Audiopipe APMR-4080MIN User manual

- 1 -
Congratulations!
Thank you for purchasing this Audiopipe marine amplifier for your audio system. Now
you own an amplifier of uncompromising design and engineering incorporating the latest
advanced circuit technology. You will discover soon that our amplifiers display optimum
sound with high quality and provide reliable performance.
Audiopipe amplifiers are adopted by advanced craftsmanship which use the highest
quality components and strict quality control system. In order to provide you the best
performance. We recommend you to contact an authorized Audiopipe Dealer to do the
installation.
Please read this manual thoroughly to ensure that you can get the maximum benefit
from this new amplifier. When you install it properly, this unit will provide you years of
trouble-free performance.
This manual describes the basic requirements to install the Audiopipe marine amplifier.
The installation of this marine amplifier can be quite complex to install, if you do not possess
the necessary knowledge and tools to perform this installation, please contact your local
Audiopipe dealer.
Audiopipe warrants this amplifier for one year from date of purchase against all manufacturing
defects only.
Warranty does not include physical damage or electrical abuse from being over-driven
or short circuit from speaker failure.
Amplifier must be installed by an authorized Audiopipe dealer or there is no warranty.
Amplifier must be returned to Audiopipe freight pre-paid, Audiopipe will pay return freight
to authorized dealer.

- 2 -
English
APMR-4080MIN
45
123
1. RCA Input Jacks
2. Rear Speaker Output 3. Front Speaker Output
321
910
678
1. Front GAIN Control
2. Front Filter Select Switch
3. Front HPF Control
4. Front Bass Boost Level
5. Front LPF Control
6. Rear GAIN Control
7. Rear Filter Select Switch
8. Rear HPF Control
9. Rear Bass Boost Level
10. Rear LPF Control
1. Ground
2. Remote Turn-on Input
3. Battery +12V Input
4. 40 Amp Fuse
5. Protection Circuit Indicator LED
6. Power Indicator LED
456
123

- 3 -
This section suggests Mounting and Wiring Precautions for installing the Audiopipe marine
amplifier. If you do not posses the necessary tools and installation experience, do not
attempt to install this marine amplifier. Instead, contact your local Audiopipe dealer to
perform the installation.
Prior to mounting the marine amplifier, make sure it is safe to mount the marine amplifier
in that location. Failure to do so can result in serious damage to the boat. In addition,
stainless steel hardware should be used to mount the marine amplifier and additional
accessories. When possible, use a nut and bolt with a lock washer to secure the marine
amplifier. Extra care and attention is necessary in marine installations due to the uncertainty
of water conditions.
Additional precautions and suggestions:
For the most efficient cooling, mount the marine amplifier so cool air runs along the
length of the heat sink, rather than across them. To increase air movement and circulation,
a cooling fan can be installed.
Mount the marine amplifier on a rigid surface; avoid mounting to subwoofer enclosures
or areas prone to vibration.
Prior to drilling and holes, make sure the proposed mounting holes will not cut into the
fuel tank, fuel lines, electrical wiring, or through the boat.
Do not mount the marine amplifier where it is susceptible to water.
1.
2.
3.
4.
When bridging two amplifiers please refer to the bridging wiring chart.
When bridging two amplifiers you should use same model amplifiers.
Please make sure the negative speaker terminal of two amplifiers are connected by
the same gauge cables as the positive terminal being used.
DO NOT connect any signal cables with the input RCA jacks when bridged as slave
unit.
The LPF, Input level and remote functions will be disabled on slave amplifier when
bridged.
All the functions of the slave amplifier will be adjusted by the master amplifier.
1.
2.
3.
4.
5.
6.
English

- 4 -
English
4-Channel Full-Range Operation
APMR-4080MIN

Bridged-Mono Subwoofer System
APMR-4080MIN
- 5 -
MIN MAX
MIN MAX
HPFFLAT
HPFFLAT
90 500
50Hz 1.2KHz
90 500
50Hz 1.2KHz
English

2-Channel Full-Range Satellite, or Subwoofer FLAT System
APMR-4080MIN
- 6 -
MIN MAX
MIN MAX
HPFFLAT
HPFFLAT
90 500
50Hz 1.2KHz
90 500
50Hz 1.2KHz
English

2-Channel Full-Range Satellite, or Subwoofer FLAT System
APMR-4080MIN
- 7 -
MIN MAX
MIN MAX
HPFFLAT
HPFFLAT
90 500
50Hz 1.2KHz
90 500
50Hz 1.2KHz
English

- 8 -
•
•
•
•
•
•
•
•
•
•
•
•
•
For additional questions please contact your authorized Audiopipe dealer.
English

- 9 -
English
RMS @ 4 Ohms (<1% DISTORTION) .....................................
RMS @ 2 Ohms (<1% DISTORTION) .....................................
Maximun Power Output ...........................................................
Frequency Response ...............................................................
Signal Noise Ratio ...................................................................
THD .........................................................................................
Input Sensitivity Level ..............................................................
LPF ..........................................................................................
HPF ..........................................................................................
Dimension (W x H x D) ............................................................
4 x 80W
4 x 115W
2 x 230W
10 ~ 30kHz
>80dB
<0.05%
0.2 ~ 6V
50 ~ 500Hz
50 ~ 1.2kHz
154 x 49 x 211mm
APMR-4080MIN
