Athena 3PAB006E User manual

4 Satellite Speakers
1 Center Channel
A STYLE THAT’S ALL YOUR OWN...athena TECHNOLOGIESTM
POINT5 MK II sound system has also been intuitively designed to let you
create your own style. Complement your décor with the sleek, sophisticated
styling of a silver baffle with a high gloss black finish. If you select
the components separately, black baffles are available. And because these
speakers are magnetically shielded, you can place them virtually anywhere
you like. Want to take performance even further? The S.5 satellites from this
system can be used as rear channel speakers with athena’s SCT™(System
Creation Technology) series. Exceptional sound performance to suit your
senses, style and budget. That’s the point of POINT5 MKII.
A PERFORMANCE ENHANCED SYSTEM... athena’s POINT5
MK II sound system has been conceived to dramatically enhance your home
theater and music listening pleasure. Capitalizing on athena’s breakthrough
research and development in acoustics and speaker engineering, this system is
designed inside out to work together perfectly, with such features as timbre-
matched drivers and Medium Density Fiberboard (MDF) cabinets to minimize
resonance and enrich the deep bass.The POINT5 MK II system comes complete
with four S.5 satellite speakers, and the matching C.5 center channel. For bass
enhancement, add the matching active subwoofers AS-P300 or AS-P400.
Both subwoofers feature athena’s exclusive SCT control for perfect subwoofer
to speaker blending, which will provide the sound of large tower speakers in a
small subwoofer satellite combination. For performance enhanced music
and home theater sound, get to the point with POINT5 MKII.
POINT5 MK II S.5 Satellites
POINT5 MKII C.5 Center Channel
Recommended subwoofer (optional)
AS-P300/AS-P400
POINT5 MKII stand
(optional)
POINT5 MKII stand
(optional)
POINT5 MK II system consists of:

“Hey,
my life’s
complicated enough without having
to worry about how to set up a home
theater sound system. I wanted
something that I could bring home
and pretty much plug in and start
enjoying right off the bat. And with
wall brackets already built in, my
POINT5 MKII speakers were easy
to set up where I wanted them.
What could be easier?”
EFFORTLESS: “I’m into
suspense
and action adventure movies. So I
wanted a home theater sound system
that could match the action blow
for blow. I got it with POINT5 MKII.
It’s brilliant as a system, but the
satellite speakers are so amazing on
their own, I created a mini sound
system for my home office. So at
work or play, I never have a dull
moment.”
THRILLING:“We just got
married, but
we still have very individual tastes.
For our home theatre sound system,
I wanted lots of power; she didn’t
want to be overpowered. POINT5
MKII was the clear winner. I was
impressed by the technology that
makes this a true system. And Lisa
fell for the performance. One listen
and we knew we’d found the
balance we were looking for.”
BALANCE:
POINT 5 MKII
Create your sound.
athena TECHNOLOGIES®
3641 McNicoll Avenue
Toronto, Ontario
Canada M1X 1G5
www.athenaspeakers.com
Printed in Canada. Subject to change without notice.
© 2003 athena TECHNOLOGIES
®
Part #3PAB006E
“When
Russell
and I first listened to POINT5 MKII,
everything clicked. The sound. The
styling. The value. I’ll admit we
don’t always pick the same movies
or listen to the same music, but
when we experienced athena’s
POINT5 MKII sound system, we were
both on the same wavelength. Best
of all, it was so easy to set up, all
we had to do was add popcorn.”
IRRESISTIBLE:
The point is performance…
At a great price point!
C.5 Center Channel Speaker | FEATURES: • Small –
High Power center channel speaker to match the S.5
speaker • C.5 is timbre matched to the other “S” models
as well • Magnetically Shielded – all drivers • Key-Way
wall mount • Bass Reflex design – Dual rear vents
COMPONENTS: • 1-1" Teteron DomeTweeter • 2-4" Composite Cone Woofers • MDF
Construction • Composite Resin Front and Rear Baffles • Binding Post terminals
SPECIFICATIONS: • Frequency Response: 80-20kHz +/- 3dB • Power Handling: 100
watts per channel RMS • Sensitivity: 86dB anechoic – 89 dB room measurement
• Crossover Point: 2.0kHz • Impedance: 8 ohms compatible • Dimensions: - Width: 15"
(38.1 cm) - Height: 5-5/8" (14.3 cm) - Depth: 6-1/4" (15.6 cm) - Weight: 9.5 lbs
(4.3 kg) each • Color: High Gloss Black with Silver or Black Injection Molded Baffles
Recommended subwoofers (optional)
AS-P300 –300 watt 8”vented subwoofer
AS-P400 –400 watt 10”vented subwoofer
(used for rooms over 400 sq feet in size)
Both models feature athena TECHNOLOGIESTM exclusive
SCT control, for precise blending of the POINT5MK II
system to the subwoofer.
S.5 Speaker | FEATURES: • Small, High Power Full-Range speaker
solution • S.5 is timbre-matched to the other “S” models •
Magnetically Shielded – all drivers • Built-In Wall Mounting System for
flexible and secure wall mounting - Will allow horizontal and vertical
movement – no tools required! • Bass Reflex design – Rear vented
COMPONENTS: • 1-1" Teteron Dome Tweeter • 1-4" Composite Cone
Woofer • MDF Construction • Composite Resin Front and Rear Baffles • Binding
Post terminals
SPECIFICATIONS: • Frequency response: 80-20kHz +/- 3dB • Power handling: 100
watts per channel RMS • Sensitivity: 86dB anechoic – 89 dB room measurement
• Crossover point: 2.0kHz • Impedance: 8 ohms compatible • Dimensions:
- Width: 5-3/4" (14.6 cm) - Height: 8-1/2" (21.6 cm) - Depth: 6-1/4" (15.9 cm) -
Weight: 6 lbs (2.7 kg) each • Color: High Gloss Black with Silver or Black Injection
Molded Baffles
