Atid XC-AT870A Reference guide

Guide for Customer
AT870A

ATID Co., Ltd
Copyright ⓒ2006 ATID Co., Ltd. An Unpublished Work –All right reserved.
No part of the contents of this documentation or the procedures described there in may be reproduced or transmitted in any form or by any means without prior written
permission of ATID Co., Ltd. or its wholly owned subsidiaries ("ATID").
Owners of ATID products are hereby granted a non-exclusive, revocable license to reproduce and transmit this documentation for the purchaser's own
internal business purposes.
Purchaser shall not remove or alter any proprietary notices, including copyright notices, contained in this documentation and shall ensure that all notices
appear on any reproductions of the documentation.
Should future revisions of this manual be published, you can acquire printed versions by contacting ATID Customer Administration. Electronic versions
may either be downloadable from the ATID web site (www.atid1.com) or provided on appropriate media.
If you visit our web site and would like to make comments or suggestions about this or other ATID publications, please let us know via the “Contact ATID” page.
Disclaimer
ATID is a registered trademark of ATID Co., Ltd.
AT870A is a registered trademark of ATID Co., Ltd. and of its wholly owned subsidiaries.
ATID Co., Ltd.
#1205, Byuksan/GyungIn Digital Valley II,
#481-10, Gasan-Dong, Gumchon-Gu, Seoul,
Korea
Tel: [phone]
Fax: [phone]
www.atid1.com

Contents
Page
Contents
5
Before using manual for AT870A
Chapter 1. Caution when using AT870A
6
1. How to use battery correctly
6
2. Caution when using AT870A
Chapter 2. Product composition
7
1. Product composition
8
2. Name of each part
9
3. Function of each part
Chapter 3. Basic function
10
1. Attaching and Detaching the battery
11
2. Charging battery
11
3. Low power mode (Sleep mode)
13
4. Checking battery gauge
13
5. Changing battery
14
6. Hard reset
15
7. Attaching Micro SD card
16
8. Attaching SIM card
17
9. Set screen brightness

Page
Contents
Chapter 3. Basic function(continues)
17
10. Screen adjustment
18
11. Volume setting
19
12. Using keypad
20
13. Inputting data
21
14. Using stylus
22
15. Connecting PDA to PC
22
16. Firmware upgrading
Chapter 4. Optional module
24
25
27
28
29
30
31
32
32
33
1. Using 1D or 2D barcode scanner
2. Barcode emulator setting
3. Barcode scanning
4. WIFI connection and termination
5. Bluetooth connection and termination
6. GPS demo program execution
7. Use of camera
8. NFC execution
9. NFC ON/OFF setting
10. UHF 900MHz RFID program
Chapter 5. Appendix
34
1. Product specification

Before using manual for AT870A
User guide inclusive of text, images, logos, product names is either the property of, or used with permission by ATID CO.LTD. The information may not be distributed,
modified, displayed, reproduced (in whole or in part) without the prior written permission of ATID CO.LTD.
There are some differences between user guide and actual function of device.
User guide can be adjusted by ATID CO.LTD without consent of user discretionally.
User guide is written for users who want to use and maintain the AT870A. Please read and understand these instruction prior to operating this unit.
Safety information
Your safety is extremely important. Read and follow all warnings and cautions in this document before you handle and operate ATID equipment. If you do not follow
the safety warnings and cautions, you might be seriously injured, and the equipment and data also might be damaged.
WARNIING
A warning requires you must pay attention to the operating procedure practice, condition, and statement strictly, or might be injured seriously.
CAUTION
A caution alerts you that you must be observe strictly when you operating procedure, practicing, configuring, for preventing from damage and destruction of
equipment, and loss of data.
NOTICE
A notice provide you the information which you must needs while you using AT870A .

Caution when using AT870A
Caution when using AT870A
Please aware of the manual contents in advance before you handle and operate your AT870N and other ATID Products.
How to use the battery correctly
In case that you dropped the main body or battery in water, please do not put into the stove or heater for drying. Just keep it in natural drying or contact purchase
place.
Please note that the battery terminal doesn’t have to be contacted to metallicobject.
If you do not use the battery for a long time, please keep it at room temperature after charging.
Operating time of battery can be shorter than usual in accordance with loss of battery and use time. In this case, please contact us.
You have to use provided adaptor when charging thedevice.
Turn off the device properly then detach or replace thebattery.
Caution when using AT870A
User careless or products repair would damage the stored data. Manufacturer is not responsible for this damage, so please do back-up the important data
separately.
If you have a problem on product, do not try to repair or disassemble it by yourself, please contact our customer service center.
Do not use your product at the specific places such as hospital, plane and so on where electromagnetic wave or the risk may occur.
Please note that using the device in environment of high temperature and humidity for long hours can make a malfunction of device. =
Please do not use other material instead of provided stylus pen, otherwise it might be damaged or not worked properly.
In case of that noise, smoke and odor occur at the device while using product, please disconnect the charger with device and off the power immediately, then
please contact our customer service center.
If you have any other questions on use of device, please contact our customer service center.

Chapter 2. Product composition
Product Composition
AT870A is based upon Android 4.2. As the state of the art product, it is equipped with barcode scanner, RFID Tag reader, MODEM, Camera and so on and it can be
applied to Industry, Enterprise, Logistics and so on, can be used extensively in many fields due to this kind of various functions
Product composition
Open the packing box and confirm the items as below.
* Please contact our customer service in defect of product composition and need to be changed.
USB sync cable
Power Adapter and AC cable
Standard battery
Protect film
Hand strap
Stylus Pen

Chapter 2. Product composition
Name of each part
Camera (option)
1D/2D Scanner
(option)
Camera flash
(option)
Cradle connector
Earphone jack
Charger jack
Sync Cable
Connector
Phone receiver
WLAN LED
(option)
Internal NFC
(option)
Charge LED
Touch Screen
Keypad
Reset button
Microphone
UHF
Volume button
Scan button
Gun handle

Chapter 2. Product composition
Function of each part
NAME FUNCTION
1D/2D Scanner (option) Please be careful not to get the damage or the foreign substances at the Window emitted the laserbeam
Warning Do not look at the laser beam directly.
UHF Connecting port
Internal NFC (option)
Reset button
Microphone
WLAN LED (option)
Battery latch
battery
Scan button (F7, F8)
Speaker
Sync cable connector
Earphone jack
Charger LED
Adapter jack
Camera flash (option)
Camera (option)
Cradle connector
Keypad
Touch screen
Hand strap hole
It is connector to equip the UHF 900MHz tag reader module.
It is where Internal NFC is placed.
It is used for hard reset.
It is used for telephone conversation.
It displays whether the wireless WLAN power gets supply.
You can attach and detach by moving it from side toside.
It attaches on body for receiving power.
You can scan the barcode or RFID tag by thisbuttons.
It is equipped for playing sound and various sound effects internally.
It makes device transmit and receive the data with computer in connection with USB synccable.
It is used for connecting the earphone with device.
It will be changed with red color in charging state / with green color infull.
Please do connect it with provided adapter when charging the device.
It functions in case of using camera.
It makes image capture and save.
It is used as a port for charging the battery or connecting the body with computer in case of equipping thecradle.
It makes device implement the program and input the key value by using input key.
You can implement and terminate the program to touch the screen by using styluspen.
Please attach hand strap and stylus pen with device for your convenience when using it for a longtime.

Chapter 3. Basic function
Basic function
A battery supplies the power to the system and RAM which could keep the data.
Battery: 3.7V 2,970 mAhLithium –Ion
Attaching and detaching the battery
▶Battery detachment
These image as below has shown the bottom of device
Please slide the battery latch to the right (Direction to UNLOCK), and then lift the battery to detach the battery after grapping the gap of battery on the bottom.
▶Battery attachment
Please put the top of the battery into the above gap of device and then, push the bottom of battery into the below gap of device and then, slide the lever to right
(Direction to LOCK).
Above gap for attachment/
top of battery
Battery latch
Both sides of the
gap for detachment

Chapter 3. Basic function
Charging battery
You have to charge it through dedicated adapter which is provided when you bought.
Red light is lit on LED when it starts to charge. It will be changed into green light in case of full charging.
Low power mode (Sleep mode)
In case that there is window screen as below or you don`t use the system in the status of running other program, the device is able to enter the low-power
mode (sleep mode).
▶ Setting low power mode (sleep mode) by Power ON/OFF button
NOTE:
If there was a tiny battery gauge remained despite of power-off, the data of RAM will be saved, and these programs will be recovered in case of power-on. If both battery and
backup battery are in the discharge state, the RAM data will disappear, and the system will be re-starting if the power is charged again.
▶ Connecting adapter
1. Plug the adapter cable to 220V socket.
2. Connect adapter DC cable with “Power Connecting Jack”
3. LED will be changed when the red light is lit on theLED
Caution:
You must use provided adapter with device. Otherwise your device might be damaged.
Power off (setting sleep mode):
Press the power button when screen is on, then screen goes off and (sleep mode) will begin.
Power on (releasing sleep mode)
Press the power button when screen is off, then screen appears and low (sleep mode) will finish.

Chapter 3. Basic function
▶ Automatic Power OFF
The device will be automatically entered to low power mode (Sleep mode) if user does not use it for the designated time. User can change the designated time at
the control panel and power as below. If user sets proper time-out, the device can be protected from the situation of power-on without user and battery can be
prolonged.
[Menu] -> [Application] -> [Settings] -> [Display] –> [Sleep mode]
Enters to the Sleep mode by double-clicking Display
Screen appears by pressing power button after Automatic Power OFF.
▶ Turn off the device in case of discharging the battery
If the system cannot be used by electric discharge, it will be automatically entered into low-power mode (sleep mode). In this case, user have to charge the
battery or connect the adaptor with the adaptor connecting jack of main body, then press the <Power> button to turn on the system since it won`t be turned on
despite of pressing the <POWER> button.

Chapter 3. Basic function
Checking battery gauge
● NOTE:
Using time for battery will be influenced by way of use, surrounding environment. In general, you can use the device from 6 hours to 12 hours after 2,970 mAhbattery is fully charged.
▶Checking the Gauge Remained
[Menu] -> [Application] -> [Settings] -> [About phone] –> [Status]
▶Caution for low battery
If the system is unavailable for low-battery, caution screen for lack of battery will be came out. In this situation, please turn off the device by pushing <POWER> button
and then charge as soon as possible.
.
Changing the battery
You need to purchase a new battery if existing battery got damaged or reached to its life.
CAUTION
Please discard the expired battery at the designated location.

Chapter 3. Basic function
Please do restart the system when the application doesn`t work properly or system receives no response.
Hard reset
In need of Hard reset
Hard reset which is called cold reset can be used for initializing the hardware completely. Registry value, copied file and installed program can be remained originally
even though user uses the hard reset, but please note that time/date will be initialized. Therefore, please do reset the time if user uses the hard rest.
[Process of hard reset]
Please press the power button and reset button with stylus pen simultaneously and then, unhand those buttons.
[Result of Hard Reset]
- Systems will be restarted
- OS will be restarted

Chapter 3. Basic function
Below image shows the back side of device when separating the battery from device
There are 1EA SIM Card Slot, 3EA SAM Card Slot and 1EA Micro SD Card Slot.
Attaching Micro SD card
Do lock the slot cover by sliding it to
left side and then, turn on the device
after equipping the battery.
Put the SD memory on the slot and
then, shut the cover up.
Lift the slot cover.
Do unlock the Micro SD card by
sliding the card slot cover right side.
Micro SD card slot
SIM card slot

Chapter 3. Basic function
When the SD memory is selected from the File Manager after installing Micro SD memory card, it is shown as below.
Attaching SIM card
Below is the screenshot after installing the SIM card.
Place and insert the SIM card so that it fits the slot shape.

Chapter 3. Basic function
Set screen brightness
Brightness of the screen affects the power consumption the most, so it is recommended to be set as required by the user.
[Setting the screen brightness]
[Menu] -> [Application] -> [Settings] -> [Display] -> [Brightness]
Brightness : adjust the screen brightness
Wallpaper : choose the wallpaper
Auto-rotate screen : set the auto-rotate screen function
Sleep mode : adjust the time period to enter into sleep mode
Font size : adjust the font size of PDA
Adjusting screen
After using the device for a while or long time, you may adjust screen through ‘Touch Calibration’ if not being pressed the right place with one pointed by stylus
pen.
Adjusting touch screen
[Menu] -> [Application] -> [Touch Calibration]
Press the middle of target with stylus pen of 5 times.

Chapter 3. Basic function
Set sound volume
The volume is set to 80% when it is dispatched. The user can set the different features of sound settings from [Menu] -> [Application] -> [Settings] ->
[Sound].

Chapter 3. Basic function
Keypad is an input method editor that inputs numbers or alphabetic characters easily.
Use keypad
To change the current input language, follow the steps below.
[Menu] -> [Application] -> [Settings] -> [Language & input]
Or change the select input method.

Chapter 3. Basic function
Keypad button execution
Describe the Keypad Function.
Keypad
Description
power
Enters to sleep mode for short press and Power ON or reboot for long press (2 seconds)
Ξ
Menu Key (Android. view. Menu) can be used by importing
home
Move to home button
back
Use for going back to previous state
call
Move to call section
sidekey - right
Control volume, has a value of KEYCODE_SOFT_RIGHT and KEYCODE_SOFT_LEFT key event
sidekey - left
BKS
erase one letter
KDB
Shows SW keyboard screen
alphabet/numberic
Description
1 <-> ALP
Switch number to alphabet and alphabet to number
numberic
Type numbers
alphabet
Type alphabet and symbols
FNC + button
Description
ESC
Cancel the selected order, program action and status
3, 9
Page UP/DOWN key
2,4,6,8
UP, DOWN, LEFT, RIGHT sdie key
7
Tap key
*, 0, #
+, 000, - key
