Atlantic MULTI ELEC User manual

MULTI ELEC
Electric Boilers
TECHNICAL MANUAL
PO Box 11 Ashton Under Lyne OL67TR
+44. (0) 161 621 5960 Fax [phone]
[e-mail]
www.atlanticboilers.com

2

3
CONTENTS
DESCRIPTION………….………………………………...……………………………………1
PERFORMANCE………………………………………………………………………………
SCHEMATIC………………………………………………………………………………….…
CONTROL PANEL DIAGRAM
COMMAND ELECTRIC DIAGRAM…………………..……………….……………………5
POWER ELECTRIC DIAGRAM…………………….……………………………….………
FUSES…………………………………………………………………………………………..
CONTROL PANEL + REGULATION………………………………………………………..
INSTALLATION……………………………………………………………………………….10
STARTING THE BOILER…………………………………………………..……………………….…….
.
SERVICING…………………………………………………………………………………….11
THE COMMISSIONING OF THE MULTI-ELEC……………………………………………27
THE GUARANTEE ON THE MULTI-ELEC……………………………………………….32
4
5
6
8
9
10
11
12
14
15
16
17
18

BOI
LER
CONTROL PANEL
- 1 waterproof control panel mounted on the boiler including:
- 1 main switch
- 3 industrial cylinder cartridge fuse per stage
- 3 contactors ( 1 per stage )
- 1 protected transformator 415 / 240 V
- 1 light « operation »
- 1 light « lock out »
( circulation and safety thermostat )
- 1 digital régulation
- Terminals for external connections
-Output from 36 to 630 kW
- Boiler body in welded steel E 24
- Working pressure 4 bars
- Test pressure 6 bars
- Working temperature below 110°C
- 50mm thick mineral fibre insulation, polyester film
aluminized glass cloth
- Safety thermostat with manual reset 110°C
- Internal expansion vessel
INCOLOY IMMERSION HEATERS

For boiler output between 36 and 288 kW
- Screwed elements diam.40
- Power of each unit: 12 kW
- 240/415Volts 3 phase + earth
- Removal of the immersion heaters: minimum
height of 2 m.
.

For boiler output between 315 and 630 kW
- Screwed elements diam.80
- Power of each unit : 35 kW
- R=1MΩ
- 415 Volts 3 phase + earth
- Removal of the immersion heaters: m
inimum height
of 2.5 m.
- Résistance d’isolement à froid à 1 mégohm
DESCRIPTION
The “Multi Elec” electric boilers have been designed for any heating system (maximum
working pressure 4 Bars)
They are Class 1 boilers that required earth connections IP21 / IK 08

PERFORMANCE, DIMENSIONS & CONNECTIONS
OUTPUT No.of elements kW per element Boiler dimensions Volume Flow rate l/s Pressure
drop
max flow
rate kPA
Ø
AD E F Boiler
dry
weight
kg
Overall
dimensions
kW Foot
print Height Litres Min Maxi H x L x P
90 3 30
520 1330 128
0.6 5.0 0.8 DN
80
235 920 180
117
1200x600x3
00
120 4 30 0.9 5.0 0.8 DN
80 121
150 5 30 0.9 9.7 2.8 DN
80 125
180 6 30 1.1 9.7 2.8 DN
80 129
210 6 35
670 1520 283
1.7 12.0 1.6 DN
100
255 1075 180
233
1400x800x3
00
245 7 35 1.7 12.0 1.6 DN
100 238
280 8 35 1.7 12.0 1.6 DN
100
243
315 9 35 1.7 12.0 1.6 DN
100 248
350 10 35 2.2 12.0 1.6 DN
100 253
1600x1000x
400
385 11 35 2.2 12.0 1.6 DN
100 258
420 12 35 2.2 12.0 1.6 DN
100 263
455 13 35
770 1520 395
2.8 26.0 1.6 DN
150
280 1020 180
340
1800x1000x
400
490 14 35 2.8 26.0 1.6 DN
150 345
525 15 35 2.8 26.0 1.6 DN
150
350
560 16 35 2.8 26.0 1.6 DN
150 355
595 17 35 3.6 26.0 1.6 DN
150 360
630 18 35 3.6 26.0 1.6 DN
150 365
Standard door opening -
A - to right
Optional door opening -
B
-
to left
Return
Drain
Control panel housing
Drain

OPTIONAL ACCESSORIES
SHUNT PUMP with contact relay and run/lock-out lamps
MOUNTING PACK with automatic air release, water flow switch, drain
ball valve, safety relief valve and temperature & pressure relief valve
Automatic air release
Two relief valves
Water flow switches
Drain ball valve

7
SCHEMATIC
1) Conventional Pipework
2) Weather compensated Pipework
3) Weather compensated pipework
Radiators or
under
-
floor heating

8
4) Heating and hot water pipework
NB: Boiler pump flow should be 5% superior to the sum of heating and DHW primary
pump
expansion
vessel
pressure &
temperature relief
valve
3 port valve
auto air
vent
pump
non return
valve
Fill loop
pressure relief
valve
isolating ball valve
Radiators

MAINS POWER
400V, THREE PHASES +
EARTH (NO NEUTRAL )
EARTH
MAIN SWITCH
TS
Fuses
COPPER PLATE
TERMINAL
TRANSFO
415/240V
Ka1
Terminal
FLEXIBLE
ISOLATED
COPPER LINKS
FAN
(from 216 kW)
Km3 Km2 Km1
CONTROL PANEL DIAGRAM

VIEW OF THE CONTROL PANEL

11
COMMAND ELECTRIC DIAGRAM
Lockout
Power
Lockout
415 Volts
3Phases supply
415/240
Fan
Sensor
Digital
Regulation
Fan V from 216 kW
F1-F2-F3 and Transfowill vary
according to boiler output
Limit Stat
Flow switch
Pump lockout
Other lockouts
Enable
Lockout signal
Green
Red
S1: Power Switch
I 1: Controller Switch
T1: 30s delay
T2: 1min delay
T3: 2min delay
Earth
: Green/Yellow 4mm²
Wires 0 to 6 : Red 1mm²
Wire 9 : Black 1mm²
Other wires : Brown 1mm²

BOILER ELECTRICAL OUTPUT
Output per step control
Output Step 1 Step 2 Step 3
90 kW 30 30 30
120 kW 60 30 30
150 kW 60 60 30
180 kW 60 60 60
210 kW 70 70 70
245 kW 105 70 70
280 kW 105 105 70
315 kW 105 105 105
350 kW 140 105 105
385 kW 140 140 105
420 kW 140 140 140
455 kW 175 140 140
490 kW 175 175 140
525 kW 175 175 175
560 kW 210 175 175
595 kW 210 210 175
630 kW 210 210 210

13
BOILER ELECTRICAL PROTECTION
Selection of fuses
Fuses F1, F2 & F3 - cartridge size 8.5 x 31.5
90kW to 280kW
F1 - 1A type aM F2 - 1A type gG F3 - 0.5A type gG
315kW to 630kW
F1 - 1A type aM F2 - 2A type gG F3 - 0.5A type gG
Fuses F4, F5 & F6
Cartridge size 22 x 58 - 63A type gG
Miniature circuit breakers
output - 0 - 125A type gG
output - 1 - 160A type gG
output - 2 - 250, 315 & 400A type gG
Selection of FUSES or CIRCUIT BREAKERS
Boiler
output F4 F5 F6 Boiler output F4 F5 F6
90 kW 63 A 63 A 63 A 385 kW 250 A 250 A 160 A
120 kW 125 A 63 A 63 A 420 kW 250 A 250 A 250 A
150 kW 125 A 125 A 63 A 455 kW 315 A 250 A 250 A
180 kW 125 A 125 A 125 A 490 kW 315 A 315 A 250 A
210 kW 125 A 125 A 125 A 525 kW 315 A 315 A 315 A
245 kW 160 A 125 A 125 A 560 kW 400 A 315 A 315 A
280 kW 160 A 160 A 125 A 595 kW 400 A 400 A 315 A
315 kW 160 A 160 A 160 A 630 kW 400 A 400 A 400 A
350 kW 250 A 160 A 160 A

14
CONTROL PANEL + REGULATION
CONTROL PANEL
REGULATION
FRONT
BACK
Factory Settings
(Heating Circuit)
Set Point Temperature
:
80°C
77°C
74°C
Stage 1
Stage 2
Stage 3
Maximum Temperature :
95°C
Minimum Temperature : 20°C
Delay T1 : 30 secondes
Delay T2 : 1 minute
Delay T3 : 2 minutes
Safety Thermostat : 110°C
Power On
Off
Lockout
Boiler
temperature
Set
Point
Stages
1 = Stage1
2 =Stage2
5 =Stage3
Stage3
Stage1
Stage2
240V
Sensor
White
Red
Red

Change the set point

Increase the set point temperature: Press the key


Decrease the set point temperature: Press the key 
Never press the
PGM
and
EXIT
keys
For other settings, please contact Atlantic.
Information on the control panel
1.
2.
3.
Identification number plate on the control panel
The maximum acceptable current is Icw = 23 kA.
Only authorised person should have acccess to the contrl panel
4.
5.
Connection to earth is compulsory. (Class 1)
After commissioning (8 days) :
A/ Check the immersions heaters tightness
B/ Check the power circuit connections tightness
For information, advised tightness of the bolts:
M6
M8
M10

1,3
m
.daN
 2,8 m.daN
 5 m.daN
Check the tightness annually.
6.
Factory test
Regulation
Isolation of the power circuit
7. The boiler and the control panel should not been installe din a corrosive atmosphere or outside.
8. Ventilation (Natural convection or fan)
Leave enough space to allow air circulation. . Do not obstruct the fan and the grid.

INSTALLATION
The “multi-elec” electric boiler should be installed in a louvered plantroom in order to
ensure an ambient temperature below 30ºC and relative humidity between 30 and 80%.
The boiler should not be used in a corrosive atmosphere or in an external position.
Adequate access should be left around the boiler in order to carry out maintenance.
The following safety devices are obligatory:
Safety valve (4 Bars maximum)
An automatic air vent on the boiler flow
A blow down valve
Electrical wiring
The“multi-elec” electric boiler should be connected to 415V without neutral
The circuit breaker and the cables section should be chosen according to British
standards.
Class 1 material IP21 / IK08
If the boiler is powered without any water, it will generate the thermocouple failure (no
warrantee)
Transport and storage
The unit should be transported and stored in the original package until it reached the
installation point.
Ambiant temperature below 80ºC
Relative humidity between 30 and 80%

STARTING THE BOILER
Remove the power fuses
Check that the boiler is filled with water
Check that the immersion heaters are sound. If isolation is below 2MΏ, please
find the reason and remdy it.
Turn the power on using the main switch and the key switch
Check that the circulation pump is running.
Check that there is a lockout if the circulations pump stops
Adjust the temperature settings
Stop the boiler using the main switch
Put the power fuse in
Switch the boiler back on
Check the immersion heaters electrically for faults. Tight all the connections up
after one week of operation
If the boiler is powered without any water, it will cause the immersion heaters or
sensors to fail (no warranty)

SERVICING
Loss of water velocity through the boiler can lead to temperature rise
Consider a sediment vessel on the return to capture sediment deposit
Blocking immersion heaters irrigation can destroy them
NOTE : The immersion heaters can be destroyed by blockage of the water flow
It is essential that a periodical cleaning is carried out on the main heat exchanger and the
sensors. The water also needs to be clean without any antifreeze or scale remover product
Removal of sludge and sediment reduce corrosion risks
On first start:
Check the electrical operation
Check each terminal to avoid any contact resistance or temperature rise
Activate the safety valve manually
Monthly servicing
Check
The automatic air vent
The safety valve
Biannual servicing
Check each terminal to avoid any contact resistance or temperature rise

19
THE COMMISSIONING OF THE ATLANTIC MULTI ELEC
All Atlantic boilers and water heaters are thoroughly tested for mechanical, electrical and
combustion performance at the factory
The prime object of the site commissioning of the boiler(s) is, subject to installed
conditions, to match the optimum combustion performance results reached at the factory
and to ensure the boiler(s) is/are installed according to the conditions of guarantee.
The following check list should be satisfied before the commissioning takes place. To
arrange the commissioning Atlantic should be given a minimum of ten days notice of the
date and time required.
Commissioning sheet

THE GUARANTEE ON THE ATLANTIC MULTI ELEC
This guarantee is to the purchaser of the boiler(s) who is deemed to be the installer. If the
boiler(s) is (are) purchased by the eventual user who then arranges to install the boiler(s),
the eventual user is deemed to be the installer. The details of the guarantee are given to
assist the installer in obtaining effective action within the guarantee and they are in
addition to the installer’s legal rights under the relevant statutory enactments for the time
being in force in England, Wales, and Scotland.
Electrical equipment:
The replacement or repair of the item, including the cost of its delivery to the site of the
installation or its equal within England, Wales and Scotland, provided that the defect or
flaw occurs within 1 calendar year of the commissioning date.
Removable component of the boiler assembly (other than the electrical equipment)
The replacement or repair of the item, including the cost of its delivery to the site of the
installation or its equal within England Wales and Scotland if the defect or flaw occurs
within 1 calendar year of the commissioning date.
The main body of the boiler.
The repair of any welding defects in the main body of the water heater including any
necessary removal or replacement of that part of the water heater on site if the defect
occurs within 3 calendar years of the commissioning date.
Definitions:
The effective actions stipulated in this guarantee are subject to the purchaser complying
completely with the following:
1) The boilers are installed according to the recommendations of this technical
booklet, the recommended codes of practice of the C.I.B.S.E and the B.S.I., and
the checklist on page 13 is satisfied.
2) The commissioning of the boilers by ACM Atlantic and their regular annual
servicing and maintenance.
3) The payment in full, by the purchaser unless otherwise agreed, of the invoice for
the supply and delivery of the boiler(s) to site, any other relevant invoices
connected with the boiler positioning and fixing, and the invoices for
commissioning and any correction of installation error, all to be made within one
calendar month of the date of the invoice.
4) The presentation, at the time of a claim under the guarantee, of the boiler
registration number, the commissioning record with date, and the necessary
information for defining any replacement part.
5) When a replacement item is supplied for a defective item, the defective item must
be returned to ACM Atlantic at their registered office within 6 weeks of the date
of notification of the defect carefully labeled with registration number of the
boiler and the name and the order reference of the purchaser of the boiler. If this
is not complied with, the purchaser will be charged with the cost of the item and
its delivery.
