ATO EM15-SP Series User manual

User Manual
EM15-SP Series VFD
ATO Inc
Address: 23555 GOLDEN SPRINGS DR. K-1, DIAMOND BAR, USA
Phone:
1800-585-1519
Zip code: 91765
Website : https://www.ato.com/

EM15-SP User Manual Preface
Preface
Thank you for purchasing the solar drive developed by our company.
Features:
⚫MPPT algorithm of fast tracking of maximum power point of PV cells, efficiency >99%.
⚫Solar battery working point voltage can be manually or automatically MPPT tracking.
⚫All weather automatic operation,can also be manually or automatically,
⚫Realize”sunrise work and sunset sleep”.
⚫35 kinds protection function. including auto detecting short circuit after power on.
⚫Auto sleep function/pump dry protect/low frequency protection/over load protection and etc.
⚫Full protections:overload,over current, overvoltage,under voltage,short circuit, dry pumping etc.
⚫Output frequency range: V/F(0~3000hz); vector control(0~300HZ).
⚫Overload capacity:60s with 150% of rated current,3s with 180% of rated current.
⚫Speed accuracy:±0.5%(SVC);±0.02%(VC).
⚫Pulse setting input:0Khz~100Khz.
⚫Remote control, support RS232/RS485 protocol, terminal control, analog control.
Before unpacking, please check carefully:
1. Whether the nameplate model of solar drive are consistent with your order ratings. The box contains the solar
drive , user manual.
2. Whether the solar drive is damaged during transportation. If you find any omission or damage, please contact
us or your local supplier immediately.
First-time Use
For the users who use this product for the first time, read the manual carefully. If in doubt concerning some
functions or performances, contact the technical support personnel to ensure correct use.
Due to the continuous improvement of solar inverter, this document will be updated without prior notice.
Solar drive complies with the following international standards.All products have passed the CE certification.
IEC/EN61800-5-1: 2003 Variable speed electric drive system safety requirements;
IEC/EN61800-3: 2004 Variable speed electric drive system, Part 3: The Electro Magnetic Compatibility (EMC)
Standards of Product and its specific testing methods.
Version:V1.0.0

Contents EM15-SP User Manual
Contents
1. Safety Information and Precautions......................................................................................................................... 1
1.1 Safety Information......................................................................................................................................... 1
2. Product Information................................................................................................................................................. 3
2.1 Designation Rules.......................................................................................................................................... 3
2.2 EM15-SP series.............................................................................................................................................. 3
2.3 Product appearance and installation dimension............................................................................................. 4
2.3.1 Product appearance............................................................................................................................. 4
2.3.2 EM15-SP VFD appearance and installing dimension(mm).................................................................4
2.3.3Appearance and installation dimension of external keypad (keypad tray).......................................... 5
3.Installation of variable frequency drive.................................................................................................................... 6
3.1 Installation environment................................................................................................................................ 6
3.2 Installation direction and space...................................................................................................................... 6
3.3 Sketch and Description of Main Circuit Terminals........................................................................................ 7
3.3.1 Function and description of Main Circuit Terminals.......................................................................... 7
3.4 Control Circuit and Main Circuit Terminals Description .............................................................................. 8
3.4.1 Control Circuit and Main Circuit Wiring............................................................................................ 8
3.4.2 Control Circuit Terminal Layout......................................................................................................... 9
3.4.3 Description of control circuit terminals.............................................................................................. 9
3.4 Collection Diagram For Different Motor..................................................................................................... 10
3.5. 1 The wiring of water-level automatic control.....................................................................................11
4 Operation and display............................................................................................................................................. 13
4.1 Instruction of operation and display ............................................................................................................ 13
4.2 Function Code Table.................................................................................................................................... 14
5. Description of Function Codes.............................................................................................................................. 19
F0: Basic Function Parameters Group............................................................................................................... 19
F1 Motor Parameter........................................................................................................................................... 22
F4 Input Terminals............................................................................................................................................. 23
F9 Faults and protection parameters.................................................................................................................. 24
FE Solar water pump control parameters .......................................................................................................... 25
FP User password parameters............................................................................................................................ 28
6. Fault Diagnosis and Solution................................................................................................................................. 29
6.1 FaultAlarm and Countermeasures............................................................................................................... 29
Appendix I. Modbus communication protocol.......................................................................................................... 31
I. About Protocol................................................................................................................................................ 31
II. Application Methods..................................................................................................................................... 31
III. Bus structure................................................................................................................................................ 31

EM15-SP User Manual 1. Safety Information and Precautions
1
1. Safety Information and Precautions
In this manual, the notices are graded based on the degree of danger:
Danger: Indicates that failure to comply with the notice will result in severe personal injury or even death.
Warning: Indicates that failure to comply with the notice will result in personal injury or property damage.
Read this manual carefully so that you have a thorough understanding. Installation, commissioning or maintenance
may be performed in conjunction with this chapter. Our company will assume no liability or responsibility for any
injury or loss caused by improper operation.
1.1 Safety Information
Danger
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
Do not use damaged or missing components solar drive. Failure to comply will result in personal injury.
Please use the electric motor with upper B insulation class. Failure to comply will result in personal injury.
Install the solar drive on incombustible objects such as metal, and keep it away from combustible materials.
Failure to comply may result in a fire.
Wiring must be performed only by qualified personnel under instructions described in this manual. Failure to
comply may result in unexpected accidents.
A circuit breaker must be used to isolate the power supply and the solar drive. Failure to comply may result
in a fire.
Ensure that the power supply is cut off before wiring. Failure to comply may result in electric shock.
Connect the solar drive to ground properly by standard. Failure to comply may result in electric shock. Cover
the solar drive properly before power-on to prevent electric shock.
Do not open the solar inverter’s cover after power-on to prevent from electric shock.
Do not touch the solar drive with wet hand and its peripheral circuit to prevent from electric shock.
Do not touch the terminals of the solar drive (including the control terminals). Failure to comply may result
in electric shock.
Do not touch the U, V, W terminal or motor connecting terminals when solar drive automatically does
safety testing for the external high-voltage electrical circuit. Failure to comply may result in electric shock.
Do not go close to the equipment when selected the restart function. Failure to comply may result in
personal injury.
Do not touch the fan or the discharging resistor to check the temperature. Failure to comply will result
in personal injury.
Signal detection must be performed only by qualified personal during operation

1. Safety Information and Precautions EM15-SP User Manual
2
Warning:
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
When two solar inverters are laid in the same cabinet, arrange the installation positions properly to ensure the
enough cooling effect.
Do not drop wire residue or screw into the solar drive. Failure to comply will result in damage to the solar
drive.
Never connect the power supply cables to the output terminals (U, V, W) of the solar drive. Failure to
comply will result in damage to the solar drive.
Make sure that all the connecting wires comply with the requirement of EMC and the safety standard in
the region. Use wire sizes recommended in the manual. Failure to comply may result in accidents.
Never connect the braking resistor between the DC bus terminals (P+) and (P-). Failure to comply may result
in a fire.
Do not perform the voltage resistance test on any part of the solar drive because such test has been done in
the factory. Failure to comply will result in accidents.
All peripheral devices must be connected properly under the instructions described in this manual. Failure
to comply will result in accidents.
Note the danger during the rotary running of motor when check the parameters. Failure to comply will
result in accidents.
Do not change the factory default settings of the solar drive. Failure to comply will result in damage to the
solar drive.
Avoid objects falling into the solar drive when it is running. Failure to comply will result in damage to solar
drive.
Do not start/stop the solar drive by turning the contactor ON/OFF. Failure to comply will result in damage
to the solar drive.

EM15-SP User Manual 2. Product Information
3
2. Product Information
2.1 Designation Rules
EM15 - SP -015
ATO-EM15
solar drive
SP:Solar Pump
1: DC 310 / AC 1PH 220V In
AC 3PH 220V Output
Product Series Product Type Output Voltage Adaption Motor
1
3: DC 540V/AC 3PH 380V In
AC 3PH 380V Output
5d5: 5.5KW
015: 15KW
Diagram 2-1 Designation rules
2.2 EM15-SP series
Table 2-1EM15-SP Models and technical datas
EM15-SP1[S]
Description
d75
1d5
2d2
004
5d5
7d5
011
015
018
022
030
037
045
DC input (+, -)
Rated power/KW
0.75
1.5
2.2
4
5.5
7.5
11
15
18.5
22
30
37
45
Min. DC voltage/V
120
Max.DC voltage/V
400
Recommended MPPT
range /V
250~400
AC output(U, V, W)
Output current/A
3.8
5.1
9
13
25
32
45
60
75
91
112
150
176
EM15-SP3
Description
d75
1d5
2d2
004
5d5
7d5
011
015
018
022
030
037
045
055
075
090
110
132
160
200
220
250
280
315
355
400
DC input (+, -)
Rated power/KW
0.75
1.5
2.2
4
5.5
7.5
11
15
18.5
22
30
37
45
55
75
90
110
132
160
200
220
250
280
315
355
400
Min. DC voltage/V
280
Max.DC voltage/V
750
Recommended MPPT
range /V
350~750
AC output(U, V, W)
Output current
2.1
3.8
5.1
9
13
17
25
32
37
45
60
75
91
112
150
176
210
253
304
377
426
465
520
585
650
725
Output frequency
0~50/60Hz
Power factor
>0.99
Communication mode
RS485 communication
Protection class
IP20
Ambient temperature
-10℃~ +40℃(ambient temperation at 40℃~50℃，please keep derated use)
Storage temperature
-20℃~ +60℃
Humidity
Smaller than 95%RH, non-condensation
Cooling
Forced Air cooling
Altitude
Lower than 1000 m
Humidity
Less than 95%RH, without condensing
Vibration
Less than 5.9 m/s2 (0.6 g)
1S: DC 310 / AC 1PH 120V In
AC 1PH 220V Output

2. Product Information EM15-SP User Manual
4
2.3 Product appearance and installation dimension
2.3.1 Product appearance
Diagram 2-2 Product appearance (With potentiometer)
2.3.2 EM15-SPvariabe frequency drive appearance and installing dimension(mm)
Diagram 2-3 Appearance and installation dimension of EM15 series (Plastic housing structure)
Matching inverter
Appearance and installing dimension (Unit: mm)
Voltege
Power Range
W
W1
H
H1
D
d
1PH 220V
0.75~2.2kW
120
108
205
195
166
Φ4.5
3PH 220V
0.75~2.2kW
3PH 380V
4~5.5kW
3PH 220V
4~5.5kW
162
148
250
238
191
Φ5.5
3PH 380V
7.5~11kW
3PH 220V
7.5~11kW
223
207
323
307
207
Φ5.5
3PH 380V
15~22kW

EM15-SP User Manual 2. Product Information
5
Diagram 2-4 Appearance and installation dimension of EM15 series (Metal housing structure)
Matching inverter
Appearance and installing dimension (Unit: mm)
Voltege
Power Range
W
W1
H
H1
D
d
3PH 220V
15~18.5kW
300
220
540
500
240
Φ7
3PH 380V
30~37kW
3PH 220V
22kW
340
260
580
540
270
Φ10
3PH 380V
45~55kW
3PH 220V
37~45KW
410
260
610
575
280
Φ12
3PH 380V
75~90kW
3PH 380V
110~132kW
460
320
710
690
335
Φ12
3PH 380V
160~220kW
535
360
885
830
370
Φ12
3PH 380V
250~315kW
650
360
1040
985
415
Φ12
3PH 380V
355~400kW
815
600
1350
1250
445
Φ12
2.3.3Appearance and installation dimension of external keypad (keypad tray)
Diagram 2-5 Appearance and installation dimension of external keypad (keypad tray)
H

3. Installation of variable frequency drive EM15-SP User Manual
6
3.Installation of variable frequency drive
3.1 Installation environment
1. The place with indoor vents or ventilation devices.
2. The environment temperature shall be -10℃~40℃. If the temperature is over 40℃but less than 50℃,
better to take down the cover of variable frequency drive or open the front door of cabinet to facilitate
heat dissipation.
3. Try to avoid high temperature and wet place; the humidity shall be less than 90% without frost deposit.
4. Avoid direct sunlight.
5. Keep away from flammable, explosive and corrosive gas and liquid.
6. No dust, floating fiber and metal particles.
7. Install on the place without strongly vibration. And the vibration should be not over 0.6G, Especially
pay attention to far away from the punching machine, etc.
8. Keep away from electromagnetic interference source.
3.2 Installation direction and space
In order to not affect the service life of variable frequency drive and reduce its performance, note
for its installation direction and space and correctly fasten it.
Diagram3-1 Ventilating duct installation dimension diagram of variable frequency drive
Power class
Installation dimension
A
B
≤7.5kW
≥ 20mm
≥ 100mm
11kW - 30kW
≥ 50mm
≥ 200mm
≥ 37kW
≥ 50mm
≥ 300mm
Please install the variable frequency drive vertically, to send out the heat upward, and pay attention to
direction of variable frequency drive to avoid inversion.
If there are several units of variable frequency drive installed, please install them side by side, do not to
install up and down.

EM15-SP User Manual 3. Installation of variable frequency drive
7
3.3 Sketch and Description of Main Circuit Terminals
3.3.1 Function and description of Main Circuit Terminals
Single phase 220V output：EM15-SP1S-d75 ~ EM15-SP1S-011
Three phase 220V output：EM15-SP1-d75~EM15-SP1-011
Three phase 380V output：EM15-SP3-d75～EM15-SP3-022
Three phase 380V output：EM15-SP3-030～EM15-SP3-090
Three phase 380V output：EM15-SP3-110～EM15-SP3-400
Terminal symbol
Function description
L,N or R,T
DC power input terminals
P+,PB
Braking resistor connectin
P,P+
External DC reactor connecting terminals,shorted by bronze before delivery
P+,P-
DC power input terminals；External brake unit DC output terminal
or E/PE
Grounding terminal
U,V,W
Three-phase AC power output terminals

3. Installation of variable frequency drive EM15-SP User Manual
8
3.4 Control Circuit and Main Circuit Terminals Description
3.4.1 Control Circuit and Main Circuit Wiring
Diagram3-2 EM15-SP control circuit and main circuit wiring

EM15-SP User Manual 3. Installation of variable frequency drive
9
3.4.2 Control Circuit Terminal Layout
Diagram3-3 EM15-SP control circuit terminal sketch diagram
3.4.3 Description of control circuit terminals
Type
Terminal
Symbol
Terminal
Name
Terminal function description
Power
Supply
+10V-GND
External
+10V power
supply
Provide +10V power supply to external unit. Maximum output
current:10Ma
Generally, it provides power supply to external potentiometer
with resistance range of 1 kΩ~5kΩ
+24V-COM
External
+24V power
supply
Provide +24 V power supply to external unit. Generally, it
provides power supply to DI/DO terminals and external
sensors.Maximum output current: 200 mA
PLC
External
power supply
input
terminals
It connect with +24V default
Analog
input
AI1-GND
Analog input
1
1. Input range: DC 0V~10V/ 0mA~20mA(decided by jumper
AI1/AI2 on the control board); AI3: DC -10V~+10V
2. Impedance: 22 kΩ (voltage input), 500 Ω (current input)
AI2-GND
Analog input
2
AI3-GND
Analog input
3
Digital
input
DI1-COM
Digital input 1
1. Optical coupling isolation, compatible with dual polarity
input
2.Input Impedance: 2.4 kΩ
3. Voltage range for level input: 9V~30 V
DI2-COM
Digital input 2
DI3-COM
Digital input 3
DI4-COM
Digital input 4
DI5-COM
Digital input 5
HDI-COM
High Speed
Pulse Input
Maximum input frequency: 100 kHz
Analog
output
AO1-GND
Analog output
1
Voltage or current output is decided by jumper AO1/AO2.
Output voltage range: 0V~10 V
Output current range: 0mA~20 mA
AO2-GND
Analog output
2
FMP- COM
High Speed
Pulse Output
Constrained by function code b4-00 "FMP terminal output
mode selection" as the high-speed pulse output, the highest
frequency is 100kHz; when use as an open collector output,

3. Installation of variable frequency drive EM15-SP User Manual
10
Type
Terminal
Symbol
Terminal
Name
Terminal function description
specifications is the same as DO.
Relay
output
TA1-TB1
NC terminal
Contact driving capacity: 250 VAC, 3 A, COSø= 0.4
DC 30 V, 1 A
TA2-TB2
TA1-TC1
NO terminal
TA2-TC2
Auxiliary
interface
PG card interface
PG cards: Open-collector, differential are selectable options.
Communications expansion
Reversed
External keypad interface
Connected to an external keypad
Jumper
PE-COM
COM grounding PE selection ,default connection.
In the case of interference, connecting PE to COM can improve
anti-interference
PE-GND
GND grounding PE selection ,default connection.
In the case of interference, connecting PE to COM can improve
anti-interference.
AI1
AI1 output selection.
Voltage or Current output, voltage output by default.
AI2
AI2 output selection.
Voltage or Current output, current output by default.
AO1/AO2
AO1/AO2 output selection.
Voltage or Current output, voltage output by default.
458
485 communication resistor selection, default connection ON.
In the case of interference, anti-interference can be improved.
3.4 Collection Diagram For Different Motor
COM
Photovoltaic cell
Water Tank
Pump
Water Pipe
+-U V W
EM15-SP
Control Terminal
DI1 DI2
Note: For the EM15-SP1S series,
U and V as single Phase 220V
output terminal.
Diagram3-4 220V three phase installed without water level sensor (PV Input)

EM15-SP User Manual 3. Installation of variable frequency drive
11
COM
Control Terminal
Water Tank
Pump
Water Pipe
Photovoltaic cell
+-U V W
EM15-SP
DI1 DI2 DI4 DI5
Diagram3-5 Diagram of 3phsae inverter connection method (PV Input)
3.5. 1 The wiring of water-level automatic control
The wiring for floater water-level switch connected by cable
The common port, which using floate water-level switch connected by cable, is fed to the terminal “COM”
of EM15-SP.And then, connected to DI1.
DI1
COM
EM15-SP
Inverter
DI1
COM
EM15-SP
Inverter
High water-level
Low water-level
Diagram3-6 Diagram of Low water level and high water level
Remarks:
When the actual water-level in the wells is higher than the horizontal line of high water-level, DI1 will be
connected to the “COM”as well as controller automatically will start the pump. On the contrary, if the
actual water-level is lower than the horizontal line of low water-level, DI1 will be disconnected from

3. Installation of variable frequency drive EM15-SP User Manual
12
“COM”as well as controller automatically stop the pump to prevent anhydrous idling.
The wiring for floater water-level switch mounted on a side
The floater water-level switch mounted on a side is the normally open contact to output and its common
wire is connected to the terminal COM of EM15-SP inverter. At the same time, the low level-water wire is
connected to terminal DI4 and the high water-level wire is connected the terminal DI5.
EM15-SP
EM15-SP
EM15-SP
EM15-SP
DI5
Low water-level
High water-level
COM DI5 COM
DI4 COM DI4 COM
Detector switch of
high water-level
Detector switch of
low water-level
Detector switch of
high water-level
Detector switch of
low water-level
Diagram3-7 Diagram of Low water level and high water level
Remarks:
When the actual water-level in the reservoir is lower than horizontal line of low water-level, DI4 and DI5
will be disconnected from the COM as well as controller automatically strat the pum. On the contrary, if the
actual water-level is higher than the horizontal line of high water-level, DI4 and DI5 will be connected to
COM as well as controller automatically stop the pump to prevent water overflow.
Notice:
1. If only use one detection signal of water-level in the reservoir, DI4 and DI5 must be connected together
by conductor.

EM15-SP User Manual 4. Operation and Display
13
4 Operation and display
4.1 Instruction of operation and display
Diagram 4-1 Operating panel
No.
Name
Function
LED display area
The 5-digit LED display is able to display the set frequency, output frequency, monitoring
data and fault codes.
Unit / Status
Indicator area
Hz
Frequency unit
A
Current unit
V
Voltage unit
STOP/
RUN
OFF indicates that the variable frequency drive is in the stop state and ON
indicates that the variable frequency drive is in the running state.
FWD/REV
It is Forward/Reversal indicator, ON indicates forward rotation.
LOCAL
/REMOTE
It indicates whether the variable frequency drive is operated by operation
keypad, terminals or remoter (communication). OFF indicates keypad
operation control state; ON indicates terminals operation control state;
Blinking indicates remote operation control state.
TRIP
/ALARM
Tunning/ Torque Control/Fault indicator
When the indicator is ON, it indicates torque control mode. When the
indicator is blinking slowly, it indicates the auto-tuning state. When the
indicator is blinking quickly, it indicates the fault state.
Encoder knob
Frequency, data or function code increase or decrease; the encoder knob has the
confirmation key function
Operation key area
Programming key: Enter or exit menu level I.
Confirmation key: Enter the menu interfaces level by level, and confirm the
parameter setting.
Multi-function key: Perform function switchover according to the setting of
b9-01
Shift key: Select the displayed parameters in turn in the stop or running
state, and select the digit to be modified when modifying parameters.
Increment key: Increase data or function code.
Decrement key: Decrease data or function code.
Running key: Start the variable frequency drive in the keypad control mode.
Stop/Reset key: Stop the variable frequency drive when it is in the running
state and perform the reset operation when it is in the fault state. The functions
of this key are restricted by b9-00.

4. Operation and Display EM15-SP User Manual
14
4.2 Function Code Table
If FP-00 set to a non-zero number, parameter protection is enabled. You must write in correct user password to
enter the menu.
To cancel the password protection function, enter with password and set FP-00 to 0。
The parameter menu under the user-defined parameter mode can directly enter without password.
A is variable frequency drive system parameter. Group “F” is basic function parameters .Group “U” is
monitoring function parameters.
Code
Name
Description
Default
F0: Basic function parameters
F0-00
G/P type selection
1: G type(Constant torque load models )
2: P type(Fan, water pump load models )
Model
dependent
F0-02
Command source selection
0: Keypad control (LED off)
1: Terminal control (LED on)
2: Communication control (LED blinking)
0
F0-03
Main frequency source X
selection
0: Digital setting (Preset frequencyF0-08, UP/DOWN
modifiable, no-record after power off)
1: Digital setting (Preset frequencyF0-08 ，UP/DOWN
modifiable, record after power off)
2: AI1
3: AI2
4: Keypad potentiometer
9: Communication setting
4
F0-08
Preset frequency
0.00Hz～maximum frequency(F0-10)
50.00Hz
F0-09
Rotation direction
0: Forward；FWD/REV lights off；
1: Reverse；FWD/REV lights on；
0
F0-10
Maximum frequency
50.00Hz～500.00Hz
50.00Hz
F0-11
Source of frequency
upper limit
0: Set by(F0-12)
1: AI1
2: AI2
3: AI3
5: Communication setting
0
F0-12
Frequency upper limit
Frequency lower limit(F0-14)～maximum frequency(F0-10)
50.00Hz
F0-13
Frequency upper limit offset
0.00Hz～maximum frequencyF0-10
0.00Hz
F0-14
Frequency lower limit
0.00Hz～frequency upper limit(F0-12)
0.00Hz
F0-15
Carrier frequency
0.5kHz～16.0kHz
Model
dependent
F0-16
Carrier frequency adjustment
with temperature
0: No
1: Yes
1
F0-17
Acceleration time 1
0.00s～650.00s(F0-19=2)
0.0s～6500.0s(F0-19=1)
0s～65000s(F0-19=0)
Model
dependent
F0-18
Deceleration time 1
0.00s～650.00s(F0-19=2)
0.0s～6500.0s(F0-19=1)
0s～65000s(F0-19=0)
Model
dependent
F0-19
Acceleration/Deceleration
time unit
0: 1s
1: 0.1s
2: 0.01s
1
F0-23
Record of digital setting
frequency of power failure
0: not record
1: record
0
F0-25
Acceleration/Deceleration time
base frequency
0: Maximum frequency (F0-10)
1: Set frequency
2: 100Hz
0
F0-26
Base frequency for UP/ DOWN
modification during running
0: Running frequency
1: Setting frequency
0
F0-27
Binding command source to
frequency source
Unit's digit: Binding keypad command to following frequency
source.
0000

EM15-SP User Manual 4. Operation and Display
15
Code
Name
Description
Default
0: No binding
1: Frequency source by digital setting
2: AI1
3: AI2
4: Keypad potentiometer
9: Communication setting
Ten's digit:: Binding terminal command to frequency source.
Hundred's digit: Binding communication command to frequency
source.
F0-28
Serial communication protocol
0: MODBUS-RTU protocol
0
F1: Motor parameter
F1-00
Motor type selection
0: General asynchronous motor
1: Variable frequency asynchronous motor
0
F1-01
Rated motor power
0.1kW～1000.0kW
Model
dependent
F1-02
Rated motor voltage
1V～2000V
Model
dependent
F1-03
Rated motor current
0.01A～655.35A(variable frequency drive power≤55kW)
0.1A～6553.5A(variable frequency drive power >55kW)
Model
dependent
F1-04
Rated motor frequency
0.01Hz～maximum frequency
Model
dependent
F1-05
Rated motor rotational speed
1rpm～65535rpm
Model
dependent
F4: input terminals parameters
F4-00
DI function selection
0: No function
1: Forward RUN (FWD) or running command
2: Reverse RUN (REV) or the direction of FED/REV
4: Forward JOG(FJOG)
5: Reverse JOG(RJOG)
8: Free stop
9: Fault reset(RESET)
10: Run pause
11: Normally open(NO) input of external fault
33: Narmally closed (NC) input of external fault
36: External STOP terminal 1
44: User-defined fault 1
47: Emergercy stop
48: External STOP terminal 2
51: Full-water detection 1
52: Full-water detection 2
53: MPPT stop/ Photovoltaic control stop
01
F4-01
DI2 function selection
09
F4-02
DI3 function selection
53
F4-03
DI4 function selection
51
F4-04
DI5 function selection
52
F4-05
DI6 function selection
02
F4-13
AI curve1 Min. input Value
00.00V～F4-15
00.00V
F4-14
Corresponding setting of AI
curve1 Min.input
-100.0%～+100.0%
000.0%
F4-15
AI curve1 input maximum value
F4-13～+10.00V
10.00V
F4-16
Corresponding setting of AI
curve1 input maximum value
-100.0%～+100.0%
100.0%
F4-17
AI1 input filter time
0.00s～10.00s
00.10s
F4-18
AI curve 2 Min. input Value
0.00V～F4-20
00.00V
F4-19
Corresponding of AI curve 2
Min. input Value
-100.0%～+100.0%
000.0%
F4-20
AI curve2 input maximum value
F4-18～+10.00V
10.00V
F4-21
Corresponding of AI curve2
input maximum value
-100.0%～+100.0%
100.0%
F4-22
AI2 filter time
0.00s～10.00s
00.10s
F4-35
DI1delay time
0.0s～3600.0s
0.0s
F4-36
DI2 delay time
0.0s～3600.0s
0.0s
F4-37
DI3 delay time
0.0s～3600.0s
0.0s

4. Operation and Display EM15-SP User Manual
16
Code
Name
Description
Default
F9: Fault and Protection parameters
F9-09
Fault auto reset times
0～20
20
F9-10
Relay action selection during
fault auto reset
0: Not act
1: Act
0
F9-11
Time interval of fault auto reset
0.1s～100.0s
5.0s
F9-12
Input phase loss
protection/contactor energizing
protection selection
Unit's digit: Input phase loss protection
Ten's digit: Contactor energizing protection
0: Disabled
1: Enabled
00
F9-13
Output phase loss protection
0: Disabled
1: Enabled
0
F9-14
Fault types
0: No fault
2: Over current during acceleration
3: Decelerated current during acceleration
4: Over current at constant speed
5: Overvoltage during acceleration
6: Decelerated voltage during deceleration
7: Overvoltage at constant speed
9: Less voltage fault
10: variable frequency drive overload
11: Motor overload
12: Power input phase loss
13: Power output phase loss
14: IGBT Module overheat
15: External equipment fault
16: Communication fault
18: Current detection fault
21: EEPROM read- write fault
22: variable frequency drive hardware
fault 23: Short circuit to ground
26: Accumulative running time reached
27: User-defined fault 1
28: User-defined fault 2
29: Accumulative power-on time reached
40: Fast current limit fault
43: Motor over-speed
55: Load distribution slave failure
00
F9-37
Frequency of fault
－
－
F9-38
Current of fault
－
－
F9-39
DC Bus voltage of fault
－
－
F9-40
Input terminals status of fault
－
－
F9-41
Output terminal status of fault
－
－
F9-42
variable frequency drive
status of fault
－
－
F9-43
Power-on time of fault
－
－
F9-44
Running time of fault
－
－
FE: parameters for solar water pump control
FE-00
PV inverter Selection
0: Disabled
1: Enabled
1
FE-01
Vmpp voltage Selection
0: Manual setting
1: MPPT Automatic algorithm tracking
1
FE-02
Vmpp voltage manual
Reference value
0-1000.0V
500.0V
FE-03
Motor Selection
0: General three phase ac motor
1: Single phase motor with capacitor
2: Single phase motor without capacitor
0
FE-04
CVT proportional gain 1
0.0%-999.9%
100.0%

EM15-SP User Manual 4. Operation and Display
17
Code
Name
Description
Default
FE-05
CVT Integral gain1
0.0%-999.9%
100.0%
FE-06
Reserved
--
--
FE-07
Reserved
--
--
FE-08
Reserved
--
--
FE-09
Reserved
--
--
FE-10
Mppt search upper limit voltage
0-1000.0V
750.0V
FE-11
Mppt search lower limit voltage
0-1000.0V
300.0V
FE-12
MPPT search gain
0%-500%
100%
FE-13
MPPT search time interval
0.0-10.0s
1.0sec
FE-14
Reserved
0
0
FE-15
Reserved
0
0
FE-16
Dormancy voltage
0.0-1000.0V
300.0V
FE-17
Dormancy wake-up voltage
0.0-1000.0V
350.0V
FE-18
Dormancy wake-up time
0-30000sec
60sec
FE-19
detection frequency of low
frequency protection
0.00Hz～300.00Hz
10.00Hz
FE-20
Detection time of low frequency
protection
0-30000s
10sec
FE-21
low frequency protection
automatic recovery time
0-30000s
60sec
FE-22
detection current of dry
pumping protection
0.0-999.9A
0.0A
FE-23
detection time of dry pumping
protection
0-30000s
10sec
FE-24
automatic recovery time of dry
pumping protection
0-30000s
60sec
FE-25
detection current of overcurrent
protection
0.0-999.9A
0.0A
FE-26
detection time of overcurrent
protection
0-30000s
10sec
FE-27
over current protection
automatic recovery time
0 -30000s
60sec
FE-28
Min. power protection value
0.00kw - 650.00kw
0.00kw
FE-29
Detection time of Min. power
protection
0 - 30000s
0sec
FE-30
Min. power protection
automatic recovery time
0 - 30000s
0sec
FE-31
Full water detection mode
0: terminal
1: AI1
2: AI2
0
FE-32
Analog full-water detection
Thresholds
0-100.0%
25.0%
FE-33
detection time of full-water
protection
0-30000s
10sec
FE-34
exit time of full-water protection
0-30000s
60sec
FE-35
analog sensor damaged
Thresholds
0-100.0%
0.0%
FE-36
PV DC correction coefficient
0.0-200.0%
100.00%
FE-37
PV DC correction offset
-100.00A-100.00A
0.00A
FE-38
power curve point 0
0.0kw-999.9kw
0.5kw
FE-39
power curve point 1
0.0kw-999.9kw
1.0kw
FE-40
power curve point 2
0.0kw-999.9kw
1.5kw
FE-41
power curve point 3
0.0kw-999.9kw
2.0kw
FE-42
power curve point 4
0.0kw-999.9kw
2.5kw
FE-43
flow curve point 0
0.0-999.9m^3/h
0.0 m^3/h
FE-44
flow curve point 1
0.0-999.9m^3/h
5.0 m^3/h
FE-45
flow curve point 2
0.0-999.9m^3/h
10.0m^3/h
FE-46
flow curve point 3
0.0-999.9m^3/h
15.0m^3/h
FE-47
flow curve point 4
0.0-999.9m^3/h
20.0m^3/h
