Atmel AT32UC3L-EK User manual

Atmel AVR UC3 32-bit Microcontrollers
UC3L Evaluation Kit
USER GUIDE
Introduction
The Atmel® AT32UC3L-EK is an evaluation kit and development system for
the Atmel AVR® UC3 AT32UC3L064 microcontroller.
As an evaluation kit, the board focus is towards Atmel QTouch® and
QMatrix™ support, and Atmel picoPower® technology.
As a development system, the board notably provides on-board memory, a
USB communication interface, an accelerometer, and the JTAG
programming and debugging interface. The AT32UC3L-EK also features
expansion headers; one of these is the wireless expansion header (named
WLESS on the PCB), which is the receptacle for one of the two RZ600 radio
boards provided in the kit package.
Atmel-32150C-UC3L-EK_User Guide-06/2015

Table of Contents
Introduction......................................................................................................................1
1. Kit Overview...............................................................................................................4
1.1. Features....................................................................................................................................... 5
1.2. Kit Contents..................................................................................................................................5
1.3. Power-up and Getting Started......................................................................................................6
1.4. Reference Materials..................................................................................................................... 6
2. Hardware Description................................................................................................ 7
2.1. Power Supply............................................................................................................................... 7
2.1.1. Overview........................................................................................................................7
2.1.2. Schematics.................................................................................................................... 8
2.1.3. UC3L-specific Information............................................................................................. 8
2.1.4. Configurations and Test Points...................................................................................... 9
2.1.5. Power Consumption Measurement............................................................................. 10
2.2. User Interface............................................................................................................................. 11
2.2.1. User Interface Schematics...........................................................................................12
2.2.2. UC3L-specific Information........................................................................................... 12
2.2.3. Hardware Configuration and Test Points..................................................................... 13
2.3. Programming and Debug Interface............................................................................................ 14
2.3.1. Overview......................................................................................................................14
2.3.2. Schematics.................................................................................................................. 15
2.3.3. UC3L-specific Information........................................................................................... 15
2.3.4. Configuration and Test Points......................................................................................15
2.4. External Memory........................................................................................................................ 17
2.4.1. Overview......................................................................................................................17
2.4.2. Schematics.................................................................................................................. 17
2.4.3. UC3L-specific Information........................................................................................... 18
2.4.4. Configuration and Test Points......................................................................................18
2.5. Real Time Clock......................................................................................................................... 19
2.5.1. UC3L-specific Information........................................................................................... 19
2.5.2. Test Points................................................................................................................... 19
2.6. Expansion Interface....................................................................................................................19
2.6.1. Overview......................................................................................................................20
2.6.2. Schematics.................................................................................................................. 21
2.6.3. UC3L-specific Information........................................................................................... 21
2.6.4. Configuration and Test Points......................................................................................23
2.7. USB Interface............................................................................................................................. 23
2.7.1. Overview......................................................................................................................24
2.7.2. Schematics.................................................................................................................. 26
2.7.3. UC3L-specific Information........................................................................................... 26
2.7.4. Configuration and Test Points......................................................................................26
2.8. AT32UC3L064............................................................................................................................ 27
2.8.1. Overview......................................................................................................................27
2.8.2. Schematics.................................................................................................................. 28
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
2

2.8.3. AT32UC3L064 Pinout.................................................................................................. 28
2.8.4. Configuration and Test Points......................................................................................30
3. UC3L-EK Schematics..............................................................................................31
4. Errata and Troubleshooting..................................................................................... 32
5. Evaluation Board/kit Important Notice..................................................................... 33
6. Revision History.......................................................................................................34
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
3

1. Kit Overview
This chapter lists the features provided by the AT32UC3L-EK evaluation kit and describes the content of
the box the kit is packaged in.
Figure 1-1 AT32UC3L-EK Block Diagram
External Memory
User Interface
AT32UC3L064
Prog. and Debug Interface
JTAG
(J9)
aWire
(J9.6)
DataFlash
3-axis
Accelerometer
RTC
32kHz crystal
User Interface
CAT &
ACIFB
GPIO
GPIO
PM
Touch
LEDs
(LED0..3)
PushButton
(WAKE)
PushButton
(RST)
Expansions Interface
USART1
SPI0
USART1
TWI0
GPIO
Expansion
Header J8
(WLESS)
Configuration
Jumper
(J44)
Expansion
Headers
(J14 *&J15)
Wireless RZ600 compliant
SPI/TWI Extension
VDDIN
VDDIO
Power
Off
VCC3
1.2NiMh battery
in the J3 socket
USB mini AB plug
DC +5V +/-10%
(J2)
Power On
PushButton
(SW2)
LED
(Power)
User INTERFACE
External 3.3V regulator
+
SCIF
aWire
JTAG
USB Interface
AT32UC3B1256
Jumper
(J12)
Configuration
Interface
GPIO
GPIO
GPIO
LEDs
(D12&D13)
USB
Mode
(button)
User
Interface
JTAG
(J13)
JTAG
Prog.& Debug
Interface
Virtual Port/
IID Qtouch Debug/
DFU Downloader
USB
USART3
SPI0
ADCIFB
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
4

1.1. Features
The following is a list of the main components and interfaces on the AT32UC3L-EK:
•Main MCU: Atmel AVR UC3 32-bit AT32UC3L064 (TQFP48)
–64KB internal flash, 16KB internal RAM
–Up to 50MHz operation
–Very low power consumption
–Capacitive touch module for support of QTouch and QMatrix capture from capacitive touch
sensors
–Peripheral event system
–FlashVault™ allows pre-programmed, secure library support for end user applications
•One touch rotor and five touch sensors
•One 3-axis accelerometer (connected to channels 6, 7, and 8 of the ADCIFB module)
•One serial data flash, 64Mb
•One RTC 32kHz crystal
•Four LEDs
•One pushbutton
•One reset pushbutton
•Wireless expansion connector for the RZ600 AT86RF231 radio board PCBA or for y SPI-based,
TWI-based, or USART-based external communication
•36-pin raw expansion header for GPIO access
•JTAG connector for programming and debugging on the AT32UC3L064 MCU
•Powered through the USB connector, through an external power supply (header), or through a 1.2V
battery (header J3)
•USB (2.0 Mini-AB receptacle) connected to the 32-bit AVR UC3 AT32UC3B1256
–AT32UC3L064 and AT32UC3B1256 are connected through two pins
–One of the pre-loaded firmware on the AT32UC3B1256 acts as a UART-USB CDC virtual com
port gateway
–One of the pre-loaded firmware on the AT32UC3B1256 acts as UART-to-USB HID QTouch
Debug interface to AVR QTouch Studio
–USB mode pushbutton: with the default pre-loaded firmware on the AT32UC3B1256, the USB
mode button is used to select between the UART-USB CDC virtual com port gateway
firmware (press the USB mode upon power up of the board) and the UART-to-USB HID
QTouch Debug interface to AVR QTouch Studio
–The J12 jumper can be used to set the AT32UC3B1256 in boot loader mode at power up
–JTAG connector for programming and debugging the AT32UC3B1256 (J13)
1.2. Kit Contents
The AT32UC3L-EK toolbox contains the following items:
•One AVR Technical Library DVD
•One AT32UC3L-EK customer letter
•One AT32UC3L-EK Getting Started Guide
•One AT32UC3L-EK evaluation kit
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
5

•One RZ600 USB adapter board PCBA
•Two RZ600 AT86RF231 radio board PCBA
•Two RF antennas
•One Mini-B plug to std-A plug ~1.5m USB cable
•One 1.2V NiMh rechargeable battery
Figure 1-2 Unpacked AT32UC3L-EK Toolbox
1.3. Power-up and Getting Started
Refer to the AVR32777: AT32UC3L-EK Getting Started Guide.
1.4. Reference Materials
1. The AVR UC3 L0 series datasheet
2. The AT32UC3L-EK Schematics
3. AVR32777: AT32UC3L-EK Getting Started Guide
4. The 32-bit AVR UC3 L series Schematic Checklist
5. The AVR Software Framework
All pre-loaded firmware source code is available in the AVR Software Framework version 2.0 or
higher.
6. The AVR UC3 UART Boot loader
7. The Atmel QTouch Library
8. QTouch Studio
9. Debuggers
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
6

2. Hardware Description
This chapter presents the hardware blocks of the AT32UC3L-EK hardware design. Each hardware block
is described with:
•An overview of the hardware block
•A location in the schematics document
•AT32UC3L-specific information (when relevant)
•All possible hardware configurations of the block and available test points
2.1. Power Supply
The power supply block of the AT32UC3L-EK is in charge of distributing power to all components of the
board.
2.1.1. Overview
Figure 2-1 AT32UC3L-EK Power Supply Logical View
The AT32UC3L-EK can be powered from three different sources: the USB Mini-AB plug (5V input), an
external power supply connected to the J2 header (DC 5V ± 10%), or a 1.2V NiMh battery (in the J3
socket on the bottom side of the board).
These inputs go through an external 3.3V switch mode regulator, which in turn supplies the rest of the
board with a 3.3V voltage.
The power indicator LED, D4, labeled POWER, indicates if the 3.3V from the external regulator is
present.
The pushbutton labeled SW2 is there to activate the use of the battery when one is installed in the J3
socket.
The AT32UC3L064 firmware may read the battery current voltage with an ADCIFB channel.
The "Power Off" signal from the AT32UC3L064 to the on-board power supply block can be used to lower
the power consumption by software.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
7

To customize the hardware configuration of this block, see Section Configurations and Test Points on
page 9, for a description of the possible hardware configurations of the power supply block.
Figure 2-2 AT32UC3L-EK Top View Power Supply Location
Figure 2-3 AT32UC3L-EK Bottom View Power Supply Location
2.1.2. Schematics
The schematic of the power supply block is on page 2 of the schematics document found here: http://
www.atmel.com/Images/AT32UC3L-EK_Schematics.zip document.
2.1.3. UC3L-specific Information
2.1.3.1. Atmel AT32UC3L064 Power Supply Mode
Of the three power supply configurations supported by the AT32UC3L064, this board implements the
3.3V single power supply mode configuration. Refer to the figure, "3.3V single power supply mode", in the
AVR UC3 L0 Series datasheet for schematics of this mode: this is how it is implemented on this board.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
8

2.1.3.2. Atmel AT32UC3L064 Pinout for the Power Supply Block
Table 2-1 UC3L Pinout for the Power Supply Block
QFP48 pin GPIO GPIO Alternate Functions Feature
1 N.A. N.A. GND
4 PA03 GPIO[3] The Power-Off signal from the AT32UC3L064 to the
power supply block.
17 N.A. N.A. VDDIN
18 N.A. N.A. VDDCORE
19 N.A. N.A. GND
33 N.A. N.A. GNDANA
34 N.A. N.A. ADVREFP
35 N.A. N.A. VDDANA
42 N.A. N.A. VDDIO
48 N.A. N.A. VDDIO
2.1.4. Configurations and Test Points
2.1.4.1. Hardware Configurations
The default hardware configuration of the power supply block implies that:
•The power supply sources are the battery or the USB plug (thus the dotted-lines on the J2 plug in
the block diagram, figure AT32UC3L-EK Power Supply Logical View and Figure 1-1 AT32UC3L-EK
Block Diagram on page 4
•The power-off signal from the AT32UC3L064 is not connected to the on-board power supply block
(thus the dotted arrow in the block diagram)
To enable the power supply through the J2 connector, mount the R5 resistor (solder patch) and remove
the R6 resistor.
To activate the Power-Off signal, remove the R17 resistor and mount the R26 resistor (solder patch).
To locate the resistors mentioned here above, use the assembly top/bottom views provided within the
AT32UC3L-EK schematics package.
2.1.4.2. Test Points
A few test points covering the power supply block have been placed on the AT32UC3L-EK for the
verification of important signals.
Table 2-2 Power Supply Block Test Points
Designation Feature
TP7 Input voltage level after D1 when the J2 external power supply is used
TP8 Input voltage for all boards' components except the AT32UC3L064. Should be 3.3V
nominal.
TP9 Input voltage for the AT32UC3L064 VDDIO pin. Should be 3.3V nominal.
TP10 Output voltage out of the external regulator
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
9

Designation Feature
TP11 Input voltage for the AT32UC3L064 VDDIN pin. Should be 3.3V nominal
TP12 GND
To locate the test points mentioned above, use the assembly top/bottom views provided within the
AT32UC3L-EK schematics package.
2.1.5. Power Consumption Measurement
To measure the power consumption of the overall board minus the AT32UC3L064, remove the 0Ω R11
resistor and measure the current over the J4 2-pin header (not mounted by default).
To measure the power consumption on the AT32UC3L064 VDDIO, remove the 0Ω R14 resistor and
measure the current over the J5 2-pin header (not mounted by default).
To measure the power consumption on the AT32UC3L064 VDDIN, remove the 0Ω R19 resistor and
measure the current over the J6 2-pin header (not mounted by default).
Figure 2-4 AT32UC3L-EK Power Consumption Measurement Headers Location
The above figure points to the location of the power consumption measurement area. To accurately locate
the components mentioned above, use the assembly top/bottom views provided within the AT32UC3L-EK
schematics package.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
10

2.2. User Interface
Figure 2-5 AT32UC3L-EK User Interface Logical View
AT32UC3L064
Touch
LEDs
(LED0..3)
PushButton
(Wake)
PushButton
(RST)
CAT&
ACIFB
GPIO
GPIO
PM
ADCIFB
3-axis
Accelerometer
User Interface
User Interface
The main user interface offered by the kit is the touch user interface consisting of the wheel sensor and
the five button sensors. The touch sensors are implemented by using the QMatrix method (X=6, Y=2).
The CAT IP of the AT32UC3L064 is used, as is the ACIFB IP (implied by the use of the QMatrix method).
Applications running on the AT32UC3L064 need to use the QTouch library for optimal touch events
management.
Four general purpose LEDs (labeled LED0, LED1, LED2, and LED3) are connected to the
AT32UC3L064.
The WAKE pushbutton can be used as a general purpose pushbutton, and is connected to the special
purpose WAKE_N pin.
The RST pushbutton is used to generate an external reset to the AT32UC3L064. A three-axis
accelerometer is connected to three channels of the AT32UC3L064's ADCIFB IP.
Note that there are other user interface components in the kit, and these are related to:
•The USB Interface, presented in Section USB Interface on page 23 of this document
•The power supply interface, presented in Section Power Supply on page 7 of this document
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
11

Figure 2-6 AT32UC3L-EK Top View User Interface Location
Figure 2-7 AT32UC3L-EK Bottom View User Interface Location
2.2.1. User Interface Schematics
In the Schematic document, the components of the user interface are found:
•On page 1 for the RST pushbutton
•On page 3 for the three-axis accelerometer
•On page 4 for the touch sensors, LEDs, and WAKE pushbutton
2.2.2. UC3L-specific Information
2.2.2.1. Atmel AT32UC3L064 Pinout for the Interface Block
Table 2-3 UC3L Pinout for the Touch Sensors Interface
QFP48 pin GPIO GPIO Alternate Functions Feature
46 PA10 CAT-CSA[5] QMatrix Y2
47 PA12 CAT-CSB[5] QMatrix YK2
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
12

QFP48 pin GPIO GPIO Alternate Functions Feature
5 PB12 CAT-CSA[15] QMatrix Y7
29 PB09 CAT-CSB[15] QMatrix YK7
36 PA14 CAT-CSA[6] QMatrix X6
37 PA15 CAT-CSB[6] QMatrix X7
40 PA19 CAT-CSA[10] QMatrix X10
9 PA22 CAT-CSB[10] QMatrix X11
21 PB04 CAT-CSA[14] QMatrix X14
20 PB05 CAT-CSB[14] QMatrix X15
38 PA16 ACIFB-ACREFN ACREFN, connected to GNDANA.
39 PA17 CAT-SMP SMP
Table 2-4 UC3L Pinout for the LEDs and Push-Buttons Interfaces
QFP48 pin GPIO GPIO Alternate functions Feature
24 PA21 GPIO[21] or TC0-B1 or PWMA[21] or SCIF-GCLK[0] LED0
23 PB10 GPIO[42] or GLOC-OUT[1] or PWMA[33] LED1
7 PB02 GPIO[34] or TC0-A2 or PWMA[25] or SCIF-GCLK[1] LED2
8 PB03 GPIO[35] or TC0-B2 or PWMA[26] or TC1-A2 LED3
27 PA11 GPIO[11] controls the pin WAKE pushbutton
22 N.A. N.A. RST pushbutton, connected to
the RESET_N pin
Table 2-5 UC3L Pinout for the Accelerometer Interface
QFP48 pin GPIO GPIO Alternate
functions
Feature
30 PB06 ADCIFB-AD[6] Ouput VoutX of the accelerometer acquired by ADC
channel 6
31 PB07 ADCIFB-AD[7] Ouput VoutY of the accelerometer acquired by ADC
channel 7
32 PB08 ADCIFB-AD[8] Ouput VoutZ of the accelerometer acquired by ADC
channel 8
2.2.3. Hardware Configuration and Test Points
2.2.3.1. Hardware Configuration
The default hardware configuration of the user interface block implies that:
There is no hardware to support debounce on the RST pushbutton: R36 is not mounted, so C4 has no
effect. This was done to support the aWire programming and debugging interface (refer to Section
Programming and Debug Interface on page 14). To enable the hardware debounce support on the RST
pushbutton, mount the 0Ω R36 resistor (solder patch).
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
13

To locate the R36 resistor mentioned above, use the assembly top/bottom views provided within the
AT32UC3L-EK schematics package.
2.2.3.2. Test Points
A few test points covering the user interface block have been placed on the AT32UC3L-EK for the
verification of important signals.
Table 2-6 User Interface Block Test Points
Designation Feature
TP1 Input voltage on the AT32UC3L064 RESET_N pin, depending on the state of the RST
pushbutton
TP18 Input voltage for the accelerometer. Should be 1.8V nominal
TP15 Output voltage on the accelerometer VoutZ pin
TP16 Output voltage on the accelerometer VoutY pin
TP17 Output voltage on the accelerometer VoutX pin
TP19 Input voltage on the AT32UC3L064 WAKE_N pin, depending on the state of the WAKE
pushbutton
TP20 Voltage level on LED0
TP21 Voltage level on LED1
TP22 Voltage level on LED2
TP23 Voltage level on LED3
To locate the test points mentioned here above, use the assembly top/bottom views provided within the
AT32UC3L-EK schematics package.
2.3. Programming and Debug Interface
The programming and debugging interface block of the AT32UC3L-EK provides the developer with a
means to debug an application running on the AT32UC3L064.
2.3.1. Overview
Figure 2-8 AT32UC3L-EK Programming and Debugging Interface Logical View
AT32UC3L064
aWire
(J9.6)
JTAG
(J9)
JTAG
aWire
Prog. & Debug
interface
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
14

The main programming and debugging interface of the AT32UC3L-EK is meant to program and debug
the AT32UC3L064. There are two debug interfaces available on the AT32UC3L064: the JTAG interface
and the aWire interface (single pin debug system), both accessible through the J9 connector.
Note that there is another programming and debugging interface block on the kit, but it is related to the
AT32UC3B1256 chip in charge of USB communication (refer to USB Interface on page 23).
Figure 2-9 AT32UC3L-EK Programming and Debugging Interface Location
2.3.2. Schematics
In the Schematics document, the programming and debugging interface is on page 5.
2.3.3. UC3L-specific Information
2.3.3.1. Atmel AT32UC3L064 Pinout for Programming and Debugging Interface
Table 2-7 Atmel AVR UC3L Pinout for Programming and Debugging Interface
QFP48 pin GPIO GPIO Alternate
Functions
Feature
11 PA00 None JTAG.TCK
14 PA01 None JTAG.TMS
13 PA02 None JTAG.TDO
4 PA03 None JTAG.TDI
22 N.A. N.A. RESET_N pin. Used when enabling/disabling the JTAG
or the aWire interface. Also, the aWire data is
multiplexed on this pin.
2.3.4. Configuration and Test Points
2.3.4.1. Special Considerations for the RESET_N Pin and the JTAG Pins
On the AVR UC3 L0 series, the RESET_N pin is used to enable/disable the JTAG interface or the aWire
interface. For this reason, the RESET_N pin should not be connected to an external reset circuit to avoid
drive contention and speed problems. To avoid this issue with the RST pushbutton, the 0Ω R36 resistor is
not mounted by default.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
15

On the AVR UC3 L0 series, the JTAG TMS, TDI, TDO, and TCK pins are multiplexed with I/O lines. While
using these multiplexed JTAG lines, all normal peripheral activity on these lines is disabled. The user
must make sure that no external peripheral is blocking the JTAG lines while debugging.
Conflict conditions over the debugging pins, highlights the components on the AT32UC3L-EK that might
interfere with the multiplexed JTAG pins. These components must not be used while debugging with the
JTAG interface. Another way to say this is that debugging over the JTAG interface will not work if there is
any external signal activity over these components.
Table 2-8 Conflict Conditions over the Debugging Pins
QFP48 pin GPIO Conflict conditions
11 PA00 If the WLESS J8 connector is configured with a jumper on J44.3-5, signal activities
over J8.1 will conflict with JTAG.TCK
14 PA01 If the WLESS J8 connector is configured with a jumper on J44.4-6, signal activities
over J8.2 will conflict with JTAG.TMS
13 PA02 No possible conflicts with JTAG.TDO
4 PA03 •Signal activities over J8.5 will conflict with JTAG.TDI
•If the Power-Off signal is enabled (refer to Section Hardware Configurations
on page 9, in the Power supply interface chapter), the power supply hardware
block or any software activity on the PA03 pin will conflict with JTAG.TDI
22 N.A. If the 0Ω R36 resistor is mounted, the effect of C4 will conflict with the RESET_N pin
To summarize, debugging will not work if:
•The WLESS connector is used
•The Power-Off signal is enabled by hardware (refer to Section Hardware Configurations on page 9)
and the software running on the AT32UC3L064 toggles PA03
2.3.4.2. Test Points
A few test points covering the programming and debugging interface block have been placed on the
AT32UC3L-EK for the verification of important signals.
Table 2-9 Programming and Debugging Interface Block Test Points.
Designation Feature
TP24 JTAG.TCK
TP25 JTAG.TDO
TP26 JTAG.TMS
TP27 JTAG.TDI
TP28 GND
TP29 VCC3
TP30 RESET_N
To locate the test points mentioned above, use the assembly top/bottom views provided within the
AT32UC3L-EK schematics package.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
16

2.3.4.3. Using the aWire
The AVR ONE! and JTAGICE mkII tools can interface with the AVR UC3 L0 series using the single-wire
aWire interface. Check the documentation of these tools to know the recommended pinout to connect to
an aWire target.
2.4. External Memory
The external memory on the AT32UC3L-EK provides extra memory to the AT32UC3L064.
2.4.1. Overview
Figure 2-10 AT32UC3L-EK External Memory Logical View
External Memory
DataFlash
SPI0
AT32UC3L064
The AT32UC3L-EK contains a 64Mbit Atmel DataFlash device (AT45DB642D-CNU) that is connected to
the SPI0 interface of the AT32UC3L064.
Figure 2-11 AT32UC3L-EK External Memory Logical View
2.4.2. Schematics
In the Schematics document, the external memory is described on page 3.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
17

2.4.3. UC3L-specific Information
2.4.3.1. Atmel AT32UC3L064 Pinout for the Atmel DataFlash
Table 2-10 UC3L Pinout for the Atmel DataFlash
QFP48 pin GPIO GPIO Alternate Functions Feature
28 PA04 SPI0.MISO DataFlash SO
12 PA05 SPI0.MOSI DataFlash SI
10 PA06 SPI0.SCK DataFlash SCK
15 PA07 SPI0.NPCS DataFlash #CS
22 N.A. N.A. RESET_N pin DataFlash #RESET
2.4.4. Configuration and Test Points
2.4.4.1. Special Considerations when using the DataFlash
The pins PA05, PA06, and PA07 are multiplexed with other components on the AT32UC3L-EK.
The following table highlights the components on the AT32UC3L-EK that might interfere with the
DataFlash pins. These components must not be used while using the DataFlash.
Table 2-11 Conflict Conditions with the DataFlash
QFP48 pin GPIO DataFlash signal Conflict conditions
28 PA04 DataFlash SO If the WLESS J8 connector is
configured with a jumper on J44.2-4,
signal activities over J8.2 will conflict
with the DataFlash SO signal.
12 PA05 If the WLESS J8 connector is configured
with a jumper on J44.1-3, signal activities
over J8.1 will conflict with the DataFlash
SI signal.
To summarize, the DataFlash cannot be used when using an external module on the WLESS connector
configured with a jumper on J44.2-4 and/or with a jumper on J44.1-3.
2.4.4.2. Test Points
Two test points covering the Atmel DataFlash have been placed on the AT32UC3LEK for the verification
of important signals.
Table 2-12 Atmel Dataflash Test Points
Designation Feature
TP13 DataFlash #CS
TP14 DataFlash #WP
To locate the test points mentioned above, use the assembly top/bottom views provided within the
AT32UC3L-EK schematics package.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
18

2.5. Real Time Clock
The RTC block on the AT32UC3L-EK provides a 32kHz oscillating crystal to the AT32UC3L064.
Figure 2-12 AT32UC3L-EK Bottom View 32kHz Crystal Location
The AT32UC3L-EK contains a 32kHz crystal connected to the AT32UC3L064.
2.5.1. UC3L-specific Information
2.5.1.1. AT32UC3L064 Pinout for the RTC Clock
Table 2-13 UC3L Pinout for the 32kHz Crystal Connections
QFP48 pin GPIO GPIO Alternate Functions Feature
26 PA13 N.A. XIN32_2 32kHz crystal input
25 PA20 N.A. XOUT32_2 32kHz crystal output
2.5.2. Test Points
Two test points covering the RTC block have been placed on the AT32UC3L-EK for the verification of
important signals.
Table 2-14 RTC Block Test Points
Designation Feature
TP2 32kHz crystal output
TP4 32kHz crystal input
To locate the test points mentioned above, use the assembly top/bottom views provided within the
AT32UC3L-EK schematics package.
2.6. Expansion Interface
The expansion interface on the AT32UC3L-EK offers the possibility to connect various external devices to
the AT32UC3L064.
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
19

2.6.1. Overview
Figure 2-13 AT32UC3L-EK Expansion Interface Logical View
AT32UC3L064
Expansions Interface
USART1
SPI0
USART1
TWI0
GPIO
Expansion
Header J8
(WLESS)
Configuration
Jumper
(J44)
Expansion
Headers
(J14 *&J15)
Wireless RZ600 compliant
SPI/TWI Extension
There are two expansion headers on the AT32UC3L-EK:
•The J8 header (labeled WLESS on the PCB) connects the Atmel RZ600 AT86RF231 radio board to
provide wireless communication capabilities to the kit. Signals on J8.1 and J8.2 are configurable
with the J44 header. The AT32UC3L064 modules available on J8 are USART1 and SPI0.
Depending on the J44 configuration, TWI0 is available too.
•The J14 and J15 headers provide access to the AT32UC3L064's GPIOs, ground, and VCC3. This
offers the possibility to check signals and/or to expand the board with additional hardware.
Figure 2-14 AT32UC3L-EK Top View Expansion Headers Location
Atmel UC3L Evaluation Kit [USER GUIDE]
Atmel-32150C-UC3L-EK_User Guide-06/2015
20
