AUDIOLINE 5016 User manual

English
User guide
Digital Cordless Telephone with
Caller Identication
5016

1 Earpiece
2 Display
3 Redial Button
4 Caller Identication
5 Talk button
6 Programming/Recall (R) Button
7 Microphone
8 Erase/Volume
9 Priority-memory button
10 Disconnect button
11 Memory button
12 Intercom/Mute

English
3
Index
Installation 4
Unpacking........................... 4
Connection ......................... 4
Belt Clips............................. 5
Battery ................................ 5
Battery Charge Indicator .... 6
Range ................................. 6
The Display......................... 7
Base Unit Indicators ........... 7
Handset Paging .................. 7
Operation 8
Making a Call...................... 8
Receiving a Call.................. 8
Redial Button ...................... 8
Volume Control ................... 8
Hold Function ..................... 8
Call Timer ........................... 8
Memory............................... 9
Caller Identication 10
Settings 11
Type of Ringer signal.......... 11
Volume of Ringer signal...... 11
Button Click ........................ 11
Auto - Answer ..................... 11
Handset PIN Code.............. 12
Tone/Pulse Dialling ............ 12
Recall Button Timing
(business use only)............. 12
PBX Function...................... 13
Optional Network Services. 13
Expanded System 14
General Information............ 14
Multiple Base Units............. 14
Multiple Handsets ............... 15
Register a New Handset/
Base Unit ............................ 15
Intercom Function............... 16
Transferring Calls Between
Handsets ............................ 16
Conference ......................... 16
Select Base Unit ................. 17
De-register a Handset ........ 17
Other 18
Troubleshooting .................. 18
Guarantee........................... 19
REN .................................... 19

English
4
Installation
Unpacking
The package should include the following items:
- Handset - Mains adapter
- Base unit - Line cord
- Battery - Belt clip
Connection
1. Connect the mains adapter to the y socket of the base unit and to an
electrical wall socket.
2. Remove the battery cover from the back of the handset. Insert the battery
plug and t the battery into the handset. Replace the battery cover.
3. Place the handset in the base unit, with the keypad facing outwards. Once
the handset is correctly placed in the base unit, a beep will be heard and the
charge indicator 7 will illuminate on the base unit.
4. Charge the handset battery without interruption for 15 hours.
5. Connect the telephone line cord to the socket marked t on the base unit
and plug into the telephone network socket (using adapter plug if required).
IMPORTANT!
Under power failure conditions, this telephone will not operate. Please ensure
that a separate telephone, not dependent on local power, is available for
emergency use. The earpiece of the handset may attract small ferromagnetic
objects such as staples and pins, care should be taken when placing the handset
near these items. Do not place the base unit in areas of high humidity or where it
will be exposed to direct sunlight or other major heat sources.
This model can only be recharged with the keypad set
facing outwards!

English
5
Installation
Belt Clips
A belt clip is included, which can be tted on the back of the handset. To attach
the clip, press it into place over the back of the handset. On either side of the
handset, there are indents for the clips to clasp onto.
Battery
The telephone comes supplied with an environmentally friendly nickel metal
hydride (NiMH) battery. As with all batteries performance may degrade over
time, should you notice that the standby time has reduced considerably or there
are signs of leakage, the battery pack should be replaced.
A fully charged battery will last for approx. 100 hours in standby or approx. 10
hours call time. These operation times apply at normal room temperature.
A completely discharged battery will take about 15 hours to fully recharge.
Please note that the charge indicator 7 on the base unit is on while charging
and will go out when the battery is fully charged.
The battery charge indicator in the handset display will ash while charging and
will stop ashing when the battery is fully charged.
The equipment has an automatic charging mechanism that prevents the battery
from being overcharged or damaged due to prolonged charging.
Please note!
When the telephone is installed for the rst time, the battery must be charged for
15 hours before using the telephone.
The guarantee does not cover any damages caused by incorrect batteries.
The handset must be charged with the buttons facing outwards.
Please dispose of any batteries in an environmentally friendly manner.

English
6
Installation
Battery Charge Indicator
The symbol in the display indicates when it is time to recharge the battery.
The symbol has two segments, which disappear as the battery charge decreases.
When the battery is running low, the symbol will appear in the display and
a warning tone will be heard. If the handset is not recharged at this time, the
phone will cease to function until it is recharged.
Range
The range of the telephone varies depending on various factors in the
surrounding environment. The radio waves transmitting the call may be
hindered by obstructions, reducing the range.
Specied ranges require an unobstructed transmission between the handset and
the base unit. In such ideal conditions, the telephone range can be up to 300
metres. In a densely populated area, house, apartment, etc. the range of the
telephone will be reduced. Try to get the best range by relocating the base unit.
The ideal location for the base unit is a high and unobstructed place.
Out of range warning
If, during a call, the handset is carried too far from the base, a warning tone will
be heard from the handset. Unless the handset is moved closer to the base unit
within a few seconds, the call will be lost.
Please note!
When the warning tone is heard, communication is interrupted for the duration
of the tone.

English
7
Installation
The Display
Indicator Function
P Programming.
5 New number/s in Caller ID log.
Speed dial.
Indicates that a call is connected.
Flashes when the phone rings.
INT z Intercom calls and Mute function.
Battery charge indicator.
6 Shown within range of the base unit. Flashes when out of range.
Base Unit Indicators
5 New number/s in Caller ID log.
7 Charging.
o/ y Illuminates when the base unit is connected, and ashes during
call and registration.
Handset Paging
Pressing j on the base unit will activate the paging signal of the handset. This
function is used to help locate the handset or to page the person carrying the
handset. The signal will stop automatically after a while, or if either the l
button on the handset or the j button on the base unit is pressed.

English
8
Operation
Making a Call
1. Enter the required number. Mistakes can be erased using C.
2. Press o, and the number is dialled.
3. Use l to terminate the call.
Please note!
If the telephone cannot connect to a line, a warning tone will be heard. The
problem may be due to the battery running low, the handset being too far from
the base unit or all of the transmission channels being engaged.
Receiving a Call
1. Wait for the handset to ring.
2. Answer the call by pressing o.
3. Use l to terminate the call.
Redial Button
If the number dialled is engaged or if you wish to redial the last number dialled,
press r and o.
Volume Control
The volume may be adjusted during a call using .
Hold Function
A call can be temporarily put on hold using the i button. Press it once more to
resume the previous call. The call cannot be resumed from another phone.
The display shows INT z as long as the call is on hold.
Call Timer
Following the connection of a call, a timer is shown on the display. The timer
helps you keep track of how long the call lasts.

English
9
Operation
Memory
The telephone has 1 Priority-memory button (u) and 10 speed dial memories.
A stored phone number can be dialled using fewer keystrokes. The memories
are numbered 0-9.
Storing Priority-memory
1. Press P.
2. Press u.
3. Enter telephone number (up to 25 digits). Use C to erase or change.
4. Press P to save settings.
Dialling using Priority-memory
1. Press u, and the number is dialled.
Storing Speed Dial Numbers
1. Press P.
2. Press m.
3. Enter memory position 0-9, or scroll using m.
4. Enter telephone number (up to 25 digits). Use C to erase or change.
5. Press P to save settings.
Please note!
Press r if you want a pause in the telephone number.
In case of a number change, store the new number in the location of the old
one.
Using Speed Dialling
1. Scroll the speed dial positions using m. You could also enter the memory
position directly using 0-9 when the display shows _ _.
2. Press o, and the number is dialled.

English
10
Caller Identication
Explanation of Caller ID
Caller ID allows you to see who is calling before you answer a call and see who
has called in your absence.
Received calls are stored chronologically. The call log will store up to 10
telephone numbers. The number will not be stored if the call is answered.
When the log is full, the oldest number will be deleted automatically, as the new
call is logged. New calls are indicated in standby mode by *.
IMPORTANT!
In order for numbers to be shown, the Caller ID service must be provided
by your network operator and a current subscription in place. Contact your
operator for more information.
This product is not compatible with type II Caller ID (CID on Call Waiting).
Retrieving and Dialling Incoming Numbers.
1. Press * The display will indicate the number of new entries (to the left) and
the total (to the right) number of entries stored in the call log.
2. Keep pressing * to scroll to the desired memory position.
3. PressP to show time/date.
4. Press o to dial the number or l to return to standby mode.
Messages
Apart from showing phone numbers, the display can show:
o or IntErnAtIonAL It is an International call or a call from a PBX (no
information received)
P or SECrEt The call is comes from a blocked number or a PBX.
Erasing Numbers
1. Scroll to the desired memory position as described below.
2. Press C to erase the number.
Erasing All Seen (i.e. Old) Numbers
1. Scroll to where the display shows how many new entries and the total
number of entries that have been stored in the memory (see above).
2. Keep C pressed until a tone is heard. All numbers are now erased.

English
11
Settings
Type of Ringer signal
There are several different types of handset ringer signals to choose from.
1. Press P 2.
2. The current setting ashes (1=type 1, 2=type 2, 3=type 3).
3. Select by pressing the corresponding digit.
4. Press P to save settings.
Volume of Ringer signal
The ringer volume can be set to different levels.
1. Press P 3.
2. The current setting ashes (0=off, 1=low, 2=medium, 3=high).
3. Select by pressing the corresponding digit.
4. Press P to save settings.
Button Click
The sound heard when the buttons are pressed can be turned off or on.
1. Press P 4.
2. The current setting ashes (0=on, 1=off).
3. Select by pressing the corresponding digit.
4. Press P to save settings.
Auto - Answer
With this function activated, incoming calls will be received (the call connected)
when the handset is lifted from the base unit.
1. Press P 0. Wait for the signal.
2. Enter PIN number (0000 when supplied). Press P.
3. Press 5. The current setting ashes (0=on, 1=off).
4. Select by pressing the corresponding digit.
5. Press P to save settings.
6. Press l to return to standby mode.

English
12
Settings
Handset PIN Code
The handset PIN code is a four-digit code that you can set yourself. It protects
against unauthorised use of certain functions.
1. Press P 0. Wait for the signal.
2. Enter the present PIN code (0000 at default). Press P.
3. Press 3.
4. Enter the new code. Press P.
5. Conrm by entering the new code again. Press P.
6. Press l to return to standby mode.
Tone/Pulse Dialling
Choose dialling method, tone or pulse.
1. Press P 0. Wait for the signal.
2. Enter PIN number (0000 when supplied). Press P.
3. Press 1. The current setting ashes (1=tone, 2=pulse).
4. Select by pressing the corresponding digit.
5. Press P to save settings.
6. Press l to return to standby mode.
Recall Button Timing (business use only)
In some advanced PBX system installations, the timing of the R button may
need to be adjusted. In normal domestic use, this setting should not require
changing.
1. Press P 0. Wait for the signal.
2. Enter PIN number (0000 when supplied). Press P.
3. Press 4. The current setting ashes (1=80 ms, 2=100 ms, 3=250 ms, 4=600
ms).
4. Select by pressing the corresponding digit.
5. Press P to save settings.
6. Press l to return to standby mode.

English
13
Settings
PBX Function
If the phone is used in a private branch exchange (PBX) system, usually you
must dial a prex (access code) in order to be connected to an external line.
There may also be a certain waiting time (a couple of seconds) after the prex,
before the external line is connected.
This telephone has a PBX function that allows you to specify an external
call prex. When you dial an external number, the phone will detect that the
number starts with the prex, and will automatically insert a pause before
dialling the actual number. The telephone can handle external line prexes of
up to 5 digits.
An example of use of the PBX function:
“9” has been specied as the external line prex. When dialling a phone
number: “9123456”, the phone will dial: ”9” followed by a pause while the
external line is connected, and then the rest of the number: “123456”. ”123456”.
It makes no difference if the number is dialled manually or by using speed
dialling. Numbers not starting with “9” (in this example) will be dialled as
usual, without any pauses.
1. Press P 0. Wait for the signal.
2. Enter PIN number (0000 when supplied). Press P.
3. Press 6.
4. Enter the prex. Use C to erase or change.
5. Press P to save settings.
6. Press l to return to standby mode.
Optional Network Services
Press the recall button R followed by the extension number to transfer calls
when connected to a PBX.
Access to additional network services can be gained by using the recall
button keys. Contact your network operator for more information.

English
14
Expanded System
General Information
DECT (Digital Enhanced Cordless Telephone) technology offers superior
performance, clarity and security using its completely digital method of
transmission. You can:
- Use up to 5 handsets with the same base unit.
- Use (register) up to 4 base units with the same handset.
- Make internal calls (intercom) and transfer calls between handsets using the
same base unit.
- Expand the range through automatic transfer to the nearest base unit.
Additional base units and handsets can be purchased from your local retailer.
This model is GAP (Generic Access Prole) compatible, which means that the
handset and the base unit can both be used with most other GAP compatible
units irrespective of manufacturer.
Multiple Base Units
By connecting several base units to the system, the useful range for the handset
can be expanded. Registering multiple base units with the handset will cause the
handset to automatically connect to another base if and when it loses contact
with the current base unit Another practical application could be to have one
base station at home and one at work. Then the same handset can be used in
both places.
The transfer from one base unit to another will then be automatic, however, this
will not occur while a call is in progress. The handset remains in contact with its
base unit until it goes out of range. When this happens, the handset will begin to
search for another base from its list of registered base units.
It is essential that the range of the base units overlap, in order to achieve
uninterrupted coverage. If not, there may be reduced communication in certain
areas where the handsets have no signal from the base units.
IMPORTANT!
Automatic switching between base units (handset handover) will not occur while
a call is in progress.

English
15
Expanded System
Multiple Handsets
The combination of multiple base units and multiple handsets provides for
many useful applications. Each can be used to answer an incoming call, be used
internally as an intercom system, and also to transfer external calls between
the handsets.
If you wish to use several handsets with one base unit, you should see to it that
the base unit is placed “in the middle”, so that the range will evenly divided
among the handsets.
Register a New Handset/Base unit
To enable the use of more than one handset or base unit a registration has
to be performed.
Every new handset must be registered in order to use a base unit. A maximum
number of 4 base units can be registered with each handset, and each base unit
can handle up to 5 handsets.
On registration the handset is allocated a handset number from 1-5.
Additional base units and handsets can be purchased from your local retailer.
1. Keep the base unit paging button j pressed for about 10 seconds until the
indicator o/y on the base unit starts ashing.
2. Press P 5.
3. Select a base number for the base unit you wish to register by pressing the
corresponding number button 1-4. Wait for the signal.
4. Enter the base unit PIN code (0000 at default). Press P.
5. If the registration is successful the handset will return to standby mode
in a few seconds. The new handset number is shown on the right of the
display.

English
16
Expanded System
Intercom Function
When using several handsets with the same base unit, calls can be made
internally between the handsets, referred to as internal calls, or intercom.
Internal calls can only be made between handsets connected to the same base
unit
1. Press i.
2. Enter the allocated call-number of the handset that you wish to call, 1-5.
Should an external call come in while an internal call is in progress, a tone will
be heard. Press the l symbol to nish the current call, and then the o.
symbol to engage the incoming call.
Transferring Calls Between Handsets
An external call can be transferred from one handset to another (they must both
be using the same base unit).
1. While an external call is connected on line.
2. Initiate an intercom call as described above.
3. To transfer the external call, press l on the calling handset.
If you decide not to transfer the call, press i on the calling handset to return
to the external caller.
Conference
It is possible to have a conference call between two handsets and an external
caller.
1. While an external call is connected on line.
2. Initiate an intercom call as described above.
3. To connect all three parties in a conference call, press and hold # until you
hear a beep.
By pressing l any one of the handsets can terminate the conference and let
the other continue the conversation with the external party.

English
17
Expanded System
Select Base Unit
You can decide which base unit you wish the handset to communicate with.
You can also set the hand unit to automatically select the base unit with the
best connection.
1. Press P 6.
2. Select a base unit by pressing the corresponding number button
(*=AUTO). The selected number will ash within the display.
3. Press P to save setting.
De-register a Handset
Any additional handset can easily be de-registered from a base unit.
1. Press P 0. Wait for the signal.
2. Enter PIN number (0000 when supplied). Press P.
3. Press 2.
4. Select the handset number you wish to delete by pressing the corresponding
number button 1-5.
5. Press P to save.
6. Press l to return to standby mode.
Warning!
Do NOT deregister the main handset (handset 1).

English
18
Other
Troubleshooting
Check that the telephone cord is undamaged and properly plugged in.
Disconnect any additional equipment that may be connected. If the problem is
resolved, the fault is with the other equipment.
Test the equipment on a known working line. If the product works then the
fault is with the line.
No Number Shown In Display When Ringing
- In order for this feature to function, you must subscribe to the Caller
Identication service from your network provider.
- If a message shows on the display, the call may be from a PBX or an
international call (no data received), or from a private or blocked number. If
the display shows SECrEt, the call is from a private or blocked number.
- A call will not be identied if it is coming from a PBX.
No Call Handover When Moving Between Base Units
The switching (or handover) of the handset/s between base units is not
possible when on a call. Handsets will search for new base units only:
- when out of range from the original base.
- while in standby mode.
Warning Signal While Talking/Cannot Connect
- The batteries may be running low (recharge the handset)
- The handset may be (nearly) out of range. Move closer to a base unit.
Telephone Does Not Work
- Check if the handset is turned on.
- Check the adapter, is it correctly connected to the base unit and to the
mains power?
- Check that the telephone cord has been correctly connected to the base unit
and to the line socket, by disconnecting and reconnecting both ends.
- Check the charge status of the handset battery.
- Try connecting another telephone, known to be in working order, to the line
socket. If that phone works then it is likely that this equipment is faulty.
If the telephone still does not work, refer to page 19.

English
19
Other
Australia and New Zealand
If you believe this product is malfunctioning, please refer to the relevant section
and/or consult the troubleshooting guide in this manual to ensure that you have
followed the instructions carefully. As an alternative you can visit our web site
for FAQ’s or send an e-mail for a prompt reply.
Guarantee
This product is guaranteed for a period of 12 months from the date of purchase.
Should you experience difculties with the product, please contact us for
assistance. If the product is then found to be faulty you will be asked to return it
directly to us with a copy of the purchase receipt.
This guarantee shall not apply to a fault caused by an accident or a similar
incident or damage, liquid ingress negligence, abnormal usage or any other
circumstances on the purchaser’s part. Furthermore, this guarantee shall not
apply to a fault caused by a thunderstorm or lightning, excessive or any
other voltage uctuations or faults on the telephone line. (As a matter of
precaution, we recommend disconnecting the telephone during a thunderstorm).
This guarantee does not affect your statutory rights.
AUSTRALIA NEW ZEALAND
DORO Australia Pty Ltd Atlas Gentech (NZ) Limited
PO Box 6760 Private Bag 14927
Baulkham Hills BC NSW 2153 Panmure
Australia Auckland
New Zealand
Consumer Support Consumer Support
Ph: [phone] Ph: 0900-500-25 (Toll Call)
Fax: [phone] Fax: [phone]
Email: [e-mail] Email: [e-mail]
Web site: www.doro.com.au

English
20
Other
Technical information
REN (RN for New Zealand)
The REN (Ringer Equivalence Number) or (RN) is of signicance only if you
wish to connect more than 1 telephone to your telephone line. A standard
telephone line has a maximum REN capacity of 3 (RN of 5). It is possible
to connect 3 devices with a REN of 1 (RN of 1) with no degradation to the
product’s performance. Exceeding this limit may cause the volume of the ringer
in any phone to decrease or not ring at all.
Notes for operation in New Zealand
The grant of a Telepermit for any item of terminal equipment indicates only
that Telecom has accepted that the item complies with the minimum conditions
for connection to its network. It indicates no endorsement of the product by
Telecom, nor does it provide any sort of warranty. Above all, it provides no
assurance that any item will work correctly in all respects with another item of
Telepermitted equipment of a different make or model, nor does it imply that
any product is compatible with all of Telecom’s network services.
This equipment shall not be set to make automatic calls to the Telecom “111“
Emergency Service.
This equipment may not provide for the effective hand-over of a call to another
device connected to the same line.
This equipment should not be used under any circumstances that may constitute
a nuisance to other Telecom Customers.
If a charge for local calls is unacceptable, the “DIAL“ button should NOT be
used for local calls. Only the 7 digits of the local number should be dialled from
your telephone. DO NOT dial the area code digit or the “0“ prex.
