FSR DV-HSW4K-41AUD User manual

43440 LIT1844
DV-HSW4K-41AUD
HDMI 2.0 4x1 Switcher
244 Bergen Blvd Woodland Park, NJ 07424
973-998-2300 www.fsrinc.com
All Rights Reserved
User Manual

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
Preface
Read this user manual carefully before using the product.
This manual is only for operation instruction, please contact the local distributor for
maintenance assistance. In the constant effort to improve the product, we reserve the
right to make functions or parameters changes without notice or obligation.
FCC Statement
This equipment generates and can radiate radio frequency energy. if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. It has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
SAFETY PRECAUTIONS
To ensure the best performance from the product, please read all instructions carefully
before using the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
Follow basic safety precautions to reduce the risk of fire, electrical shock, and injury
to persons.
Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration, or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install
this product near water.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with adequate ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on the housing, unplug the module immediately.
Do not twist or pull by force cable ends.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
Table of Contents
1. Product Introduction....................................................................................................5
1.1 Features ............................................................................................................5
1.2 Package List ......................................................................................................6
2. Technical Specification................................................................................................7
3. Panel Description........................................................................................................8
3.1 Front Panel........................................................................................................8
3.2 Rear Panel.........................................................................................................9
4. System Connection...................................................................................................10
4.1 Usage Precaution ............................................................................................10
4.2 System Diagram ..............................................................................................10
5. Source Button Control...............................................................................................11
5.1 Manual Switching ............................................................................................ 11
5.2 Automatic Switching ........................................................................................ 11
6. IR Remote Control ....................................................................................................12
7. RS232 Control ..........................................................................................................13
7.1 RS232 Control Software..................................................................................13
7.2 RS232 Command ............................................................................................13
7.2.1 Signal Switching ....................................................................................13
7.2.2 Source Device Control...........................................................................14
7.2.3 Display Device Control ..........................................................................15
7.2.4 Audio Selection......................................................................................15
7.2.5 System Control ......................................................................................15
8. EDID Management ...................................................................................................16
8.1 Predefined EDID Setting..................................................................................16
8.2 User Defined EDID Setting..............................................................................17
9. ARC Mode ................................................................................................................18
10. Firmware Upgrade .................................................... Error! Bookmark not defined.
11. Panel Drawing .......................................................... Error! Bookmark not defined.
12. Troubleshooting & Maintenance .............................................................................19
13. Customer Service ...................................................................................................19

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
5
1. Product Introduction
The DV-HSW4K-41AUD is an ultrathin auto switcher with four HDMI video inputs and
one HDMI output. This switcher supports HDMI video resolution up to 4K@60Hz 4:4:4
HDR and multichannel audio. Except passing EDID information from the display, there
are multiple built-in EDID settings to simplify an installation. The switcher will de-embed
digital stereo audio to provide an analog audio source for an audio system. The
switcher also supports audio return channel (ARC) for transmitting audio back to HDMI
input port from the connected display.
In auto-switch mode, it switches to an HDMI input as soon as a new source is
connected. When the active input is removed, the switcher will select the first source on
the lowest numbered input. The switcher may also be controlled via RS232, IR with the
included remote, or from the source button on the front of the switcher.
1.1 Features
Switches any one of four HDMI inputs to one HDMI output.
Supports video resolution up to 4K@60Hz 4:4:4, Dolby Vision, HDR.
18Gbps high bandwidth.
Fully compliant with the HDMI 2.0 and HDCP2.3 specifications.
Supports audio return channel (ARC).
Advanced EDID management: multiple preset and user defined allowed.
Controllable via RS232 and IR.
Supports CEC.
Provides seven LEDs to indicate the current operating status and to assist
troubleshooting and installation.
Firmware upgrade by Micro-USB port.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
6
1.2 Package List
1x HDMI 2.0 4x1 Switcher
2x Mounting Ears
4x Mounting Screws
4x Plastic Cushions
1x RS232 Cable (3.5mm to DB9)
1x IR Remote
1x IR Receiver
1x Power Adapter (5V DC 1A)
1x User Manual
Note: Please contact your distributor immediately if any damage or defect is found.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
7
2. Technical Specification
Video Input
Input
(4) HDMI
Input Connector
(4) Female type-A HDMI
HDMI Input Resolution Up to 4K@60Hz 4:4:4, Dolby Vision, HDR
HDMI Standard
2.0
HDCP Version 2.3
Video Output
Output
(1) HDMI
Output Connector
(1) Female type-A HDMI
HDMI Output Resolution Up to 4K@60Hz 4:4:4, Dolby Vision, HDR
HDMI Standard
2.0
HDCP Version 2.3
Audio
Output
(1) AUDIO
Output Connector
(1) 3.5mm mini stereo audio jack
Audio Format PCM
Audio Output Impedance
70 Ohms
Frequency Response 20Hz to 20kHz, ±3dB
Control
Control
(1) IR IN; (1) RS232
Control Connector
(2) 3.5mm mini jacks
General
Bandwidth
18Gbps
Operation Temperature
-5 to +55
℃
(+23° to +131°F)
Storage Temperature -25 to +70℃(-13° to +158°F)
Relative Humility 10% to 90%, non-condensing
Power Supply Input:100V~240V AC; Output: 5V DC 1A
Power Consumption
5W(Max)
Dimension (W*H*D)
194mm (7.6”) x 15mm (.6”) x 81mm (3.2”)
Net Weight
324g (11.4oz)
Note: Please adopt a high-qualified HDMI cable fully compliant with HDMI 2.0 specifications for reliable
transmission and connection.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
8
3. Panel Description
3.1 Front Panel
①Auto/Source Button:
Press to switch to next input source.
Press and hold for three seconds to switch between manual mode and auto
mode.
②Power LED: The LED illuminates red when power is applied.
③Audio Mode LED:
Illuminates green when de-embedding audio has been selected.
Illuminates yellow when in ARC mode.
④Switching Mode LED:
Illuminates green in manual switch mode.
Illuminates yellow in auto-switch mode. LIFO
⑤Input 1~4 LED: The LED illuminates green when there is an HDMI input on the
corresponding channel.
⑥FIRMWARE: Micro-USB port for firmware upgrade.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
9
3.2 Rear Panel
①IN 1~4: Four type-A female HDMI input ports to connect HDMI sources. Only input
4 port supports ARC.
②OU T: Type-A female HDMI output port to connect HDMI display.
③AUDIO: 3.5mm mini jack for analog audio output.
④RS232: 3.5mm mini jack to connect control device (e.g., PC).
⑤IR IN: 3.5mm mini jack to connect the included IR receiver for remote control.
⑥EDID: 4-pin DIP switch for EDID settings.
⑦DC 5V: DC port to connect a 5V DC power adapter.
Note: Output HDCP compliant status depends on input signal. When the input signal is
with HDCP, then output signal is with HDCP and vice versa.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
10
4. System Connection
4.1 Usage Precaution
Make sure all components and accessories are included before installation.
System should be installed in a clean environment with proper ventilation and
humidity.
All plugs, sockets, and power cords should meet local and national code.
All devices should be connected before powering on.
4.2 System Diagram
The following diagram illustrates typical input and output connections that can be
utilized with this switcher:

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
11
5. Source Button Control
5.1 Manual Switching
When the switcher is in manual switching mode, the Switching Mode LED will be green,
and pressing Auto/Source button will switch to the next input.
5.2 Automatic Switching
To enable automatic switching, press and hold the Auto/Source button for three
seconds. The Switching Mode LED will turn to yellow.
When in auto-switch mode, the switcher follows the below rules:
New Input: Upon detecting a new input, the switcher will automatically select the
new source.
Reboot: Once power is restored to the switcher, if the last selected source is still
available, the switcher will still output this signal, otherwise, the switcher will switch
to the first available active input starting at HDMI Input 1.
Source Removed: When an active source is removed, the switcher will switch to the
first available active input starting at HDMI Input 1.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
12
6. IR Remote Control
Connect the IR receiver to the IR input port; the IR remote is used for input switching
and it can also be used to control source and display devices based on CEC
functionality.
Note:
HDMI input 4 port does not support CEC, the source device connected to this port
cannot be controlled via the IR remote.
The source and display devices are required to support CEC when the IR remote is
used to control them.
INPUTS:
1~4: Select the corresponding input source.
MANUAL/AUTO: Switch Auto or manual mode.
SOURCE: Control the input source (e.g., DVD).
DISPLAY: Control the display (e.g., HDTV).

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
13
7. RS232 Control
Connect the switcher to the control device (e.g., PC, Control System) with an RS232
cable and set the parameters correctly.
7.1 RS232 Control
Basic Settings
Baud rate: 9600
Data bit: 8
Stop bit: 1
Parity bit: none.
RS232 Commands
Note: All commands must end with “<CR><LF>”. Carriage Return and Line Feed.
7.1.1 Signal Switching
Function
Command
Feedback Example
Switch to HDMI input 1. >>HDMI1 <<HDMI1
Switch to HDMI input 2. >>HDMI2 <<HDMI2
Switch to HDMI input 3. >>HDMI3 <<HDMI3
Switch to HDMI input 4. >>HDMI4 <<HDMI4
Enable auto-switching mode. >>AUTO <<AUTO Switch
Enable manual switching mode. >>MANUAL <<MANUAL Switch

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
14
7.1.2 Source Device Control
Note:
The input source device is required to support CEC.
HDMI input 4 port does not support CEC, the source device connected to this port
cannot be controlled by IR remote.
Function
Command
Feedback Example
Turn on the input source device,
e.g., Blue-ray DVD. >>SRCOn <<SRCOn
Turn off the input source device,
e.g., Blue-ray DVD. >>SRCOff <<SRCOff
Play >>SRCPlay <<SRCPlay
Pause >>SRCPause <<SRCPause
Stop >>SRCStop <<SRCStop
Fast Forward x1 >>SRCForward <<SRCForward
Fast Rewind x1 >>SRCBackward <<SRCBackward
Next Section >>SRCSkipForward <<SRCSkipForward
Previous Section >>SRCSkipBackward <<SRCSkipBackward
Open the menu setting >>SRCMenu <<SRCMenu
Go back >>SRCBack <<SRCBack
Confirm (OK) >>SRCOk <<SRCOk
Exit >>SRCExit <<SRCExit
Up direction >>SRCUp <<SRCUp
Down direction >>SRCDown <<SRCDown
Left direction >>SRCLeft <<SRCLeft
Right direction >>SRCRight <<SRCRight

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
15
7.1.3 Display Device Control
Note:The display device is required to support CEC.
Function
Command
Feedback Example
Turn on the display device, e.g.,
HDTV. >>TVOn <<TVOn
Turn off the display device, e.g.,
HDTV. >>TVOff <<TVOff
Volume up. >>TVVOL+ <<TVVOL+
Volume down. >>TVVOL- <<TVVOL-
Mute.
>>TVMUTE
<<TVMUTE
Unmute
<<TVUNMUTE
7.1.4 Audio Selection
Function
Command
Feedback Example
Select ARC audio channel.
>>AUDExternal <<AUDExternal
Select the HDMI audio input
channel. >>AUDInternal <<AUDInternal
7.1.5 System Control
Function
Command
Feedback Example
System reset.
>>RESET <<RESET
Get system information. >>SYSInfo
<<AUDExternal
<< DV-HSW4K-41AUD
<< V1.xx
<< --------
<<HDMI1
<<Auto Switch
<<AUDExternal
<<EDID0

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
16
8. EDID Management
8.1 Predefined EDID Setting
The rear panel provides a 4-pin DIP switch to set a predefined EDID. The unit has ten
types of embedded EDID and their corresponding switch status are shown in the list
below.
When in the lower
position, the switch
represents “ON”,
while putting the
switch in the up
position, it
represents “OFF”.
ID
Switch
Status Video Audio
0
0000
Pass though
Pass though
1 0001 1920x1080p@60Hz 4:4:4
RGB 8bit Stereo
2 0010
1920x1080p@60Hz 4:4:4
RGB 8bit High Definition
3 0011
1920x1080p@60Hz 4:4:4
RGB 12bit Stereo
4 0100
1920x1080p@60Hz 4:4:4
RGB 12bit High Definition
5 0101
3840x2160p@60Hz 4:2:0
RGB 8bit Stereo
6 0110 3840x2160p@60Hz 4:2:0
RGB 8bit High Definition
7 0111
3840x2160p@60Hz 4:4:4
RGB 10bit HDR Stereo
8 1000
3840x2160p@60Hz 4:4:4
RGB 10bit HDR High Definition
9 1001 1280x800@60Hz Stereo
10
1010
1920x1200@60Hz
Stereo

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
17
8.2 User Defined EDID Setting
There are five EDID settings that can be customized following the below operations.
1) Rename the user defined EDID according to the following format.
EC_xx_xxxx_xxx.bin
EC: Represents EDID.
xx: Represents EDID ID. It is 11~15.
xxxx: Represents the video parameter.
xxx: Represents the audio format.
Example: EC_11_720P_LPCM.bin
2) Power on the switcher, and then connect the switcher to the PC with USB cable.
The PC will automatically detect a U-disk named of “BOOTDISK”.
3) Double-click the U-disk, a file named of “READY.TXT” to view.
4) Copy the user defined EDID (such as EC_11_720P_LPCM.bin) to the
“BOOTDISK” U-disk.
5) Reopen the U-disk to check the filename “READY.TXT” this should automatically
become “SUCCESS.TXT”, if yes, the user defined EDID was imported into the
switcher and saved as its corresponding EDID ID successfully.
6) Repeat the above third to fifth step to copy another user defined EDID to the
“BOOTDISK” U-disk.
7) Remove the USB cable, connect the adaptor to power on the switcher.
8) The new EDID also can be invoked via the 4-pin DIP switch directly. The EDID ID
and its corresponding switch status are shown in the below list.
ID
Switch Status
11
1011
12 1100
13
1101
14
1110
15
1111

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
18
9. ARC Mode
Audio Return Channel (ARC) allows audio from a display to pass “upstream” through
an HDMI cable to an audio processing device, such as an AV amplifier. When ARC
mode is active on the switcher, the ARC stream will pass to the active HDMI source
device if it can process the signal.
Only the fourth HDMI input port features ARC, when the display and AV amplifier
support ARC, the audio connection diagram is shown below:

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
19
10. Troubleshooting & Maintenance
Problems Potential Causes Solutions
Color loss or no video
signal output on HDMI
display. The connecting cables
may not be connected
correctly, or they may be
broken.
Check whether the cables
are connected correctly
and in working condition.
No HDMI signal output
from this switcher while
local HDMI input is in
normal working state.
Splash screen on output
devices.
Poor quality of the
connecting cable.
Change out cable for
another cable of good
quality.
Cannot control this
switcher with control
device (e.g., a PC)
through RS232 port.
Wrong RS232
communication
parameters.
Make sure the RS232
communication
parameters are correct.
This switcher is broken. Send to authorized dealer
for repairing.
Static becomes stronger
when connecting the
video connectors.
Bad grounding.
Check the grounding and
make sure it is connected
well.
Note: If your problem still exists after following the above troubleshooting steps, please
contact your local dealer or distributor for further assistance.
11. Customer Service
Before returning any equipment for repair, please be sure that it is adequately packed
and cushioned against damage in shipment, and that it is insured. We suggest that you
save the original packaging and use it to ship the product for servicing. Also, please
enclose a note giving your name, address, phone number and a description of the
problem.
NOTE: all equipment being returned for repair must have a Return authorization (RMA)
Number. To get a RMA Number, please call the FSR Service Department (1-800-332-
FSR1). Please display your RMA Number prominently on the front of all packages.

DV-HSW4K-41AUD, HDMI 2.0 4x1 Switcher
20
Limited Warranty
The DV-HSW4K-41AUD is warranted against failures due to defective parts or faulty
workmanship for a period of three years after delivery to the original owner. During this
period, FSR will make any necessary repairs or replace the unit without charge for
parts or labor. Shipping charges to the factory or repair station must be prepaid by the
owner, return-shipping charges (via UPS Ground) will be paid by FSR.
This warranty applies only to the original owner and is not transferable. In addition, it
does not apply to repairs done by other than the FSR factory or Authorized Repair
Stations.
This warranty shall be cancelable by FSR at its sole discretion if the unit has been
subjected to physical abuse or has been modified in any way without written
authorization from FSR. FSR’s liability under this warranty is limited to repair or
replacement of the defective unit.
FSR will not be responsible for incidental or consequential damages resulting from the
use or misuse of its products. Some states do not allow the exclusion of incidental or
consequential damages, so the above limitations may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights which vary from
state to state.
Warranty claims should be accompanied by a copy of the original purchase invoice
showing the purchase date (if a Warranty Registration Card was mailed in at the time of
purchase, this is not necessary). Before returning any equipment for repair, please read
the important information on service below.
CONTACT INFORMATION:
FSR INC.
244 Bergen Blvd.
Woodland Park, NJ 07424
Phone: [phone]
*Order Desk Fax: [phone]
E-mail: [e-mail]
Web Site: http://www.fsrinc.com
