Atomos AtomX Cast User manual

Download the latest firmware for
your Ninja V or Ninja V+ to enable the
optimum functionality for AtomX CAST
atomos.com/product-support
To access more information about AtomX CAST
or AtomX Accessories for you Ninja V or Ninja V+
scan the QR code or visit atomos.com/accessories
Register for firmware update notifications
Create your account at my.atomos.com
This will ensure you receive notifications of the
latest firmware updates for your AtomX CAST
my.atomos.com/register

Introduction
Thank you for purchasing the AtomX CAST Switching and
Streaming Dock that will transform the Ninja V and Ninja V+
into a 4 input HDMI video switcher.
Dock your Ninja V/V+ on to the AtomX CAST, connect your
inputs and unlock multicam production and streaming to
deliver broadcast quality production to your choice of local or
global platforms/CDNs.
Checklist
q 1 x AtomX CAST
q 1 x AtomX SSDmini handle
q 1 x USB to USB-C cable
q Quick Start Guide
You will also need (sold separately)
q Atomos Ninja V / Ninja V+ Monitor-Recorder
q HDMI Cable/s
You will require HDMI cables to connect your input devices
to both the AtomX CAST and Ninja V/Ninja V+. Atomos have
a range of HDMI cables with die cast connectors and coiled
cables in a range of lengths and connections (sold separately).
Dock, connect and power-up
NOTE: AtomX CAST will power the docked Ninja V/V+
device. AtomX CAST is reliant on DC power from the
international DC power supply included with the Ninja V
or Ninja V+ you are using with this device OR alternatively,
AtomX CAST and the docked Ninja V or Ninja V+ can be
powered via a D-Tap power source using the optional D-Tap
battery cable (ATOMDTPCB1). Ensure you have a suitable
power supply ready to commence operation.
Connecting Ninja V / Ninja V+
NOTE: Before attempting to attach monitor, ensure locking
arm is released to allow docking. Never force or apply
undue pressure when attaching your monitor. When
correctly aligned the devices will lock together eortlessly.
1. Rotate the thumb screw to release CAST’s locking arm
(used to secure Ninja V/V+ once docked).
2. With the Ninja V/V+ in hand, align the battery slot of Ninja
with expansion port of CAST and gently slide in to place in
the same fashion as connecting a battery. The Ninja V/V+ will
engage with a reassuring click of the battery release button.
3. Move locking arm into position, align with Ninja top mount
and rotate the thumbscrew to secure the locking arm in place.
Attach Power
With the docking process complete, insert the DC jack into the
DC port on the rear of the CAST and rotate the locking nut to
secure it in place. The DC connection will provide power to both
the AtomX CAST and the Ninja V/V+.

Release /Disconnect Physical features
To remove the Ninja V/V+ from the AtomX CAST, release
thumbscrew to disconnect the locking arm, press the battery
release button on the rear right hand side of the Ninja V/V+
to disengage the Xpansion port and gently slide the unit
downwards. Once Ninja device is removed, fold the locking
arm down and rotate the thumbscrew to secure for transit.
Note: Failure to fold the arm back in to place could result in
damage to the unit.
Using AtomX SSDmini
Included with the AtomX CAST is a SSDmini handle. For ease
of removing the SSDmini from the Ninja V/V+ when docked in
the CAST it is advised to attach the handle to the SSDmini.
Mount Points
AtomX CAST features a 3/8” screw hole with 1/4” adapter and
anti-rotational design on the base of the device. This allows
you to secure the device when used on cage/rail setups or to
secure on a DIT Cart.
The Locking Arm of the AtomX CAST utilizes the top mount
of the docked Ninja device to ensure stable connection and
reduce any chance of damage to expansion ports.
CAST i/o
A. DC Input Jack - for use with the original Atomos DC power
supply provided with the Ninja V or Ninja V+.
B. HDMI Input 1, 2, 3, 4 - Support for inputs in 1080, both
interlaced and progressive up to 60 frames per second.
C. PRG Out - Provides a HDMI broadcast quality output in
either 1080i or 1080p program out of the switched feed, with
graphics and picture-in-picture eect.
D. CAST Out - Connect the provided USB-C cable to the
CAST Out and connect to your Mac/PC. The CAST Out
provides program out as a plug and play UVC source that
appears as a high quality webcam in your chosen application.
E. Ventilation - Do not obstruct
F. Drive Access Port - Recess allows easy insertion and
removal of HDD/SSD whilst Ninja device attached to dock
G. CAST Locking Arm - Secures Ninja device
H. AtomXpansion Port
Docking the Ninja V/V+ into the AtomX CAST will utilise battery
locking system to engage the unit in to the dock. After releasing
the locking arm Press the release button to disengage the
Ninja V/V+ from the AtomX CAST.
I. Channel Cue/Select Buttons
Cue / select input channels. Refer to User Manual for more info.
J. Function Buttons
Navigate menus /settings. Refer to User Manual for more info.

A. DC Input
E. Ventilation
F. Drive Access Port
G. CAST locking arm
I. Channel Cue/Select
J. Function Buttons
H. AtomXpansion Port
B. HDMI Inputs C. PRG Out D. CAST Out
K. When docked into the AtomX CAST
the HDMI input on the Ninja V/V+ is
NOT IN USE.
L. HDMI OUT - The HDMI Output
of the Ninja V/V+ can be congured
for use as Program, Preview or
Multiview output. This is congured
from within the menu of the Ninja V/V+.
M. Release Button - press the battery
release button on the rear right hand
side of the Ninja V/V+ to disengage
the AtomXpansion Port.
MK
L

Warranty & ConditionsSafety Instructions
The AtomX CAST is designed to a high standard, but there are some things you
should be aware of that will prolong the life of the unit and for your own safety.
Using the AtomX CAST safely
Although the AtomX CAST is very lightweight compared to all the devices it
replaces, it is still a solid object that could cause injury if misused.
• Always make sure that the AtomX CAST is mounted securely and is unable
to fall onto anyone nearby. This is especially important when there are
children present who might be tempted to pull on cables.
• Always ensure that cables that run to the AtomX Cast are clearly visible and
do not present a trip hazard.
• Do not place on uneven or unstable surfaces.
• Do not insert anything but a Atomos Master Caddy II or AtomX SSDmini in
the drive slot on the rear of the Ninja V/Ninja V+.
• Do not touch the Expansion Port with sharp, metallic or abrasive objects.
• Do not expose to strong electrical or magnetic elds.
• Do not expose to liquids, rain or moisture.
• Do not dispose of the AtomX CAST in municipal waste and do not
incinerate it, always follow local regulations for safe disposal.
Notifications
USA
WARNING: This product contains the chemical lead (Pb) which is known to the
State of California to cause cancer.
For more information, visit p65warnings.ca.gov
Notice
Copyright ©2021 ATOMOS Global Pty Ltd (‘referred to as ATOMOS’). All
rights reserved. All information in this document is subject to change without
notice. No part of the document may be reproduced or transmitted in any
form, or by any means, electronic or mechanical, including photocopying or
recording, without the express written permission of ATOMOS. A reference
to ATOMOS includes its related entities, subsidiaries and parent company.
Trademarks
AtomX CAST is a registered trademark of ATOMOS Pty Ltd. All other
trademarks are the property of their respective holders.
International Hardware Limited Warranty (1 Year Standard)
ATOMOS warrants that:
• The main product, or any external accessories, will be free from defects in
materials and workmanship for a period of 1 year from the date of purchase.
If during the warranty period the product is shown to be defective ATOMOS
may at its option:
a) replace the goods or supply equivalent ones, b) repair the goods, c) pay
the cost of replacing the goods or of acquiring equivalent ones or d) paying
the cost of having the goods repaired; The customer must notify ATOMOS
of any defect in the goods in writing prior to the expiry of the warranty
periods set out above. The customer will be solely responsible for returning
the goods to ATOMOS or its authorized distributor. Upon acceptance of a
warranty claim by ATOMOS, where ATOMOS repairs or replaces the goods,
it will be responsible for reasonable shipping costs incurred in sending the
goods to the Customer, provided that customer is located in a country in
which ATOMOS has an authorized distributor or repair center or agent.
Warranty Exclusions
This warranty applies only to defects in workmanship and does not cover
defects caused by:
• A failure to comply with the then current operating instructions
issued by ATOMOS;
• Neglect;

Warranty & Conditions CONT.
• Improper or negligent acts or omissions;
• Unauthorized repairs or attempted repairs;
• Tampering with or modication of the goods;
• Connection to incompatible equipment or power sources;
• Exposure to water or weather;
• Exposure to magnetic elds or corrosive liquids or substances;
EXCEPT AS STATED IN THIS WARRANTY, ATOMOS, IT’S VENDORS,
AGENTS, RESELLERS AND DISTRIBUTORS DISCLAIM IN THEIR ENTIRETY
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION ALL WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. THE REMEDIES OUTLINED IN THIS WARRANTY
ARE THE EXCLUSIVE REMEDY A CUSTOMER HAS ARISING FROM
DEFECTIVE GOODS WHICH ARE SUBJECT TO THE WARRANTY. ATOMOS
DOES NOT WARRANT THAT THE GOODS WILL OPERATE IN A MANNER
WHICH IS ERROR FREE, OR UNINTERRUPTED.
Software License Agreement
IMPORTANT, PLEASE READ CAREFULLY. THIS IS A LICENSE
AGREEMENT.
This ATOMOS software, related documentation, any included sample
images and other les (the “Software”), is protected by copyright laws and
international copyright treaties, as well as other intellectual property laws and
treaties. The Software is licensed, not sold.
This End User License Agreement (“EULA”) is a legal agreement between
you (either an individual or a single entity) and ATOMOS with regard to
the copyrighted Software provided with this EULA. Use of the Software
provided to you by ATOMOS in whatever form or media, will constitute
your acceptance of these terms, unless separate terms are provided by the
software supplier, in which case certain additional or different terms may
apply. If you do not agree with the terms of this EULA, do not download,
install copy or use the Software. By installing, copying or otherwise using the
Software, you agree to be bound to the terms of this EULA. If you do not agree
to the terms of this EULA, ATOMOS is unwilling to license the Software to you.
1. Eligible licensees. This Software is available for license solely to
purchasers of the AtomX Cast, who have purchased a unit manufactured by
ATOMOS and purchased through an ATOMOS authorized reseller, with no
right of duplication or further distribution, licensing or sub-licensing.
2. License Grant. ATOMOS grants you a personal, non-transferable and
non-exclusive right to use the copy of the Software provided with this EULA.
You agree you will not copy the Software except as necessary to use it with
the AtomX Cast. You agree that you may not copy the written materials
accompanying the Software. Modifying, reverse engineering, translating, renting,
copying, transferring or assigning all or part of the Software or any rights granted
hereunder, to any other persons or reverse engineering the hardware on which
the Software runs, is strictly prohibited. The software is license, not sold. You
acknowledge that no title to intellectual property in the Software is transferable to
you. You further acknowledge that title and full ownership rights to the Software
will remain the exclusive property of ATOMOS and/ or its suppliers, and you will
not acquire any rights to the Software, except as expressly set forth above. All
copies of the software will contain the same proprietary notices as contained
in or on the Software. All title and copyrights in and to the Software (including
but not limited to any images, animations, video, audio, text incorporated), the
accompanying printed materials, and any copies of the Software are owned by
ATOMOS or its suppliers.
3. Reverse engineering. You agree that you will not attempt, and if you are
a corporation, you will use your best efforts to prevent your employees and
contractors from attempting to reverse compile, derive circuits, modify, translate
or disassemble the Software and/or the AtomX Cast in whole or in part. Any
failure to comply with the above or any other terms and conditions contained
herein will result in the automatic termination of this license and the reversion of
the rights granted hereunder by ATOMOS.
ATOMOS reserves the right to terminate this license without prejudice to any
additional recourse ATOMOS may have against you if you violate any of its
terms and conditions.

© Atomos 2021. TM ® All trademarks and registered trademarks are the property of their respective owners.
atomos.com/quickstart
GET STARTED
