User Manual
Model C-1080
Four-Position Analog Audio
Demo Switcher
2048 Mercer Road, Lexington, KY 40511-1071 USA
800-322-8346 • 859-233-4599 • Fax: [phone]
[e-mail] • www.audioauthority.com
752-662 Rev. 20130829

POWER
INPUT
OUTPUT TO
SOUNDBARS
1
4 3 2 1
2 3 4
DEMO
TIMEOUT
SOURCE
INPUT
(TV OR OTHER DEVICE)
TIMEOUT
DEFAULT
PRODUCT SELECT BUTTONS
The C-1080 is a switch with timeout and keep-awake features. It demonstrates
analog audio devices such as soundbars and sound docks in a retail environment.
Press push-button 1, 2, or 3 to connect the C-1080 input to the selected output.
The demo is active until the timeout interval is complete. When the demo times
out, the C-1080 switches to the fourth position until a button is pressed. Every 15
minutes, the keep-awake feature switches to each position for 5 seconds to prevent
soundbars from going into sleep mode.
Switch 1 2
30 sec. ON ON
60 sec. ON OFF
90 sec. OFF ON
120 sec. OFF OFF
Installation
• ConnecttheaudiooutputofaTVorotheranalogaudiosourcetotheTVinput
on the C-1080.
• ConnecteachC-1080audiooutputtoaSoundbarinput,orotherdevicethat
accepts low-level analog audio.
• Connectamomentarypush-buttonswitchtothetwo-pinport.
• Setthetimeoutfortheperiodoftimeeachdemo
should last. Use the table to set the two Dip
switches.
• ConnecttheC-1080toanACpoweroutletusing
the power supply included.
• Testoperationusingananalogaudiosource
and soundbars or similar devices. Position #4 is
the default, which is selected after the timeout
interval. The illuminated button indicates the
position that is currently selected.
Demo Timeout Settings
