AUDAC Atellio NWP300 User manual

Hardware Manual
NWP300 &
NWP400
audac.eu

NWP300 & NWP400 - Quick Start Manual NWP300 & NWP400 - Quick Start Manual
02
ADDITIONAL INFORMATION
This manual is put together with much care, and is as complete as could be on the publication date.



NWP300 & NWP400 - Quick Start Manual 03
Table of contents
Introduction 05
Networked audio in- & output wall panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
Precautions 06
Chapter 1 08
Connections and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
Network settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
Chapter 2 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Front panel description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Overview rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Rear panel description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 3 12
Quick start guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
 
Notes 15

NWP300 & NWP400 - Quick Start Manual NWP300 & NWP400 - Quick Start Manual
04

NWP300 & NWP400 - Quick Start Manual 05
Introduction







existing products. Thanks to the limited PoE power consumption, the NWP series is compatible with




design.
Networked audio in- & output wall panels

NWP300 & NWP400 - Quick Start Manual NWP300 & NWP400 - Quick Start Manual
06
Precautions



HEED ALL WARNINGS








HEAT











    



The WEEE marking indicates that this product should not be disposed with regular

possible harm to the environment or human health.
 



help to protect the environment in which we all live.

NWP300 & NWP400 - Quick Start Manual 07

NWP300 & NWP400 - Quick Start Manual NWP300 & NWP400 - Quick Start Manual
08
RJ45 (Network, PoE)
Network connections
Ethernet (POE):


-
cations in it.





NWP series.
-
mended to upgrade the network cabling to CAT6A or better cabling to achieve the best possible thermal

Chapter 1
3.5 mm jack:
For unbalanced line input connections
CONNECTION STANDARDS


Tip:
Ring:
Sleeve:
  
Right
Ground
Connections
Pin 1 White-Orange
Pin 2 Orange
Pin 3 White-Green
   
  
Pin 6 Green
 
  

NWP300 & NWP400 - Quick Start Manual 0909
Network settings

 ON
 Depending on DHCP
 
 
 
 

NWP300 & NWP400 - Quick Start Manual NWP300 & NWP400 - Quick Start Manual
010
Chapter 2

Overview rear panel
Front panel description







Unbalanced Stereo Line Input

Button Bluetooth Connection



  
connection and status
indicator LED

Ethernet connection


NWP300 & NWP400 - Quick Start Manual 011
Rear panel description
Ethernet connection




Installation





n
68

(

NWP300 & NWP400 - Quick Start Manual NWP300 & NWP400 - Quick Start Manual
012

Step 1: Step 2: Step 3: Step 4: Step 5:


NWP300 & NWP400 - Quick Start Manual 013
Chapter 3
Quick start guide


TouchTM.
1) Connecting the NWP series to your network




2) Connecting the XLR


3) Connecting the Bluetooth



Connecting the NWP series




NWP300 & NWP400 - Quick Start Manual NWP300 & NWP400 - Quick Start Manual
014
Conguring the NWP series
1) Dante controller








axis all the devices with their receiving channels shown and on the vertical axis all the devices with their

icons.



To give custom names to the devices or the channels, double-click the device name and the device view








2) NWP series settings

TM


TM and much more.

NWP300 & NWP400 - Quick Start Manual 015
Technical specications
Inputs  
 
Connector 
Impedance 
 
THD+N <0.02% - 0.013%
Signal / Noise 
 
 

 Gain, AGC, Noise Gate, WaveTuneTM
Output  
Connector 
Output level 
 
 PoE
Power consumption  
Phantom power 
 
Dimensions  80 x 80 x 52.7 mm
 75 mm
Colours 

 
Accessoiries 
Compatible devices All Dante compatiable devices



Discover more on audac.eu
