Installation & Operation Manual
RCP-201-01-x
AM-FM Tuner / Cassette Player
Document # 540204
a DeCrane Aircraft Company

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 1 of 19
Document Revision History
Rev. Level Date Description
IR 1/2001 Initial Release
Reference Documents
Document # Description
523260 Rev IR1 RCP-201-01-x Outline Drawing
Service Bulletin List
Service
Bulletin# Subject Manual Revision Revision Date
Table of Illustrations
Section # Illustration # Description Page #
I 5.0 Technical Specifications 5
I 6.2 Typical Application 5
II 6.1 Electrical Specifications 11
II 6.6 Mating Connector Information 12
II 6.7 Pinout Assignment and Descriptions 12
II 8.2 Troubleshooting Chart 14
II 9.0 Reference Drawings 15
III 2.0 Front Panel Controls 17
PROPRIETARY INFORMATION NOTICE: Despite any other copyright notice, this document
and information disclosed herein contains confidential, proprietary designs owned by Audio
International, Inc. Neither this document nor the data contained herein shall be reproduced,
used, or disclosed to anyone without the written authorization of Audio International, Inc.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 2 of 19
Table of Contents
Section Description Page
I General Information………………………………………… 4
1.0 Introduction…………………………………………………… 4
2.0 Purpose of the Equipment…………………………………… 4
3.0 Operational Features………………………………………… 4
4.0 Optional Equipment…………………………………………… 5
5.0 Technical Specifications……………………………………… 5
6.0 Application……………………………………………………… 5
II INSTALLATION……………………………………………… 7
1.0 Prior to Installation…………………………………………… 7
2.0 Unpacking and Inspection…………………………………… 8
3.0
Cautions &Warnings………………………………………… 8
4.0 Wiring Requirements………………………………………… 9
5.0 Physical Characteristics……………………………………… 10
6.0 Electrical Characteristics……………………………………… 11
7.0 Post-Installation Test………………………………………… 12
8.0 Troubleshooting……... ……………………………………… 13
9.0 Reference Drawings…………………………………………… 15
III OPERATION…………………………………………………… 17
1.0 General Information…………………………………………… 17
2.0 Front Panel Controls………………….……………………… 17
3.0 Radio Operating Instructions………………………………… 18
4.0 Cassette Player Operating Instructions..…………………… 19

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 3 of 19
RCP-201-01-x
AM-FM Tuner / Cassette Player

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 4 of 19
SECTION I –GENERAL INFORMATION
1.0 Introduction
This manual contains information for the proper installation and operation of
Audio International’s (AI) AM-FM Tuner / Cassette Player,
Model # RCP-201-01-x. The “-x”suffix in the model number designates the type
of connector utilized; “-1”= Positronic and “-2”= D-Subminiature. Also included
are mechanical and electrical characteristics of the unit.
2.0 Purpose of the Equipment
2.1 The RCP-201-01-x is an AM-FM Tuner /Cassette Tape Player specifically
designed to meet the special requirements of aircraft use. This radio,
cassette tape player combines radio-tuning capabilities with a cassette
tape player in one compact unit. The front bezel may be customized to
customer finish requirements.
2.2 The RCP-201-01-x can be mounted in a cabinet or bulkhead. A unique
strapping feature allows up to eight (8) similar devices to be used in the
same system at the same time while maintaining independent control.
3.0 Operational Features
Key features of the RCP-201-01-x:
q Operates directly from +28 VDC
q Front panel controls
q Optional infrared remote controllable
q Radio allows for AM or FM frequency tuning
q Frequency response of 30Hz to 18kHz
q Cassette player allows complete control of track selection
q Backlit LCD indicator
q Customized front bezel finish capabilities
q AI proprietary RS-485 data bus compatible
q Compact, lightweight package

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 5 of 19
4.0 Optional Equipment
The RCP-201-01-x can be optionally controlled by infrared remote or AI’s touch
screen panel. Digital codes allow the unit to interface with an infrared handheld
remote via an infrared receiver, IFR-9A or IFR-485. Multiple units can be
controlled independently using available programming pins. Playback options
with remote or touch screen include play, stop, pause, search (forward and
reverse), and skip (forward and reverse).
Contact your AI representative for details.
5.0 Technical Specifications
Physical Specifications
Housing Aluminum
Weight 3.1 lb / 1.41 kg
Dimensions
(l x w x h) 7.69" x 7.27" x 2.2" 19.53 cm x 18.47 cm x 5.59 cm
6.0 Application
6.1 Introduction
The RCP-201-01-x operates at +28 VDC. Audio output is 1 to 5 VRMS
adjustable with 4k-ohms, minimum.
6.2 Typical Application
6.2.1 This system is fully compatible with Audio International’s proprietary
RS-485 digital data bus system. It can be configured for IR remote
control utilizing AI’s remote control unit AI-RC1-17xxxx and
IFR-485.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 6 of 19
6.2.2 The unit can also be configured for IR remote control utilizing AI’s
remote control unit AI-RC1-17xxxx and IFR-9A. This following
configuration utilizes a +5 VDC digital logic level for activation of
infrared commands. Connection to multiple IFR-9A units using the
+5 VDC digital logic connection requires use of external Schottkey
diode connection at each IFR-9A unit to prevent signal loading.
Contact AI for details.
6.2.3 The unit can also be configured for Touch Screen or remote panel
control (i.e. entertainment control panels). The panels are on AI’s
proprietary RS-485 digital data bus system and configured to
control the operational features of the RCP-201-01-x.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 7 of 19
SECTION II - INSTALLATION
1.0 Prior to Installation
1.1 During the design and layout of the aircraft cabin, careful consideration of
the location of this and all other audio/visual modules is necessary. Some
of the items to be considered include:
• Space
• Available power supply
• Environmental conditions (temperature, humidity, etc.)
• Length of cable runs
• Location of other aircraft systems (oxygen delivery)
1.2 The RCP-201-01-x shall be installed to conform to the standards
designated by the customer, installing agency, and existing conditions as
to the unit location and type of installation.
1.3 Mounting screws are required to secure the unit. Refer to Section II, 9.0
for mounting hole diameters and configurations.
1.4 Long low-level audio runs may introduce noise into the audio signal. All
headphone amplifiers and line level amplifiers should be located no more
than three (3) feet away from source equipment.
1.5 Audio level adjustment controls are located on the rear of the unit. The
level controls must be accessible for periodic system adjustments.
1.6 The installing agency shall supply and fabricate all external cables to the
RCP-201-01-x. The length and routing of external cables shall be
carefully studied and planned before attempting installation of the unit.
Allow adequate space for installation of cable and connectors. Mating
connectors are the responsibility of the installing agency. Correct pin
assignments as outlined in Section II, 6.7 are the responsibility of the
installing agency.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 8 of 19
2.0 Unpacking and Inspection
2.1 Carefully open the packaging and remove the RCP-201-01-x. Verify that
all components have been included in the package per the packing list.
Inspect the unit for shipping damage.
2.2 If damage has occurred during shipping, a claim should be filed with Audio
International WITHIN 24 hours and a Return Request Authorization
Number shall be obtained from AI. Refer to the front cover of this manual
for address and telephone number of Audio International, Inc. Repackage
the unit in its original packaging materials and return it to AI following
instructions given by the AI representative. If no return is necessary,
retain the packing list and the packing materials for storage.
3.0 Cautions & Warnings
3.1 It is important to do a pin-to-pin power and ground check on all
connectors. Ensure that power and ground are applied only where
specified. Damage to the unit may result if power or ground is applied to
the wrong points.
3.2 DO NOT connect or disconnect the unit while power is applied.
3.3 DO NOT remove any factory-installed screws. Damage to the unit may
result and void any warranties.
3.4 DO NOT drop the unit or subject it to strong shock. The unit contains
glass parts that may break or crack.
3.5 DO NOT place foreign objects into openings. Contact with foreign objects
may result in dangerous voltage or electric shock.
3.6 DO NOT touch the liquid crystal fluid if the LCD is damaged or broken. If
the fluid from the LCD display contacts your body or clothing, wash it off
with soap immediately.
3.7 DO NOT place near hot air ducts, heating elements, or other heat
sources.
3.8 DO NOT use this unit near water, moisture, or volatile sprays. Do not use
any type of solvent when cleaning surface; damage may occur.
3.9 DO NOT leave tape cassettes loaded in the unit with no power applied.
Damage to the unit may occur.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 9 of 19
3.10 No scheduled maintenance is required to ensure continued airworthiness.
3.11 ESD (Electro Static Discharge) guidelines shall be followed.
4.0 Wiring Requirements
4.1 Introduction
The installing agency shall supply and fabricate all external cables. The
length and routing of external cables shall be carefully studied and
planned before attempting installation of the equipment. Allow adequate
space for installation of cable and connectors. Avoid sharp bends and
placing cables near aircraft control cables. Maintain a minimum clearance
of three (3) inches from any control cable. If wiring is run parallel to
combustible fluid or oxygen lines, maintain a separation of six (6) inches
between the lines.
4.2 Power Wires
All power and ground wires shall be 22 AWG, MINIMUM. Power ground
wires shall be grounded within twelve inches of the unit. All wires shall be
in accordance with the standard military specification of MIL-W-22759 or
equivalent. Twisted, shielded cable shall be in accordance with the
standard military specification of MIL-DTL-27500 or equivalent. Protect
power wires with circuit breakers or fuses located close to the electrical
power source bus.
4.3 Audio Wires
All audio wire connections require twisted shielded cable with the shield
properly grounded at the source. Twisted shielded cable shall be in
accordance with the standard military specification of MIL-DTL-27500 or
equivalent.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 10 of 19
4.4 AI’s Proprietary RS-485 Data Bus
4.4.1 The RCP-201-01-x is designed to interface with other Audio
International equipment via AI’s proprietary RS-485 serial data bus.
The data bus shall be implemented using a twisted shielded pair
cable in accordance with the standard military specification of
MIL-DTL-27500 or equivalent. The wire size for the conductors in
this cable shall be 22 AWG, MINIMUM. The shield shall be
connected everywhere a shield pin is provided. Shield terminations
shall be made as close to the connector pin as possible.
4.4.2 All modules on AI’s proprietary RS-485 data bus shall be connected
in a ‘daisy-chain’configuration. AI’s proprietary RS-485 data bus
specification is available upon request.
5.0 Physical Characteristics
5.1 Refer to Section II, 9.0 for unit dimensions and attachment points.
5.2 When mounting the unit, allow sufficient space for mating connectors.
5.3 Allow a MINIMUM of one (1) inch of air space around the unit to allow for
proper air circulation.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 11 of 19
6.0 Electrical Characteristics
6.1 Electrical Specifications:
Electrical Power 500 mA at +28V DC (playing)
Operating Voltage Range +18 to +32V DC
Audio Output 1 to 5 VRMS adjustable
(4 k , MINIMUM)
Factory preset 2 VRMS
Data Bus Type AI Proprietary RS-485
Cassette Tape speed 4.76 cm / second
Tape
Player Weight on Wheels and Flutter 0.08%
Frequency Response 30 Hz to 18 kHz (±3 dB)
Separation (1 kHz) 43 dB
Signal to Noise Ratio 54 dB (Dolby B NR Off)
63 dB (Dolby B NR On)
FM Tuner Frequency Range 87.9 to 107.9 MHz
Channel Space 200 kHz
Usable Sensitivity
(S/N = 30 dB) 9.3 dBf (0.8 9 
Signal to Noise Ratio 75 dB (MONO)
Stereo Separation 40 dB (1 kHz)
AM Tuner Frequency Range 530 to 1700 kHz
Channel Space 10 kHz
Usable Sensitivity 23 dB (25 V)
6.2 The RCP-201-01-x utilizes one (1) 15-pin connector for electrical
connections. This connector provides power, data bus control, infrared
input, and three (3) infrared strapping pins for alternate configuration of
infrared digital command codes.
6.3 Standard configuration requires no infrared strap pins to be connected.
Each different type of AI source equipment can be configured to accept
one (1) of four (4) different sets of infrared codes. To change the code
settings, connect one (1) of the strap pins to the strap common (never
connect more than one (1) strap pin to the strap common). Three (3)
strap pins are available to allow the infrared codes to be configured.
6.4 The infrared input provides a ground reference connection (-). For
optimum infrared signal transmission, this ground reference connection
should connect along with the chassis ground reference connection (pin 2)
to the same ground termination location as that of the IFR-9A or IFR-485
module being utilized. If this is not possible, then the infrared ground
reference connection for the RCP-201-01-x shall be made within 12" of the
unit.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 12 of 19
6.5 Mating Connector Information
Model # Mating Connector
RCP-201-01-1 RD15F10JVL0
RCP-201-01-2 DAMA-15S
D20418-2 Female Screwlock
Antenna BNC AMP 413760-8 or equivalent
6.6 Pinout Assignment and Descriptions
Pin # Description
1 + 28 VDC (Power Input)
2 Ground
3 R+ Audio Output
4 R- Audio Output
5 L+ Audio Output
6 L- Audio Output
7 Data Bus (A)
8 Data Bus (B)
Data Shield to Pin 2
9 Infrared Input +
10 Infrared Input -
11 IR Strap 2
12 IR Strap 3
13 IR Strap 4
14 IR Strap Common
15 +12 VDC Battery Holdup Power Input
7.0 Post-Installation Test
7.1 Verify +28 VDC power has been connected to the unit. The audio signal
output of the unit is generally connected to cabin speaker systems in
addition to headphone locations. Verify all connections before supplying
power to the unit.
7.2 Load the cassette player with selected material. Use the RCP-201-01-x
front panel controls or the handheld remote control unit to select PLAY.
Verify audio can be heard through the speaker and/or headphone system.
7.3 Use the front panel controls to turn ‘ON’the AM-FM tuner. Use the AM-
FM random search button to select a desired radio station. Verify that the
station can heard through the speaker and/or headphone system.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 13 of 19
8.0 Troubleshooting
8.1 General Troubleshooting Procedures
Many problems can be isolated with the following general techniques:
• To verify power to the unit, recheck +28 VDC power is applied to the
proper pins on the unit. Use a voltmeter to verify correct level.
• Reset by removing power from the unit for at least one minute and
reapply power. Verify the problem still exists.
• Recheck all connections to the unit for security. Check all harness
runs for possible pinching. Recheck all pinouts for application
accuracy.
• To check data bus integrity, utilizing a voltmeter, oscilloscope, or other
voltage instrument, verify proper input voltage on the data bus pins.
• The RS-485 data bus is a bi-directional bus that does not have a ‘bus
controller’. The bus uses a differential digital signal that will transmit
only when commands are entered via switch selection or other system
synchronizing commands. The “A”leg of the bus is HI and the “B”leg
LOW.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 14 of 19
8.2 Troubleshooting Chart
Problem Possible Cause Solution
No sound ½ Unit is improperly
installed
½ No cassette in source
unit.
½ Audio system not
powered or active
½ Tuner not activated
½ Cassette tape defective
• Verify +28 VDC power and video
input is present
• Insert tape in source unit
• Verify audio system is in active
mode
• Turn the tuner to the ‘ON’position
• Replace cassette tape
No power ½ Faulty wiring
½ Circuit breaker has
opened
• Connect +28 VDC. Check
connections
• Reset circuit breaker
Poor audio quality ½ Audio controls not
properly adjusted
• Adjust output level
Buttons not operating ½ Moisture may have
condensed inside unit. • Allow unit to warm to room
temperature and moisture has
evaporated.
• Contact AI Product Support
Cassette tape cannot
be loaded ½ Foreign object in disc slot • Remove foreign object
• Contact AI Product Support
Poor AM-FM tuner
reception ½ Antenna connection may be faulty
• Verify antenna connections
Unit does not eject
cassette tape ½ EJECT button not functioning • Play cassette to end for automatic
cassette ejection
• Contact AI Product Support

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 15 of 19
9.0 Reference Drawings
The following diagrams show the unit dimensions, mounting locations, and
connector locations for the RCP-201-01-x.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 16 of 19

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 17 of 19
SECTION III –OPERATION
1.0 General Information
1.1 The RCP-201-01-X can be operated via front panel ‘buttons’or optionally
controlled by infrared remote or AI’s touch screen panel. Digital codes
allow the unit to interface with an infrared handheld remote via an infrared
receiver, IFR-9A or IFR-485. Multiple units can be controlled
independently using available programming pins.
1.2 Playback options with front ‘button’control, remote or touch screen include
play, AM tuner mode, FM tuner mode, pause, forward and reverse search,
etc.
1.3 Before setup or playing a cassette, ensure that aircraft power is applied to
the player. There are no on/off controls on the unit.
1.4 Activate monitors and speakers from the appropriate control panels.
Audio will be supplied through headphones and/or speakers per system
design.
2.0 Front Panel Controls

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 18 of 19
The names and functions of the RCP-201-01-x are as follows:
Press the button to toggle between playback of a cassette, the AM
tuner mode or the FM tuner mode. Each time the button is
pressed, the mode will advance to the next function.
Press the button to play or pause a cassette. Press and hold the
button for approximately two (2) seconds to eject the cassette from
the unit.
Press the button to rewind or reverse a cassette tape or to start a
reverse radio station search while the unit is in AM or FM tuner
mode.
Press the button to fast-forward a cassette tape or to start a forward
radio station search while the unit is in AM or FM tuner mode.
Press the button to toggle between auto seek tuning or to activate /
deactivate metal cassette selection. Press the button again to
toggle, this will select or store the frequency of a radio station.
3.0 Radio Operating Instructions
3.1 Press the CASS / AM / FM button until AM or FM is indicated in the digital
display. Each time the button is pressed, the band switches between
cassette player / AM radio / FM radio.
3.2 The reverse and fast-forward buttons may be used to “search”for and lock
in a radio station. Press the appropriate button until the desired station is
located. The digital display will indicate the selected station.
3.3 Press the METAL / PRESET button to auto seek a radio station and to
select or store the selected frequency in memory.

Audio International, Inc. RCP-201-01-x Installation & Operation Manual
Document # 540204, Rev IR, 1/2001 Page 19 of 19
4.0 Cassette Player Operating Instruction
4.1 Insert a cassette into the slot with the label facing up. The digital disply
will read CASSETTE –IN. The symbol on the front panel will
illuminate when a cassette is being played.
4.2 The symbol or the symbol will illuminate on the digital display to
indicate the direction of play of the cassette.
4.3 To stop playback of a cassette tape, press the button on the front
panel. The cassette will stop playing and eject from the slot.
4.4 To fast-forward cassette playback, press the button. The cassette will
fast-forward until the next selection is located. Advancing will stop once
the next selection is located and playback will resume.
4.5 To reverse cassette playback, press the button. The digital display
will indicate a ‘0’(current selection). Press the button once to search back
to the beginning of the current track, press twice to search back to the
beginning of the previous selection. The display will indicate ‘1’, press the
symbol again to search back to the beginning of the previous selection;
the display will indicate ‘2’, etc. Each press of the button will change the
display to count the number of selections from 1 to 9. Playback starts at
the beginning of the displayed selection number.
4.6 To make a forward track search, press the button. The display will
indicate a ‘1’. Press once to fast-forward to the next selection. The
display will indicate a ‘2’. Press the button again to fast-forward to the
next selection, the display will indicate a ‘3’, etc. Each press of the button
will change the display to count the number of selection from 1 to 9.
Playback starts at the beginning of the displayed selection number.
4.7 To eject the cassette from the slot, press the button.
