ATOMI Smart AC Controller AT1310 User manual

Wi-Fi
Date Code: 01/19 (v.1.0)
Watch Video
Open your smaphone camera
and point it at the QR Code
Download Free APP
WE
CAN
HELP
Can’t connect? Need help?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Sma AC Controller
User Manual
Call 1-800-757-1440
Mon-Fri 9:00 a.m. - 5:00 p.m. EST (US)
or email us at suppo@atomiusa.com

The atomi Sma AC Controller controls your AC’s
power, temperature, mode and fan speed from your
phone anytime, anywhere in the world! Set weekly
schedules, turn your air conditioner on and o
automatically, and much more.
Sma AC Wall Plate
10 Micro-USB Cable
Sma AC Controller
User Manual
1 2
Thankyou for purchasing
the atomi Sma AC Controller.
Inside the box you’ll find:
Specifications
Input: 125V~60Hz 15A 1875W (Resistive)
USB Input: 100-125V~50/60Hz 0.3A
USB Output: 5V 1A
Before you begin
1. Know your Wi-Fi network and password
2. Make sure that you are operating on:
• iPhone®8 or higher and iOS®8 or higher.
Any previous iPhone®or iOS®may experience
slower connections.
• Android™ 4.1x or higher.
3. Make sure you’re connected to a 2.4GHz Wi-Fi
network (atomi Sma can’t connect to 5GHz
networks)
Compatibility
The atomi Sma AC Controller can be installed to
control all window or free-standing air conditioners
with a remote control.

Connect the Micro-USB Cable
to the Sma AC Controller and
the Sma AC Wall Plate.
Plug your atomi Sma AC
Wall Plate into any standard
grounded outlet.
*Micro-USB and SmaAC Controller must be plugged-in before Wi-Fi setup.
*Keep the Sma AC Controller close to the Sma AC Wall Plate on initial setup.
3 4
*Light indicatorwill blinkfor two seconds to signal loading
Step 1:
Plug in
Step 2:
Connect

Download the atomi sma app from the
App Store or Google Play.
5 6
Step 3:
Download App
Step 4:
Register
Enter your mobile phone
number or email address.

7 8
Step 5:
Add Device
Enter the verification
code and create
a password.
Log in to
the app.
Select “Add Device”
or click (+) at the top
right corner of the
devices screen.
Choose “Sma AC
Controller” from the
device list.

Hold the power buon
for five seconds until the indicator light stas
flashing rapidly, then press “Continue”.
*Make sure you are in close proximityof the router
910
Enter your Wi-Fi
network and
password.
The atomi sma
app will connect
your device.

No LCD
Screen
Page 14-18
with LCD
Screen
Page 19-21
Based on the style of your AC's remote
control, choose the correct option above
and read the corresponding pages.
Plug in your AC cable into the
Sma AC Wall Plate
11 12
Step 6:
Plug in your AC
Step 7:
AC Remote
Control Setup

Point your AC Remote at the Sma AC Controller.
Make sure that the remote and your AC are
within one meter from the Sma AC Controller.
Tip: The Sma AC Controller will blink blue
when the remote pairing is successful.
No LCD Screen
Remote Control
13 14
Select “No LCD
Screen” and
click “Continue”.
Click “Continue”
to begin AC
remote pairing.

15
*Function will be confirmed once ADDED screen is displayed *Function will be confirmed once ADDED screen is displayed
16
Press the power
buon on the
AC remote.
Press the
temperature “up”
buon on the
AC remote.
Press the
temperature “down”
buon on the
AC remote.
Press the fan
speed buon on
the AC remote.

18
Mode
Selects the
operating mode
such as cool,
dry or fan.
Down
Lowers
temperature.
Up
Increases
temperature.
Power
Turns the AC
on and o.
Schedule
Sets up weekly
schedules that fit
your lifestyle.
Countdown
Automatically
powers the AC
on and o based
on a timer.
Usage
Monitors the
electric
current usage
of your AC.
Fan Speed
Adjusts the fan
speed between
low, medium
or high.
Room Temperature
Displays current room temperature.
*Does not display AC temperature.
*Function will be confirmed once ADDED screen is displayed
17
Press the mode
speed buon on
the AC remote.
Setup is complete!
Enter the remote name
and select save.

With LCD Screen
Remote Control
19 20
This mode allows for unlimited
presets. Create your favorite
temperature seings.
*We suggest naming your presets.
*AC remote with LCD screen only suppos preset modes.
Select
“with LCD Screen”
and click “Continue”.
Point your AC Remote
at the AC Sma
Controller and
Click “Next”.
Set your favorite
AC seings on your
AC remote and
Click “Next”.
Press the power
buon on your
AC Remote.
Enter preset name
and select save.

Reset the Sma AC Controller
To reset the Sma AC Controller, unplug the Sma
AC Controller and plug it back in. Press and hold the
power buon for ten seconds.
- Reset one time (press and hold) to reach Easy
Mode (Fast blinking blue)
- Reset two times (press and hold) to reach AP Mode
(Slow blinking blue)
21 22
Room Temperature
Displays current room temperature.
*Does not display AC temperature.
Power
Turns the AC
on and o.
Schedule
Sets up weekly
schedules that fit
your lifestyle.
Countdown
Automatically powers
the AC on and o
based on timer.
Usage
Monitors the
electric
current usage
of your AC.

Troubleshooting
Cannot connect to your Wi-Fi network.
Make sure you entered the correct Wi-Fi password
during the Wi-Fi setup. Checkwhether there are
problems with your internet connection. If the Wi-Fi
signal is too weak, reset your Wi-Fi router and try again.
Setup is not working properly.
1. Close all apps that are running in the background
then re-open the atomi sma app.
2. Uninstall and reinstall the atomi sma app then
repeat the setup process. For setup instructions,
please refer to page 8.
3. Reset or restore your Sma AC Controller to factory
default seings. Please go to page 22 for the reset
instructions.
IMPORTANT: Reseing your Sma AC Controller to its default factory
seings will delete all the data that was saved in it. You will need to set up
your Sma AC Controller again. Please refer to page 8 for the setup
instructions.
Setup completed but the app is not responding.
Make sure to keep the Sma AC Controller in the line
of sight of your air conditioner.
Temperature control is not changing.
If temperature is not changing on the atomi sma app
it’s because you are in the wrong MODE. Push the
MODE buon until you are in the cooling mode.
Wi-Fi pairing is not working.
Make sure the Micro-USB Cable and Sma AC
Controller are plugged in before the Wi-Fi setup.
AC remote is not pairing with the app.
For initial setup, make sure that the Sma AC
Controller is within one meter of your air conditioner.
AC temperature is not showing on the app.
The AC temperature shown on the app monitors your
room temperature and not your AC temperature.
The AC remote control app is slow.
The AC remote control app mayfunction slower
depending on the Wi-Fi strength.
23 24

25 26
FCC Notice:
This device complies with Pa 15 of the FCC Rules.
Operation is subject to the two following conditions:
1. This device may not cause harmful inteerence.
2. This device must accept any inteerence received,
including inteerence that may cause undesired
operation.
Note: This equipment has been tested and found to
complywith the limits for a Class B digital device,
pursuant to Pa 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful inteerence in a residential installation.
Impoant Information:
Before installing, read and follow all precautions,
including the following:
CAUTION: Suitable for indoor use only.
DO NOT IMMERSE IN WATER.
DO NOT EXCEED RATED CA PAC I TY.
This product can exposeyou to chemicals including Pb,
which is known to the State of California to cause bih
defects or other reproductive harm. For more information,go
to www.P65Warnings.ca.gov.
For questions or concerns,
email us at suppo@atomiusa.com
Manufactured and marketed by Atomi Inc.
10 West 33rd St., New York, NY 10001
atomi™ is a trademarkof Atomi Inc.
Designed by atomi in New York. Made in China.
One-year limited warranty from the date of purchase against
defects in material and workmanship.
Google is a trademarkof Google LLC. Amazon, Alexa and all
related logos are trademarks of Amazon.com, Inc. or its aliates.
WARNING
