Audio 2000 AWM6014U User manual

WARNING AND SAFETY INSTRUCTIONS 1...............................
FEATURES 3................................................................
HANDLING PRECAUTIONS 3..............................................
HEADSET MICROPHONE 4.............................................
RECEIVER BODY PACK 5(-)............................................
BASIC CONNECTIONS 6...................................................
GENERAL OPERATION 7..................................................
SAFETY PRECAUTIONS 8.................................................
TROUBLESHOOTING 9....................................................
SPECIFICATIONS 10........................................................
SERVICE INFORMATION 11................................................
TRANSMITTER BODY PACK 4(-).......................................
DESCRIPTIONS AND FUNCTIONS

UHF Band Frequencies-
Including One AEM6014U Headset Microphone, One AWX6014U Wireless
Transmitter, and One AWR6014U Receiver
One 3.5mm Mono Microphone Output on the AWR6014U
One 3.5mm Mono Headphone Output on the AWR6014U
Power ON/OFF Switch and Audio Level Control on the AWR6014U
Power LED Indicator, AF LED Indicator, and RF LED Indicator on the AWR6014U
One 3.5mm Microphone Input on the AWX6014U
One Low Battery (LOW BATT) LED Indicator on the AWX6014U
Omni-Directional Antenna on AWX6014U and AWR6014U
Operating Range up to 100ft
Both AWX6014U and AWR6014U Powered by Two AA Batteries (Not Included)

3 5mm Plug.
Cartridge
Head-Band Support
Cable 3ft()
LOW BATT
LOW BATT Low Battery LED
Indicator
-
MIC Headset Microphone Input Jack-

DC 4 5V.
DC 4 5V DC 4 5V Input Jack..-
Output Volume Control
(for Microphone)
AF Audio Signal LED Indicator
-
OUTPUT Microphone Output Jack-
MIN
OUTPUT
VOLUME
12
12

1 Headset Microphone Connection)
3 5mm Plug.
3 5mm Stereo Plug.
3 5mm Plug.Mono
Video Camera
Audio Cable
Connect the 3.5mm plug of the headset microphone to the MIC input jack
on the AWX6014U transmitter.
2 Headphone Connection)
3 Output Connections)
Connect the 3.5mm plug of the headphones to the Headphone Output jack on
the AWR6014U receiver.
Connect the mono(TS) 3.5mm plug of the included audio cable
to the microphone output jack on the AWR6014U receiver. Connect the
stereo(TRS) 3.5mm plug of the included audio cable to the
microphone input jack of a video camera or a video recording device.
Headphones
DC 4 5V.
LOW BATT

2 Install two AA batteries (not included) to the AWX6014U transmitter and.
the AWR6014U receiver respectively. Make sure that the polarities of the
AA batteries are oriented as indicated in the battery compartment.
Connect the AWR6014U receiver microphone output to the microphone
input of a video recording device via the included 3.5mm audio cable. (Refer to
the "Output Connections" section on page 6 for the connection details.)
AWX6014U.The red LOW BAT LED indicator
Once the AWX6014U is turned on, the LOW BAT LED indicator will stay off
until the battery level of the installed AA batteries is below a predetermined level.
(The LOW BAT LED indicator will stay on only after the battery level of the
installed AA batteries is below the predetermined level.)
On the AWX6014U will blink once.

10
AWR6014U TRANSMITTER
AWR6014U Transmitter
AWR6014U SYSTEM
ACCESSORIES
Batteries
2 AA Batteries
or DC 4.5V
*
One Cable ( 3.5mm Stereo-3.5mm Mono)
AWR6014U RECEIVER
AWR6014U Receiver
OWNER S MANUAL
'
Headset Microphone
Lanyards

11
