MPS-H-3 SERIES DC POWER SUPPLY
USER MANUAL
MATRIX TECHNOLOGY INC.
Certification: NOM-001-SCFI-2018 (NMX-I-60950-1-NYCE-2015)

Triple channel linear DC power supply
MPS-H-3 Series
•Current/voltage are all four-digit display, •CH1, CH2 can output independently,
the accuracy is improved , and can be controlled.
•Resolution 10mV, 1mA, Voltage precision •Voltage and current values in series and
0.03%+10mV, current precision 0.1%+5Ma and parallel are displayed without calculation
•All potentiometers are replaced by coded •Coarse and fine adjustment of voltage and
switches with low failure rate and long current can be simply carried by pressing
service life the knob;
•Select series, parallel and follow mode with •USB and RS-232 and RS-485 interface
one key are optional

3
2.2 Additional features
Recommended calibration frequency: 1 year/1 time
Cooling method: forced air cooling
Operating environment temperature: 0 to 40 ℃
Storage temperature: -15 to 80 ℃
Use environment: indoor use design, pollution level 2, maximum humidity 80%RH.
Chapter 3 Quick Start
This chapter will briefly introduce the appearance and basic functions of the MPS-3003H-3 series DC power
supply, so that you can quickly know about the MPS-3003H-3 series DC power supply. At the same time, it will
tell you the basic inspections to be done after getting the power supply to ensure the normal operation of the
product.
3.1 Introduction to the front and rear panels
The front panel of MPS-3003H-3 series DC power supply is shown in the figure below.
