Atmel ATBTLC1000 BluSDK User manual

ATBTLC1000 BluSDK
Health Thermometer Profile (HTP) –Getting Started Guide
USER GUIDE
Introduction
This getting started guide describes the setup of Atmel®ATBTLC1000 with a supported platform (see
Chapter 4) bringing-up an example profile supplied as part of BluSDK release. The Bluetooth Health
Thermometer Profile (HTP) is an example profile application that is embedded as part of the software
release package. The device advertises itself as a Health Thermometer. The ATBTLC1000 Xplained
PRO Extension board includes an on-board temperature sensor (accessible from the host MCU) for the
purpose of sensing the ambient temperature.
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
2
2
Table of Contents
1Features .....................................................................................................................3
2Description...................................................................................................................3
3Services and Characteristics...................................................................................... 3
4Supported Hardware Platforms and IDEs..................................................................4
5Demo Setup .................................................................................................................4
6Hardware Setup...........................................................................................................5
6.1 SAM L21 Xplained Pro Health Thermometer Setup..............................................................................5
6.2 SAM D21 Xplained Pro Health Thermometer Setup .............................................................................5
6.3 SAM G55 Xplained Pro Health Thermometer Setup.............................................................................6
6.4 SAM 4S Xplained Pro Health Thermometer Setup ...............................................................................6
7Temperature Measurement Location.........................................................................7
8Temperature Type .......................................................................................................7
9Software Setup ............................................................................................................8
9.1 Installation Steps...................................................................................................................................8
9.2 Build Procedure.....................................................................................................................................9
10 Running the Demo.....................................................................................................13
11 Software Architecture ...............................................................................................18
12 Console Logging....................................................................................................... 19
13 ATMEL EVALUATION BOARD/KIT IMPORTANT NOTICE AND DISCLAIMER........20
14 Revision History........................................................................................................21

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
3
3
1 Features
Device Discovery and Disconnection
Pairing / Bonding
RSSI Sampling
Health Thermometer Service
Health Thermometer Profile iOS/Android Application
2 Description
The Health Thermometer Profile is used to enable a data collection device to obtain data from a
thermometer sensor that exposes the Health Thermometer Service.
The profile defines two roles:
Thermometer:
The Thermometer is the device that measures the temperature.
Collector:
The Collector is the device that receives the temperature measurement and other data from a
Thermometer.
This document explains the details about
1. Getting Started with the setup of supported platform (see Chapter 4) to be used as a Thermometer
2. Getting the Health Thermometer Profile Application working on the above mentioned setup.
3 Services and Characteristics
The Thermometer implements the one and only one Health Thermometer Service in addition to the
Device Information Service to display the information about the Thermometer device.
The current Thermometer profile implementation implements the following characteristics.
Temperature Measurement
Intermediate Temperature
Measurement Interval

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
4
4
4 Supported Hardware Platforms and IDEs
Table 4-1. BluSDK –Supported Hardware and IDEs
Platform
MCU
Supported
BLE device
Supported evaluation kits
Supported IDEs
SAM L21 (MCU)
ATSAML21J18B
ATBTLC1000
ATBTLC1000-XSTK
(ATSAML21-XPRO-B + ATBTLC1000
XPRO)
Atmel Studio v7.0
SAM L21 (MCU)
ATSAML21J18A
ATBTLC1000
ATSAML21 XPRO + ATBTLC1000
XPRO
Atmel Studio v7.0
SAM D21 (MCU)
ATSAMD21J18A
ATBTLC1000
ATSAMD21-XPRO + ATBTLC1000
XPRO
Atmel Studio v7.0
SAM G55 (MCU)
ATSAMG55J19
ATBTLC1000
ATSAMG55-XPRO + ATBTLC1000
XPRO
Atmel Studio v7.0
SAM 4S (MCU)
ATSAM4SD32C
ATBTLC1000
ATSAM4S-XPRO + ATBTLC1000
XPRO
Atmel Studio v7.0
5 Demo Setup
BLE LINK
ATBTLC1000+
Supported Atmel MCU
iPhone/Android
Atmel Smart Connect app
(Health Thermometer
Collector)

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
5
5
6 Hardware Setup
6.1 SAM L21 Xplained Pro Health Thermometer Setup
Figure 6-1. ATBTLC1000 Xplained Pro Extension Connected to a SAM L21 Xplained Pro
6.2 SAM D21 Xplained Pro Health Thermometer Setup
Figure 6-2. ATBTLC1000 Xplained Pro Extension Connected to a SAM D21 Xplained Pro

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
6
6
6.3 SAM G55 Xplained Pro Health Thermometer Setup
Figure 6-3. ATBTLC1000 Xplained Pro Extension Connected to a SAM G55 Xplained Pro
6.4 SAM 4S Xplained Pro Health Thermometer Setup
Figure 6-4. ATBTLC1000 Xplained Pro Extension Connected to a SAM 4S Xplained Pro

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
7
7
7 Temperature Measurement Location
Onboard the supported platform (see Chapter 4), the user button is configured to change the temperature
measurement location in the human body
The Health Thermometer profile specifies the following locations at which temperature measurements
can be read.
Body (general)
Ear (usually ear lobe)
Finger
Gastro-intestinal Tract
Mouth
Rectum
Toe
Tympanum (ear drum)
So in order to simulate the change of temperature measurement location from the Thermometer Sensor
device (supported platform, see Chapter 4), the user button had been programmed. So, every time the
user button is pressed, the temperature location will be changed as per the above list.
This can clearly be observed on a Health Thermometer Collector (Mobile Application).
8 Temperature Type
One more parameter that needs to be simulated is the temperature measurement type which contains
two values, Centigrade and Fahrenheit.
To simulate this change on the peripheral side, as there is only one user button available on board which
had already been used for changing the temperature location, the trigger that is used for this is to run
through all the locations once. Then the application shall toggle the temperature type.
B

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
8
8
9 Software Setup
9.1 Installation Steps
1. Atmel Studio installation [Atmel Studio 7.0 (build 594) Installer –with .NET]
http://www.atmel.com/tools/atmelstudio.aspx
(Note: SAM L21 Rev B/SAM D21/SAM G55/SAM 4S part pack is built-in as part of Atmel Studio 7.0)
2. Atmel USB Driver Installer from http://www.atmel.com/tools/atmelstudio.aspx.
3. Install the standalone ASF package from
http://www.atmel.com/tools/AVRSOFTWAREFRAMEWORK.aspx
Note: Refer to the BluSDK release notes for updates to version numbers of the components mentioned
above.
This package will install the following examples within the Atmel Studio environment.
1. Health Thermometer Application for SAM L21.
2. Health Thermometer Application for SAM D21.
3. Health Thermometer Application for SAM G55.
4. Health Thermometer Application for SAM 4S.

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
9
9
9.2 Build Procedure
The following procedure is explained for SAM L21 application example. The same procedure is valid for
the case of all the other supported platforms (see Chapter 4) as well.
1. Select New Example Project.
Figure 9-1. Creating a New Project

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
0
10
2. Enter “htpt” in search window and expand Atmel Corp. Projects. The location and the name of the
project can be selected in the respective fields. Click OK.
Figure 9-2. Selecting HTPT Sensor Application from Example Projects
3. Accept the license Agreement. The studio will generate the Health Thermometer Profile project for
SAM L21.

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
1
11
4. Build the solution.
Figure 9-3. Building the HTPT Temperature Sensor Application
5. Download the application via the USB to the SAM L21 board.
6. Once the application is flashed, it is ready to be simulated as Health Thermometer Device.

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
2
12
Figure 9-4. Flashing the Application on Atmel MCU

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
3
13
10 Running the Demo
1. Power on the SAM L21 + ATBTLC1000 demo setup.
2. Open the console using TeraTerm or any serial port monitor application and connect to the
corresponding COM port of “EDBG”. Serial Port Settings: Baudrate 115200, Parity None, one Stop
bit, one Start bit, no Hardware Handshake.
3. Press the Reset button on the SAM L21 board.
4. Wait for around 10 seconds for the patches to be downloaded from SAM L21 to ATBTLC1000
board.
5. The board should be in advertising mode. Ensure that the console log looks as shown below.
Figure 10-1. Console Log for Advertising Mode

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
4
14
6. Start the Thermometer application on the iPhone/Android:
Figure 10-2. iOS (left)/Android (right) Thermometer Profile App Launch Screen
7. Use the Atmel Smart Connect app to scan for devices. A device with name ‘ATMEL-HTP’ will be
seen in the list of discovered devices.
Figure 10-3. Atmel Smart Connect App Initial Screens

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
5
15
8. Click on ATMEL-HTP to connect to the device. Subsequently the services page will be seen.
Clicking on the services will result in initiation of pairing procedure. Enter the pass key ”123456”
show in the Tera term in the pairing pop up.
Figure 10-4. Pairing Procedure Initiation
Figure 10-5. Console Log on the Device During Pairing

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
6
16
9. The temperature value, RSSI and the device name are displayed on the Mobile App. Console log
will be as shown below.
Figure 10-6. App Health Thermometer Connected Screen
Figure 10-7. Console Log after Connection, Pairing, and with Notifications

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
7
17
10. To change the body measurement location, press the user button (SW0) on the SAM L21 or on the
supported platform (see Chapter 4). The new value should be updated in the application.
Figure 10-8. SW0 Button for changing Body Measurement Location
11. On the Atmel Smart Connect application, going back to the scanning screen will disconnect the
device with mobile application.
SW0

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
8
18
11 Software Architecture
The following diagram illustrates the various layers in the BLE subsystem for the ATBTLC1000
configuration. The External host can be any supported platform (see Chapter 4).
The application in this example is Health Thermometer Sensor. In the case of Health Thermometer
Profile, the profile in itself is implemented inside ATBTLC1000. Specific HTPT APIs are provided as part
of the Adapter API that is used by the HTP example application.
Figure 11-1. BluSDK Software Architecture

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
1
9
19
12 Console Logging
For the purpose of debugging, a logging interface had been implemented in the Health Thermometer
Application.
The logging interface utilizes the same EDBG port that connects to supported platform (see Chapter 4). A
serial port monitor application (for example TeraTerm) shall be opened and attached to the EDBG COM
port.
Figure 12-1 shows the information about BLE and HTP initialization and advertisement.
Figure 12-1. Example HTP App Console Log –After Initialization is Completed
.
The screenshot below shows the information about connection and temperature notification.
Figure 12-2. Example HTP App Console Log –Connection, Pairing, and Temperature Notification

Health Thermometer Profile (HTP) –Getting Started Guide [USER GUIDE]
Atmel-42530C-ATBTLC1000-BluSDK-Health-Thermometer-Profile-HTP-Getting-Started-Guide_UserGuide_022016
2
0
20
13 ATMEL EVALUATION BOARD/KIT IMPORTANT NOTICE AND
DISCLAIMER
This evaluation board/kit is intended for user's internal development and evaluation purposes only. It is
not a finished product and may not comply with technical or legal requirements that are applicable to
finished products, including, without limitation, directives or regulations relating to electromagnetic
compatibility, recycling (WEE), FCC, CE or UL. Atmel is providing this evaluation board/kit “AS IS”
without any warranties or indemnities. The user assumes all responsibility and liability for handling and
use of the evaluation board/kit including, without limitation, the responsibility to take any and all
appropriate precautions with regard to electrostatic discharge and other technical issues. User
indemnifies Atmel from any claim arising from user's handling or use of this evaluation board/kit. Except
for the limited purpose of internal development and evaluation as specified above, no license, express or
implied, by estoppel or otherwise, to any Atmel intellectual property right is granted hereunder. ATMEL
SHALL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMGES RELATING TO USE OF THIS EVALUATION BOARD/KIT.
ATMEL CORPORATION
1600 Technology Drive
San Jose, CA 95110
USA
