Atmel AT88CK109STK3 User manual

8731A–SMEM–9/10
Atmel CryptoAuthentication Starter Kit
Atmel AT88CK109STK3
Getting Started Guide
Features
•Installing Atmel CryptoAuthentication Utilities
•Configuring the board
•Powering the board
•Reading the HOST (Atmel AT88SA10HS) and
CLIENT (Atmel AT88SA102S) devices
Contents
•Atmel AT88CK109BK3 modular Atmel
CryptoAuthentication daughter board
•Atmel AT88Microbase for demos and development
•Common 10-PIN header for the Atmel STK and
EVK platforms
•Atmel CryptoAuthentication Development Library
•JTAG, LED, and buzzer for debug and feedback
•Atmel CryptoAuthentication device assortment
and USB cable
Introduction
Atmel®AT88CK109STK3 is an Atmel CryptoAuthenticationStarter Kit, which can be used as a reference design
and development system for the Atmel AT88SA100S, Atmel AT88SA102S and Atmel AT88SA10HS products.
Figure 0-1. Atmel AT88CK109STK3 Starter Kit

2Atmel AT88CK109STK3 Quick Start Guide
8731A–SMEM–9/10
1. Install the Atmel CryptoAuthentication Utilities
•Visit www.atmel.com/cryptokits to download and install the latest Atmel®CryptoAuthentication
Utilities
•Scroll down the webpage to Software Files and select the software icon for:
−PC Application: CryptoAuthentication Utility Version x.x
−Microcontroller Firmware: CryptoAuthentication Firmware AT88CK109STK3 Version x.x
(The Atmel AT88Microbase is preloaded with the appropriate firmware image for your convenience)
2. Configuring the board
Ensure there is a device in the HOST and CLIENT sockets.
Figure 2-1. HOST and CLIENT sockets
The kit is shipped with an Atmel AT88SA102S device in the CLIENT socket and an Atmel AT88SA10HS
device in the HOST socket. To use this kit with the CryptoAuthentication Utilities software, the host and
client devices must be in their respective sockets according to the texts (silkscreen) on the PCB.
Also, ensure the jumpers are configured as follow:
Figure 2-2. Jumper Configuration

Atmel AT88CK440RED Quick Start Guide 3
8731A–SMEM–9/10
3. Powering up the board
The Atmel®AT88CK109STK3 is a USB powered device. The Atmel AT88Microbase can be directly inserted
into the USB port or be used with the six-inch USB cable provided.
Figure 3-1. Atmel AT88CK109STK3 USB Device
Upon receiving power, the blue power LED “LEDP” on the AT88Microbase and the two red LEDs on the
AT88CK109BK3 will light.
4. Reading the Device Configuration Information
•Insert the Atmel AT88CK109STK3 into a USB port (Section 2)
•Launch the Atmel CryptoAuthentication Utilities
•Click Start, All Programs, Atmel Crypto Solutions, CryptoAuthentication Utilities
Figure 4-1. Atmel CryptoAuthentication Utilities
Power LEDs

4Atmel AT88CK109STK3 Quick Start Guide
8731A–SMEM–9/10
The Atmel®CryptoAuthenticationUtilities will open to the AT88SA102S/ Hardware Operation tab.
Figure 4-2. Hardware Operations Tab
If the following screen appears, then one of four problems exists.
1. No device has not been inserted into the socket
2. The devices are not in their respective sockets, HOST / CLIENT
3. The device is not seated properly
4. The firmware is outdated
−See Section 8, “Firmware Upgrade”
Figure 4-3. No SA102S Device Detected Notification

Atmel AT88CK440RED Quick Start Guide 5
8731A–SMEM–9/10
•Click the Read button in the AT88SA102S Configuration Information section
−The section will populate
Figure 4-4. Atmel AT88SA102S Configuration Information populated

6Atmel AT88CK109STK3 Quick Start Guide
8731A–SMEM–9/10
5. Programming the Secret Fuse Value
•Click the Hardware Setup tab
1. Select the Client Socket radio button
2. Enter a Secret Fuse Value (remember this value)
−This can be any arbitrary data
−Length must equal 8-bytes
3. Ensure the Lock Device on Burn is checked
4. Click the Burn button
5. Click OK on the popup box
6. Select the Host Socket radio button
7. Repeat steps two through five
−The CLIENT and the HOST devices must have the same Secret Fuse Value
Figure 5-1. Hardware Setup tab

Atmel AT88CK440RED Quick Start Guide 7
8731A–SMEM–9/10
6. Executing the Message Authentication Command on the
CLIENT device
•Click the Hardware Operation tab
1. Select Mode 20
2. Enter KeyID FFFF
3. Enter a Challenge (up to 32-bytes)
4. Click the Send button to obtain the MAC (Atmel AT88SA102S response)
Figure 6-1. Hardware Operations tab
1
2
3
4

8Atmel AT88CK109STK3 Quick Start Guide
8731A–SMEM–9/10
7. Verifying the CLIENT’s MAC with the HOST Device
•Click the Host Verification tab
•Click the Read button in the AT88SA10HS Host Values section
−The section will populate
•Click the Verify button and observe the Host Response, which should be true
Response Summary: True is returned when both the HOST and CLIENT devices have the same Secret
Fuse value and produce the same MAC to the same Challenge
Congratulations, your Atmel®AT88CK109STK3 is up and running
See the CryptoAuthentication Help shortcut on your desktop for additional information.
For additional samples, go to: http://www.atmel.com/forms/Samples.asp?family_id=699
Figure 7-1. Host Verification tab
8. Firmware Upgrade
To upgrade the firmware, click the Help tab and complete steps one through six.
The following steps enable the DFU mode:
1. Load the Atmel FLIP (FLexible In-System) Programming utility
2. http://www.atmel.com/dyn/products/tools_card_v2.asp?tool_id=3886
3. Click the Firmware upgrade mode Enable button
4. Click OK in the popup box
5. All three LEDs will blink three times indicating the board is in DFU mode
6. Launch FLIP to load the new firmware

Atmel AT88CK440RED Quick Start Guide 9
8731A–SMEM–9/10
9. References and further information
A complete reference design including schematics, Gerber files, bill of materials (BOM), Hardware User
Guide and development and demonstration software is conveniently downloadable from
www.atmel.com/cryptokits.
