Atlantic Technology lcr2 User manual

LCR2
Compact High Performance Loudspeaker
Specications for the LCR2
Type Sealed-box, 2-way
Drivers: Woofers (1) 31/2˝ CPP
Tweeter (1) 3/4˝ silk dome tweeter
Frequency Response 115Hz - 20kHz (± 3dB)
Nominal Impedance 6 ohms
Crossover Frequency 3.5kHz
Sensitivity 87dB
Recommended Amplier Power 10-125 Watts
Dimensions 43/4˝ x 8˝x 5˝ (120mm x 204mm x 127mm) w/grille
Weight (each, unpacked) 3.22 lbs; 1.4kg
Specications are those in effect at the ti e of printing. Atlantic Technology reserves the right to change specications or
appearance at any ti e without notice.
Dolby Digital, AC-3, 5.1, Dolby Stereo and Dolby Pro Logic are trade arks of Dolby Laboratories Licensing Corporation.
DTS is a registered trade ark of DTS Inc.
343 anderbilt Avenue Norwood, MA 02062
[phone]
www.atlantictechnology.com

LCR2
Compact High Performance
Loudspeaker
Thank you for choosing Atlantic Technology home
theater products. Your new speaker system is precision
craed to give you years of enjoyable, trouble free serv-
ice. is manual covers the Atlantic Technology LCR2.
e LCR2 is a versatile loudspeaker that can be used in
any position in a home theater such as a le or right
channel or a center channel or even a surround channel.
Each LCR2 consists of a low resonance DF cabinet,
3.5˝ CPP driver, 3/4˝ silk dome tweeter and high quality
crossover components. e LCR2 is designed for use
with all surround formats such as Dolby Digital, DTS or
Dolby Atmos.
Positioning the LCR2 as a Front,
Center or Surround Channe Speaker
We recommend placing the LCR2 with the tweeters
facing upward. Set the receiver bass management or
speaker size to “small” and the crossover to 100Hz.
Alternatively, if you have limited room you can use the
LCR2 horizontal positioned just like a center channel.
We have included four 4mm rubber feet in each accessory
bag to mount to the bottom of the cabinet depending on
how you choose to place the speaker.
Connecting Your System
We recommend that you connect your LCR2 speaker
systems with high quality dual conductor stranded wire
of 18 gauge or larger, for lengths up to 25 feet. Use 16
gauge dual conductor or larger for longer runs of wire.
Contact your local audio/video specialist for specic
cable recommendations and further information for
special circumstances.
Warning: To prevent risk of electrical shock or da age
to your equip ent, always switch off the a plier or
receiver when aking connections to the speaker.
You can connect your LCR2 speakers by using a variety
of audio connectors, or you can:
Strip about 1/2˝ (13mm) of insulation from the connect-
ing wires. Connect them to the appropriate push termi-
nal, being careful to observe polarity (positive to the red
terminal, negative to the black terminal).
Whether you are connecting a complete LCR2 system,
or adding a single speaker component to your present
system, the wiring should look like the diagram in Fig-
ure 2.
Figure 2: Typical wiring diagra for speakers in a ho e theater.
Figure 1: Gold plated spring posts. Accepts up to 14 gauge bare wire.
Warning: Before turning on the a plier, be certain that no
stray wire strands are touching across the two ter inals as this
ight da age your a plier.
Finally, check the polarity of your front speakers by listening to some music.
If the sound seems hollow, unusually spread out, or has weak bass, recheck
your connections for proper polarity. If necessary, reverse any out of phase
connections. Only one speaker wired out of phase is usually the culprit.

P acement and Operation
Speaker/room interactions have a huge impact on the sound of the system.
oving the speakers just a little bit can make a dramatic difference in what you
hear. e ultra-compact design of LCR2 provides you with maximum placement
exibility while creating a large, seamless, acoustically accurate soundeld for your
home theater or music system. e best placement of the speakers will vary from
room to room. Use the following placement guidelines and Figure 3 as a starting
point. But also feel free to experiment. In fact, it may be benecial to hook up the
speakers with some extra wire and to simply drape the wire across the oor before
installing the speakers permanently. is will allow you the opportunity to move
the speakers around easily so you can nd the best sonic and visual locations.
Typical arrange ent for speakers in a ho e theater. For best results, place the sur-
round speakers within the shaded area. Note that the surround speakers are arked
Le and Right. It is i portant that the speakers be placed correctly for proper i aging.
Mounting
e LCR2 speakers can be mounted
in a variety of ways:
On speaker stands:
We recommend speaker stands with
an approximate height of 29˝ above
the oor. Ideally the tweeter of the
speaker should be at ear level when
seated.
On the wa :
To mount your speakers on a wall,
we have installed metal key-hole
brackets on the back of the LCR2
speakers. Be sure to use a strong
screw whose head and sha will t
within the keyhole opening and
slot. Also be sure to drive the screw well into a stud or use a mounting device (such
as a molly-bolt) that is capable of holding the weight of the speaker. Never simply
drive a nail or screw into a sheet rock or other wall materials. Always follow the
above guidelines for safe speaker mounting.
On a bookshe f:
Adhesive rubber feet are included.
Listening Leve s and Power
Hand ing – IMPORTANT!
e power recommendation for these speaker
components assumes that you will not operate
your amplier/receiver in a way that produces
distortion. Even rugged speakers like LCR2 can
be damaged by a moderately powered system
driven beyond its intended capacity. e harsh
amplier clipping that occurs in this situation will
cause damage to the speaker system. is type of
damage is easily identiable through examination
of the damaged speaker’s voice coil and is not cov-
ered by the warranty. e LCR2 will play very
loudly when provided with enough clean power
to do so. Again, consult your dealer or Atlantic
Technology for additional information.
Care and Feeding of Your Speakers
Clean your speaker cabinets using a so cloth
moistened with a mild, non-abrasive glass cleaner
being careful not to wet the edges of the cabinet.
Also, be careful not to get any cleaning uids on
the driver cones or domes. It may be best to
dampen the cloth with the cleaner and then wipe
the speakers. Use a so cloth, but do not use any
paper products, because no matter how so they
may feel, they will scratch the nish. Aer care-
fully removing the grilles from the speakers, clean
them with a quick pass from a vacuum cleaner
with a brush attachment. is should remove any
dust accumulation. Avoid placing your speakers
in direct sunlight or near a source of heat that
may, over time, damage the nish.
Important: Save Your Boxes!
If possible, save the cartons, packing pieces,
and plastic bags that ca e with your speak-
ers. ey will be useful in case you ove or
have to ship your loudspeakers for any rea-
son. In any case, save all packing aterials
until you are certain that the syste s have
suffered no da age in ship ent. If you nd
such da age, either visible or internal, con-
tact your dealer i ediately for the proper
return procedure.
Figure 3

Warranty
ank you for purchasing an Atlantic Technology product. We wish you
many years of enjoyment and satisfaction from it. You do not need to send
in anything to be covered by the Limited Warranty. All you need to do is
keep your original Invoice or Bill of Sale for proof of purchase, meet the
stated requirements, and follow the instructions listed within the Warranty.
Please attach your Original Invoice or Bill of Sale to this manual as proof
of purchase and keep them in a safe place.
ERY IMPORTANT NOTE: PLEASE NOTE THAT ATLANTIC TECH-
NOLOGY PRODUCTS CARRY ONLY A 90 DAY LI ITED WAR-
RANTY. YOU UST EET ALL THE FOLLOWING REQUIRE ENTS
AND REGISTER ONLINE IN ORDER TO BE COVERED BY THE FREE
EXTENDED SERVICE AGREE ENT TO ASSURE EXTENDED FREE
PROTECTION!!
Free Extended Service Agreement
Atlantic Technology offers a free Extended Service Agreement that provides
enhanced protection against product defects. In order to qualify for the free
Extended Service Agreement you must:
1. Have purchased your Atlantic Technology products from an Authorized
Atlantic Technology Reseller or Installer.
2. Go to www.atlantictechnology.com and click on Support>Register Your
Warranty. Fill out the required information. Be sure to have your home ad-
dress, name, address and invoice from the business you purchased, and the
serial numbers of all Atlantic Technology products purchased. THIS MUST
BE DONE WITHIN 30 DAYS OF PURCHASE.
If you purchased multiple Atlantic Technology products you will be able
to enter them all using one online form. odel and Serial numbers can be
found on the back of each unit and on the outside of their respective boxes.
Once all the criteria have been met, you qualify for a free Extended Service
Agreement that entitles you to additional coverage against defects in work-
manship and manufacturing for a period of up to 5 years on nonpowered
product and up to 1 year on powered product. is coverage is in addition
to the 90 Day Limited Warranty included with all Atlantic Technology
products.
If you are not able to register your product using the internet, please call
customer service at 781.762.6300.
Limited Warranty
Statement of Warranty: Atlantic Technology International Corp. warrants
Atlantic Technology Products to be free from defects in material and work-
manship for 90 days from the time of original purchase. is Warranty cov-
ers the original retail purchaser of this product only and is valid only in the
Continental United States, Alaska, and Hawaii and all US Possessions.
Extended Service Agreement (only available in the Continental United
States, Alaska, and Hawaii and all US Possessions): You must Register your
Warranty online, and have purchased your product(s) from an authorized
Atlantic Technology reseller to receive the Extended Service that covers your
Atlantic Technology products beyond the standard 90 day Warranty.
To obtain Warranty service: Please contact your local Atlantic Technology
reseller to determine if they are an Authorized Repair Center for Atlantic
Technology products. You will need your original Invoice or Bill of Sale to
prove Warranty eligibility. If your local dealer is not an Authorized War-
ranty Center you may contact us at 781-762-6300 for further help or to send
the product to us for service and repair. You must rst request a Return Au-
thorization Number from us to ship the product back, so it is imperative
that you call us rst.
What we are responsible for: We will pay for all labor and parts for covered
items. If the repairs are eligible for coverage under the terms of this Warranty
we will also pay for return shipping charges to you.
What you are responsible for: You must pack the product properly for
safe shipping to your Authorized Dealer or us. You are responsible to pay
for all packing, shipping, and insurance costs to get the unit(s) back to At-
lantic Technology or your Authorized Dealer.
Optional replacement: We, at our option, may replace rather than repair
your Atlantic Technology product with a new or reconditioned one of the
same or similar design. e repair or replacement will be warranted for 90
days from date of receipt back to you. All details in terms of eligibility for
an Extended Service Agreement will carry over from the original purchase
to the replacement item.
What this Warranty does not cover: is Warranty does not cover defects
resulting from accidents, damage while in transit, alterations, unauthorized
repair, failure to follow instructions, misuse, re, ood, and Acts of God.
is Warranty will be void if the product’s serial number has been altered
or removed or if the product has been modied or defaced.
Exclusions and Limitations: Implied warranties, including those of tness
for a particular purpose and merchantability (an unwritten warranty that
the product is t for ordinary use) are limited to the period of any Warranty
granted hereby. We will not pay for loss of time, inconvenience, loss of use,
or property damage caused by your Atlantic Technology product or its fail-
ure to work, or any other incidental or consequential damages.
State law rights: Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion
may not apply to you. is Warranty gives you specic legal rights, and you
may have other rights which vary from state to state.
is Warranty is valid only when Atlantic Technology products are pur-
chased from an Authorized Atlantic Technology Reseller in the Continental
United States, Alaska, and Hawaii and all US Possessions. If you purchase
Atlantic Technology products outside the United States please consult your
local distributor or reseller for applicable Warranty coverage and restric-
tions.
Should you have any questions or problems please feel free to contact us
at 781-762-6300 or through our web site, www.atlantictechnology.com.
343 anderbilt Avenue Norwood, MA 02062
[phone]
www.atlantictechnology.com
For Future Reference
Record your serial numbers and date of purchase here:
odel Number _____________________________________
Serial Number ______________________________________
Date of Purchase _____________________________________
e serial number is found on the back panel.
Copyright ©2016 Atlantic Technology International.
Specications are those in effect at the ti e of printing.
Atlantic Technology reserves the right to change specications
or designs at any ti e without notice.
