Audeze Deckard User manual

C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 2 4/13/2015 1:31:50 PM

Industrial design by
Package Includes
• Audeze Deckard Headphone Amp/DAC/Preamp
• 5-ft USB cable
• 6-ft AC IEC power cord
• Warranty and Certificate of Authenticity
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 3 4/13/2015 1:31:51 PM

Thank you for purchasing the Audeze Deckard
Headphone Amplifier and DAC with industrial design
by BMW DesignworksUSA. The pure class-A circuitry
drives any headphone to best effect.
To get the most out of your purchase, please take
the time to carefully read through this user guide
and warranty.
DECKARD HEADPHONE AMP/DAC
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 4 4/13/2015 1:31:51 PM

Package Includes
• Audeze Deckard Headphone Amp/DAC/Preamp
• 5-ft USB cable
• 6-ft AC IEC power cord
• Warranty and Certificate of Authenticity
Specifications
Line Out
Type Single-ended class-A
SNR 106dB A-Weighting
THD+N 0.00045% at 1kHz, 2VRMS A-Weighting
Frequency Response 5Hz to 100kHz, -1dB
Line Out Impedance 50 ohms
Gain Low - 0dB, Mid - 10dB, High - 20dB
Headphone Out
SNR 106dB A-Weighting
THD+N Less than 0.1%, 20Hz-20kHz,
4W with 20 ohm load
Frequency Response 5Hz to 100kHz, -1dB
Output Impedance 3 ohms
Output Power 4W at 20 ohms
DAC Section
Sample Rate 44.1kHz, 48kHz, 88.2kHz, 96kHz
176.4kHz, 192kHz, 384kHz, 16 to 32-bit
System Support Windows XP/Vista/7/8 up to 192kHz / 24 bit
USB 2.0 driver requires installation.
Native support for Mac OS 10.6.4 and above
Up to 384kHz / 32 bit
AC Input
Input Voltage AC100V: 90V-110V
(Factory Set) AC110V: 100V-120V
AC230V: 210V-230V
Power Consumption <19W
Fuse 10A, 250VAC
Physical Specs 2.1kg, 155 x 46 x 257mm
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 5 4/13/2015 1:31:51 PM

Product Registration
Register your Audeze Deckard at www.audeze.com for
information, updates and news.
Safety Guide
Listening to music for long periods of time at excessive
levels can cause irreparable damage to your ears.
Audeze recommends turning off the Deckard before
connecting or removing audio or power cables.Lower the
volume before connecting (or removing) your headphone
cable from the Deckard, then gradually increase the volume
until you reach a comfortable volume level.
The Deckard’s class-A circuitry generates some heat so we
recommend leaving 1-inch clearance around the chassis for
proper heat dissipation.
AC Power
Ensure the voltage indicated on the rear panel of your
Audeze Deckard matches your AC mains supply. Attempt-
ing to use your Deckard at any voltage other than that
specified on the rear panel of the unit may cause damage
not covered by the Warranty.
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 6 4/13/2015 1:31:51 PM

Care and Maintenance
Regular maintenance is not required, but an occasional wipe
with a clean, dry, lint-free cloth is recommended while the
Deckard is powered down.
TIP: If you leave your cables connected to the Deckard for long
periods of time, we recommend that every six months you shut
off the Deckard and disconnect and connect the cables several
times; the wiping motion cleans the RCA terminals of oxidation.
NOTE: Opening device will void warranty. Contact Audeze for
service. Keep the product, accessories and packaging out of
reach of children. This product is not intended for use by
children under the age of 12.
Unpacking
Be careful when handling the Deckard. It’s important to note
that the side panel heatsinks are relatively sharp.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
Specifications
Line Out
Type Single-ended class-A
SNR 106dB A-Weighting
THD+N 0.00045% at 1kHz, 2VRMS A-Weighting
Frequency Response 5Hz to 100kHz, -1dB
Line Out Impedance 50 ohms
Gain Low - 0dB, Mid - 10dB, High - 20dB
Headphone Out
SNR 106dB A-Weighting
THD+N Less than 0.1%, 20Hz-20kHz,
4W with 20 ohm load
Frequency Response 5Hz to 100kHz, -1dB
Output Impedance 3 ohms
Output Power 4W at 20 ohms
DAC Section
Sample Rate 44.1kHz, 48kHz, 88.2kHz, 96kHz
176.4kHz, 192kHz, 384kHz, 16 to 32-bit
System Support Windows XP/Vista/7/8 up to 192kHz / 24 bit
USB 2.0 driver requires installation.
Native support for Mac OS 10.6.4 and above
Up to 384kHz / 32 bit
AC Input
Input Voltage AC100V: 90V-110V
(Factory Set) AC110V: 100V-120V
AC230V: 210V-230V
Power Consumption <19W
Fuse 10A, 250VAC
Physical Specs 2.1kg, 155 x 46 x 257mm
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 7 4/13/2015 1:31:51 PM

Connecting Your Deckard
If you’re using the Deckard in digital input mode, connect its
USB input to your computer or other USB-equipped source
and ensure the input switch on the front panel is set to “USB”.
In the event you want to use the Deckard in analog mode, you
can connect the source to the left and right RCA analog inputs
and change the input switch on the front panel to “RCA”. To
use the Deckard as a system preamplifier use the pair of left
and right RCA outputs on the rear panel labeled “OUTPUT”;
just add powered speakers and you’ve got a desktop audio
system ready to go.
The internal DAC has impressive specifications that plays 16 to
32-bit audio and sampling rates from 44.1kHz to 384kHz on
Mac OS 10.6.4 and above. Windows computers are system
limited to 192kHz and 24-bits. The front-panel gain switch
chooses between three gain settings and we recommend
starting at the uppermost position labeled Mid with Audeze
headphones; other brands may require changing the gain.
The headphone output is a standard quarter-inch stereo jack
with RCA line-level analog inputs and outputs.
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 8 4/13/2015 1:31:51 PM

Window’s Driver Installation
Visit Audeze.com to download drivers for Windows. Mac users
be aware that OS 10.6.4 and above feature native support so
no drivers are necessary.
1. Plug in the power cord and plug in the USB cable on the Deckard.
2. Plug in the Deckard USB cable into your PC.
3. Turn the power switch (located on the rear panel) to the on position.
4. Insert the provided mini-CD into your disk drive or download on the
Deckard page on Audeze.
5. On the CD you will find “Deckard Windows Driver.exe”,
right click on the file and select “Run as administrator”.
6. You will be prompted to allow the installation process to make
changes to your computer. Select “Yes” to install the software.
If you select “No” you cannot install the software.
Warranty
The Audeze product comprising the Deckard Headphone Amp/DAC/Preamp (an
“Audeze Product”) is under warranty for three (3) year from the date of original
retail purchase (the “Warranty Period”).
What’s covered: Audeze warrants to the original purchaser that the Audeze
Product will be free of defects related to manufacturing, parts, materials, and
workmanship under normal and accepted use in accordance with Audeze’s
published guidelines. Audeze’s guidelines include, but are not limited to,
information contained in technical specifications, user manuals and service
communications.
What’s not covered: This warranty does not cover defects resulting from
improper or unreasonable use or maintenance; cosmetic damage, including
but not limited to scratches, dents and broken parts; failure to follow
operating instructions; accident; excess moisture; excess temperature; power
surges; connections to improper voltage supply; unauthorized alteration or
modification of original condition; damage caused by use with non-Audeze
products; products purchased from unauthorized dealers; or defects incurred
during transportation for which claims must be presented to the carrier.
Because we use natural woods and leather in some Audeze Products, variations
in grain and color are the inherent and natural characteristics of the wood. These
variations are natural and are considered by Audeze as acceptable. Additionally,
as wood ages, the finished color may change. These changes in color and finish
are natural wood characteristics and are not covered under this warranty.
What we will do: We will, at our sole discretion and to the extent permitted by
law, repair or replace (using new or refurbished Audeze Products) Audeze
Products that are under warranty for the period listed, from the date of original
retail purchase.
What we will not do: Except as stated below, pay shipping, insurance or
transportation charges from you to us, or any import fees, duties and taxes. If
the Audeze Product is covered by this warranty and is provided to us within
the first 30 days of the Warranty Period, then we will reimburse you for
shipping charges.
If the Audeze Product you send to us is not covered by this warranty, you will be
charged the shipping costs. If you are outside the USA and purchased this
product directly from Audeze you must claim your warranty service from
Audeze, not from a foreign dealer or distributor.
Warranty eligibility statement: To be eligible for service under this warranty you
must include with the repair item(s) a valid bill of sale from an authorized Audeze
retailer detailing the following information:
Retailer’s name
Original date and proof of purchase
Model or SKU number of the product purchased
Serial Number
Additional product information and limitations
Warranty replacements: Audeze strives to improve the performance of our
products, and therefore reserves the right to make changes to our
design/specifications/materials at any time without notification. Audeze may,
at its discretion, choose to replace the Audeze Product completely with a new
or remanufactured product. In the event of product obsolescence, a suitable
replacement will be chosen based upon the features, the intended use (as
determined by Audeze) and the retail price of the original Audeze Product.
Product: All warranty replacements are guaranteed for 90 days or until the
conclusion of the Warranty Period of the original Audeze Product, whichever
period is greater. Audeze does not provide advance replacements for Audeze
Products.
Determining authority: Audeze will be the final determining authority for all
potential warranty claims for service and/or replacement.
How to claim warranty service
A) If you reside in the United States and purchased direct from
Audeze.com email [email protected].
B) If you reside in the United States and purchased from an authorized
Audeze dealer contact your dealer or [email protected].
C) If you are an international customer who has purchased through your
local dealer contact your local dealer or distributor for warranty service.
D) If you are an international customer who purchased direct from
Audeze.com you must contact Audeze at [email protected] for
service and support. Any shipment back to Audeze for repair will be
at the expense of the customer.
You will need your serial number and proof of purchase to complete any
RMA process.
Other conditions/rights: EXCEPT AS PROVIDED IN THIS WARRANTY AND
TO THE MAXIMUM EXTENT PERMITTED BY LAW, AUDEZE IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR
ANTICIPATED PROFITS; LOSS OF GOODWILL; LOSS OF, DAMAGE TO,
COMPROMISE OR CORRUPTION OF DATA; OR ANY INDIRECT OR
CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED INCLUDING
THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
THE FOREGOING LIMITATION SHALL NOT APPLY TO DEATH OR PERSONAL
INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR INTENTIONAL AND
GROSS NEGLIGENT ACTS AND/OR OMISSIONS. SOME STATES IN THE USA
OR OTHER COUNTRIES..DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE
REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN,
STATUTORY, EXPRESS OR IMPLIED. AUDEZE DISCLAIMS ALL STATUTORY
AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE
EXTENT PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT
BE DISCLAIMED, AUDEZE LIMITS THE DURATION AND REMEDIES OF SUCH
WARRANTIES TO THE DURATION OF THIS EXPRESS WARRANTY AND, AT
AUDEZE'S OPTION, THE REPAIR OR REPLACEMENT SERVICES DESCRIBED
HEREIN. SOME STATES (INCLUDING COUNTRIES AND PROVINCES) DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY (OR
CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT
APPLY TO YOU.
Audeze LLC
http://support.audeze.com
Window’s Driver Installation
Visit Audeze.com to download drivers for Windows. Mac users
be aware that OS 10.6.4 and above feature native support so
no drivers are necessary.
1. Plug in the power cord and plug in the USB cable on the Deckard.
2. Plug in the Deckard USB cable into your PC.
3. Turn the power switch (located on the rear panel) to the on position.
4. Insert the provided mini-CD into your disk drive or download on the
Deckard page on Audeze.
5. On the CD you will find “Deckard Windows Driver.exe”,
right click on the file and select “Run as administrator”.
6. You will be prompted to allow the installation process to make
changes to your computer. Select “Yes” to install the software.
If you select “No” you cannot install the software.
DRIVER AND MANUAL
DRIVER AND MANUALDRIVER AND MANUAL
A
U
D
E
Z
E
D
E
C
K
A
R
D
A
M
P
/
D
A
C
D
R
I
V
E
R
A
N
D
M
A
N
U
A
L
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 9 4/13/2015 1:31:51 PM

7. Follow the on screen instructions of the installation
Wizard then select “Install”.
8. Check “Accept” and click “Next” when prompted with the
End User License Agreement. If you do not accept the
agreement you cannot install the software.
9. Choose installation destination. The default installation
destination is C:\Program Files\AUDEZE. Then select “Install”.
10.When the installation is complete, select “Next”.
11. Select “Finish” to exit the Installation Wizard.
12. On your local drive navigate to
Control Panel > Hardware and Sound > Sound.
13. Select the option “XMOS USB Audio”.
Highlight and select “Set Default”.
Warranty
The Audeze product comprising the Deckard Headphone Amp/DAC/Preamp (an
“Audeze Product”) is under warranty for three (3) year from the date of original
retail purchase (the “Warranty Period”).
What’s covered: Audeze warrants to the original purchaser that the Audeze
Product will be free of defects related to manufacturing, parts, materials, and
workmanship under normal and accepted use in accordance with Audeze’s
published guidelines. Audeze’s guidelines include, but are not limited to,
information contained in technical specifications, user manuals and service
communications.
What’s not covered: This warranty does not cover defects resulting from
improper or unreasonable use or maintenance; cosmetic damage, including
but not limited to scratches, dents and broken parts; failure to follow
operating instructions; accident; excess moisture; excess temperature; power
surges; connections to improper voltage supply; unauthorized alteration or
modification of original condition; damage caused by use with non-Audeze
products; products purchased from unauthorized dealers; or defects incurred
during transportation for which claims must be presented to the carrier.
Because we use natural woods and leather in some Audeze Products, variations
in grain and color are the inherent and natural characteristics of the wood. These
variations are natural and are considered by Audeze as acceptable. Additionally,
as wood ages, the finished color may change. These changes in color and finish
are natural wood characteristics and are not covered under this warranty.
What we will do: We will, at our sole discretion and to the extent permitted by
law, repair or replace (using new or refurbished Audeze Products) Audeze
Products that are under warranty for the period listed, from the date of original
retail purchase.
What we will not do: Except as stated below, pay shipping, insurance or
transportation charges from you to us, or any import fees, duties and taxes. If
the Audeze Product is covered by this warranty and is provided to us within
the first 30 days of the Warranty Period, then we will reimburse you for
shipping charges.
If the Audeze Product you send to us is not covered by this warranty, you will be
charged the shipping costs. If you are outside the USA and purchased this
product directly from Audeze you must claim your warranty service from
Audeze, not from a foreign dealer or distributor.
Warranty eligibility statement: To be eligible for service under this warranty you
must include with the repair item(s) a valid bill of sale from an authorized Audeze
retailer detailing the following information:
Retailer’s name
Original date and proof of purchase
Model or SKU number of the product purchased
Serial Number
Additional product information and limitations
Warranty replacements: Audeze strives to improve the performance of our
products, and therefore reserves the right to make changes to our
design/specifications/materials at any time without notification. Audeze may,
at its discretion, choose to replace the Audeze Product completely with a new
or remanufactured product. In the event of product obsolescence, a suitable
replacement will be chosen based upon the features, the intended use (as
determined by Audeze) and the retail price of the original Audeze Product.
Product: All warranty replacements are guaranteed for 90 days or until the
conclusion of the Warranty Period of the original Audeze Product, whichever
period is greater. Audeze does not provide advance replacements for Audeze
Products.
Determining authority: Audeze will be the final determining authority for all
potential warranty claims for service and/or replacement.
How to claim warranty service
A) If you reside in the United States and purchased direct from
Audeze.com email [email protected].
B) If you reside in the United States and purchased from an authorized
Audeze dealer contact your dealer or [email protected].
C) If you are an international customer who has purchased through your
local dealer contact your local dealer or distributor for warranty service.
D) If you are an international customer who purchased direct from
Audeze.com you must contact Audeze at [email protected] for
service and support. Any shipment back to Audeze for repair will be
at the expense of the customer.
You will need your serial number and proof of purchase to complete any
RMA process.
Other conditions/rights: EXCEPT AS PROVIDED IN THIS WARRANTY AND
TO THE MAXIMUM EXTENT PERMITTED BY LAW, AUDEZE IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR
ANTICIPATED PROFITS; LOSS OF GOODWILL; LOSS OF, DAMAGE TO,
COMPROMISE OR CORRUPTION OF DATA; OR ANY INDIRECT OR
CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED INCLUDING
THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
THE FOREGOING LIMITATION SHALL NOT APPLY TO DEATH OR PERSONAL
INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR INTENTIONAL AND
GROSS NEGLIGENT ACTS AND/OR OMISSIONS. SOME STATES IN THE USA
OR OTHER COUNTRIES..DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE
REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN,
STATUTORY, EXPRESS OR IMPLIED. AUDEZE DISCLAIMS ALL STATUTORY
AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE
EXTENT PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT
BE DISCLAIMED, AUDEZE LIMITS THE DURATION AND REMEDIES OF SUCH
WARRANTIES TO THE DURATION OF THIS EXPRESS WARRANTY AND, AT
AUDEZE'S OPTION, THE REPAIR OR REPLACEMENT SERVICES DESCRIBED
HEREIN. SOME STATES (INCLUDING COUNTRIES AND PROVINCES) DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY (OR
CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT
APPLY TO YOU.
Audeze LLC
http://support.audeze.com
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 10 4/13/2015 1:31:51 PM

Warranty
The Audeze product comprising the Deckard Headphone Amp/DAC/Preamp (an
“Audeze Product”) is under warranty for three (3) year from the date of original
retail purchase (the “Warranty Period”).
What’s covered: Audeze warrants to the original purchaser that the Audeze
Product will be free of defects related to manufacturing, parts, materials, and
workmanship under normal and accepted use in accordance with Audeze’s
published guidelines. Audeze’s guidelines include, but are not limited to,
information contained in technical specifications, user manuals and service
communications.
What’s not covered: This warranty does not cover defects resulting from
improper or unreasonable use or maintenance; cosmetic damage, including
but not limited to scratches, dents and broken parts; failure to follow
operating instructions; accident; excess moisture; excess temperature; power
surges; connections to improper voltage supply; unauthorized alteration or
modification of original condition; damage caused by use with non-Audeze
products; products purchased from unauthorized dealers; or defects incurred
during transportation for which claims must be presented to the carrier.
Because we use natural woods and leather in some Audeze Products, variations
in grain and color are the inherent and natural characteristics of the wood. These
variations are natural and are considered by Audeze as acceptable. Additionally,
as wood ages, the finished color may change. These changes in color and finish
are natural wood characteristics and are not covered under this warranty.
What we will do: We will, at our sole discretion and to the extent permitted by
law, repair or replace (using new or refurbished Audeze Products) Audeze
Products that are under warranty for the period listed, from the date of original
retail purchase.
What we will not do: Except as stated below, pay shipping, insurance or
transportation charges from you to us, or any import fees, duties and taxes. If
the Audeze Product is covered by this warranty and is provided to us within
the first 30 days of the Warranty Period, then we will reimburse you for
shipping charges.
If the Audeze Product you send to us is not covered by this warranty, you will be
charged the shipping costs. If you are outside the USA and purchased this
product directly from Audeze you must claim your warranty service from
Audeze, not from a foreign dealer or distributor.
Warranty eligibility statement: To be eligible for service under this warranty you
must include with the repair item(s) a valid bill of sale from an authorized Audeze
retailer detailing the following information:
Retailer’s name
Original date and proof of purchase
Model or SKU number of the product purchased
Serial Number
Additional product information and limitations
Warranty replacements: Audeze strives to improve the performance of our
products, and therefore reserves the right to make changes to our
design/specifications/materials at any time without notification. Audeze may,
at its discretion, choose to replace the Audeze Product completely with a new
or remanufactured product. In the event of product obsolescence, a suitable
replacement will be chosen based upon the features, the intended use (as
determined by Audeze) and the retail price of the original Audeze Product.
Product: All warranty replacements are guaranteed for 90 days or until the
conclusion of the Warranty Period of the original Audeze Product, whichever
period is greater. Audeze does not provide advance replacements for Audeze
Products.
Determining authority: Audeze will be the final determining authority for all
potential warranty claims for service and/or replacement.
How to claim warranty service
A) If you reside in the United States and purchased direct from
Audeze.com email [email protected].
B) If you reside in the United States and purchased from an authorized
Audeze dealer contact your dealer or [email protected].
C) If you are an international customer who has purchased through your
local dealer contact your local dealer or distributor for warranty service.
D) If you are an international customer who purchased direct from
Audeze.com you must contact Audeze at [email protected] for
service and support. Any shipment back to Audeze for repair will be
at the expense of the customer.
You will need your serial number and proof of purchase to complete any
RMA process.
Other conditions/rights: EXCEPT AS PROVIDED IN THIS WARRANTY AND
TO THE MAXIMUM EXTENT PERMITTED BY LAW, AUDEZE IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR
ANTICIPATED PROFITS; LOSS OF GOODWILL; LOSS OF, DAMAGE TO,
COMPROMISE OR CORRUPTION OF DATA; OR ANY INDIRECT OR
CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED INCLUDING
THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
THE FOREGOING LIMITATION SHALL NOT APPLY TO DEATH OR PERSONAL
INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR INTENTIONAL AND
GROSS NEGLIGENT ACTS AND/OR OMISSIONS. SOME STATES IN THE USA
OR OTHER COUNTRIES..DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE
REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN,
STATUTORY, EXPRESS OR IMPLIED. AUDEZE DISCLAIMS ALL STATUTORY
AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE
EXTENT PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT
BE DISCLAIMED, AUDEZE LIMITS THE DURATION AND REMEDIES OF SUCH
WARRANTIES TO THE DURATION OF THIS EXPRESS WARRANTY AND, AT
AUDEZE'S OPTION, THE REPAIR OR REPLACEMENT SERVICES DESCRIBED
HEREIN. SOME STATES (INCLUDING COUNTRIES AND PROVINCES) DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY (OR
CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT
APPLY TO YOU.
Audeze LLC
http://support.audeze.com
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 11 4/13/2015 1:31:51 PM

Warranty
The Audeze product comprising the Deckard Headphone Amp/DAC/Preamp (an
“Audeze Product”) is under warranty for three (3) year from the date of original
retail purchase (the “Warranty Period”).
What’s covered: Audeze warrants to the original purchaser that the Audeze
Product will be free of defects related to manufacturing, parts, materials, and
workmanship under normal and accepted use in accordance with Audeze’s
published guidelines. Audeze’s guidelines include, but are not limited to,
information contained in technical specifications, user manuals and service
communications.
What’s not covered: This warranty does not cover defects resulting from
improper or unreasonable use or maintenance; cosmetic damage, including
but not limited to scratches, dents and broken parts; failure to follow
operating instructions; accident; excess moisture; excess temperature; power
surges; connections to improper voltage supply; unauthorized alteration or
modification of original condition; damage caused by use with non-Audeze
products; products purchased from unauthorized dealers; or defects incurred
during transportation for which claims must be presented to the carrier.
Because we use natural woods and leather in some Audeze Products, variations
in grain and color are the inherent and natural characteristics of the wood. These
variations are natural and are considered by Audeze as acceptable. Additionally,
as wood ages, the finished color may change. These changes in color and finish
are natural wood characteristics and are not covered under this warranty.
What we will do: We will, at our sole discretion and to the extent permitted by
law, repair or replace (using new or refurbished Audeze Products) Audeze
Products that are under warranty for the period listed, from the date of original
retail purchase.
What we will not do: Except as stated below, pay shipping, insurance or
transportation charges from you to us, or any import fees, duties and taxes. If
the Audeze Product is covered by this warranty and is provided to us within
the first 30 days of the Warranty Period, then we will reimburse you for
shipping charges.
If the Audeze Product you send to us is not covered by this warranty, you will be
charged the shipping costs. If you are outside the USA and purchased this
product directly from Audeze you must claim your warranty service from
Audeze, not from a foreign dealer or distributor.
Warranty eligibility statement: To be eligible for service under this warranty you
must include with the repair item(s) a valid bill of sale from an authorized Audeze
retailer detailing the following information:
Retailer’s name
Original date and proof of purchase
Model or SKU number of the product purchased
Serial Number
Additional product information and limitations
Warranty replacements: Audeze strives to improve the performance of our
products, and therefore reserves the right to make changes to our
design/specifications/materials at any time without notification. Audeze may,
at its discretion, choose to replace the Audeze Product completely with a new
or remanufactured product. In the event of product obsolescence, a suitable
replacement will be chosen based upon the features, the intended use (as
determined by Audeze) and the retail price of the original Audeze Product.
Product: All warranty replacements are guaranteed for 90 days or until the
conclusion of the Warranty Period of the original Audeze Product, whichever
period is greater. Audeze does not provide advance replacements for Audeze
Products.
Determining authority: Audeze will be the final determining authority for all
potential warranty claims for service and/or replacement.
How to claim warranty service
A) If you reside in the United States and purchased direct from
Audeze.com email [email protected].
B) If you reside in the United States and purchased from an authorized
Audeze dealer contact your dealer or [email protected].
C) If you are an international customer who has purchased through your
local dealer contact your local dealer or distributor for warranty service.
D) If you are an international customer who purchased direct from
Audeze.com you must contact Audeze at [email protected] for
service and support. Any shipment back to Audeze for repair will be
at the expense of the customer.
You will need your serial number and proof of purchase to complete any
RMA process.
Other conditions/rights: EXCEPT AS PROVIDED IN THIS WARRANTY AND
TO THE MAXIMUM EXTENT PERMITTED BY LAW, AUDEZE IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR
ANTICIPATED PROFITS; LOSS OF GOODWILL; LOSS OF, DAMAGE TO,
COMPROMISE OR CORRUPTION OF DATA; OR ANY INDIRECT OR
CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED INCLUDING
THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
THE FOREGOING LIMITATION SHALL NOT APPLY TO DEATH OR PERSONAL
INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR INTENTIONAL AND
GROSS NEGLIGENT ACTS AND/OR OMISSIONS. SOME STATES IN THE USA
OR OTHER COUNTRIES..DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE
REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN,
STATUTORY, EXPRESS OR IMPLIED. AUDEZE DISCLAIMS ALL STATUTORY
AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE
EXTENT PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT
BE DISCLAIMED, AUDEZE LIMITS THE DURATION AND REMEDIES OF SUCH
WARRANTIES TO THE DURATION OF THIS EXPRESS WARRANTY AND, AT
AUDEZE'S OPTION, THE REPAIR OR REPLACEMENT SERVICES DESCRIBED
HEREIN. SOME STATES (INCLUDING COUNTRIES AND PROVINCES) DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY (OR
CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT
APPLY TO YOU.
Audeze LLC
http://support.audeze.com
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 12 4/13/2015 1:31:51 PM

Warranty
The Audeze product comprising the Deckard Headphone Amp/DAC/Preamp (an
“Audeze Product”) is under warranty for three (3) year from the date of original
retail purchase (the “Warranty Period”).
What’s covered: Audeze warrants to the original purchaser that the Audeze
Product will be free of defects related to manufacturing, parts, materials, and
workmanship under normal and accepted use in accordance with Audeze’s
published guidelines. Audeze’s guidelines include, but are not limited to,
information contained in technical specifications, user manuals and service
communications.
What’s not covered: This warranty does not cover defects resulting from
improper or unreasonable use or maintenance; cosmetic damage, including
but not limited to scratches, dents and broken parts; failure to follow
operating instructions; accident; excess moisture; excess temperature; power
surges; connections to improper voltage supply; unauthorized alteration or
modification of original condition; damage caused by use with non-Audeze
products; products purchased from unauthorized dealers; or defects incurred
during transportation for which claims must be presented to the carrier.
Because we use natural woods and leather in some Audeze Products, variations
in grain and color are the inherent and natural characteristics of the wood. These
variations are natural and are considered by Audeze as acceptable. Additionally,
as wood ages, the finished color may change. These changes in color and finish
are natural wood characteristics and are not covered under this warranty.
What we will do: We will, at our sole discretion and to the extent permitted by
law, repair or replace (using new or refurbished Audeze Products) Audeze
Products that are under warranty for the period listed, from the date of original
retail purchase.
What we will not do: Except as stated below, pay shipping, insurance or
transportation charges from you to us, or any import fees, duties and taxes. If
the Audeze Product is covered by this warranty and is provided to us within
the first 30 days of the Warranty Period, then we will reimburse you for
shipping charges.
If the Audeze Product you send to us is not covered by this warranty, you will be
charged the shipping costs. If you are outside the USA and purchased this
product directly from Audeze you must claim your warranty service from
Audeze, not from a foreign dealer or distributor.
Warranty eligibility statement: To be eligible for service under this warranty you
must include with the repair item(s) a valid bill of sale from an authorized Audeze
retailer detailing the following information:
Retailer’s name
Original date and proof of purchase
Model or SKU number of the product purchased
Serial Number
Additional product information and limitations
Warranty replacements: Audeze strives to improve the performance of our
products, and therefore reserves the right to make changes to our
design/specifications/materials at any time without notification. Audeze may,
at its discretion, choose to replace the Audeze Product completely with a new
or remanufactured product. In the event of product obsolescence, a suitable
replacement will be chosen based upon the features, the intended use (as
determined by Audeze) and the retail price of the original Audeze Product.
Product: All warranty replacements are guaranteed for 90 days or until the
conclusion of the Warranty Period of the original Audeze Product, whichever
period is greater. Audeze does not provide advance replacements for Audeze
Products.
Determining authority: Audeze will be the final determining authority for all
potential warranty claims for service and/or replacement.
How to claim warranty service
A) If you reside in the United States and purchased direct from
Audeze.com email [email protected].
B) If you reside in the United States and purchased from an authorized
Audeze dealer contact your dealer or [email protected].
C) If you are an international customer who has purchased through your
local dealer contact your local dealer or distributor for warranty service.
D) If you are an international customer who purchased direct from
Audeze.com you must contact Audeze at [email protected] for
service and support. Any shipment back to Audeze for repair will be
at the expense of the customer.
You will need your serial number and proof of purchase to complete any
RMA process.
Other conditions/rights: EXCEPT AS PROVIDED IN THIS WARRANTY AND
TO THE MAXIMUM EXTENT PERMITTED BY LAW, AUDEZE IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR
ANTICIPATED PROFITS; LOSS OF GOODWILL; LOSS OF, DAMAGE TO,
COMPROMISE OR CORRUPTION OF DATA; OR ANY INDIRECT OR
CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED INCLUDING
THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
THE FOREGOING LIMITATION SHALL NOT APPLY TO DEATH OR PERSONAL
INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR INTENTIONAL AND
GROSS NEGLIGENT ACTS AND/OR OMISSIONS. SOME STATES IN THE USA
OR OTHER COUNTRIES..DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE
REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN,
STATUTORY, EXPRESS OR IMPLIED. AUDEZE DISCLAIMS ALL STATUTORY
AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE
EXTENT PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT
BE DISCLAIMED, AUDEZE LIMITS THE DURATION AND REMEDIES OF SUCH
WARRANTIES TO THE DURATION OF THIS EXPRESS WARRANTY AND, AT
AUDEZE'S OPTION, THE REPAIR OR REPLACEMENT SERVICES DESCRIBED
HEREIN. SOME STATES (INCLUDING COUNTRIES AND PROVINCES) DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY (OR
CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT
APPLY TO YOU.
Audeze LLC
http://support.audeze.com
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 13 4/13/2015 1:31:51 PM

Certifications
The aim of EU’s Waste Electrical and Electronic Equipment (WEEE) directives
2002/96/EC and the RoHs directive is to reduce waste from electric and
electronic products and to recycle as much of the materials as possible. Any
remaining waste should be virtually risk-free to handle and the risk of hazardous
emissions should be minimal.
Recycling
This product must either be sent for repairs and reused or sent for treatment and
recycling through an approved disposal system. For recycling and waste disposal
agents for Audeze products, contact us at [email protected].
Warranty
The Audeze product comprising the Deckard Headphone Amp/DAC/Preamp (an
“Audeze Product”) is under warranty for three (3) year from the date of original
retail purchase (the “Warranty Period”).
What’s covered: Audeze warrants to the original purchaser that the Audeze
Product will be free of defects related to manufacturing, parts, materials, and
workmanship under normal and accepted use in accordance with Audeze’s
published guidelines. Audeze’s guidelines include, but are not limited to,
information contained in technical specifications, user manuals and service
communications.
What’s not covered: This warranty does not cover defects resulting from
improper or unreasonable use or maintenance; cosmetic damage, including
but not limited to scratches, dents and broken parts; failure to follow
operating instructions; accident; excess moisture; excess temperature; power
surges; connections to improper voltage supply; unauthorized alteration or
modification of original condition; damage caused by use with non-Audeze
products; products purchased from unauthorized dealers; or defects incurred
during transportation for which claims must be presented to the carrier.
Because we use natural woods and leather in some Audeze Products, variations
in grain and color are the inherent and natural characteristics of the wood. These
variations are natural and are considered by Audeze as acceptable. Additionally,
as wood ages, the finished color may change. These changes in color and finish
are natural wood characteristics and are not covered under this warranty.
What we will do: We will, at our sole discretion and to the extent permitted by
law, repair or replace (using new or refurbished Audeze Products) Audeze
Products that are under warranty for the period listed, from the date of original
retail purchase.
What we will not do: Except as stated below, pay shipping, insurance or
transportation charges from you to us, or any import fees, duties and taxes. If
the Audeze Product is covered by this warranty and is provided to us within
the first 30 days of the Warranty Period, then we will reimburse you for
shipping charges.
If the Audeze Product you send to us is not covered by this warranty, you will be
charged the shipping costs. If you are outside the USA and purchased this
product directly from Audeze you must claim your warranty service from
Audeze, not from a foreign dealer or distributor.
Warranty eligibility statement: To be eligible for service under this warranty you
must include with the repair item(s) a valid bill of sale from an authorized Audeze
retailer detailing the following information:
Retailer’s name
Original date and proof of purchase
Model or SKU number of the product purchased
Serial Number
Additional product information and limitations
Warranty replacements: Audeze strives to improve the performance of our
products, and therefore reserves the right to make changes to our
design/specifications/materials at any time without notification. Audeze may,
at its discretion, choose to replace the Audeze Product completely with a new
or remanufactured product. In the event of product obsolescence, a suitable
replacement will be chosen based upon the features, the intended use (as
determined by Audeze) and the retail price of the original Audeze Product.
Product: All warranty replacements are guaranteed for 90 days or until the
conclusion of the Warranty Period of the original Audeze Product, whichever
period is greater. Audeze does not provide advance replacements for Audeze
Products.
Determining authority: Audeze will be the final determining authority for all
potential warranty claims for service and/or replacement.
How to claim warranty service
A) If you reside in the United States and purchased direct from
Audeze.com email [email protected].
B) If you reside in the United States and purchased from an authorized
Audeze dealer contact your dealer or [email protected].
C) If you are an international customer who has purchased through your
local dealer contact your local dealer or distributor for warranty service.
D) If you are an international customer who purchased direct from
Audeze.com you must contact Audeze at [email protected] for
service and support. Any shipment back to Audeze for repair will be
at the expense of the customer.
You will need your serial number and proof of purchase to complete any
RMA process.
Part
Name
部件名称
Toxic or Hazardous Substances and Elements 有毒或有害物质和元素
Lead
铅
(Pb)
Mercury
汞
(Hg)
Cadmium
镉
(Cd)
Hexavalent
Chromium
六价铬
(Cr6)
Polybrominated
Biphenyls
多溴联苯
(PBB)
Polybrominated
Diphenyl Ethers
多溴联苯醚
(PBDE)
Deckard
: Indicates that this toxic or hazardous substance is below the specified limits
as decribed in SJ/T11363-2006.
:表示该有毒物质或元素在SJ/T11363-2006 标准规定的限量要求以下。
:Indicates that this toxic or hazardous substance is above the specified limits
as decribed in SJ/T11363-2006.
:表示该有毒物质或元素超出SJ/T11363-2006 标准规定的限量要求。
Other conditions/rights: EXCEPT AS PROVIDED IN THIS WARRANTY AND
TO THE MAXIMUM EXTENT PERMITTED BY LAW, AUDEZE IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO LOSS OF USE; LOSS OF REVENUE; LOSS OF ACTUAL OR
ANTICIPATED PROFITS; LOSS OF GOODWILL; LOSS OF, DAMAGE TO,
COMPROMISE OR CORRUPTION OF DATA; OR ANY INDIRECT OR
CONSEQUENTIAL LOSS OR DAMAGE HOWSOEVER CAUSED INCLUDING
THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
THE FOREGOING LIMITATION SHALL NOT APPLY TO DEATH OR PERSONAL
INJURY CLAIMS, OR ANY STATUTORY LIABILITY FOR INTENTIONAL AND
GROSS NEGLIGENT ACTS AND/OR OMISSIONS. SOME STATES IN THE USA
OR OTHER COUNTRIES..DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND THE
REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL, WRITTEN,
STATUTORY, EXPRESS OR IMPLIED. AUDEZE DISCLAIMS ALL STATUTORY
AND IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRAN-
TIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS, TO THE
EXTENT PERMITTED BY LAW. IN SO FAR AS SUCH WARRANTIES CANNOT
BE DISCLAIMED, AUDEZE LIMITS THE DURATION AND REMEDIES OF SUCH
WARRANTIES TO THE DURATION OF THIS EXPRESS WARRANTY AND, AT
AUDEZE'S OPTION, THE REPAIR OR REPLACEMENT SERVICES DESCRIBED
HEREIN. SOME STATES (INCLUDING COUNTRIES AND PROVINCES) DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY (OR
CONDITION) MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT
APPLY TO YOU.
Audeze LLC
http://support.audeze.com
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_ENG_CS6_PRESS.pdf 14 4/13/2015 1:31:51 PM

Design industriel Deckard par
Design industriel Deckard par
Contenu de l’emballage
• Amplificateur/DAC/préamplificateur
pour casque Audeze Deckard
• Câble USB de 1,5 m (50 po)
• Cordon électrique CA CEI de 1,8 m (60 po)
• Déclaration de garantie et certificat d’authenticité
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_FR_CS6_PRESS.pdf 3 4/13/2015 11:50:41 AM

Nous vous remercions d’avoir acheté l’amplificateur et DAC
pour casque Audeze Deckard avec un design industriel par
BMW DesignworksUSA. Le circuit pure classe A garantit les
meilleurs résultats sur n’importe quel casque.
Pour profiter au mieux de votre achat, veuillez prendre le
temps de lire attentivement ce guide de l’utilisateur et la
déclaration de garantie qui l’accompagne.
AMPLIFICATEUR/DAC/PRÉAMPLIFICATEUR
POUR CASQUE DECKARD
Design industriel Deckard par
Design industriel Deckard par
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_FR_CS6_PRESS.pdf 4 4/13/2015 11:50:41 AM

Caractéristiques
Sortie Ligne
Type Asymétrique, classe A
SNR 106 dB, pondération A
DTH+N 0,00045 % à 1 kHz, 2 VRMS, pondération A
Réponse en fréquence 5 Hz à 100 kHz, -1 dB
Impédance 50 ohms
Gain Bas - 0 dB, Moyen - 10 dB, Élevé - 20 dB
Sortie casque
SNR 106 dB, pondération A
DTH+N Moins de 0,1 %, 20 Hz-20 kHz,
4 W avec charge de 20 ohms
Réponse en fréquence 5 Hz à 100 kHz, -1 dB
Impédance de sortie 3 ohms
Puissance de sortie 4 W à 20 ohms
Section DAC
Taux d’échantillonnage 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz
176,4 kHz, 192 kHz, 384 kHz, 16 à 32 bits
Système pris en charge Windows XP/Vista/7/8 Jusqu’à 192 kHz/24 bits
le pilote USB 2.0 doit être installé.
Prise en charge native pour Mac OS 10.6.4 et
versions ultérieures jusqu’à 384 kHz/32 bits
Entrée Secteur
Tension d’entrée 100 VCA : 90 V-110 V
(configurée en usine) 110 VCA : 100 V-120 V
230 VCA : 210 V-230 V
Consommation électrique <19W
Fusible 10 A, 250VCA
Caractéristiques physiques 2.1kg, 155 x 46 x 257mm
Contenu de l’emballage
• Amplificateur/DAC/préamplificateur
pour casque Audeze Deckard
• Câble USB de 1,5 m (50 po)
• Cordon électrique CA CEI de 1,8 m (60 po)
• Déclaration de garantie et certificat d’authenticité
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_FR_CS6_PRESS.pdf 5 4/13/2015 11:50:41 AM

Enregistrement du produit
Enregistrez votre produit Audeze sur audeze.com pour recevoir
des renseignements, mises à jour et actualités.
Guide de sécurité
Écouter de la musique à un volume excessif pendant des périodes
prolongées peut entraîner une détérioration irréversible de l’ouïe.
Audeze recommande d’éteindre le Deckard avant de brancher ou
de débrancher les câbles.
Diminuez le volume avant de brancher (ou de débrancher) le câble
du casque sur le Deckard, puis augmentez-le progressivement
jusqu’à atteindre un volume confortable.
Le circuit pure classe A de Deckard générant de la chaleur, nous
recommandons de maintenir un espace de 2,5 cm (1 po) tout
autour du châssis pour assurer une dissipation thermique
adéquate.
Alimentation CA
Veillez à ce que la tension indiquée sur le panneau arrière de votre
Audeze Deckard corresponde à la tension de votre alimentation
secteur. L’utilisation de votre Deckard à une tension autre que celle
indiquée sur le panneau arrière de l’appareil pourrait entraîner des
dommages non couverts par la garantie.
Caractéristiques
Sortie Ligne
Type Asymétrique, classe A
SNR 106 dB, pondération A
DTH+N 0,00045 % à 1 kHz, 2 VRMS, pondération A
Réponse en fréquence 5 Hz à 100 kHz, -1 dB
Impédance 50 ohms
Gain Bas - 0 dB, Moyen - 10 dB, Élevé - 20 dB
Sortie casque
SNR 106 dB, pondération A
DTH+N Moins de 0,1 %, 20 Hz-20 kHz,
4 W avec charge de 20 ohms
Réponse en fréquence 5 Hz à 100 kHz, -1 dB
Impédance de sortie 3 ohms
Puissance de sortie 4 W à 20 ohms
Section DAC
Taux d’échantillonnage 44,1 kHz, 48 kHz, 88,2 kHz, 96 kHz
176,4 kHz, 192 kHz, 384 kHz, 16 à 32 bits
Système pris en charge Windows XP/Vista/7/8 Jusqu’à 192 kHz/24 bits
le pilote USB 2.0 doit être installé.
Prise en charge native pour Mac OS 10.6.4 et
versions ultérieures jusqu’à 384 kHz/32 bits
Entrée Secteur
Tension d’entrée 100 VCA : 90 V-110 V
(configurée en usine) 110 VCA : 100 V-120 V
230 VCA : 210 V-230 V
Consommation électrique <19W
Fusible 10 A, 250VCA
Caractéristiques physiques 2.1kg, 155 x 46 x 257mm
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_FR_CS6_PRESS.pdf 6 4/13/2015 11:50:41 AM

Soins et entretien
Un entretien régulier n’est pas nécessaire, mais nous recom-
mandons un nettoyage occasionnel avec un chiffon propre, sec
et non pelucheux lorsque le Deckard est hors tension.
CONSEIL : Si vous laissez les câbles branchés au Deckard
pendant une période prolongée, nous recommandons d’étein-
dre le Deckard tous les six (6) mois et de débrancher puis de
rebrancher les câbles plusieurs fois de suite. Ce mouvement de
va-et-vient permettra de retirer toute oxydation éventuelle sur
les bornes RCA.
REMARQUE : l’ouverture de l’appareil annulera la garantie.
Contactez Audeze pour l’entretien et la réparation. Maintenez
le produit, les accessoires et l’emballage hors de la portée des
enfants. Ce produit n’est pas destiné aux enfants de moins de
12 ans.
Déballage
Manipulez le Deckard avec soin. Il est important de noter que
les dissipateurs de chaleur latéraux sont relativement acérés.
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
les dissipateurs de chaleur latéraux sont relativement acérés.
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_FR_CS6_PRESS.pdf 7 4/13/2015 11:50:41 AM

Enregistrement du produit
Enregistrez votre produit Audeze sur audeze.com pour recevoir
des renseignements, mises à jour et actualités.
Guide de sécurité
Écouter de la musique à un volume excessif pendant des périodes
prolongées peut entraîner une détérioration irréversible de l’ouïe.
Audeze recommande d’éteindre le Deckard avant de brancher ou
de débrancher les câbles.
Diminuez le volume avant de brancher (ou de débrancher) le câble
du casque sur le Deckard, puis augmentez-le progressivement
jusqu’à atteindre un volume confortable.
Le circuit pure classe A de Deckard générant de la chaleur, nous
recommandons de maintenir un espace de 2,5 cm (1 po) tout
autour du châssis pour assurer une dissipation thermique
adéquate.
Alimentation CA
Veillez à ce que la tension indiquée sur le panneau arrière de votre
Audeze Deckard corresponde à la tension de votre alimentation
secteur. L’utilisation de votre Deckard à une tension autre que celle
indiquée sur le panneau arrière de l’appareil pourrait entraîner des
dommages non couverts par la garantie.
Branchement du Deckard
Si le Deckard est utilisé en mode d’entrée numérique, branchez
l’entrée USB sur votre ordinateur ou toute autre source USB, et
assurez-vous que le commutateur d’entrée du panneau avant est
réglé sur « USB ». Si vous souhaitez utiliser le Deckard en mode
analogique, vous pouvez brancher la source sur les entrées RCA
gauche et droite et régler le commutateur d’entrée du panneau
avant sur « RCA ». Pour utiliser le Deckard comme système de
préamplification, vous pouvez utiliser la paire de sorties RCA
gauche et droite du panneau arrière (« OUTPUT »). Il vous suffit
alors de brancher des haut-parleurs alimentés pour disposer d’un
système audio de bureau prêt à l’emploi.
Le DAC interne est doté de caractéristiques impressionnantes, qui
permettent une lecture audio entre 16 et 32 bits avec des taux
d’échantillonnage entre 44,1 kHz et 384 kHz sur Mac OS 10.6.4 et
les versions ultérieures. Les ordinateurs Windows sont limités à 192
kHz et 24 bits. Le commutateur de gain du panneau avant permet
de choisir entre trois réglages de gain. Pour un casque Audeze,
nous vous recommandons de commencer par le réglage le plus en
haut intitulé « Mid ». Un réglage différent sera peut-être recom-
mandé pour d’autres marques.
La sortie casque est une prise stéréo standard de 1/4 po avec des
entrées et sorties analogiques RCA de niveau de ligne.
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_FR_CS6_PRESS.pdf 8 4/13/2015 11:50:41 AM

Installation des pilotes Windows
Consultez Audeze.com pour télécharger les pilotes Windows. Étant donné
que le système Mac OS 10.6.4 et les versions supérieures disposent d’une
prise en charge native, aucun pilote n’est requis.
1. Raccordez le cordon électrique et branchez le câble USB sur le Deckard.
2. Branchez le câble USB du Deckard sur votre ordinateur.
3. Placez le commutateur d’alimentation (situé sur le panneau arrière) en
position de marche (ON).
4. Introduisez le mini-CD fourni dans votre lecteur ou téléchargez les pilotes
depuis la page Deckard du site d’Audeze.
5. Vous trouverez sur le CD un fichier intitulé « Deckard Windows Driver.exe ».
Cliquez avec le bouton droit de la souris sur ce fichier et sélectionnez
« Exécuter en tant qu’administrateur ».
6. Vous serez invité(e) à autoriser le processus d’installation à effectuer des
modifications sur votre ordinateur. Sélectionnez « Oui » pour installer le
logiciel. L’installation ne sera pas possible si vous sélectionnez « Non ».
Déclaration de garantie
Le Produit Audeze comprenant l’amplificateur/DAC/préamplificateur pour casque
Deckard (le « Produit Audeze ») est sous garantie pendant trois (3) ans à compter
de la date initiale d’achat au détail (la « Période de garantie »).
Ce que couvre la garantie : Audeze garantit à l’acheteur original que le Produit
Audeze sera sans défaut ou vice lié à la fabrication, aux pièces, aux matériaux et à
la qualité de la main-d’œuvre dans des conditions d’utilisation normales et
acceptées, conformément aux directives publiées par Audeze. Les directives
d’Audeze comprennent, mais sans s’y limiter, les informations contenues dans les
caractéristiques techniques, les guides de l’utilisateur et les communications de
réparation/d’entretien.
Ce que la garantie ne couvre pas : cette garantie ne couvre pas les défauts
résultant d’une utilisation ou d’un entretien inapproprié(e) ou déraisonnable ; les
dommages d’ordre cosmétique, y compris, mais sans s’y limiter, les rayures, les
éraflures, les bosses et les matériaux plastiques cassés ; tout non-respect des
instructions d’utilisation ; un accident ; l’humidité excessive ; les températures
excessives ; les surtensions ; tout branchement à une source d’alimentation dont la
tension est inappropriée ; tout changement ou toute modification non autorisé(e)
de l’état d’origine du produit ; tout dommage provoqué par une utilisation avec
des produits non-Audeze ; les produits achetés auprès d’un distributeur non
autorisé ; ou les défauts survenus durant le transport (les réclamations doivent
être adressées au transporteur).
Puisque nous utilisons des bois naturels et du cuir dans certains produits Audeze,
les variations au niveau du grain et de la couleur sont des caractéristiques
inhérentes et naturelles du bois. Ces variations sont naturelles et sont
considérées comme acceptables par Audeze. De plus, la couleur finale du bois
peut également changer lorsque celui-ci vieillit. Ces changements de couleur et
de finition sont des caractéristiques naturelles du bois et ne sont pas couverts
par cette garantie.
Ce que nous ferons : nous procéderons, à notre entière discrétion et dans la
mesure autorisée par la loi, à la réparation ou au remplacement (par des produits
Audeze neufs ou remis à neuf en usine) de tout Produit Audeze valablement sous
garantie, à compter de la date de l’achat initial.
Ce que nous ne ferons pas : sauf exceptions indiquées ci-après, nous ne paierons
ni les frais d’expédition, d’assurance ou de transport ni les frais d’importation,
droits de douane et taxes quand vous nous envoyez un produit. Si un Produit
Audeze est couvert par cette garantie et que nous le recevons dans les 30
premiers jours de la Période de garantie, alors nous vous rembourserons les frais
d’expédition.
Si vous nous envoyez un Produit Audeze non couvert par cette garantie, les
coûts d’expédition seront à votre charge. Si vous êtes en dehors des États-Unis
et que vous avez acheté ce produit directement auprès d’Audeze, vous devez
réclamer votre service/réparation sous garantie auprès d’Audeze et non auprès
d’un distributeur ou revendeur étranger.
Déclaration d’admissibilité à la garantie : pour être admissible aux services
couverts par cette garantie, vous devez inclure avec le(s) produit(s) à réparer un
acte de vente valable émis par un détaillant Audeze autorisé et comprenant les
renseignements suivants :
Nom du détaillant
Date et preuve d’achat originales
Modèle ou numéro de référence du produit acheté
Numéro de série
Informations et limitations complémentaires liées au produit
Remplacements sous garantie : Audeze s’efforce d’améliorer la performance
de ses produits et se réserve par conséquent le droit de modifier ses
conceptions/caractéristiques techniques/matériaux à tout moment et sans
préavis. Audeze peut, à sa discrétion, choisir de remplacer intégralement le
Produit Audeze par un produit neuf ou remis à neuf en usine. Dans le cas de
l’obsolescence d’un produit, un remplacement convenable sera sélectionné
sur la base des caractéristiques, de l’utilisation prévue (telle que déterminée
par Audeze) et du prix de détail du Produit Audeze original.
Produit : tous les remplacements sous garantie sont garantis pendant 90 jours
ou jusqu’à la fin de la Période de garantie du Produit Audeze original, la
période la plus longue étant retenue. Audeze ne fournit aucun remplacement
par avance pour les produits Audeze.
Autorité responsable de la détermination : Audeze sera l’autorité finale
responsable de la détermination pour toutes les réclamations potentielles de
réparation et/ou de remplacement en vertu de la garantie.
Pour réclamer un service/réparation sous garantie :
A) Si vous habitez aux États-Unis et que vous avez acheté votre produit
directement sur Audeze.com, envoyez un e-mail à [email protected].
B) Si vous habitez aux États-Unis et que vous avez acheté votre produit
auprès d’un revendeur Audeze autorisé, contactez votre revendeur ou
envoyez un e-mail à [email protected].
C) Si vous êtes un client international et que vous avez acheté votre produit
auprès d’un revendeur local, contactez votre revendeur ou le distributeur
pour réclamer votre service/réparation sous garantie.
D) Si vous êtes un client international et que vous avez acheté votre produit
sur Audeze.com, vous devez contacter Audeze par e-mail à l’adresse
[email protected] pour votre service/réparation ou de l’aide. Tout
produit expédié à Audeze pour réparation se fera à charge du client.
Vous aurez besoin du numéro de série de votre produit et d’une preuve
d’achat avant de procéder au retour.
Autres conditions/droits : SAUF EXCEPTIONS INDIQUÉES DANS LA
PRÉSENTE GARANTIE ET DANS LA PLUS GRANDE MESURE AUTORISÉE
PAR LA LOI, AUDEZE N’EST PAS RESPONSABLE DE TOUT DOMMAGE
DIRECT, SPÉCIAL, ACCESSOIRE OU CONSÉCUTIF RÉSULTANT DE TOUTE
VIOLATION DE GARANTIE OU DE CONDITION, OU EN VERTU DE TOUTE
AUTRE THÉORIE JURIDIQUE, Y COMPRIS MAIS SANS S’Y LIMITER, LA PERTE
D’USAGE, LA PERTE DE REVENUS, LA PERTE DE BÉNÉFICES RÉELS OU
ANTICIPÉS, LA PERTE DE CLIENTÈLE, LA PERTE, L’ENDOMMAGEMENT, LA
COMPROMISSION OU LA CORRUPTION DE DONNÉES, OU TOUTE PERTE OU
TOUT DOMMAGE INDIRECT(E) OU CONSÉCUTIF(VE), QUELLE QU’EN SOIT
LA CAUSE, Y COMPRIS LE REMPLACEMENT D’ÉQUIPEMENTS ET DE BIENS.
LA LIMITATION DE RESPONSABILITÉ QUI PRÉCÈDE NE S’APPLIQUERA PAS
AUX RÉCLAMATIONS POUR CAUSE DE DÉCÈS OU DE PRÉJUDICE
CORPOREL, OU À TOUTE RESPONSABILITÉ CIVILE PRÉVUE PAR LA LOI
POUR LES ACTES ET/OU OMISSIONS INTENTIONNEL(LES) ET DE
NÉGLIGENCE GRAVE. CERTAINS ÉTATS AMÉRICAINS OU D’AUTRES PAYS
NE PERMETTENT PAS L’EXCLUSION OU LA LIMITATION DES DOMMAGES
ACCESSOIRES OU CONSÉCUTIFS ; IL SE PEUT DONC QUE LA LIMITATION
OU L’EXCLUSION CI-DESSUS NE S’APPLIQUE PAS À VOUS.
DANS LA MESURE AUTORISÉE PAR LA LOI, CETTE GARANTIE ET LES
RECOURS ÉTABLIS SONT EXCLUSIFS ET SE SUBSTITUENT À TOUTE AUTRE
GARANTIE, TOUT AUTRE RECOURS ET TOUTE AUTRE CONDITION,
QU’IL/ELLE SOIT VERBAL(E), ÉCRIT(E), PRÉVU(E) PAR LA LOI, EXPRÈS(SE)
OU IMPLICITE. AUDEZE REJETTE TOUTE GARANTIE PRÉVUE PAR LA LOI ET
TOUTE GARANTIE IMPLICITE, Y COMPRIS MAIS SANS S’Y LIMITER, LES
GARANTIES DE QUALITÉ MARCHANDE ET D’ADÉQUATION À UNE
UTILISATION SPÉCIFIQUE ET LES GARANTIES CONTRE LES VICES CACHÉS
OU LATENTS, DANS LA MESURE AUTORISÉE PAR LA LOI. DANS LA
MESURE OÙ DE TELLES GARANTIES NE PEUVENT ÊTRE REJETÉES,
AUDEZE LIMITE LA DURÉE ET LES RECOURS DE CES GARANTIES À LA
DURÉE DE LA GARANTIE EXPRESSE ET, AU GRÉ D’AUDEZE, AUX SERVICES
DE RÉPARATION OU DE REMPLACEMENT DÉCRITS AUX PRÉSENTES.
CERTAINS ÉTATS (Y COMPRIS CERTAINS PAYS ET PROVINCES) NE
PERMETTENT PAS DE LIMITE SUR LA DURÉE D’UNE GARANTIE (OU
CONDITION) IMPLICITE ; IL SE PEUT DONC QUE LA LIMITATION DÉCRITE
CI-DESSUS NE S’APPLIQUE PAS À VOUS.
Audeze LLC
http://support.audeze.com
Installation des pilotes Windows
Consultez Audeze.com pour télécharger les pilotes Windows. Étant donné
que le système Mac OS 10.6.4 et les versions supérieures disposent d’une
prise en charge native, aucun pilote n’est requis.
1. Raccordez le cordon électrique et branchez le câble USB sur le Deckard.
2. Branchez le câble USB du Deckard sur votre ordinateur.
3. Placez le commutateur d’alimentation (situé sur le panneau arrière) en
position de marche (ON).
4. Introduisez le mini-CD fourni dans votre lecteur ou téléchargez les pilotes
depuis la page Deckard du site d’Audeze.
5. Vous trouverez sur le CD un fichier intitulé « Deckard Windows Driver.exe ».
Cliquez avec le bouton droit de la souris sur ce fichier et sélectionnez
« Exécuter en tant qu’administrateur ».
6. Vous serez invité(e) à autoriser le processus d’installation à effectuer des
modifications sur votre ordinateur. Sélectionnez « Oui » pour installer le
logiciel. L’installation ne sera pas possible si vous sélectionnez « Non ».
DRIVER AND MANUAL
DRIVER AND MANUALDRIVER AND MANUAL
A
U
D
E
Z
E
D
E
C
K
A
R
D
A
M
P
/
D
A
C
D
R
I
V
E
R
A
N
D
M
A
N
U
A
L
C
M
Y
CM
MY
CY
CMY
K
Decakrd UserGuide2_FR_CS6_PRESS.pdf 9 4/13/2015 11:50:42 AM
