OTS FTD110DBMicro User manual

Quick Installation Guide
FTD110DBMicro / version 2.0
OT Systems Ltd. | www.ot-systems.com
1
FTD110DBMicro
Microtype 8-bit Digital 1-ch Video with 1-ch Bi-directional Data
Safety Instructions
Please be familiar with all information in this quick installation guide and
product manual before installation and operation.
Note 1: Each productcontains a Class 1 laser or LED fiber optic emitter.The following safety
precautions apply.
Warning: Do not disconnect the fiber optic connector while the unit is powered up.
Exposure to Class I invisible optical radiation is possible when the internal fiber optic
connector is disconnected while the unit is powered up.
Caution:Any accessto the controls, adjustments, or performing operations, which are other

Quick Installation Guide
FTD110DBMicro / version 2.0
OT Systems Ltd. | www.ot-systems.com
2
than those facilitated and/or specified may result in hazardous radiation exposure.
Permanent eye damage or other bodily injuries may be resulted from such exposure even
for only seconds.
Note 2: This assembly contains parts sensitive to damage by electrostatic discharge (ESD).
ESD precautionary procedures should be applied in the course of touching, removing or
inserting parts or assemblies.
Cable Connection Diagram
FTD110DBMicro-SST(SMT) FTD110DBMicro-SSR(SMR)

Quick Installation Guide
FTD110DBMicro / version 2.0
OT Systems Ltd. | www.ot-systems.com
3

Quick Installation Guide
FTD110DBMicro / version 2.0
OT Systems Ltd. | www.ot-systems.com
4
RS-232/422/485 data channels switch settings and
connections
The RS-232/422/485 data channels switch sets the data input and output formats. Refer to
Table 1 and the input/output connection diagrams to set and connect data signals
Table1-Dipswitch Setting
Type/Switch
Position
1
2
RS-422 4-WIRE
OFF
OFF
RS-485 4-WIRE
ON
ON
RS-485 2-Wire
ON
OFF
RS-232
OFF
ON
Pin Assignment
 Data default is RS-422 4-wire
Data
function
RJ45 pin assignment (for mini type)
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
PIN 6
PIN 7
RS422
IN+
IN-
OUT+
OUT-
GND
RS485-4
IN+
IN-
OUT+
OUT-
GND
RS485-2
IN/OUT+
IN/OUT-
GND
RS232
GND
IN
OUT
(A) RS422/485 (4-Wire Full Duplex) Data Communication Connection diagram at data port:

Quick Installation Guide
FTD110DBMicro / version 2.0
OT Systems Ltd. | www.ot-systems.com
5
(B) RS485 (2-Wire Half Duplex) Data Communication Connection diagram at data port:
User’s Equipment User’s Equipment
(C) RS232 (3-Wire Full Duplex) Data Communication Connection diagram at data port:
User’s Equipment User’s Equipment
Operational Guides
LED
COLOR
Descriptions
PWR
Red
Power
Illuminated when power is supplied to the transmitter.
LCK
Green
Fiber Optic Link
Status
Illuminated when an optical link has been set up
between theTransmitter and Receiver.
Red
Un-illuminated when an optical link hasn’t been set up
between theTransmitter and Receiver.
V1
Green
Video
Illuminated when video signals are received.
Video
Un-illuminated when video signals aren’t received.
RX
Green
Data
Illuminated when Data signals are transmitted.
TX
Green
Data
Illuminated when Data signals are received
Signal Ports:
OPT -
ST Optical Connector for Optic-fiber cable connection.
Data -
7-pin Mini Terminal Blocks for Data Transmission.
DATA Tx/Rx-
DATA Tx/Rx+
DATA Tx/Rx-
DATA Tx/Rx+
GND
DATATx
DATARx
GND
DATATx
DATARx
D
A
T
A
D
A
T
A
D
A
T
A
D
A
T
A

Quick Installation Guide
FTD110DBMicro / version 2.0
OT Systems Ltd. | www.ot-systems.com
6
Physical Dimensions (Dimensions shown in mm)
Manual Earth Green manual is available on our website www.ot-systems.com
