Audi M1000-C-BT1-AUD1 User manual

Audi
Installation Instructions
Version 1.1
Bluetooth Gateway M1000-C-BT1-AUD1

Kit Contents:
• Bluetooth ECU
• Microphone
• Vehicle Interface Loom
• Operating Manual
Tools/Ancillaries Required:
• Panel Removal tools
• Torx screwdriver
•Vehicle Diagnosis Computer,
e.g. VAS 5052 or PC with VCDS VAG-COM software
•DoubleSidedxingtape
Vehicle Requirement:
Installationcanbecarriedoutinvehicleswiththefollowingspecication:
• Multi Function Steering Wheel & Driver Information Display (DIS) with
eitherofthefollowingAudiosystems:Chorus 2+, Concert 2+,
Concert 3, Symphony 2+, Symphony 3, RNS-E
OR
• Vehicles WITHOUT Multi Function Steering Wheel and Driver Information
Display (dis) with the following audio systems RNS-E
WhenttedtovehiclesWITHOUTMultiFunctionSteeringWheelandMulti
Function Display Plus (MFD+) the Phone System operation is limited to the
head unit controls.

Contents
 Procedure: 02
1.1 General preparation of the vehicle for
installation of the components 03
1.2 Mounting the Bluetooth ECU 03
1.3 Routing the Vehicle Interface Loom 03
1.4 Connecting the Vehicle Interface Loom
to the Radio/Radio Navigation unit. 03
1.5 Microphone Installation 04
1.6 Coding the vehicle for Telephone 04
1.7  Functionaltestandnaltting 07
1.8  VehicleSpecicECUMountingLocations 08
1.9  VehicleSpecicMicrophoneMountingLocations 09

Installation Instructions Bluetooth Gateway
Procedure:
PLEASE NOTE:
• Installation of the Integrated Bluetooth Hands-free Phone System
should be carried out by a competent workshop. Special tools,
diagnosticequipmentandspecialliteraturespecictothecaris
requiredfortting.
• Incorrect installation can result in damage to the vehicle or the
product.
• After completing the installation the car must be coded for operation
with the Bluetooth system using a diagnostics, measuring and
information system
• Secure all cables and harnesses so that they cannot come into
contact with any rotating or other moving parts and so that they
cannot chafe on any sharp metal or plastic edges.
1.1 General preparation of the vehicle
for installation of the components
• Switch off the ignition and all electrical equipment
• Remove the radio/radio navigation system (refer to vehicle repair manual)
• Remove any existing hands-free phone system that is connected to
theCANBUSwiringanddonotre-installitasitwillconictwiththe
Bluetooth Gateway system.
02

Installation InstructionsBluetooth Gateway 03
1.2 Mounting the Bluetooth ECU
• Clean the underside of the Bluetooth ECU with a clean towel and
alcohol,andthenattachdoublesidedxingtapetotheundersideof
the Bluetooth ECU.
• Mount the ECU with the sockets facing upwards (if ECU is to be mounted
vertically) so that the plugs cannot fall out.
• Please see pictures Section 1.8forvehiclespecicECUmounting
positions.
1.3 Routing the Vehicle Interface Loom
• Route the QUADLOCK Plug/Socket end of the Vehicle Interface Loom
from behind the head unit to the location of the Bluetooth ECU.
• Secure the Vehicle Interface Loom using the supplied cable ties within
the dashboard to the existing wiring/wiring looms.
1.4 Connecting the Vehicle Interface Loom
to the Radio/Radio Navigation unit.
• With the Radio/Radio Navigation unit removed, connect the socket
side of the Vehicle Interface Loom to the plug that usually connects to
the radio/radio navigation system.
• Connect the plug side of the vehicle interface loom to the radio/radio
navigation unit.

Installation Instructions Bluetooth Gateway
1.5 Microphone Installation
• Please see Section 1.9forvehiclespecicMicrophonemountingpositions.
• Clean surface that the microphone is to be mounted to with alcohol
and clean towel.
• Once the Microphone is mounted in the correct position, route the
cable to the Bluetooth ECU location.
• Secure the microphone cable using the supplied cable ties within the
dashboard to the existing wiring/wiring looms.
• Connect the microphone plug to the Bluetooth ECU 2.5mm
microphone socket.
• Bundle any spare microphone cable together and cable tie to the
Vehicle interface loom.
1.6 Coding the vehicle for Telephone
• Connect a vehicle diagnosis, measurement and information
system to the vehicle.
• Select the operating mode “Self Diagnosis”
NOTE: ‘X’ denotes digits in the coding which vary depending on the vehicle
04

Installation InstructionsBluetooth Gateway 05
Head Unit Coding
The following head units require coding, if not listed here they do not
need coding.
• RNS-E Head Unit
Address 56 (Radio)
0XXX?XX- Digit marked ? Has to be changed to 7
The RNS-E head unit need to have a software index of at least 350.
RNS-E RESET After coding you need to complete a RESET of the head unit.
Please turn the device off. When the head unit is turned back on keep
the ON/OFF button held down for 45 seconds until the head unit resets.
• Concert 2+, Symphony 2+
Address 56 (Radio)
0?XXXXX- Add 4to the existing value of ? (e.g. 3 to 7)
• Concert 3, Symphony 3 – only for A4 8K, A5 8T, A5 8F, Q5 8R
Address 56 (Radio)
-Select Coding
-Select master
-Select Byte 3
-Change value of Byte 3 from 10000000 to 10000010
Address 47 (Sound system)
- only for A4 8K, A5 8T, A5 8F, Q5 8R with B&O sound system
-Select Byte 3
-Set Bit 0 to 1
-Set Bit 1 to 0

Installation Instructions Bluetooth Gateway06
Chassis Coding
• Chassis A4 8E and A6 4B
Address 17 (Instrument cluster)
Channel 62, add 2 to the existing value (e.g. 17 to 19)
• Chassis A4 8E
Address 16 (Steering Wheel)
02XXX– change 02XXX to 03XXX
• Chassis A6 4B and A8 4D
Address 16 (Steering wheel)
0XXX2– change 0XXX2to 0XXX1
• Chassis A38P,TT8J,A48K,A58T,A58F,Q58R
Address 19 (CAN gateway)
- Select Address 19 – Diagnostic Interface Databus
- Select Coding
- Option 77 Telephone
- Set option 77 to coded.

Installation InstructionsBluetooth Gateway 07
1.7 Functional test and nal tting
• Check the function of the Integrated Bluetooth Hands-Free Phone
System by pairing a mobile telephone to the system (Bluetooth ID is
BT Gateway, PIN code is 1234) and then make a call. End the call via
the Multi Function Steering Wheel.
• Test the answering function by calling the paired mobile telephone
from another phone and answering using the Multi Function Steering
Wheel.
• While on the call test the microphone and the speaker system (make
sure you can hear the caller and that they can hear you)
• While the mobile telephone is paired, turn the ignition off and remove the
key. The mobile telephone should disconnect from the Bluetooth system.
Leave the ignition off for 30 seconds and then switch it back on. The
mobile telephone should re-connect with the system within 90 seconds.
• If the vehicle has an RNS-E head unit or is an A4/A5/Q5 with Con-
cert3 or Symphony3 please ensure that the phone operating console
is displayed on the screen when the PHONE button (on the radio
control panel) is pressed.
•Rettheradio/radionavigationunitandallothertrimpanelsthat
were removed. (refer to the vehicle repair manual)

Installation Instructions Bluetooth Gateway
1.8 Vehicle Specic ECU Mounting Locations
1A A3 (8P), TT (8J)
Remove bolt behind trim panel & two
bolts underneath dash.
1B A3 (8P)
Location:Mountedtodashsupport
brace using double-sided tape.
1C A4 (8K) A5 (8T & 8F) Q5 (8R)
Remove bolt behind trim panel & two
bolts underneath dash.
1D A4 (8K) A5 (8T & 8F) Q5 (8R)
Location:Mountedtodashsupport
brace using double-sided tape.
1E A4(B7)
Location:Mountedtodashsupport
brace using double-sided tape.
08
STEERING
COLUMN
FUSE
BOX
STEERING
COLUMN
FUSE
BOX
FUSE
BOX

Installation InstructionsBluetooth Gateway 09
1.9 Vehicle Specic Microphone Mounting Locations
2A A3 (8P)
Location:Attachedtotrimpanelwith
wire routed behind trim panel.
2B A4 (8K) A5 (8T & 8F) Q5 (8R)
Location:Attachedtosteeringcolumn
shroud with wire routed behind vinyl.
2C A4(B7)
Location:Attachedtotrimpanelwith
wire routed behind trim panel.
