Atex GL10 User manual

Warning
When bending horizontally, minimum
allowable Bending Radius is 30mm.
It is not allowed to bend vertically.
It will cause cracks in the solder.

Long Silicone Light GL10 Installation Manual
We will appreciate for your purchase of 'Long Silicone Light'. Please peruse this manual and install correctly and safely. ver. 200304
□
□
such as AC100 to 230V. It will cause fume or fire.
□Do not put screws on the products directly. It may cause damages.
Please refer to "How to Install"
□Please do not perform the following actions on the product.
It will cause to decline in water resistant and installation performance.
・ Excessive bending and twisting of the product.
・ Dropping and strongly striking the product.
□It is dangerous working with wet hand. May cause electrical shock.
□This product is IP67 rated:
This product should not be installed in a location where water is
continuousｌｙ splashed or underwater.
□The product can not be used the place such as "Atmosphere of corrosive
gas and flammable gas"
Because it may cause troubles.
Please do not use the product in the following area. (** : Color temperature)
・Area with synthetic rubbers and cardboards. 22 25 28 30 32 35 40 50 RX GX BX YX
・Area with the material containing sulphur.
・Area with atmosphere of sulphur such as hot springs.
□If there is any trouble with the product, please immediately DC24V
turn off the power and contact the dealer or installer. 11 W / m (Only Red 9 W/m)
-10 ~ +55℃(Indoor / Outdoor)
60mm (6 LED) * Customized length order available
W 9(13)×H16(20) ×L mm *Note : (Size of "end parts")
160 g / m
R30 mm horizontal
□Please perform installation or removal, after the switch must be turned off.
□Please be careful that eyes might be hurt when you look straight at
light emitting part.
□The temperature rise of the product is influenced with the capacity and
the distance from housing.
Ambient temperatures must remain the product specification.
□Please be careful about static electricity. It will damage LED's.
□The product is horizontal bending type. Please do not bend the product
toward vertical direction. It may cause the failure.
□Please note that there is some variation in color among LED's.
When installing the product, please use the Atex AL channel and theAtex fixing material. Please set the fixing material at the position 125mm from the product's edge.
And please use the fixing material every 240mm pitch as follows.
* In case of installing onto the ceiling
When total length of the products is 10.1m ( 5055mm + 5055mm ) or less, serial connection is
available.
When total length of the products is more than 10.1m ( 5055m + 5055m ) , parallel connection is
required.
How to Install
4 pieces per meter.
Flexible line installations / L=1000mm
Recommended total length connectable per power supply
AL Flexible Channel
FAC10-01S
BLUE
LED Pitch
10 mm
Fixing Material
FJB30-01
Accessories
Product Name
Product No,
Remarks
AL Rigid Channel
FAS00-01S
RED
Straight line installations / L=1000mm
YELLOW
5000K
Precautions
How to wire
Specification
Warning
Electrical works certificate is required to install and inspect this product.
Input voltage is 24VDC only. Please do not apply other voltage
Product Specification
Input Voltage
Weight
Dimension
Power Consumption
Bending Radius
GREEN
Product No.
GL10-96A1**K
2200K
2500K
2800K
3000K
3200K
3500K
**
Operating Temperature
Cutting points
Color
Temperature
4000K
240mm
240mm
125mm
240mm
125mm
Fixing material
Fixing material
Fixing material
Fixing material
240mm pitch
For Keeping
Flat-head screws M３
AL Channel
Pan-head screws M4
Fixing material
Long Silicone Light
Width 33.2mm
unit :mm
75 ～ 5055 +0
-30
150
10
9
20
16
13
+2
-2
240
3D
Dimension
L = R ×0.7 ÷P
L: The product's connectable length to a power supply (m)
R: Rated wattage of a power supply (W)
P: Power consumption of a product (W/m)
e.g. 100(W) x 0.7 / 11(W/m) = 6.3(m)
(100W power supply can be used for product's length 6.3m as maximum.)
As for the product's connectable length to a power supply, please refer to the following formula.
<Example>
WhenLength of the product is 975mm.
AC Line
+
-
Power
Supply
DC24V
10meters(5m+5m)maximum
10.1m maximum
Branch cable not to exceed 10m
Power
Supply
DC24V
AC Line
Connection portion is treated with heat-shrinkable tube,
insulation tape or sleeve for insulation and Water proof.
PINK WIRE ：DC24V（＋）
10meters(5m+5m) maximum
+
-
BLUE WIRE ：GND
Red
Black
10.1m maximum
