AudioCodes MediaPack Series User manual

MP-252-WDNB
MP-263-DB
MP-264-DB
MP-272-DB
Multimedia Home Gateways
Quick Guide
AudioCodes® MediaPack™ Series
DECT Handset

2
Notice
This Quick Guide describes the operation of AudioCodes’
MediaPack™ series MP-252-WDNB, MP-264-DB, MP-263-DB,
and MP-272-DB Cordless Digital Enhanced Cordless
Telecommunications (DECT) Voice-over-IP (VoIP) phones.
Information contained in this document is believed to be
accurate and reliable at the time of printing. However, due to
ongoing product improvements and revisions, AudioCodes
cannot guarantee accuracy of printed material after the Date
Published nor can it accept responsibility for errors or
omissions. This document is subject to change without notice.
Refer to the current Release Notes that may be included with
your documentation or hardware delivery. Updates to this
document as well as software files can be viewed by
registered customers at www.audiocodes.com/downloads.
© Copyright 2013 AudioCodes Ltd. All rights reserved.
Date Published: April-24-2013

3
Table of Contents
Safety Instructions ........................................................ 6
Initial Installation of DECT Handset............................... 8
Registering the DECT Handset to the Base Unit...... 10
Charging the Handset.............................................. 11
Checking the Battery Level...................................... 11
Replacing the Batteries ........................................... 12
Setting the Display Language .................................. 14
Overview ..................................................................... 15
General Screen Description..................................... 17
Screen Description during a Call ............................. 17
Main Menu Description .......................................... 18
Using the Phone .......................................................... 19
Making an External Call........................................... 19
Pre-Dialing........................................................... 19
Direct Dialing....................................................... 19
Calling from your Phonebook.............................. 20
Calling from the Call List...................................... 20
Establishing a Second Call ................................... 21

4
Redialing a Number............................................. 22
Answering a Call...................................................... 22
Answering or Rejecting a Second Call ..................... 23
Ending a Call............................................................ 23
Adjusting the Volume during a Call......................... 24
Muting a Call ........................................................... 24
Turning Off the Ringer............................................. 25
Activating the Speakerphone.................................. 25
Locking / Unlocking the Keypad.............................. 25
Paging your Handset ............................................... 26
Redial List ................................................................ 26
Saving a Redial Number to the Phonebook ........ 27
Deleting a Number from the Redial List.............. 27
Deleting the Entire Redial List ............................. 28
Call Handling for Multiple Handsets ....................... 28
Calling (Intercom) another Handset.................... 29
Transferring an External Call to another Handset29
Three-Way Conference Calls................................... 30
Making a Three-Way Conference Call with another
Handset and an External Party............................ 30

5
Making a Three-Way Conference Call with your
Handset and two External Calls........................... 31
Adding a Contact to the Phonebook ....................... 31

6
Safety Instructions
CAUTION:
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE
Before using your DECT phone, read the following
safety instructions:
1. Read and understand all the instructions.
2. Follow all warnings and instructions marked on the
product.
3. Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example,
near a bath tub, kitchen sink, swimming pool).
5. Do not overload wall outlets and extension cords
as this can result in the risk of fire or electric shock.
6. Unplug this product from the wall outlet and refer
servicing to AudioCodes under the following
conditions:
•When the power supply cord or plug is
damaged or frayed.
•If the product does not operate normally by
following the operating instructions.
•If the product has been dropped and the
cabinet has been damaged.

7
•If the product exhibits a distinct change in
performance.
7. Avoid using a telephone (other than a cordless
type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
8. Do not use the telephone to report a gas leak in
the vicinity of the leak.
9. Use only the supplied nickel-metal hydride cell
(NiMH) rechargeable batteries! The operation
periods for the handsets are only applicable with
the default battery capacities.
10. Use only the supplied 12VDC +/-10%, 2A, limited
power source wall mount Class II power supply
adapter. Before connecting the MediaPack to
power, ensure that the VAC ratings match.
11. The use of other battery types or non-rechargeable
batteries/primary cells can be dangerous. These
may cause interference and/or unit damage. The
manufacturer will not be held liable for damage
arising from such non-compliance.
12. Do not use third-party charging bays. The batteries
may be damaged.
13. Please note the correct polarity while inserting the
batteries.
14. Do not immerse batteries in water; do not place in
fire.

8
Initial Installation of DECT Handset
The handset is shipped with rechargeable batteries
already installed in the battery compartment. However,
a plastic sheath separates the batteries from the
handset’s electrical circuit. Before you can charge the
handset, you need to remove this plastic sheath. On
the handset, pull out the plastic tab jutting out from
the battery compartment. This closes the battery
circuit and provides power to the handset.
1. On the lower part of the MediaPack front panel,
remove the cover protecting the connector for the
handset cradle.

9
2. Attach the handset cradle to the unit by inserting it
into the exposed groove and then pushing it up so
that it clicks on to the connector. Attach the
removed cover to the front of the cradle.
Note: Charge the batteries for at least 16
hours before initial use.

10
Registering the DECT Handset to the Base Unit
Before you can make or receive calls, you need to
register the DECT handset to the MediaPack base unit.
Note: Applicable for purchased stand-alone
handset.
1. Press the Menu softkey, and then select the
Registration icon.
2. Press (for 2-5 seconds) the DECT LED button until it
starts flashing green; the base unit enters
registration mode.
3. On the handset, select base unit "Base 1" to which
the handset must register; the registration process
begins and "Registering - Waiting" is displayed on
the handset screen. When the handset identifies
the base unit, it displays its radio frequency
identification (RF ID).
4. Click the Accept softkey to confirm registration.

11
Charging the Handset
Ensure that the MediaPack is connected to power.
Place the handset in the charging cradle of the base
unit so that the bottom of the phone sits in the base
cradle. When correctly inserted in the cradle, the
phone begins charging, indicated by the display of the
charging levels of the battery icon on the phone's
screen.
Checking the Battery Level
The battery icon located in the main screen, displays
the current battery level, as shown below:
Handset battery is fully charged
Handset battery is two-thirds charged
Handset battery is one-third charged
Handset battery is empty and needs charging
(this icon flashes)

12
Replacing the Batteries
The handset is shipped with rechargeable batteries.
However, if you need to replace them, do the
following:
1. Remove the battery compartment cover, by sliding
the cover out from the base of the phone toward
the top end (in the direction of the arrow label
printed on the cover). You can use your thumb to
push at the base of the cover.
2. Remove the old batteries (if any) and then place
the two batteries (supplied) into the battery
compartment, as indicated.
3. Slide the battery compartment cover back into
place.

13
Warnings:
•Risk of explosion if battery is replaced by an
incorrect battery type; use only the nickel-metal
hydride cell (NiMH) rechargeable batteries as
provided with your phone. The manufacturer will
not be held liable for damage arising from such
non-compliance.
•Verify correct polarity of batteries when
inserting the batteries. Incorrect polarity may
damage the product.
•The operation periods for the handset are only
applicable with the default battery capacities.
•Do not use third-party charging bays to charge
the batteries.
•Do not immerse batteries in water and do not
place in fire.
•Do not mix old and new batteries.
•Do not open or mutilate the batteries. Released
electrolyte from the batteries is corrosive and
may cause burns or injury to the eyes or skin.
The electrolyte is toxic and may be harmful if
swallowed.
•Do not allow conductive materials such as rings,
bracelets, or keys to touch the batteries,
otherwise a short circuit may cause the batteries
and/or the conductive material to overheat and
cause burns.
•Avoid touching the battery ends (+, -) or the base
unit contacts.

14
Setting the Display Language
You can change the display language of your handset.
1. In idle state, press the Menu softkey.
2. Press the navigation keys to scroll to the
HS Settings icon, and then press the Select
softkey.
3. Press the navigation keys to choose the
Language option, and then press the Select
softkey.
4. Press the navigation keys to choose the desired
language, and then press the Select softkey; the
saved message is displayed in the chosen language
and the display is changed accordingly.

15
Overview
Item Name Description
1Right Soft Key Key action is according to the text
on the handset screen.
2Left Soft Key Key action is according to the text
on the handset screen.
1
4
6
7
2
5
8
3

16
Item Name Description
3Navigation Key For up, down, left, and right
navigation in LCD screen.
4End Call Key During a call: press to end a call
and go back to idle screen.
Off Key Press and hold to power off the
handset.
On Key When the handset is powered
off: press and hold to power on
the handset.
5Talk On After entering a number or
selecting a number from the
phone book, press to make the
call.
During ringing: press
to answer a
call.
6Alphanumeric
Keypad
Dials and edits numbers and
text.
7Speakerphone During a call: press to turn
on/off the speakerphone.
During
ringing: press to answer a
call with speakerphone.
8Bluetooth
This button will be supported in the
next applicable release.

17
General Screen Description
Icon Description
Steady when the handset is in range of the base.
Additional bars (red, orange, and blue) are
displayed as the signal strength increases.
Flashes when the handset is not registered to
the base or out of range of the base. When the
handset is out of range, the LCD displays "Out of
Range" message.
For up, down, left, and right navigation in LCD
screen.
The alarm is set. When the alarm time is
reached, this icon flashes. This icon disappears
when the alarm is off.
Screen Description during a Call
Icon Description
Phone is ringing (i.e., incoming call)
Call is in progress
Intercom is in progress
Hands-free is in use

18
Icon Description
Ringer is switched off
Keypad is locked
Main Menu Description
Unselected Icon Selected Icon Description
Phonebook
Alarm clock
Base setting
Phonebook
Handset setting
Registration

19
Using the Phone
Making an External Call
Pre-Dialing
Preparatory dialing is when you first enter the phone
number and only then dial it. This therefore, allows you
to make changes to the number before making the call.
1. Enter the phone number; the number is displayed
on the screen. You can make changes to the
number before dialing. Press the Clear softkey to
delete digits to the left of the cursor.
2. Press or to dial the number.
Direct Dialing
Direct dialing is when you activate dialing and only then
enter the phone number.
1. Press or to take the line.
2. Enter the phone number; the phone waits a few
seconds and then dials the number.

20
Calling from your Phonebook
If you have added any contacts to your phonebook, you
can dial from the phonebook.
1. Press the PB softkey to access the phonebook.
2. Press the navigation keys to choose the desired
phonebook entry, and then press the Select
softkey.
3. Press or to dial the selected
phonebook entry.
Calling from the Call List
You can dial numbers from previously received or
missed calls, which are stored in the Call List:
1. Press the navigation key to access the Call List.
2. Press the navigation keys to select the desired
entry, and then press the Select softkey.
3. Press or to dial the selected entry.
