Audio international CTP-010-01 User manual

7300 Industry Drive, North Little Rock, AR 72117
Phone: [phone] Fax: [phone]
Guide to Operations
Cassette Tape Player
Model #’s: CTP-010 & CTP-010-01
Document #560014

AUDIO INTERNATIONAL, INC. 1/98
2
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
The CTP-010 & CTP-010-01 has been specially engineered to meet
aircraft use requirements.
READ THIS MANUAL COMPLETELY BEFORE
OPERATING YOUR PLAYER
If you have any questions, please contact Audio International, Inc. See the last
page of this booklet for the nearest AI representative.

AUDIO INTERNATIONAL, INC. 1/98
3
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
(This page intentionally left blank)

AUDIO INTERNATIONAL, INC. 1/98
4
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
TABLE OF CONTENTS
Page
#
Cover Page………………………………………………………………………………. 1
Table of Contents………………………………………………………………………... 4
Product Features…………………………………………………………………………. 5
Warnings………………………………………………………………………………… 6
Cautions………………………………………………………………………………….. 7
Introduction……………………………………………………………………………… 8
Illustration of Front Panel………….…………………………………………………… 10
Operating Instructions………………………………………………………………….. 11
To Play a Cassette………………………………………………………………. 11
To Rewind the Tape…..…..……………………………………………………... 12
To Advance the Tape…………..………………………………………………... 12
To Reverse the Direction of Play..………………………………………………. 12
To Stop of Eject a Cassette...……………………………………………………. 13
Optional Infrared Remote Operation………..…………………………………………... 14
Troubleshooting Guide…………...……………………………………………………… 16
Authorized Representatives………...……………………………………………………. 17

AUDIO INTERNATIONAL, INC. 1/98
5
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
PRODUCT FEATURES
•Multiple control options: Backlit LCD indicator with front panel controls
Infrared remote control capability
RS-485 digital data bus control capability
•High-quality output: Dolby noise reduction
Frequency response of 30 Hz to 18kHz (+/-3dB)
Audio output of 1 V to 10 V RMS adjustable
WOW and flutter of .08% (WRMS)
Signal to noise ratio of 63 dB
Tape speed of 4.76 cm/sec. (1 7/8 inch per second)

AUDIO INTERNATIONAL, INC. 1/98
6
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
WARNINGS
- DO NOT insert or leave metallic objects inside the unit.
- DO NOT touch the liquid crystal display fluid if the LCD is
damaged or broken. The fluid may be dangerous or fatal. If
body or clothing comes in contact with fluid from the display,
wash immediately with soap and water
- DO NOT attempt to open the case of the unit. Removal of case
voids all warranties.
STOP

AUDIO INTERNATIONAL, INC. 1/98
7
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
CAUTIONS
- DO NOT take food or beverages near the unit.
- DO NOT use long tapes such as 120-minute cassettes. The tape
utilized is very thin and easily become entangled in the unit.
CAUTION

AUDIO INTERNATIONAL, INC. 1/98
8
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
INTRODUCTION
•General Care:
1. Do not play cassettes with slack tape spools; slack tapes can become
entangled around the capstand and/or pinch rollers. If the spool is slack,
re-tension using a pencil in one of the spools and “tightening”the tape.
2. Do not play deformed cassettes or cassettes with loose labels. The
cassette may become lodged inside the unit or cause it to malfunction.
3. Do not store cassettes in hot locations or expose to direct sunlight.
4. Do not leave cassettes in the unit when not in use; tapes may stick to the
tape head and cause a malfunction.

AUDIO INTERNATIONAL, INC. 1/98
9
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
•Cleaning the unit:
1. Turn the power “OFF”and wipe the panel with a dry, lint free, silicon
cloth.
Note: Use of rough cloth or volatile solvents such as paint thinner or
alcohol may damage the surface of the panel and/or cause damage
to the liquid crystal display.
2. The cassette slot in the faceplate should be cleaned periodically as
accumulated dust can scratch the surface of the cassettes when inserted or
removed from the player. A dry cotton swab is recommended for this
cleaning. (Clean only the outer, exposed surfaces.)
3. Magnetic powder and dust accumulation on the tape head can cause noise
and deterioration of sound quality. To clean the tape head, use a
commercial cleaning tape designed for this purpose.

AUDIO INTERNATIONAL, INC. 1/98
10
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
ILLUSTRATION OF FRONT PANEL
CassetteInsertion/
Removal Slot
Display
Refer to page 11 for names and functions of buttons.

AUDIO INTERNATIONAL, INC. 1/98
11
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
OPERATING INSTRUCTIONS
•General Information:
Ensure power is available to the tape player; there are no “ON/OFF”controls on
the unit. Power is controlled from the cockpit.
When the unit powers up, it will sequence through a series of diagnostics. When
the diagnostics are complete, the display will read ALL OFF.
Power up speakers from the appropriate control panel. Audio will be supplied
through headphones or speakers.
•To Play a Cassette:
Insert a cassette with the tape exposed to the right, into the cassette slot. Apply a
slight amount of pressure to the outer edge of the cassette. The CTP will accept
the cassette and “pull”it into the unit.
Once the tape is inserted, the display will read TAPE.
Playback will begin automatically. The unit will reverse direction automatically
when all tracks have been played in sequential order.

AUDIO INTERNATIONAL, INC. 1/98
12
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
Referring to the front view drawing on page 10 of this publication:
1. To Rewind the Tape:
Press and release the button to return to the beginning of the current
track and resume play. Press the button one to nine times to rewind
through multiple tracks. The unit will resume playback when the desired
track is reached.
Press the button at any time to resume normal play at the current
location.
2. To Advance the Tape:
With a cassette inserted in the player, press and release the button.
The unit will advance to the next track on the cassette and resume play.
Press the FF button one to nine times to advance through multiple tracks.
The unit will resume playback when the desired track is reached.
The display will indicate the number of tracks. Press the program button
at any time to resume normal play at the current location.

AUDIO INTERNATIONAL, INC. 1/98
13
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
3. To Reverse the Direction of Play:
While a cassette is playing, press the button. The cassette will
reverse direction and begin playing the other side of the tape. The display
will indicate the direction of the tape with a left or right arrow.
4. To Stop or Eject a Cassette:
While a cassette is playing, press the button. Playback will stop,
the cassette will eject from the unit, and the unit will turn off.
Note: The cassette will eject approximately 1½inches from the slot. Be
sure no obstructions are blocking the slot.
The display will read ALL OFF.

AUDIO INTERNATIONAL, INC. 1/98
14
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
OPTIONAL INFRARED REMOTE OPERATION
The following functions can be controlled using Audio International’s optional remote control
unit customized for your system configuration. Refer to the operations manual supplied with the
unit to determine functions available on the unit.
•To Stop or Eject a Cassette:
Press the stop/eject button on the remote. Playback will stop and the cassette will
eject.
•To Reverse the Direction of Play:
Press and release the program button on the remote. The player will reverse
direction to play the other side of the cassette.
•To Advance the Tape:
Press and release the fast forward button on the remote to advance to the next
track and begin play. Each time the button is pressed, the unit will advance an
additional track (up to nine tracks).

AUDIO INTERNATIONAL, INC. 1/98
15
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
•To Rewind the Tape:
Press and release the rewind button on the remote to return to the beginning of the
current track and resume play. Each time the button is pressed, the unit will
rewind an additional track (up to nine tracks). Press the program button on the
remote to resume normal play at the current location.

AUDIO INTERNATIONAL, INC. 1/98
16
Document #560014, Rev. A, Model No.: CTP-010 & CTP-010-01
TROUBLESHOOTING GUIDE
PROBLEM CAUSE SOLUTION
No sound can be heard. Bad cassette. Replace cassette.
Sound quality is poor or
distorted. Volume too high.
Tape head is dirty
Turn volume “down”.
Clean the head referring to section of this
publication on cleaning the unit.
Cassette cannot be
loaded Cassette is deformed
Cassette has been inserted incorrectly.
Replace cassette.
Reload the cassette.
Error Messages Unit malfunctioning Contact Audio International, Inc.
