MODEL NO.
RCP-020-x (-40x)
RCP-021-40x
Cassette Player / AM-FM Tuner
1.0 General Information
1.1 Introduction
This manual contains information for the installation of the Audio International,
Inc. (AI) Cassette Player / AM-FM Tuner, Model Nos. RCP-020-x and RCP-021-
40x. The “x”suffix in the number designates the specific model purchased.
Information contained within this publication includes relative physical,
mechanical, and electrical characteristics. Also included within this publication
are additional references needed for installation of the unit.
1.2 Purpose of the Equipment
The RCP is a high quality AM-FM cassette tape player specifically designed to
meet the special requirements of aircraft use. The unit allows complete control of
track selection. Features include track search, track repeat, track scan and random
play mode. The unit has high quality output, adjustable stereo output level from 1
to 5 volts RMS, and full range frequency response of 20Hz to 20kHz (+/-1dB).
The cassette tape player can be mounted in a cabinet or in a bulkhead. AI source
equipment can be optionally controlled by infrared remote. A unique strapping
feature allows up to four (4) similar devices to be used in the same system at the
same time while maintaining independent control.
1.3 Operational Features
Operational features of the units include a backlit LCD indicator display along
with a user controllable keypad interface. Additionally, the units are infrared
remote control capable. The model number RCP-020–40x and RCP-021-40x will
interface with AI proprietary RS-485 data bus; the RCD-020-x will not interface
with AI’s proprietary RS-485 data bus.
1.4 Optional Equipment
The front bezel of the RCD can be customized to match the interior style of any
aircraft. This includes plating and painting to match aircraft interiors.

AUDIO INTERNATIONAL, INC. 3/98
6
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
AI source equipment is configured to accept digital infrared commands. Digital
codes allow the source equipment to interface with an infrared handheld remote
control (AI-RC1-17xxxx) via infrared receiver, IFR-9A. Multiple units can be
controlled independently using available programming pins. The infrared code
allows up to four (4) similar devices to be used in the same system while
maintaining independent control. To install multiple units, contact Audio
International, Inc.
2.0 Installation
2.1 Prior to Installation
The RCP is a simple AM-FM cassette tape player to use and install. The RCP is
capable of accepting infrared digital input and/or a RS-485 two-wire digital data
bus input. All audio input and output cables on the unit should be twisted
shielded pair (24 AWG minimum) unless otherwise specified. The unit must be
attached to conform to the standards designated by the customer, installing
agency, and existing conditions as to the unit location and type of installation.
The following should be carefully considered before installing:
2.1.1 Select a mounting location for the unit where 28 VDC power and audio
signal has been previously installed. Long low-level runs may introduce
noise into the audio signal. Refer to Section 5.0 Specifications and
Drawings for location of mounting points.
2.1.2 Locate the unit to allow easy audio level adjustments. Level adjustment
controls are located on the rear of the unit. These adjustment level
controls must be accessible for periodic system adjustments.
2.1.3 All headphone amplifiers and line level amplifiers should be located no
more than three feet away from source equipment.
2.1.4 Avoid installing the unit where it will be exposed to excessive heat,
excessive moisture, splashing liquids, dusty areas, direct sunlight, or
angled/inclined installations.
2.2 Unpacking & Inspection
2.2.1 Carefully open the packaging and remove the cassette tape player / AM-
FM Tuner. Verify that all components have been included in the package
per the packing list. Inspect the unit for damage. Retain the packing
materials and packing list. The components should arrive in good
condition.

AUDIO INTERNATIONAL, INC. 3/98
7
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
If damage has occurred during shipping, a claim must be filed with AI
within 24 hours and a “Return Request Authorization Number”must be
obtained from AI. Refer to the front cover of this manual for address and
telephone number of Audio International. Repackage the unit in its
original packaging materials and return it to AI following instructions
given by the AI representative. If no return is necessary, retain the
packing materials for storage or reshipment if necessary.
2.3 Cautions & Warnings
2.3.1 All audio connections to the RCP should be shielded and properly
grounded at the source. Perform a pin-to-pin check to confirm that all
wires terminate in their proper location. It is important to do a power and
ground check on the pin connections. Ensure that power and ground are
applied only where required.
2.3.2 DO NOT connect or disconnect the unit while power is applied.
2.3.3 DO NOT remove any factory-installed screws. Damage to the unit may
result and void any warranties.
2.4 Wiring Requirements
2.4.1 The installing agency must supply and fabricate all external cables. The
length and routing of external cables must be carefully studied and
planned before attempting installation of the equipment. Allow adequate
space for installation of cable and connectors. Avoid sharp bends and
placing cables near aircraft control cables. Maintain a minimum clearance
of three (3) inches from any control cable. If wiring is run parallel to
combustible fluid or oxygen lines, maintain a separation of six (6) inches
between the lines.
2.4.2 All power and ground wires must be 24 AWG minimum. All audio lines
require twisted, shielded cable with the cable shields grounded. Power
ground wires must be grounded within twelve (12) inches of the unit. All
wires must be in accordance with MIL-W-22759 or equivalent. Twisted,
shielded cable must be in accordance with MIL-W-27500 or equivalent.
Protect power wires with circuit breakers or fuses located close to the
electrical power source bus.
2.4.3 The RCP-020-40x and RCP-021-40x are designed to interface with other
AI equipment via the proprietary RS-485 data bus. This is a bi-directional
data bus that allows multiple units to be connected simultaneously. The
lines are daisy-chained between units with 120-ohm resistors installed at
both ends of the wiring harness. Cable designed specifically for data bus
use with 120-ohm nominal impedance should be utilized. Contact Audio
International for recommended cables.

AUDIO INTERNATIONAL, INC. 3/98
8
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
2.5 Physical Requirements
2.5.1 Refer to Section 5.1 for unit dimensions and mounting attachment points.
2.6 Electrical Connections
2.6.1 The RCP-020-x (-40x) utilizes one 21-pin connector for electrical
connections. This connector provides 28 VDC, 12 VDC battery holdup,
left/right audio output, data bus control, data bus shield, infrared input,
four (4) strapping pins for alternate configuration of infrared digital
command codes, and antenna high and shield. Refer to Section 2.8 for
connector/unit connector information.
2.6.2 The RCP-021-40x utilizes one 15-pin connector with a flying lead BNC
connector. This 15-pin connector provides 28 VDC, left/right audio
output, data bus control, infrared input, four (4) strapping pins for alternate
configuration of infrared digital command codes, and 12 VDC battery
holdup. The flying lead BNC connector provides antenna high and
antenna shield connections.
2.6.3 Standard configuration requires no infrared strap pins to be connected.
Each different type of AI source equipment can be configured to accept
one of four (4) different sets of infrared codes. To change the code
settings, connect one (1) of the strap pins to the strap common (never
connect more than 1 strap pin to the strap common). Three (3) strap pins
are available to allow the infrared codes to be configured.
2.7 Pinouts / Descriptions
2.7.1 The RCP-020-x (-40x) unit connector with its respective pins and
descriptions is as follows:
Pin # Description
1 +28 VDC Power In 12 Infrared Input -
2 Ground 13 Ground
3 +12 VDC Battery Holdup Power In 14 IR Strap 2
4 R+ Audio Output 15 IR Strap 3
5 R- Audio Output 16 IR Strap 4
6 L+ Audio Output 17 IR Strap Common
7 L- Audio Output 18 Reserved
8 Data bus (A) 19 Reserved
9 Data bus (B) 20 Reserved
10 Data bus Shield A1 Antenna High
11 Infrared Input + A1 Antenna Shield

AUDIO INTERNATIONAL, INC. 3/98
9
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
2.7.2 The RCP-021-40x unit connectors with their respective pins and
descriptions are as follows:
Pin # Description
1 +28 VDC Power In 9 Infrared Input +
2 Ground 10 Infrared Input -
3 R+ Audio Output 11 IR Strap 2
4 R- Audio Output 12 IR Strap 3
5 L+ Audio Output 13 IR Strap 4
6 L- Audio Output 14 IR Strap Common
7 Data bus (A) 15 +12 VDC Battery Holdup Power In
8 Data bus (B)
Pin # BNC 1 Description
AI Antenna High A1 Antenna Shield
2.8 Connector / Mating Connector Information
Mating connector part numbers are as follows:
Model # Connector Mating Connector
RCP-020 & RCP-020-402 CBD21WIM CBD21WIF
D20418-2 Female Screw Lock D20419-18 Male Screw
RCP-020-1 & RCP-020-401 CBD21WIM CBD21WIF
D9/370000V30 Locking Tab
RCP-021-401 RD15M10JV30 RD15F10JVL0
RCP-021-402 DAMA-15P DAMA-15S
D20418-2 Female Screw Lock D20419-18 Male Screw
Antenna BNC Amphenol 413779-4 or
equivalent.
2.9 Post Installation Test
2.9.1 The audio signal output of the unit is generally connected to cabin speaker
systems in addition to headphone locations. It is important to verify that
all equipment has been set to the recommended initial settings. Verify all
connections before supplying power to the unit.
2.9.2 Utilize the front panel controls to turn “ON”the AM/FM tuner. Utilize
the AM/FM random search button to select a desired radio station. Verify
that the station can be heard through the speaker and/or headphone system.

AUDIO INTERNATIONAL, INC. 3/98
10
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
2.9.3 Load the cassette player with selected material. Verify that the RCP
automatically plays back the selected cassette. Use the front panel
controls or the hand-held remote control to select track search, play, pause,
eject, etc. Refer to operating instructions for the unit. Verify that all
functions are operational. Verify that the RCP audio can be heard through
the speaker and/or headphone system.
3.0 Operation
3.1 Audio Input
Load the cassette player with selected material. With the aircraft and audio power
“ON”, apply power to the unit by turning the unit “ON”either by remote control
or pressing play on the front panel. Refer to operating instruction for the unit.
3.2 Potentiometer Adjustment
Verify that the selected material may be heard. If applicable, adjust the output
level gain adjustment potentiometers on the rear of the unit until the desired audio
options have been obtained.
3.3 Audio Adjustment
To operate the AM/FM radio, apply power to the unit by turning the tuner power
to the “ON”position. Use AM/FM random search to select the desired radio
station. The station numbers will appear in the digital window as they are “tuned”
in.
3.4 Power Removal
If a cassette is in the unit, and power is removed, the cassette must be ejected and
reinserted to resume play once power is reapplied.
4.0 Troubleshooting
Problem Possible Cause Solution
No sound RCP is improperly installed
No audio material in source unit.
Verify 28 VDC power and audio
output is present
Insert audio material in source
unit
Poor audio quality Audio controls are not adjusted
properly. Adjust output level.
Poor Tuner reception Antenna connection may be
faulty Verify antenna connections

AUDIO INTERNATIONAL, INC. 3/98
11
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
5.0 Specifications and Drawings
5.1 RCP Unit Specifications
Physical Specifications
Housing Black Anodized Brushed Aluminum
Dimensions Length-8.09”, width-7.38”, height-2.30”
Weight 4.0 lbs.
Electrical Specifications
Power 500mA from 12 to 28 VDC (playing)
Audio Output 1 V RMS to 5 V RMS adjustable (4K-ohms min.)
Data bus Type RS-485
Cassette Player Specifications
Tape Speed 4.76 cm/sec.
Wow & Flutter (WRMS) 0.08%
Frequency Response 30 Hz to 18 kHz (+/- 3 dB)
Separation (1 kHz) 43 dB
Signal to Noise Ratio 54 dB (Dolby B NR Off)
63 dB (Dolby B NR On)
FM Tuner Specifications
Frequency Range 87.9 MHz –107.9 MHz
Channel Space 200 kHz
Usable Sensitivity (S/N=30dB) 9.3 dBf (0.8 µV/75-ohms)
Frequency Response 30 Hz to 15 kHz (+/-3 dB)
Signal to Noise Ratio 75 dB (MONO)
Stereo Separation 40 dB (1 kHz)
AM Tuner Specifications
Frequency Range 530 kHz –1700 kHz
Channel Space 10 kHz
Usable Sensitivity 23 dB (25 µV)
5.2 Applicable Drawings:
5.2.1 The following diagram shows an exaggerated view of the front panel of
the RCP unit.
TRACK
TUNER
OFF
AM/FM
DOLBY
AUDIO INTERNATIONAL

AUDIO INTERNATIONAL, INC. 3/98
12
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
5.2.2 The following diagram shows the top view of the RCP with unit
dimensions.
5.2.2 The following is a reduced diagram showing the side and rear views of the
RCP-020-x (-40x) unit showing the ball stud location and unit dimensions.

AUDIO INTERNATIONAL, INC. 3/98
13
Document #540068, Rev. IR, Model No.: RCP-020-x & RCP-021-40x
5.2.3 The following is a reduced diagram showing the side and rear views of the
RCP-021-40x unit showing the ball stud location and unit dimensions.
