealer.
The EC1000 package consists of:
1 EC1000 Energy Box
1 power adapter
1 mounting kit
4 J-45 cables
1 user instructions
International http://www.aten.com
North America http://www.aten-usa.com

EC1000 User Manual
vi
Contents
Compliance Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Chapter 1.
Introduction
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sensor Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
EC1000 Front View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
EC1000 Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 2.
Hardware Setup
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rack Mounting - Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rack Mounting - Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Rack Mounting - Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Securing the Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 3.
Front Panel Operation
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Front Panel Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chapter 4.
rowser Operation
Operation Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
eco DC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Browser Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
The EC1000 Main Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Page Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Browser Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
First Time Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Changing the Administrator Login . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

EC1000 User Manual
vii
Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Energy Sensor Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Monitor Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Administrator Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
The System Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Notification Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Device Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Service Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IPv4 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Date/Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Login Failures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Working Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Session Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Account Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Login String / IP Filter / Mac Filter . . . . . . . . . . . . . . . . . . . . . . . . . 41
Authentication & Authorization. . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Private Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
SNMP & Telnet Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
SNMPv3 Account Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
SNMPv1/v2c Community. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Telnet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Event Notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
SMTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
SNMP Trap Receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Syslog Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
PDU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
Firmware File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
Upgrading the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Firmware Upgrade Recovery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Backup/Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Backup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Chapter 5.
Telnet Commands
Remote Terminal Operations - Telnet. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EC1000 User Manual
viii
Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Read Outlet Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switch Outlet Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Read Power Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Read Environmental Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Close Telnet Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Appendix
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
EC1000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
IP Address Determination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Method 1: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Method 2: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Method 3: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Administrator Login Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

EC1000 User Manual
ix
About This Manual
This User Manual is provided to help you get the most from your EC1000
system. It covers all aspects of installation, configuration and operation. An
overview of the information found in the manual is provided below.
Chapter 1, Introduction, introduces you to the EC1000 System. Its
purpose, features and benefits are presented, and its front and back panel
components are described.
Chapter 2, Hardware Setup, provides step-by-step instructions for setting
up your installation, and explains some basic operation procedures.
Chapter 3, Front Panel Operation, explains how to operate the EC1000
from the local console.
Chapter 4, rowser Operation, describes how to login to the EC1000
with a browser, and explains the functions of the icons and buttons that appear
on the opening page, and explains the administrative procedures that are
employed to configure the EC1000’s working environment.
Chapter 5, Telnet Commands, describes how to connect to the EC1000
and the available Telnet commands.
Appendix , provides specifications and other technical information regarding
the Energy Box with eal-time Power Monitoring.
Note:
ead this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit and/or connected
devices.
The product may be updated, with features and functions added, improved,
or removed since the release of this manual. For an up-to-date user
manual, visit http://www.aten.com/global/en/.

EC1000 User Manual
x
Conventions
This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means
to press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential
steps.
>
Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start
>
Run means to
open the Start menu, and then select Run.
Indicates critical information.

1
Chapter 1
Introduction
Overview
The EC1000 Energy Box solution is the latest evolution of ATEN’s energy
intelligence product line. The EC1000 monitors the electrical current of 4
Energy PDU's, along with room temperature, humidity, and differential
pressure using environmental sensors. The Energy Box provides instant real-
time power management and energy-saving control for data centers– allowing
you to upgrade and maintain your current IT power resources quickly and cost-
effectively.
The EC1000 Energy Box has four J-45 ports to connect to four Energy PDUs
and four J-11 ports to connect external sensors to monitor environmental
conditions. Each environmental sensor can provide measured readings of
temperature, humidity, and differential pressure from separate areas of a room,
giving you a wide range of monitoring and protection.
The EC1000 features real-time status, system logs, threshold alerts, and event
notification. The Energy Box logs power and environmental conditions
according to customizable minimum/maximum thresholds set for; current,
temperature, humidity, and differential pressure.
The Energy Box allows the power and environmental data to be monitored by
display at the rack or remotely for easy viewing and maintenance. The Energy
Box is a standalone unit with over IP monitoring that is controlled by a built-
in web GUI or ATEN eco DC (Energy & DCIM Management Web GUI).
emote monitoring offers secure access with 128bits SSL encryption, and
customizable account policies for user management. emote authentication
supports ADIUS and additional management interfaces including HTTP,
HTTPS, and SNMPv1&v2&v3 ( ead, Write, Trap). Event notifications can be
monitored via Syslog/SMTP/SNMP trap and by audible alarm for real-time
local and remote alerting.
The EC1000 Energy Box is the intelligent cost effective solution to monitor
ATEN's Energy PDUs – to ensure safe and effective energy-saving power
management.

EC1000 User Manual
2
Features
Operation
Space saving 1U and 0U rack mounting with front, rear, and side mounting
4 J-45 Energy Sensor Ports to monitor four Energy PDUs (0A to 32A per
port) electrical currents
4 J-11 Environmental Sensor Ports to monitor temperature, humidity,
and differential pressure*
Maximum Amperage Monitor 32A@100V~240V (Energy Box)
3 digit 7 segment front panel LED displays current/sensor/IP address
information
Threshold monitoring for:
Current
Temperature*
Humidity*
Differential pressure*
Threshold alerting through:
Local: audible alarm and LED lights
emote: SMTP/SNMP trap/Syslog
Management
Front panel LED indicators for current, temperature*, humidity*,
differential pressure*, and IP address at the Energy Box
emote real-time current, temperature*, humidity*, and differential
pressure* monitoring and management
Management through eco DC Energy & DCIM Management Web GUI or
3rd party SNMP manager
Supports name assignment for individual Energy PDUs
Multi-language GUI supports: English, Traditional Chinese, Simplified
Chinese, Japanese, Korean, German, Italian, Spanish, Portuguese, French,
ussian
Event Logging – 128 line event log
Syslog support
F/W upgradable

Chapter 1. Introduction
3
Remote Access
emote management via TCP/IP using built in 10/100Mbps Ethernet port
Management via built in browser based GUI
Network Interfaces: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, DHCP,
NTP, DNS, 10Base-T/100Base-TX, auto sense, Ping
Supports SNMP Manager V1, V2, V3
Security
Strong security features include password protection and advanced
encryption technologies – TLS1.2
ADIUS authorization and authentication
* equires external sensors (see Optional Accessories, page 5).

EC1000 User Manual
4
Requirements
Energy PDU PE1216, PE1324, PE2220, or PE2340
Environmental Sensors EA1140, EA1240, EA1340 to monitor
environmental data
One Cat 5e Ethernet cable to connect the EC1000 to the local area network
Browsers accessing the EC1000 must support SSL 128 bit encryption.

Chapter 1. Introduction
Optional Accessories
Sensors
Sensors are optional accessories. You can use the EC1000 Energy Box without
sensors. However, if you want to have complete energy management of your
data center with the full use of the EC1000 Energy Box, you would need to use
eco DC (Energy & DCIM Management Web GUI) and install 4 sensors for
each of the racks to generate more complete energy-efficient data and charts.
Sensors help you maintain a safe and highly efficient data center by monitoring
environmental conditions. Higher sensor density installations help to generate
more accurate and precise data. Available sensors are show in the table, below:
Sensor Management
Sensors can be managed via the EC1000’s browser based graphical user
interface (GUI) or with ATEN eco DC that can be downloaded from the ATEN
website.
Sensor Part Number
Temperature EA1140
Temperature / Humidity EA1240
Differential Pressure / Temperature EA1340

EC1000 User Manual
6
Components
EC1000 Front View
No. Component Description
1 Readout Section
The first single-digit LED indicates the port selected:
Energy Sensor (1-4)
Environmental Sensor (1-4)
IP Address (1)
The second 3-digit LED displays information related to
the first LED:
Current
Temperature, Humidity, Differential Pressure
IP Address
2 Energy and
Environmental Sensor
LEDs
Lights (Orange) for connected Energy Sensors and
(Green) for Environmental Sensors, currently connected
to a port and taking readings.
3 Selection LED Lights (Green) to indicate the selection (Energy,
Environment, IP) that the Readout is currently displaying.
4 Select Button Press the Select button to cycle through the selections
(Energy, Environment, IP) to display their data readout
on the 3-digit LED.
Reset Switch This switch must be pushed with a thin object, such as
the end of a paper clip.
Press and release to reboot the device.
Press and hold for more then three seconds to
reset the Energy Box to its factory default settings

Chapter 1. Introduction
7
EC1000 Rear View
*External sensors are sold separately (see Optional Accessories, page 5).
6 Power LED Lights (Green) when the Energy Box is powered up and
ready to operate.
No. Component Description
1 Grounding Terminal The wire used to ground the Energy Box attaches here.
2 Energy Sensor Ports The four RJ-4 cables that connect the Energy Box to
your Energy PDUs, plug in here.
3 Environmental Sensor
Ports
External sensors plug into these four RJ-11 ports.*
4 Power Jack The power adapter cable plugs into this jack.
LAN Port The cable that connects the Energy Box to the LAN
plugs in here.
No. Component Description

EC1000 User Manual
8
This Page Intentionally Left Blank

9
Chapter 2
Hardware Setup
Rack Mounting
The EC1000 can be mounted in a 19” (1U) rack or in an 0U configuration
mounted to the side of the rack. To rack mount the device, use the rack
mounting brackets that came with your device. The brackets are screwed to the
front, rear or middle sides of the device, depending on the installation type and
then the unit can slide into the front of the rack, or mount to the side of the rack,
as shown in the diagrams below:
Rack Mounting - Front
1. Use 3 M3 x 8 Phillips hex head screws supplied with the rack mounting kit
to screw the rack mounting brackets into the sides near the front of the
unit.
2. Position the unit in the front of the rack and align the holes in the mounting
brackets with the holes in the rack.
1. Important safety information regarding the placement of this
device is provided on page 63. Please review it before proceeding.

EC1000 User Manual
10
3. Screw the mounting brackets to the rack.
