Congratulations on acquiring the AVR® AT90USBKey. This kit is designed to give
designers a quick start to develop code on the AVR® and for prototyping and testing of
new designs with the AT90USB microcontroller family.
1.1 Overview
This document describes the AT90USBKey dedicated to the AT90USB AVR
microcontroller. This board is designed to allow an easy evaluation of the product using
demonstration software.
To increase its demonstrative capabilities, this stand alone board has numerous on-
board resources: USB, joystick, data-flash and temperature sensor.
Figure 1-1 . AT90USBKey

Introduction
1-4 AT90USBKey Hardware User Guide
7627A–AVR–04/06
1.2 AT90USBKey Features
The AT90USBKey provides the following features:
 AT90USB QFN64
 AVR Studio® software interface (1)
 USB software interface for Device Firmware Upgrade (DFU bootloader) (2)
 Power supply flagged by “VCC-ON” LED:
– regulated 3.3V
– from an external battery connector (for reduced host or OTG operation)
– from the USB interface (USB device bus powered application)
 JTAG interface (connector not mounted):
– for on-chip ISP
– for on-chip debugging using JTAG ICE
 Serial interfaces:
– 1 USB full/low speed device/host/OTG interface
 On-board resources:
– 4+1-ways joystick
– 2 Bi-Color LEDs
– temperature sensor
– serial dataflash memories
– all microcontroller I/O ports access on 2x8pin headers (not mounted)
 On-board RESET button
 On-board HWB button to force bootloader section execution at reset.
 System clock:
– 8 MHz crystal
Notes: 1. The AVRUSBKey is supported by AVR Studio®, version 4.12 or higher. For up-to-
date information on this and other AVR tool products, please consult our web site.
The most recent version of AVR Studio®, AVR tools and this User Guide can be
found in the AVR section of the Atmel web site, http://www.atmel.com.
2. ATMEL Flip®, In System Programming Version 3 or Higher shall be used for Device
Firmware Upgrade. Please consult Atmel web site to retrieve the latex version of Flip
and the DFU bootloader Hex file if needed.

AT90USBKey Hardware User Guide 2-5
7627A–AVR–04/06
Section 2
Using the AT90USBKey
This chapter describes the AVRUSBKey and all its resources.
2.1 Overview
Figure 2-1 . AT90USBKey Overview

Using the AT90USBKey
2-6 AT90USBKey Hardware User Guide
7627A–AVR–04/06
2.2 Power Supply
2.2.1 Power Supply Sources
The on-board power supply circuitry allows two power supply configurations:
 from USB connector
 from battery connector
USB powered When used as a USB device bus powered application, the AVRUSBKey can be directly
powered via the USB VBUS power supply line.
Battery powered The external battery connector should be used when the AT90USBKey is used as a
USB host. This mode allows the AT90USBKey to provide a 5V power supply from its
VBUS pin.
– Need of a female battery clip
– Input supply from 8 up to 15V DC (min. 100mA)
Figure 2-2 . Power supply schematic
VCC3
IN
1
GND
2OUT 3
U5
LM340
VBUS
VBAT
D4
LL4148
-
C16
4.7uF
R19
124k 1%
U3out=1.25*(1+(R15+R18)/R19)
R18100k 1%
D3
LL4148
C17
220nF
VCC3
5V
R15
100k 1%
MTA
Ext power supply
1
2
J8
C18
100nF
OUT 1 IN
2
GND
3
OUT 4
FAULT 8
SHDN
7
CC 6
SET 5
U4
LP3982 C15
33nF
D6
LL4148

Using the AT90USBKey
AT90USBKey Hardware User Guide 2-7
7627A–AVR–04/06
2.2.2 VBUS Generator
When using the AT90USB microcontroller in USB host mode, the AT90USBKey should
provide a 5V power supply over the VBUS pin of its USB mini AB connector.
A couple of transistors allows the UVCON pin of the AT90USB to control the VBUS
generation (See Figure 2-3). In this mode the AT90USBKey is powered by external
battery power supply source.
Figure 2-3 . VBUS generator schematic
2.2.3 “POWER-ON“ LED
The POWER-ON LED (“D1”) is always lit when power is applied to AVRUSBKey
regardless of the power supply source.
R25
100k
Q1
BC847B -
C19
4.7uF
R24
10k M1
FDV304P/FAI
UVCON
VBUS
5V

Using the AT90USBKey
2-8 AT90USBKey Hardware User Guide
7627A–AVR–04/06
2.3 Reset
Although the AT90USB has its on-chip RESET circuitry (c.f. AT90USB Datasheet,
section “System Control and Reset), the AVRUSBKey provides to the AT90USB a
RESET signal witch can come from two different sources:
Figure 2-4 . Reset Implementation
2.3.1 Power-on RESET
The on-board RC network acts as power-on RESET.
2.3.2 RESET Push Button
By pressing the RESET push button on the AVRUSBKey, a warm RESET of the
AT90USB is performed.
2.3.3 Main Clock XTAL
To use the USB interface of the AT90USB, the clock source should always be a crystal
or external clock oscillator (the internal 8MHz RC oscillator can not be used to operate
with the USB interface). Only the following crystal frequency allows proper USB
operations: 2MHz, 4MHz, 6MHz, 8MHz, 12MHz, 16MHz. The AT90USBKey comes with
a default 8MHz crystal oscillator.
RST
VCC
R6
47k C8
220nF RESET

Using the AT90USBKey
AT90USBKey Hardware User Guide 2-9
7627A–AVR–04/06
2.4 On-board Resources
2.4.1 USB
The AVRUSBKey is supplied with a standard USB mini A-B receptacle. The mini AB
receptacle allows to connect both a mini A plug or a mini B plug connectors.
Figure 2-5 . USB mini A-B Receptacle
When connected to a mini B plug, the AT90USB operates as an “USB device” (the ID
pin of the plug is unconnected) and when connected to a mini A plug, the AT90USB
operates as a “USB host” (the ID pin of the A plug is tied to ground).
2.4.2 Joystick
The 4+1 ways joystick offers an easy user interface implementation for a USB
application (it can emulate mouse movements, keyboard inputs...).
Pushing the push-button causes the corresponding signal to be pulled low, while
releasing (not pressed) causes an H.Z state on the signal. The user must enable
internal pull-ups on the microcontroller input pins, removing the need for an external
pull-up resistors on the push-button.
Figure 2-6 . Joystick Schematic
C7
1uF
VBUS
R4 0
GND
VBUS
1-V_BUS
3-D+
2-D-
4-ID
5-GND
SHIELDSHIELDSHIELDSHIELD
USB_MiniAB
J3 VBUS
VBUS
GND
R3 22
R2 22
D+
D-
UID
CR1 CR2
UCAP
Select 5
Left 7
Up 3
Right 6
Down 4
Com1
1
Com2
2
SW3
TPA511G
PE[7..0]
PB[7..0]
PB5
PB6
PB7
PE4
PE5
Select 5
Left 7
Up 3
Right 6
Down 4
Com1
1
Com2
2
SW3
TPA511G
PE[7..0]
PB[7..0]
PB5
PB6
PB7
PE4
PE5
Select 5
Left 7
Up 3
Right 6
Down 4
Com1
1
Com2
2
SW3
TPA511G
PE[7..0]
PB[7..0]
PB5
PB6
PB7
PE4
PE5

Using the AT90USBKey
2-10 AT90USBKey Hardware User Guide
7627A–AVR–04/06
2.4.3 LEDs
The AT90USBKey includes 2 bi-color LEDs (green/red) implemented on one line. They
are connected to the high nibble of “Port D” of AT90USB (PORTD[4..7]).
To light on a LED, the corresponding port pin must drive a high level. To light off a LED,
the corresponding port pin must drive a low level.
Figure 2-7 . LEDs Implementation schematic
Table 2-1 . Leds references
2.4.4 Temperature Sensor
The temperature sensor uses a thermistor (R29), or temperature-sensitive resistor. This
thermistor have a negative temperature coefficient (NTC), meaning the resistance goes
up as temperature goes down. Of all passive temperature measurement sensors,
thermistors have the highest sensitivity (resistance change per degree of temperature
change). Thermistors do not have a linear temperature/resistance curve.
The voltage over the NTC can be found using the A/D converter (connected to channel
0). See the AT90USB Datasheet for how to use the ADC. The thermistor value (RT) is
calculate with the following expression:
Where: RT= Thermistor value (Ω) at Ttemperature (°Kelvin)
RH= Second resistor of the bridge -100 KΩ±10% at 25°C
VADC0 = Voltage value on ADC-0 input (V)
VCC = Board power supply
LED Reference AT90USB Connection Color
D2 PORTD.4 Red
PORTD.5 Green
D5 PORTD.6 Green
PORTD.7 Red
D2
D5
R141k
R171k
LEDs
In-line Grouped LEDs
PD4
PD5
PD7
PD[7..0]
PD6
R221k
R231k
RTRHVADC0 ⋅()VCC VADC0 – ()⁄=

Using the AT90USBKey
AT90USBKey Hardware User Guide 2-11
7627A–AVR–04/06
The NTC thermistor used in AT90USBKey has a resistance of 100 KΩ±5% at 25°C (T0)
and a beta-value of 4250 ±3%. By the use of the following equation, the temperature (T)
can be calculated:
Where: RT= Thermistor value (Ω) at Ttemperature (°Kelvin)
ß= 4250 ±3%
R0= 100 KΩ±5% at 25°C
T0= 298 °K (273 °K + 25°K)
The following cross table also can be used. It is based on the above equation.
Table 2-2 . Thermistor Values versus Temperature
Temp.
(°C) RT
(KΩ)Temp. (°C) RT (KΩ)Temp. (°C) RT (KΩ)Temp. (°C) RT (KΩ)
-20 1263,757 10 212,958 40 50,486 70 15,396
-19 1182,881 11 201,989 41 48,350 71 14,851
-18 1107,756 12 191,657 42 46,316 72 14,329
-17 1037,934 13 181,920 43 44,380 73 13,828
-16 973,006 14 172,740 44 42,537 74 13,347
-15 912,596 15 164,083 45 40,781 75 12,885
-14 856,361 16 155,914 46 39,107 76 12,442
-13 803,984 17 148,205 47 37,513 77 12,017
-12 755,175 18 140,926 48 35,992 78 11,608
-11 709,669 19 134,051 49 34,542 79 11,215
-10 667,221 20 127,555 50 33,159 80 10,838
-9 627,604 21 121,414 51 31,840 81 10,476
-8 590,613 22 115,608 52 30,580 82 10,128
-7 556,056 23 110,116 53 29,378 83 9,793
-6 523,757 24 104,919 54 28,229 84 9,471
-5 493,555 25 100,000 55 27,133 85 9,161
-4 465,300 26 95,342 56 26,085 86 8,863
-3 438,854 27 90,930 57 25,084 87 8,576
-2 414,089 28 86,750 58 24,126 88 8,300
-1 390,890 29 82,787 59 23,211 89 8,035
0 369,145 30 79,030 60 22,336 90 7,779
1 348,757 31 75,466 61 21,498 91 7,533
2 329,630 32 72,085 62 20,697 92 7,296
3 311,680 33 68,876 63 19,930 93 7,067
4 294,826 34 65,830 64 19,196 94 6,847
Tβ
RT
R0
-------
ln
⎝⎠
⎛⎞
β
T0
------+
-------------------------------=

Using the AT90USBKey
2-12 AT90USBKey Hardware User Guide
7627A–AVR–04/06
Figure 2-8 . Thermistor Schematic
2.4.5 Data Flash memory
For mass-storage class demonstration purpose, the AT90USBKey provides two on-chip
serial Flash memories (AT45DB642D) connected to the AT90USB Serial Port Interface
(SPI).
The data-flash chip select signals are connected to PortE bit 0 and bit 1 of the AT90USB
(See Figure 2-9).
Figure 2-9 . On-board data flash schematic
5 278,995 35 62,937 65 18,493 95 6,635
6 264,119 36 60,188 66 17,820 96 6,430
7 250,134 37 57,576 67 17,174 97 6,233
8 236,981 38 55,093 68 16,556 98 6,043
9 224,606 39 52,732 69 15,964 99 5,860
Temp.
(°C) RT
(KΩ)Temp. (°C) RT (KΩ)Temp. (°C) RT (KΩ)Temp. (°C) RT (KΩ)
PF[7..0]
R29
R27
100k
PF0
VCC
PE0
VCC3
VCC3
PB[7..0]
PB1
R9
100k
RESET
PB3
PB2 SI
1
SCK
2
RESET
3
CS
4WP 5
VCC 6
GND 7
SO 8
U2
AT45DB642D CASON8
PE1
VCC3
VCC3
RESET
PB1
R10
100k
PB3
PB2 SI
1
SCK
2
RESET
3
CS
4WP 5
VCC 6
GND 7
SO 8
U3
AT45DB642D CASON8
R12
100k
R11
100k

Using the AT90USBKey
AT90USBKey Hardware User Guide 2-13
7627A–AVR–04/06
2.5 In-System Programming
2.5.1 Programming with USB bootloader: DFU (Device Firmware Upgrade)
AT90USB part comes with a default factory pre-programmed USB bootloader located in
the on-chip boot section of the AT90USB. This is the easiest and fastest way to
reprogram the device directly over the USB interface. The “Flip” PC side application, is
available from the Atmel website, offers a flexible an user friendly interface to reprogram
the application over the USB bus.
The HWB pin of the AT90USB allows to force the bootloader section execution after
reset. (Refer to AT90USB datasheet section “boot loader support”). To force bootloader
execution, operate as follow:
 Press both “RST” and “HWB” push buttons
 First release the “RST” push button
 Release the “HWB” push button
For more information about the USB bootloader and “Flip” application, please refer to
the “USB bootloader datasheet document” and “Flip’s user manual”.
Note: The HWB pin is active only if the HWBE fuse is set (default factory configuration).
2.5.2 Programming with AVR JTAGICEmKII
The AT90USB can be programmed using specific JTAG link. To use the AVR
JTAGICEmkII with an AT90USBKey an optional HE10 connector should be soldered to
J9 footprint. Then the JTAG probe can be connected to the AT90USBKey as shown in
Figure 2-10.
Note: When the JTAGEN Fuse is unprogrammed, the four TAP pins are normal port pins, and
the TAP controller is in reset. When programmed, the input TAP signals are internally
pulled high and the JTAG is enabled for Boundary-scan and programming. The
AT90USB device is shipped with this fuse programmed.

Using the AT90USBKey
2-14 AT90USBKey Hardware User Guide
7627A–AVR–04/06
Figure 2-10 . Connecting AVR JTAG ICE to AVRUSBKey
The Flash, EEPROM and all Fuse and Lock Bit options ISP-programmable can be
programmed individually or with the sequential automatic programming option.
Note: See AVR Studio® on-line Help for information.
2.6 Debugging
2.6.1 Debugging with AVR JTAG ICE mkII
The AT90USBKey can be used for debugging with JTAG ICE MK II.
Connect the JTAG ICE mkII as shown in Figure 2-10, for debugging, please refer to
AVR Studio® Help information.
When using JTAG ICE MK II for debugging, and as AT90USB parts are factory
configured with the higher security level set, a chip erase operation will be performed on
the part before debugging. Thus the on-chip flash bootloader will be erased. It can be
restored after the debug session using the bootloader hex file available from ATMEL
website.

AT90USBKey Hardware User Guide 3-15
7627A–AVR–04/06
Section 3
Troubleshooting Guide
Figure 3-1 . Troubleshooting Guide
Problem Reason Solution
The Green “VCC-ON”
LED is not on No power supply Verify the power supply source (check
battery charge or USB connection).
AVRUSBKey does not
work
The AT90USB cannot be
programmed
The AVR JTAG ICE
probe is not
connected
Connectthe JTAG ICE 10-PIN headerto
the correct AVRUSBKey JTAG header
(page 13)
The memory lock bits
are programmed Erase the memory before programming with JTAG ICE.
The fuse bits are
wrongly programmed Check the fuse bits with JTAG ICE
Can not connect to
USB bootloader
Force bootloader execution with HWB
under reset.
USB bootloader erased after a JTAG
debugging session: reprogram the USB
bootloader with JTAG.
AVR Studio does not
detect the AVR JTAG
ICE.
Serial/USB cable is
not connected, or
power is off
Connectserial cable to RS232 (STK500 -
AVR ISP) and check power connections
Connect serial cable to USB (JATG ICE
MKII, AVR ISPmkIIl) and check power
connections
PC COM port is in
use
Disable other programs that are using
PC COM port.
Change PC COM port
AVR Studio does not
detect COM port.
Disable COM port auto-detection in AVR
Studio file menu. Force COM port to
correct COM port

AT90USBKey Hardware User Guide 4-16
7627A–AVR–04/06
Section 4
Technical Specifications
 System Unit
– Physical Dimensions.....................................................L=90 x W=30 x H=8 mm
– Weight...........................................................................................................12 g
 Operating Conditions
– Internal Voltage Supply ...............................................................................3.3V
– External Voltage Supply .........................................................................8V -15V
 Connections
– USB Connector......................................................................Mini AB receptacle
– USB Communications .......................................................Full speed/low speed
– JTAG Connector.................................................... Footprint for HE10 connector
– All ports connectors.............................................................J1, J2, J4, J5, J6, J7
– Battery connector....................................................................... MTA right angle

AT90USBKey Hardware User Guide 5-17
7627A–AVR–04/06
Section 5
Technical Support
For Technical support, please contact [e-mail]. When requesting technical
support, please include the following information:
 Which target AVR device is used (complete part number)
 Target voltage and speed
 Clock source and fuse setting of the AVR
 Programming method (ISP, JTAG or specific Boot-Loader)
 Hardware revisions of the AVR tools, found on the PCB
 Version number of AVR Studio. This can be found in the AVR Studio help menu.
 PC operating system and version/build
 PC processor type and speed
 A detailed description of the problem

AT90USBKey Hardware User Guide 6-18
7627A–AVR–04/06
Section 6
Complete Schematics
On the next pages, the following documents of AT90USBKey are shown:
 Complete schematics,
 Bill of materials.

Complete Schematics
AT90USBKey Hardware User Guide 6-19
7627A–AVR–04/06
Figure 6-1 . Schematics, 1 of 2
C7 1uF C3216-A
VBUS
RST
RST
DTSM-3
AVCC
PD[7..0]
PD[7..0]
PA0
UCAP Capacitor Closed to the MCU
VCC
PA1
R4 0
R0603
PE0
PF7
PE2
PE1
PE4
PE3
PE6
PE[7..0]
PE5
11
2
233
4
455
6
677
8
899
10
10 J2
1.27 mm Dual H1.27-10
PE7
PA3
UGND
(not mounted)
PE2
VCC
PA[7..0]PA[7..0]PA[7..0]
PF0
PA2
RESET
PA4
PF2
Reset Circuit
UVCON
VBUS
PA5
HWB HWB
DTSM-3
R1 0
R0603
PF4
RESET
UGND
R8 0
R0603
PA6
AGND
C1
100nF C0603
PF1
UCAP
PA7
(not mounted)
(not mounted)
(not mounted)
PF3
PE2
PF[7..0]
PC7
R5 0
R0603
VCC
C9
220nF
C0603
(not mounted)
PE4
VCC
PB[7..0] PB[7..0]PB[7..0]
PE5
PC6
VCC AVCC
C2 100nF C0603
GND
Title Size Document Number Rev Date: Sheet of
<Doc> 1.0.0 CPU
A4
12Monday, January 09, 2006
PE6PE6
PF6
PC5
PD0
PD2
PD1
PD4
PD3
PD6
PD[7..0]
PD5
(not mounted)
11
2
233
4
455
6
677
8
899
10
10 J4
1.27 mm Dual H1.27-10
PD7
PC4
QFN64
VCC
PB0
VCC
Ferrite & capacitors closed to the MCU
PB0
PB2
PB1
PB4
PB1
PB3
PB6
PB[7..0]
PB5
11
2
233
4
455
6
677
8
899
10
10 J6
1.27 mm Dual H1.27-10
PB7
PA0
1-V_BUS
3-D+
2-D- 4-ID
5-GND
SHIELDSHIELDSHIELDSHIELD
USB_MiniABF
<ASSEMBLY>J3
MINI_USBC
PA2
PA1
PA4
PA3
PA6
PA[7..0]
PB2
PA5
PC3
PF[7..0]
11
2
233
4
455
6
677
8
899
10
10 J7
1.27 mm Dual H1.27-10
PA7
R6 47k R0603
PE7
2
UVcc
3
D-
4
D+
5
UGND
6
UCAP
7
VBUS
8
PE3
9
PB0
10
PB1
11
PB2
12
PB3
13
PB4
14
PB5
15
PB6
16
PB7
17
PD0
25
PD1
26
PD2
27
PD3
28
PD4
29
PD5
30
PD6
31
PD7
32
PE4
18
PE5
19 AREF 62
RESET
20
GND 53
GND 63
GND
22
XTAL2
23
XTAL1
24
PE0 33 PE1 34
PE6
1
PE2 43
PC0 35 PC1 36 PC2 37 PC3 38 PC4 39 PC5 40 PC6 41 PC7 42
PA7 44 PA6 45 PA5 46 PA4 47 PA3 48
PA2 49
PA1 50
PA0 51
PF7 54
PF6 55
PF5 56
PF4 57
PF3 58
PF2 59
PF1 60
PF0 61
VCC 52
VCC
21
AVCC 64
AT90USB128
U1
QFN64
PB3
UVCON PE7 C5
100nF C0603
VCC
DECOUPLING CAPACITORS CLOSED TO THE DEVICE MCU Pin3
VBUS
PC2
PB4
Y1 8MHz CRYSTAL
8MHz 49US C11
15pF C0603
C10
15pF C0603
PC1
PB5
PC0
PC2
PC1
PC4
PC3
PC6
PC[7..0]
PC5
11
2
233
4
455
6
677
8
899
10
10 J5
1.27 mm Dual H1.27-10
PC7
VBUS
AREF
PC0
PB6
PE[7..0]
PE1
PB7
VCC
PF0
PE0
C8
220nF
C0603
UGND UGNDUGNDUGNDUGND
PC[7..0]
PC[7..0]
C3
100nF C0603
GND
PF1
R3 22
R0603
R7 47k R0603
R2 22
R0603
RESET
D+
C4 100nF C0603
D- UID PE3
PF2
A90USBKey
VCC
GND
PD0
XTAL2
PD1
PD2
PF5
PF3
PD3
AGND
CR1
PGB0010603 R0603
PA[7..0]PA[7..0]PA[7..0]
CR2 PGB0010603 R0603
PD4
XTAL1
VCC
PD5
11
2
233
4
455
6
677
8
899
10
10 J1
1.27 mm Dual H1.27-10
PD6
DECOUPLING CAPACITORS CLOSED TO THE DEVICE MCU Pin52
RESISTORS CLOSED TO THE DEVICE
PD7
PF4
VCC
XTAL2
VCC
UCAP
PF7
UVCC
D+ D- RESISTORS Closed to the MCU
PF5
Bootloader Activation
C6
100nF C0603
VCC
PA[7..0]
VCC
AREF
DECOUPLING CAPACITORS CLOSED TO THE DEVICE MCU Pin21
PF6
XTAL1

Complete Schematics
6-20 AT90USBKey Hardware User Guide
7627A–AVR–04/06
Figure 6-2 . Schematics, 2 of 2
PE0
VCC3
!!! R21 not mounted
D2
IN
1
GND
2OUT 3
U5
LM340
-
C14 4.7uF
VCC3
When mounting R21: R20 not mounted U4 not mounted Allows to generate 3.3V from U1 internal regulator CAUTION: R21 default not mounted !!! VBUS generator for OTG/HOST mode 1F <Cap Vbus < 6F OTG Specification
5V
VBUS
VBAT
RESET
D4 LL4148
PF[7..0]
JTAG Interface
VCC
DECOUPLING CAPACITOR CLOSE TO THE CONNECTOR
TCK
1GND 2
TDO
3VCC 4
TMS
5RESET 6
VCC
7n.c. 8
TDI
9GND 10
CON 2x5
J9
CON 2x5
2.54 mm JTAG CON
C20
100nF
PF4PF4 PF7 PF6 PF5PF5
R26 0
VCC3
VCC
VCC3
R25 100k
-
C16
4.7uF
D1 TOPLED LP M676 POWER LED(RED)
R19 124k 1%
U3out=1.25*(1+(R15+R18)/R19)
Temp Sensor
PF[7..0]
R29
NCP18WF104J03RB
R27 100k
PF0
VCC
R28 220k
R18100k 1%
R13 1k
R30 100k
D3 LL4148
Data Flash
A90USBKey
DECOUPLING CAPACITOR CLOSE TO THE DEVICE
C12 100nF
PB[7..0]
PB1
R9 100k
RESET
PB3 PB2
VBAT
VCC
Select 5
Left 7
Up 3
Right 6
Down 4
Com1
1
Com2
2
SW3
TPA511G
PE[7..0]
Q1 BC847B
PB[7..0]
PB6 PB5 PE5 PE4 PB7
Joystick Interface
D5
SI
1
SCK
2
RESET
3
CS
4WP 5
VCC 6
GND 7
SO 8
U2
AT45DB642D CASON8
R141k
PF3
Title Size Document Number Rev Date: Sheet of
<Doc> 1.0.0 Power & Interfaces
A4
22Saturday, February 18, 2006
R171k
LEDs In-line Grouped LEDs
PD4 PD5 PD7
PD[7..0]
PD6
R221k
C17 220nF
VBat Mon.
VCC
R231k
VCC3
-
C19 4.7uF
5V
PE1
VCC3
VCC3
VCC3
DECOUPLING CAPACITOR CLOSE TO THE DEVICE
C13 100nF
RESET
PB1
R10 100k
PB3 PB2 SI
1
SCK
2
RESET
3
CS
4WP 5
VCC 6
GND 7
SO 8
U3
AT45DB642D CASON8
R12 100k
R24 10k
R15
100k 1%
MTA Ext power supply
1 2
J8
C18 100nF
VCC
OUT 1
IN
2
GND
3
OUT 4
FAULT 8
SHDN
7
CC 6
SET 5
U4
LP3982 C15
33nF
R11 100k
(not mounted)
M1
FDV304P/FAI
D6 LL4148
R16 0R20
0
UCAP
UVCON
R21
0
VCC
VBUS
