Atlas Copco TEX 419 User manual

19245-9983-61 BARREL 3”
29245-9963-10 LOCK RING BUMPER
39245-9963-30 PISTON 3”
49245-9983-64 FULCRUM PIN
59245-9963-60 BUMPER VALVE SEAT
69245-9983-65 VALVE SPACER
79245-9963-50 VALVE PLATE
89245-9964-25VALVE DOWEL (2)
99245-9983-67 PUSH PIN
10 9245-9967-00 PUSH PIN BUSHING
11 9245-9983-68 HANDLE BARE
NS 9245-9983-69 HANDLE COMPLETE
13 9245-9964-80 THROTTLE VALVE BALL
15 9245-9965-40 THROTTLE VALVE PLUG
16 9245-9965-30 THROTTLE VALVE SPRING
17 9245-9966-20 TRIGGER
18 9245-9983-70 FLANGE
19 9245-9983-71 HANDLE BOLT ( 4 )
19B9245-9983-72 SPRING WASHER ( 4 )
20 9245-9983-73 BUMPER WASHER ( 4 )
22 9245-9983-74 HANDLE BOLT SPACER ( 4 )
23 9245-9983-75 HANDLE BOLT NUT ( 4 )
25 9245-9964-40 EXHAUST DEFLECTOR (2pc)
28 9247-9853-50 OVAL COLLAR RETAINER
34 9245-9964-90 RETAINER SPRING
35 9245-9965-00 SWIVEL(7/8 - 24, 1/2” HOSE BARB)
36 9245-9965-20 HANDLE BUSHING
44 9245-9965-80 BUSHING FOR ROUND SHANK (.680”)
44 9245-9965-90 BUSHING FOR HEX SHANK (.580”)
CHIPPING HAMMER TEX 319
INDEX PART DESCRIPTION
1
2
3
8
5
6
7
9
10
13
11
17
4
15
16
19B
36
19
35
25
44
18
20
22
23
28
34

Notes:
1: Nylon locking rings(2) must be
replaced each time the handle is
removed.
2: Add 5ml of oil into the air inlet,
twice per shift. See table for
recommended lubricants.
Atlas Copco TEX 419
See
Note #1,
Below
See Note #2, Below
Safety Warnings—Symbols in these Instructions
Pay special attention to sections in these documents dealing with safety.
If you see either of these symbols:
WARNING! A danger, or hazardous procedure which CAN lead to
serious injury, or worse.
CAUTION A risk, or risky procedure which CAN lead to injury, or
damage to the tool.
!
!
Before Starting
Make sure you have:
 the correct hose size and length.
 checked for damage to air line and
couplings.
 all air connectons correctly
tightened.
 the correct operating pressure
(max 100 psi). Higher pressure
can be dangerous and damage the
tool.
 blown the air line clean.
 oiled the hammer.
 a steel with a round collar and
the correct shank size.
 checked that the steel is securely
latched. Repair any tool with poor
retention.
 use proper safety gear: boots,
helmet, gloves and ear protection
are the minimum.
General Safety Rules
 Before using the tool, read through these instructions carefully.
 Also read the Red Safety Instructions thoroughly.
 For your safety, the tool must not be modified.
 Use approved personal safety equipment.
 Use Atlas Copco Genuine Parts only.
 Always replace worn or damaged warning stickers.
Lubricant Temperature
range ºC
Viscosity grade
Synthetic
AIR-OIL
-30 to +50 ISO VG 46-100
Mineral Oil -20 to +15 ISO VG 32-46
Mineral Oil +15 to +35 ISO VG 46-100
Recommended lubricants

Specifications -TEX 318
Net Weight 6.4 kg 18 lbs
Length 387 mm 15.25 in
Bore 29 mm 1.125 in
Stroke 102 mm 3 in
Blows per minute 2200 2200
Chuck Sizes 14.8 mm Hex .580 in Hex
17.5 mm Rnd .680 in Rnd
Air Inlet (NPT) 10 mm 3/8 in
Air Consumption* .89 m3/m 31.5 cfm
Atlas Copco TEX 319
Operation
Make sure you have:
 steels sharpened correctly for the job.
 correct posture, feet spread and away from the working
end of the tool.
 both hands clear of the steel, especially when using the
tool in an elevated position.
 the steel in contact with the work surface before
pressing the trigger.
 blank-firing will cause premature retainer wear.
 follow local laws and safety procedures.
Optional Equipment
The following optional equipment is available from Atlas
Copco:
 MANTEX lightweight airhose
 VAM water separators
 Steel Accessories
Maintenance
For best results and security:
 always check that hammer is disconnected from the air hose before removing steel
 clean and inspect hammer every 3 months.
 always keep the hammer well lubricated during work and storage.
 flush the hammer with paraffine-based lubricant before long-term storage. Follow with a normal lubrication and a
short period of operation. Always store in a dry place.
