Audiovox FPE1080 User manual

128-7656
Operating Instructions
Model No.: FPE1080
8 LCD TV/DVD Player
Forassistance, please call:1-800-645-4994
Or Visit us at http://www.audiovox.com
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

2
Thankyou. ..
...for choosing thistablet DVD player. For your own safety and in order
to learn all about thefunctions available, pleaseread thismanualand
keep it for future reference. Note:
AnLCD panel and/orvideomonitor may be installed ina motor vehicle
and visible to the driver ifthe LCD panel or videomonitor is usedfor
vehicleinformation, system control, rear or sideobservationor
navigation. If the LCD panel or video monitor is used for television
reception, video or DVD play, the LCD panel or video monitor must be
installedso that these features willonlyfunctionwhenthevehicle isin
park”or when thevehicle’sparking brakeis applied.
An LCD panelor video monitor used for television reception, videoor
DVD play that operateswhen the vehicle is ingear orwhen the
parking brake isnot appliedmust be installed tothe rearof thedriver’s
seat whereit will not bevisible, directly or indirectly,to the operator of
the motor vehicle.
Note:
This productincorporatescopyright protection technology thatisprotectedby
method claimsof certain U.S. patents and otherintellectual propertyrights
owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology mustbe authorized by Macrovision Corporation
,and isintended for homeand other limited viewing uses onlyunless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

3
TableofContents
A.CautionsandWarnings...........................................................................04
B.About This Manual............................................................................06
C.DesktopBaseInstallation............................................................................08
D.Mounttheunitonthewall..........................................................................09
E.PriortoOperation.......................................................................10
F.Remote Control..........................................................................12
G.DVDPlayer...............................................................................13
H.PowerSupplies ............... ..................................................................14
I.Connections.......................................................................................15
J.Receiving TV Programs.....................................................................16
K.Reading SD (SecureDigital)andMMC(Multimedia)Card..............16
L.PlayingDVDs...................................................................................17
M.PlayingCDs.....................................................................................21
N.Playing MP3 Disc.............................................................................21
O.Setup...........................................................................................23
P.Specifications....................................................................................27
Warranty.......................................................................................30
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

4
A.Cautions andWarnings
Alloperation and maintenanceinstructions must befollowed and warningsadhered
to.
Do not expose the unit to excessive moisture.
Do not place objects filled with liquids, such as vases, on the unit.
Do not use the unit where there are temperature extremes (below41°F, 5°C or
exceeding 95°F, 35°C).
Adjust the volume to prevent damage to speakers.
Sudden changesin theambient temperature maycause condensation to form on
the optical lens inside the unit. Ifthis happens, remove the disc, and allowabout
2 hours to pass and then proceed with normal operation.
To ensure proper ventilation and proper operation, never coveror block the
slots and openings with acloth or other material.
Keep the unit awayfromstrong magnets, heating sources, sunlight, and
excessive dust.
Never allowobjects ofanykind or liquids to be pushed/spilled into the unit
openings as theymaycome into contact with dangerous voltages.
Unplugthe unit from the wall outletbefore cleaning. Do not use liquid or
aerosol cleaners.
Do not use accessories not recommended in this manual as theymaybe
hazardous.
Power cords should be routed so that theyare not likelyto be walkedon or
pinched by itemsplacedupon or against them. Pay particular attentionto plugs
and the point fromwhich the cord exits the unit.
Do not attempt to service this product yourselfas opening or removing covers
mayexpose you to dangerous voltage points or other hazards. Referall servicing
to qualified service personnel.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

5
When replacement partsare required, be sure theservice technician has used
replacementparts that are specified. Unauthorised substitutions mayresultin
fire, electric shock or other hazards.
Upon completion ofanyservice or repairs to the unit, ask the service techni-
cian to performoperational checks to determine that the product is operating
correctly.
Handlingthe LCDpanel
Donot press hardor jolt the LCDpanel. Itmay causetheLCDpanelglasstobreak
and injurymayoccur.
Ifthe LCD panel is broken, do not touch liquid in the panel.
If theliquid in the LCDpanel is ingested, immediately gargle and consult withyour
doctor.Also, ifthe liquid getsin your eyes or touchesyour skin, consult with your
doctor after rising forat least 15 minutes or longer with clean water.
Contents
1.1x8”LCD Monitor&DVDPlayer
2.1xRCAAVCable
3. 1xAC ToDCAdapter
4. 1xVehicleDC PowerAdapter
5.1xRemoteControl
6.1xBase
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

6
B.AboutThis Manual
Theoperationsdescribedmainlyreferstotheuseoftheremotecontrol.
Buttons with same orsimilar marking on the main unit have the same function as
those on the remote control.
Ifthe symbol occurs on the screen during operation, the function requested is
notsupported by themedia type inserted intheDVDplayer.Theunitwill play
thefollowing:
Many Disc Formats are supported
DVD-VideoDVD+RW
CD-RDVD+R
CD-RWDVD-ROM
CD AudioMP3
Photo CDDVD-RAM
DVD-RWCD-G
DVD-RHDCD
= YES =NO
Important Information
Note: Usuallythe unitplaysCD-R,CD-RWand MP3 discs.Butdueto the variety
ofdisc types,recordingcomputers,operatingsystemsand softwareforburningwe
cannot guaranteethat every CD-R, CD-RW orDVD isplayable within this unit.
Pleasebe awareofthefollowing:
This instruction manual explains the basic instruction ofthis unit.
Some DVD discshave different functions that maynot be explained in this
instruction manual. You mayneed extra instructions. In thiscase, pleasefollow
the instructions displayed on the screen or jacket or case ofthe disc.
The disc information takes priorityin various settings.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

7
1
In this manual, thelanguagein the on-screen displayisEnglish. If you
change the language, pleasefollow the selectedlanguagein the on-screen display.
The screen shown as an example in this manualmaybe different fromthe
actual screen.
On-screen displays subject to change without notice.
Note: The types offunctions and operations that can beused for a particular
disc varydepending on the features ofthat disc. In some cases, these functions
and operations maydiffer fromthe descriptions given in this Owner’s Manual.
In this event, followthe instructions given on the screen and on the sleeve ofthe
disc.
Region ManagementInformation
This DVD playeris designed and manufactured to respond to
the region management information that is recorded on a DVD
disc. If the region number described on the DVD disc does not
correspond to the Region number ofthis DVD player, this
DVD player cannot playthis disc. The region number for this
DVD player is ‘1’.
Please note thatthe programofa DVD may be divided into several ‘titles’(e.g.
main movie, bonus material, interviews etc.). Each of these titlescan be divided
into ‘chapters’. The programofaudio CD’s is divided into “tracks”.
3
Multiple languages
16:9
LB Multi-aspect
2
Multi-languagesubtitles
3
Multi-angle
CC Closed caption
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

8
C.Desktop Base Installation
1. Place the tablet DVD player base on flat surface.
2. Align the thumb screwwith the hole on the back ofthe DVD player.
3. Thread the thumb screwinto the hole on the back ofthe DVD player and turn
the thumbscrewcounter-clockwise to tighten the base to the DVD player.
4. Whileholding theDVDplayer and the base, adjustthe unit’sswivelanglefora
comfortable viewing position.
UnitBase
Screw Hole
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

9
D. Mount theunit onthewall
The unitcan be easilybe mounted on the wall.You willneed an optionalVESA75
Wall Mount Bracket.The VESA75Wall Mount Bracket can bepurchased at
most localelectronic retailers.The wallbracket plate which attaches tothe wall
hasfour screwholes. The rearofthe unitcontains four screwholes(Refer to
Figure1).The VESA75 Wall Mount Bracketisattached to theback oftheunit
with fourscrews(M4x6 orM4x8).Followthe instructionssupplied with the
VESA75 WallMountBracketto complete theinstallation.
Screw Holes Screws Holes
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

10
E. Priorto Operation
Place inPosition
For setting up the unit please choose a location with sufficientair circulation
to prevent overheating.
The product must be positioned horizontally only. Do not place heavy
objects on its housing.
To protect the laser unit avoid dustysurroundings.Ifnecessary,please use a
cleaning disccarefully following its operating instructions.
MoistureCondensation
In some cases watermaycondense on the laser lens causing a
malfunction:
The unit was suddenlybrought froma cold to a warmsurrounding.
=> Please take out the disc and wait for about an hour,
until the unit has warmed up.
The unit was operated in a veryhumid surrounding.
=> Please choose a location with lower humidity.
Handling Disc s
In order to keep the disc clean, never touch the shinysurface.
Neverplace astickeror adhesivelabel on the disc.
Don’t expose discs to direct sunlight or other heat sources.
Please store the discs onlyin their sleeves.
7
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

11
Cleaning aDisc
To clean adisc use a soft cloth without anycleaning agents.
Onlywipe fromthe center hole towards
the outer edge, never in toward the center.
Using the RemoteControlHandset
1. The remote control uses a pre-installed Li-ion type
battery.Topreventthe battery fromdischarging, we’ve
inserted an insulatingstrip. Pleasepull it
outpriorto first use.
Ifthe remote control should begin to operate
unreliablyreplace the batterywith a newbatteryof
the sametype. To replace thebatteryopen thebattery
compartment. Push the retention clip in the direction of
arrowand pull outthe battery mounting.
2. Before you remove thebattery, remember the battery
position.The ‘+’marking must face upwards, otherwise
the remote control will not work and maybe damaged.
Replace the cover.
3. Please pointthe remote control towards themain unit whenoperatingthebuttons.
The remotecontrol works bestwith a distance less than 16 feet (5m) and in an
angle ofup to 45o center ofthe front ofthe unit. Obstacles between the remote
controland infraredsensorwilladversely affectoperation ofthe remote control.
Batteries shoulddisposed in an environmentallycorrect manner. .Never
throw batteries into fire.
Iftheremote controlis not tobe usedfor an extended periodoftime, please
remove thebatteryfromthe compartmentto preventdamage bybattery
leakage.
When replacingthebattery,please observe thepolarity. The ‘+’mustface
upwards.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

12
F.TheRemote Control
1.0-9
2.PLAY/ PAUSE
3. ENTER
4. STOP
5.CH+/-
6.TV/CATV
7. SKIP SEARCH
8. AUTO
9.+ /-
10. PICTURE
11.MENU
12. SETUP
13.REPEAT
14. SKIP+/-
15. REW, FF
16. SUBTITLE
17. AUDIO
18.DISPLAY
19.POWER
20. DVD/TV/AUX
21. SD/DVD
22.EJECT
Numeric Buttons
Startsplay orpauses the playback
Navigation keys tooperatethe menu. ENTER confirms the selection
Stops DVDplayback
Selects next orprevious channelwhile inTV mode
Selectsthe TVreceivingmode (TV, IRC, HRC, STD)
Skips channels thatthe userwishes not to view.
Automaticallysearches forTVchannels
Used with “PICTURE”functiontoincrease ordecrease the itemyouselect
orthe volumeup or down
Selectsthe pictureadjustsetting
Brings up the DVDplayer’smenu
Accesses the menus forbasic setup
Activates repeat mode
Skips toprevious/nextchapter (DVD) oraudiotrack (CD)
Speeds up playback backwards or forwards by2x, 4x, 8x, up to 20times
normalspeed(DVD)
Toggles the subtitlelanguages available
Toggles DVDaudiolanguages
Provides the elapsedplaying time, subtitle, audio
Turns the unit on or off
Selects signalfromDVD/SD, TV andauxiliaryequipment
Selects signalfromDVD or SD card
Ejectsthe disk.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

13
G.DVDPlayer
1. PowerButton
2.ProgramButton
3. Channel +/- Button
4.Volume +/- Button
5. PictureButton
6. TV/AV/DVDButton
7. PreviousButton
8. Play/Pause Button
9. Next Button
10. Stop Button
11.Eject Button
12. Disk Slot
13. Power Indicated LED
14. IR Remote Sensor
15. SD Slot
16. CableAntenna Connector
17. DC12VInputJack
18.AV In/Out Switch
19. AudioRightJack
20. Audio Left Jack
21. VideoJack
22. Headphone Jack
1
2
3
4
5
6
7
8
9
10
11
12
1314
16
17
18
19
20
21
15
22
+
PROG
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

14
Vehicle DC Power Adapter
INPUT: DC12-14V
OUTPUT:DC 12-14V
H. Power Supplies
a. UsingACadaptor
Connect the supplied AC adaptor.
INPUT: AC100 ~240V,50/60Hz, 0.4A
OUTPUT: DC 12V,1.7A
Use this unitonlythesupplied ACadaptor.
Use with other AC adaptors maydamage the unit.
Do not touch the AC adaptor with wet hands. Doing so is dangerous, as this
could result inan electricshock.
Do not use with a voltage other than the voltage displayed. Improper voltage
could cause fire,electricalshock,ordamage.
b. Using cigarettelighter adaptor
Connect the supplied DC power
adaptorto vehicle power outlet.
Caution on the cigarettelighter adaptor:
Use only the supplied DCpower adaptor.Usingother DC power adaptors
coulddamage the unit.
After use, disconnect the cigarette lighter adaptor plugs fromboth this unit and
the vehicle power socket.
The DC power adaptor may cause interference with reception fromthe car
radio oranother radio inside the vehicle. If this is the case, disconnect the
DC power adaptor fromthe vehicle powersocket, or use the radiolocated at a
further distance fromthe vehicle power socket.
Trafficsafety:
Do not use while operating a motorized vehicle. It maycreate a traffichazard
and isillegalin manyareas.
a
b
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

15
After connecting the unit to power, press “POWER”button, and the logo
picture will appear on the screen and the LED power indicator located on lower
left front ofthe unit will belight.
I.Connections
Althoughthis unit has its own screen,youcanconnect itto an external
televisionsetas well.
1. Playing aVideoGame
1)Slide the AV in/outswitch
to the “In”position.
2)Plugthe AVoutput fromyour
gamesysteminto theAudio L+ R
and video inputjack on the left side of
the unit with corresponding color:
(AudioLeft= White, AudioRight= Red,Video=yellow).
3)Press “DVD/TV/AUX”until the word “AUX”
appears on thetopright; Adjustthevolume
controland thebrightness controlon thetop
ofthe unittoyourindividual preference.
2. Connecting toaTVor another monitor
Youcan also connect the DVD
playertoa TV ormonitorto
enjoy high qualitystereo.
Insert each cable firmlyinto its designated jack.
Ifyourantennauses 300-ohmtwinleadcables,do notcoil thecables.Also, keep
thetwin lead cables awayfromaudio/video cables.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

16
1) Connect the supplied AV(RCA) cables into the Audio L+ R
andvideo jack on theleftsideofthe unitfollowing the corresponding colors:
(AudioLeft= White, AudioRight= Red, Video=yellow).
2) Connect the supplied AVcables on the other end to your TV. Match the cable
bycolor code.
J. Receiving TV Programs
1. Press “DVD/TV/AUX”until the word “TV”
appearson the top right.
2. Press “AUTO”,the unitwill search TV channels
automatically.
3. After the channels are searched, you can use CH+/-
to choose the channel you like.
Note:
a. The picture and audio are not visible when searching channels.
b. If you don’tlike achannel,press “SKIPSEARCH”.The channelwill not appear
when youpress “CH+/-”.
K.Reading SD (SecureDigital)andMMC
(Multimedia)Card
You can enjoyhigh-quality pictures , musicand cinema stored in an SD card.
Note:
Themaximumcardsizeis512MB. Acardsize1GB orgreatermayresult inabnormal
operation.
1. Press “DVD/TV/AUX”until the word “DVD”appearson the top right.
2. Insertthe SD card (with the label sidefaced to you) into the SD slot on the left
sideofthe unit and the unit willread it automatically.
3. Press “SD/DVD”until the word “SD”appears on the screen display;
4. Press the and buttonto switch between Music and Photos.
5. To pull out the SD card, press the card once till it flips out a little.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

17
L. Playing DVDs
DVDPlayback
1. Press “DVD/TV/AUX”until the word “DVD”appears on thetop rightofthe
screen.;
2. Insert the disk in the right side ofthe unit with label
facing to you. Then the disk will be pulled into the unit
and playwill begin automatically.
DVDdiscs willusuallyshowa menu to choose from. Use the navigation buttons
on the remote control.
Highlight the desired menu itemand press the ENTER button to activate it. This
starts theplayback of the selected item.
Tostop playback press the STOP buttononce.The
screen shows “”. The player will recall
the location whereplayback was stopped.
Press the PLAY button to resume playback there.But if
youpress the STOPbuttonagain the unitwill stop
and not recall thelast position ofplayback.
The “resume play”isnotsupported byalldiscs.
Ifthis symbol appears on the screen during operation, the function
requestedisnot supported by themedia typeinserted.
Volume: The Volume +/-is on the top ofthe unit. Press to
adjust the volume.
Picture: the buttonis on the top of the unit. Press it to
choose the itemabout picture you wantto change. Then
press Volume +/- to adjust it.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

18
Display
a. Duringplayback press the ‘DISPLAY’button to display thecurrent
Title Number(1),thetotal Numberof Titles (2), thecurrent Chapter
Number (3),the total Number ofChapters (4),andthe Playing
elapsed Time forthetitle (5).
Title, ChapterNumber, and TimeScreenDisplay
Press “DISPLAY”asecond time, the heading content will be changed to the on
shown below. Thecurrent number ofaudio language(1), thetotal numberof
audio languages(2), the current language(3), current language mode(4), current
number ofsubtitle language(5),the total numberof subtitle languages(6),cur-
rent subtitle language(7),Angle mode(8).
b.Press ‘DISPLAY’constantly to choose the options belowinsequence.
(DVD)
Chapter Elapsed: Theelapsed time ofthe
chapter
ChapterRemain:The remaining time of the
chapter
TitleElapsed: The elapsed time of the title
Title Remain: The remaining time of the title
Display Off: The DVD’stime Information will
not bedisplayed.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

19
DVDCamera Angles
Duringplayback ofadisc,press ‘ANGLE’to display the availableanglesfor
discscontaining multi-angles*.Press ‘ANGLE’to selectanother angle, then press
again to exit and return to thenormal viewing angle.The angle displaywill disap-
pear automaticallyif the ‘ANGLE’button is not pressedagain within 3 seconds.
*NOTE: Notalldiscs containthis feature.
Skip&Search
Press , to playback the
beginning ofthe previous or next chapter
(DVD) or audio track (CD).
To pause the DVD,press the
button. Toprotect the screen, ascreen saver
(a flying DVD symbol) appears after several minutes
that pictureis paused.Press this button againto
resume normal playback.
Still Picture
These buttons activate a backward and forward search mode . Depend-
ing on howoften youpress the button, playback speed increases to 2x, 4x, 8x or
20 times andthe audio is muted. Press the PLAYbutton to resumeplayback at
normal speed with audio.(DVD)
PlaybackSpeeds [FF ] [REW ]
Press the REWor FF ( ) buttons repeatedly
to select the fast forward or reverse play speeds during playback.
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com

20
Repeat Modes
ChangeSoundtrackLanguage
During DVD playback press the AUDIO button to select a different audio
language (if the DVD disccontains several audiolanguages).
ChangeSubtitle Language
During DVD playbackpress the SUBTITLE button to selectthe languagefor
subtitles(ifthe DVD contains subtitle languages) or to deactivate that function.
DVDMenu
Pressing the MENU button of the remote control accessesthe contentmenu ofthe
DVD (ifavailable). This may include varioustitles, bonus material and specials.
When playing othermedia, press the ENTER button, to access the content menu
a.Duringplaybackpress ‘REPEAT’constantlyto see therepeat
modeshownbelow.
Chapter: Repeatthecurrent chapter
Title: Repeat the current title
All:Repeat allchaptersandtitles
Off: Resume normalplayback
Repeat Modes
PDF created with FinePrint pdfFactoryPro trial version http://www.fineprint.com
