SAFETY PRECAUTIONS
Thelightningflashwitharrowheadsymbol,
within an equilateral triangle, is intended
to alert the user to the presence of
uninsulated“dangerousvoltage”withintheproduct’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
Theexclamationpoint within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance(servicing)instructions in the literature
accompanying the appliance.
WARNING : TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USERSERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CLASS 1 LASER PRODUCT
APPAREIL À LASER DE CLASSE 1
CAUTION
• DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE.
• TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT OF
WALLOUTLET, THEN FULLY INSERT.
This product
contains a low
powerlaser device.
The symbol for Class II
(Double Insulation)
WARNING :
• TO PREVENTFIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE. DO NOT PLACE OBJECTS
FILLED WITH LIQUIDS ON OR NEAR THIS
UNIT.
• SHOULD ANY TROUBLE OCCUR,
DISCONNECT THE AC POWER CORD AND
REFER SERVICING TO A QUALIFIED
TECHNICIAN.
PLACEMENT INFORMATION
• Do not use this unit in places which are
extremely hot, cold, dusty or humid.
• Do not restrict the air flow of this unit by placing
it somewhere with poor air flow, by covering it
witha cloth,byplacing itonbedding orcarpeting.
SAFETY INFORMATION
• Whenconnecting or disconnectingtheACpower
cord,grip the plug and not the cord itself.Pulling
the cord may damage it and create a hazard.
• When you are not going to use the unit for a
long period of time, disconnect the AC power
cord.
CONDENSATION INFORMATION
• When left in a heated room where it is warm
and damp, water droplets or condensation may
form inside the equipment. When there is
condensation inside the unit, the unit may not
functionnormally. Let the unitstandfor1-2hours
before turning the power on or gradually heat
the room and let the unit dry before use.
RATING PLATE LOCATION
The rating plate is located on the rear of unit.
FCC STATEMENTS
NOTE: This unit has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This unit generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
causeharmful interference toradiocommunication.
However, there is not guarantee that interference
will not occur in a particular installation. If this unit
does cause harmful interference to radio or
television reception, which can be determined by
turning the unit off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the unit and
receiver.
- Connect the unit into an outlet on a circuit
different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
WARNING: Changes or modifications to this unit
not expressly approved by party responsible for
compliancecould void the user authority to operate
unit.
AVIS
CAUTION
INVISIBLE LASER RADIATION WHEN UNIT IS
OPENED AND INTERLOCKS ARE DEFECTED.
AVOID EXPOSURE TO LASER BEAM.

E
2
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (Including amplifiers)
that produce heat.
9) Do not defect the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other.Agrounding type plug
has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the provided
plug does not fit into your outlet, consult
an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11) Only use detachments / accessories
specified by the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use
caution when moving the
cart / apparatus
combination to avoid
injury form tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damages, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
MAINTENANCE
CLEANING THE DISC
A defective or dirty disc inserted into the unit can cause sound to drop out during playback.
Handle the disc by holding its inner and outer edges.
• Do NOT touch the surface of the unlabeled side of the disc.
• Do NOT stick paper or tape on the surface of the disc.
• Do NOT expose the disc to direct sunlight or excessive heat.
• Clean the disc before playback. Wipe the disc from the center outward
with a cleaning cloth.
• NEVER use solvents such as benzine or alcohol to clean the disc.
• Do NOT use irregular shape discs (example : heart shaped, octagonal, etc.). They may cause
malfunctions.
CLEANING THE UNIT
• Be sure to turn the unit off and disconnect theAC power cord before cleaning the unit.
• Wipe the unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth which has
been dipped in a weak soap-and-water solution and wrung out thoroughly. Then wipe it with a dry
cloth.
• Never use alcohol, benzine, paint-thinner, cleaning fluid or other chemicals. Do NOT use compressed
air to remove dust.
IMPORTANT NOTE
Before shipping the unit, remove any disc from the disc compartment.

E
3
CONTENTS
SAFETY PRECAUTIONS ................ 1
IMPORTANT SAFETY
INSTRUCTIONS ............................... 2
MAINTENANCE ................................ 2
CONTENTS ...................................... 3
DISC FORMATS .............................. 4
ACCESSORIES ................................ 5
USING OF REMOTE CONTROL ...... 5
CONTROL REFERENCE GUIDE . 6-7
CONNECTIONS.............................. 8-9
Connecting a TV Antenna ................ 8
Connecting to other Equipment with
Video Output (VCR, Camcorder, Video
Game System, Cable, Satellite system,
etc.) .................................................. 8
Connectingto anotherTV withA/VInput
.......................................................... 9
Connecting theAC Power Cord ........ 9
INSTALLATION..................................10
Removing the Base Sand ................ 10
Mounting on the wall ....................... 10
USINGHEADPHONES .................... 10
SCREEN VIEWING ANGLE
ADJUSTMENT ................................ 11
UNIT OPERATION .......................... 11
SOUND SYSTEM ............................ 11
USINGTHETV ...................................12
Searching for TV Channels
Automatically ................................... 12
Manual Searching for TV Channels
......................................................... 12
WatchingTelevision ......................... 12
Resetting the TV Channels .............. 12
TVSETUP ....................................13-15
PictureSetting.................................. 13
Sound Setting .................................. 13
TimerSetting.................................... 14
MiscSetting......................................14
TVChannel Setting .......................... 15
PLAYINGADISC ......................... 16-17
Playing a Disc .................................. 16
Playing a Picture File Disc ................ 16
Pausing Playback (still mode) .......... 16
Stopping Playback ........................... 16
Skipping to a different Track ............ 16
Fast Forward / Fast Reverse .......... 17
Audio Selection (DVD) ..................... 17
Subtitle Selection (DVD) ................... 17
Angle Selection (DVD) ..................... 17
SPECIAL FUNCTION ..................... 18
Display ............................................ 18
Locating a Specific tTtle (DVD) ........ 18
Locating s Specific Chapter / Track .. 18
Locating a Specific Time (DVD) ....... 18
REPEAT PLAYBACK ....................... 19
Repeating a Chapter / Title (DVD) .... 19
RepeatingaSingleTrack/ an Entire Disc
(CD) ................................................ 19
DVD/CD PROGRAMMABLE
PLAYBACK .................................... 20
Title / Chapter Programmed Playback
(DVD) .............................................. 20
Track Programmed Playback (CD)
........................................................ 20
CUSTOMIZING THE FUNCTION
SETTINGS ................................. 20-21
Language Setup .............................. 20
Video Setup .................................... 21
System Setup ................................. 21
TROUBLESHOOTINGGUIDE .......... 22

E
4
DISC FORMATS
NOTES ON COPYRIGHT
It is forbidden by law to copy, broadcast, show,
broadcast on cable, play in public or rent
copyrighted material without permission.
Apparatus Claims of U.S. Patent Nos. 4,907,093;
5,315,448 and 6,516,132 licensed for limited
viewing uses only.
DVD video discs are copy protected, and any
recordings made from these discs will be
distorted. This product incorporates copyright
protection technology that is protected by method
claims of certain U.S. patents and other
intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this
copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses
only, unless otherwise authorized by Macrovision
Corporation.Reverseengineering or disassembly
is prohibited.
The unit can play:
DVDs [8cm/
12cm disc]
Audio CDs [8cm/
12cm disc] CD-R CD-RW
Compatible
REGION MANAGEMENT INFORMATION
Region Management Information: This unit is
designed and manufactured to respond to the
Region Management Information that is encoded
on DVD discs. If the Region number printed on
the DVD disc does not correspond to the Region
number of this unit, this unit cannot play that disc.
The region number of this equipment is 1.
1
DISC FUNCTION OR OPERATION THAT
IS NOT AVAILABLE
When the symbol appears on the screen, it
indicates that the function or operation attempted
is not available at that time.This occurs because
the DVD disc manufacturer determines the
specific functions. Certain functions may not be
available on some discs. Be sure to read the
documentation provided with the DVD.
ICONS USED ON DVDs
Sample Icons:
Language selections for audio
Languageselectionsforsubtitles
Screen aspect ratio
Multiple camera angles
Region code indicator
2
2
2
1. English
2. French
1. English
2. French
LB
1
NOTE:
When playing back a CD-G (Graphics) or CD
EXTRA disc, the audio portion will be played, but
the graphic images will not be shown.
TITLES, CHAPTERS AND TRACKS
• DVDs are divided into “TITLES” and
“CHAPTERS”. If the disc has more than one
movie on it, each movie would be a separate
“TITLE”. “CHAPTER” are sections of titles.
Chapter 1
Titel 1 Titel 2
Chapter 2 Chapter 1 Chapter 2Chapter 3
• Audio CDs are divided into “TRACKS”. A
“TRACK” is usually one song on an audio CD.
Track 1 Track 2 Track 3 Track 4 Track 5
NOTE
Numbers identify each title, chapter and track on
a disc. Most discs have these numbers record on
them, but some do not.
NOTES ON UNAUTHORIZED DISCS
You may not able to playback some DVD discs on
thisequipment if theywerepurchased fromoutside
your geographic area or made for business
purpose.

E
5
ACCESSORIES
Please check and identify the supplied accessories.
AC Power Cord .................................................................................................... x 1
AC Adapter ........................................................................................................ x 1
Remote Control (with batteries) .............................................................................. x 1
USINGOFREMOTECONTROL
USING THE REMOTE CONTROL
• This remote control is magnetic and can be
attached to most refrigerators. Some
refrigerator panels are not metallic. In this
case,try attachingthemagnetic remotecontrol
to the side of the refrigerator.
• Point the remote control at the remote sensor
located on the unit.
• When there is a strong ambient light source,
the performance of the infrared remote sensor
may be degraded, causing unreliable
operation.
• The recommended effective distance for
remote operation is about 16 feet (5 meters).
TO INSTALL BATTERIES
1. Open the battery door.
2. Insert 2 “AAA” batteries.
BATTERY REPLACEMENT
When the batteries become weak, the operating
distance of the remote control is greatly reduced
and you will need to replace the batteries.
+
_
+
_
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the
same or equivalent type.
NOTES
• Do not place the remote control near
magnetic devices.
• If the remote control is not going to be used
for a long time, remove the batteries to avoid
damagecausedby battery leakage corrosion.
• Do not mix old and new batteries. Do not mix
ALKALINE, standard (CARBON-ZINC) or
rechargeable (NICKEL-CADMIUM) batteries.
• Always remove batteries as soon as they
become weak.
• Weakbatteries can leak andseverelydamage
the remote control.
• WARNING : Do not dispose of batteries in a
fire. Batteries may explode or leak.

E
6
CONTROL REFERENCE GUIDE
REMOTE CONTROL
1. FUNCTION button
Switch between TV / AV IN / DVD.
2. Number (0 - 9) buttons
3. MEMORY button
Set predetermined playback.
• [dot] button
Digital TV channels (i.e. 11.3 or 12.7)
4. EXIT button
Press to exit the TV menu and return directly
to normal viewing.
RETURN button
Return to normal operation after using the
SETUP menu of a DVD.
5. CURSOR ( , , , ) buttons
Usetohighlightselections on a menu screen
and adjust certain settings.
ENTER button
Presstoconfirmselectionsonamenu screen.
CH+ / CH- buttons
Press + / - button to move the TV channels.
6. DVD MENU button
Press to enter the main menu of the DVD
you are watching.
7. VOLUME (- / +) buttons
Press to adjust the volume level. Use to
highlight selections on a menu screen and
adjust certain settings.
8. GOTO button
Skip directly to a specific location on a DVD/
CD.
9. PREV button
Select previous chapters or tracks on a disc.
10. ANGLE button
Switch the camera angle of the video
presentation when scenes with multiple
camera angles are recorded on a DVD.
11. AUDIO button
Select audio soundtracks of a DVD or change
the output mode of a CD.
MTS button
PresstoselectMONOsound, STEREO sound
and SecondaryAudio Program (SAP).
12. FORMAT button
Press to select the picture format.
13. PICTURE button
Select from preset screen display settings to
match the type of show you are watching.
14. / ON button
Press to turn ON the unit or put it in STANDBY
(OFF) mode.
15. LAST CH button
Press to switch repeatedly between the last
two channels displayed.
16. TV MENU button
Press to display the on-screen TV menu.
17. MUTE button
Press to turn off the sound.
18. STOP button
Stop playing a disc.
PLAY button
Press to start and resume playback of a disc.
PAUSE button
Pause playback and single frame advance.
19. SEARCH / buttons
: Fast reverse playback.
: Fast forward playback.
20. SUBTITLE button
Select one of the subtitle languages
programmed on a DVD.
21. NEXT button
Select next title, chapter or track on a disc.
22. SOUND button
Press to select from preset sound settings to
match the type of show you are watching.
23. REPEAT button
Repeat chapter or title of a DVD.
Repeat single track or whole CD.
SETUP button
Enter and exit the SETUP menu of the DVD.
24. DISP (DISPLAY) button
Change disc status information displayed on
the screen.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

E
7
CONTROL REFERENCE GUIDE
FRONT & BACK VIEWS
1. Color LCD screen
2. Remote sensor
Point the remote control here.
Standby indicator
3. Right speaker
4. Removable stand
5. MENU button
Enters the on-screen TV menu.
6. / ON button
Turns the unit on and off.
7. DVD DOOR OPEN button
Open the disc door.
8. AUDIO / VIDEO OUT jacks (DVD out)
Connects to another TV.
9. PREV button
Press PREV button to go back to previous
chapters / tracks.
Press and hold fast reverse playback.
10. NEXT button
PressNEXTbuttontoadvancechapters/tracks.
Press and hold to fast forward playback.
11. PAUSE button
Pause playback and single frame advance.
12. STOP button
Stop playing a disc.
13. PLAY button
Press to start and resume playback of a disc.
14. Wall mounting holes
15. DC IN 12V jack
16. Headphones jack
17. AUDIO IN (Left/Right)/ VIDEO IN jacks
18. TV ANTENNA terminal
Connects a TV antenna or CATV cable.
19. - VOL + controls
Adjusts the volume level and highlights
selections (Left & Right) on the TV menu
screen.
20. CH buttons
Press to confirm selections on the TV menu
screen and / to move the TV channels.
21. FUNCTION button
Selects TV / AV IN / DVD
22. Left speaker
23. DVD door
Close by pushing the disc door.
1
2
3
4
5
6
7
8
9
1011
12
1314
15
16
17
18
19
20
21
23
22

E
8
CONNECTIONS
CONNECTING A TV ANTENNA
To view television channels correctly, a signal must be received from one of the following sources:
- An indoor or outdoor aerial antenna
- A cable system
- A satellite system
NOTE
For receiving over-the-air TV broadcasts, we recommend that you use an external fixed antenna.
Should you require the use of a temporary antenna, please ensure that you purchase an antenna with
sufficient ability to receive in weak signal areas. Only when you are in close proximity to a transmitter
will a temporary antenna reproduce a signal as strongly as a fixed antenna.
To TV
Antenna
terminal
To Home
Antenna
terminal
Cable without a CATV
converter
Combination VHF/UHF
antenna
(ATSC / NTSC signal)
Separate VHF/UHF
antenna
(ATSC / NTSC signal)
VIDEO IN
LR
AUDIO IN
VCR / CAMCORDER /
VIDEO GAME SYSTEM / CABLE /
SATELLITE SYSTEM etc.
CONNECTING TO OTHER EQUIPMENT WITH VIDEO OUTPUT
Connecting to a VCR /
Camcorder / Video Game
System / Cable / Satellite
System
Connects the AUDIO / VIDEO cable
(not included) as shown:
Make sure you connect the cable from
the other equipment (AUDIO/VIDEO
OUT) to this unit (AUDIO/VIDEO IN).
NOTE
Please refer to the user manual for the
other equipment for more information.
To connect to other equipment such as a VCR, camcorder, video game system, cable or satellite system
etc.
To AUDIO /
VIDEO IN jacks
To AUDIO / VIDEO OUT jacks

E
9
VIDEO
OUT
AUDIO
OUT
DVD
TV
CONNECTIONS
CONNECTING TO ANOTHER TV WITH A/V INPUT
NOTE
• Please refer to your another TV user
manual for more information.
To AUDIO /
VIDEO OUT
jacks
To AUDIO /
VIDEO IN jacks
CONNECTING THE AC POWER CORD
NOTES
• The included AC adapter and AC
power cord are for use with this unit
only. Do not use them with other
equipment.
• TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO
WIDE SLOT OF WALL OUTLET,
THEN FULLY INSERT.
• When the AC power cord is plugged
in, the unit is not completely
disconnected from the main, even when the power is turned off.
• Be sure the AC power cord is disconnected and all functions are off before making connections.
• Make sure that all the components are connected correctly.
• When you are not going to use the unit for a long period of time, disconnect the AC power cord.
Connecting to another TV
Connects the AUDIO / VIDEO cable
(not included) as shown:
Make sure you connect the cable from
another TV (AUDIO/VIDEO IN) to this
unit (AUDIO/VIDEO OUT).
This AC adapter operates on AC 110-
240V.
1. Connect the AC power cord to the
AC adapter.
2. Plug the AC adapter cord into the
DC-IN 12V on the unit.
3. Connect the AC adapter and AC
power cord into a wall outlet. To AC wall
outlet
To DC
IN 12V
AC adapter

E
10
INSTALLATION
REMOVING THE BASE STAND
WARNING: The LCD display is very
fragile, and must be protected at all
times when removing the base stand.
Be sure that no hard or sharp objects,
or anything that could scratch or
damage the LCD display, come in
contact with it. Do NOT place pressure
on the rear of the unit at anytime
because the screen could crack.
MOUNTING ON THE WALL
This unit is VESA-compliant, and is
designed to be wall-mounted with a
VESA-compliant 1.375” x 2.9375”
(35mm x 75mm) mounting kit designed
for flat-panel TVs (sold separately).
Mount this unit according to the
directions included with the mounting
kit.
NOTE
Remove the base stand before
mounting the unit on the wall.
1. Disconnect any cables or cords
connected to the unit.
2. Lay the unit down on a flat surface,
so the back side is facing up, making
sureto place asoftcushioned material
(such as a pillow or thick piece of
foam) beneath the screen.
3. Remove the 3 screws and then
remove the BASE STAND from the
unit.
WALL MOUNTING HOLES : 35 X 75 MM
WALL MOUNTING HOLES :35 X 75 MM
WALL M OUNTING HOLES: 3 5 X 75MM
USINGHEADPHONES
• Turn down the volume before
connecting headphones to the unit,
then adjust the volume to your
desired level.
• Whenheadphones are connected,no
sound will come from the front
speakers.
NOTE
Avoid listening to sound at high levels
for prolonged periods of time. This may
be harmful to you and may cause
hearing loss.
Headphones
(1/8” [3.5mm]
diameter plug)

E
11
SOUNDSYSTEM
DOLBY DIGITAL (FOR DVD)
Dolby Digital is a sound system developed by Dolby Laboratories Inc. that gives movie theatre ambience
to audio output when the unit is connected to a Dolby Digital 5.1 channel processor or amplifier.
This unit automatically recognises DVDs that have been recorded with Dolby Digital.
Not all Dolby Digital sources are recorded with 6 channels.
Some sources marked Dolby Digital may be recorded in Dolby Surround, 1 2 channel system. Look for
this logo on your unit.
Manufacturer under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
1
2
+16° -8°
SCREEN VIEWING ANGLE ADJUSTMENT
The unit is designed to allow users to have a comfortable
viewing angle.
1. Hold the stand firmly.
2. Gently adjust the TV.
CAUTION
Do not force the LCD screen over the maximum viewing
angle settings as stated above. Attempting this will result
in damage to the unit.
UNIT OPERATION
TURNING THE UNIT ON
When the AC power cord is connected, press the /ON button to turn it on.
Press the FUNCTION button to select the desired mode (TV / AV IN / DVD).
If you select DVD, the DVD logo will appear on the screen.
NOTE
When the unit is not going to be used for a long time, disconnect the AC power
cord from the AC wall outlet.

E
12
USINGTHE TV
Connect an antenna or CATV cable or Satellite system to the TV antenna terminal
before searching TV channels.
Searching for TV channels automatically
(Only appears to the first time Power ON)
Watching television
Viewing a television station after the auto/manual search for channels.
1. Press the FUNCTION button to TV mode.
2. Press the CH+ or CH- button to select a channel, or press the number button on the remote to
select the channel you want to watch.
• For channels 1 to 9, enter one-digit channel number.
• For channels 10 to 99, enter two-digit channel number.
• For channels 100 or over, enter three-digit channel number.
NOTE
• When a channel is selected, the channel number is displayed on the top right corner of the screen.
This number will disappear after a few seconds.
Manual searching for TV channels
1. Connect the TV antenna.
2. Connect the AC adapter and AC cord.
3. Press the / ON button to turn on the unit.
4. Press the ENTER button.
5. Press the or button to select “Air” or “CATV”, then press the
ENTER button to start auto scan.
6. The unit will immediately search all channels for those with adequate
signal strength and store those channels with signals in memory. The
unit will take a short minutes to finish auto scan and aftter this is
completed, the unit will switch to the first channel found.
ATSC TV mode:
Press the DISPLAY button, the upper
window will pop up, then press the
DISPLAYbuttonagain,thelowerwindow
will pop up. Press the DISPLAY button
once to exit.
NTSC TV mode:
Press the DISPLAY button, the upper
window will pop up, then press the
DISPLAY button once to exit.
RF CH 13
Press “MENU” To Exit Auto Scan
Found 0
: SELECT
“ENTER” : CONFIRM
PROCEED WITH AUTO SCAN?
NO YES
: SELECT
“ENTER” : CONFIRM
PLEASE SELECT ANTENNA TYPE.
AIR CATV
1. Press the TV MENU button, then press the button to TV
CHANNEL SETTING.
2. Press the button to select ANTENNA. Use the or button to
select AIR or CATV.
3. Use the button to select Auto Scan.
4. Press the ENTER button to enter sub menu of Auto Scan.
5. Use the button to select “Start to Scan” in the sub menu.
6. Press the ENTER button to start the search for TV channels.
7. The screen will show the first received channel when auto search is completed.
2.3 Xxxxxxx Xxxx
AUDIO 1/1(L+R) FTA
2007/01/31 07:38 07:00-08:00 TV LEVEL: Good
Xxxx xx xxxxxx xx xxxx xx xxxxxxxx x xxxx xxxxx xxx xx xxx
xxxxxxxxxxx xx xxxx xxxxx xx x xxxxx xxx xxxxxx x xxxxxx xxx
xxxxxx xx xxxx xx xxxxxxxx x xxxx xxxxx xxx xx xxx
xxxxxxxxxxx xx xxxx xxxxx xx x xxxxx xxx xxxxxx x xxxxxx xxx
Position no.
Time information Audio
information
ATSC data information
(only ATSC) Signal
strength
(only ATSC)
Rating
information
ATSC data
information
(only ATSC)

E
13
TV SETUP
PICTURE SETTING
1. Press the TV MENU button.
2. Use the or button to select the options
(Picture Mode / Contrast / Brightness /
Sharpness / Tint / Color).
3. Use or button to make adjustment. The
screen will change to your selected mode
immediately. Press the TV MENU button to
return to the previous menu.
4. Repeat steps 2 and 3 to adjust other options.
5. To exit the TV SETUPMENU and return to the
normal screen, press the EXIT button on the
remote control.
NOTE
You can also access these setting by pressing
the PICTURE button.
Picture Mode:Select from preset screen display settings to match the type of show you are watching
(Standard, Dynamic, Soft & Personal).
Contrast: Adjust to sharpen the picture quality. The black portions of the picture become richer in
darkness and the white become brighter.
Brightness: Adjust to brighten or darken the whole picture.
Sharpness: Adjust the sharpness level to improve detail in the picture.
Tint: Adjust natural skin tones in the picture quality.
Color: Adjust the color of the picture.
SOUND SETTING
1. Press the TV MENU button.
2. Use the or button to select SOUND
SETTING.
3. Use the or button to select the options
(Sound Mode / Bass / Treble / Balance).
4. Use the or button to make adjustment.
Press the TV MENU button to return to the
previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit the TV SETUPMENU and return to the
normal screen, press the EXIT button on the
remote control.
NOTE
You can also access these setting by pressing
the SOUND button.
Sound Mode: Select from preset sound
settings (Standard, Music,
Movie, Personal) to match the type of show you are watching.
Bass: Adjust the bass range.
Treble: Adjust the treble range.
Balance: Adjust the balance level toward the left or right speakers.
Audio Language: Use the or button to select English, French or Spanish (Available for Digital
TV system only).
NOTE
Only for DTV/ATSC input source mode, thus it is not available in other input source
mode.
Treble
UP/DOWN ADJUST “MENU”:EXIT
Balance
Audio Language
Sound Mode
Bass
Standard
50
0
English
50
Brightness
UP/DOWN ADJUST “MENU”:EXIT
Sharpness
Tint
Color
Picture Mode
Contrast
Standard
50
50
50
50
0

E
14
TV SETUP
TIMER SETTING
1. Press the TV MENU button.
2. Use the or button to select TIMER
SETTING.
3. Use the or button to select the options
(OSD Duration / Sleep Timer / Time Zone /
Day Saving Time).
4. Use the or button to make adjustment.
Press the TV MENU button to return to the
previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit theTV SETUP MENU and return to the
normal screen, press the EXIT button on the
remote control.
Time Zone / Day Saving Time / Clock
1. Set the local Time Zone, eg. Pacific.
2. After selecting the time zone, the Day Saving Time must be activated for those areas observing
such change.
3. The clock will be recoded automatically (for ATSC only).
OSD Duration:Select amount the time of TV
menu showing on screen.
Sleep Timer: Set the LCD TV to turn itself
off within a certain time.
MISC SETTING
1. Press the TV MENU button.
2. Usethe or buttontoselect MISCSETTING.
3. Use the or button to select the options
(Language / Color Mode / Restore Setting).
4. Use the or button to make adjustment.
Thescreenwillchangetoyourselectedmode
immediately. Press the TV MENU button to
return to the previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit the TV SETUP MENU and return to
the normal screen, press the EXIT button on
the remote control.
Language : Select from English /
Français / Español.
Color Mode : Adjust the three color
temperature of the picture.
Select Normal (balanced) /
Warm (red white) / Cool (blue white) mode.
Restore Setting :If you reset the TV to the factory settings, all your present settings on picture &
sound will be erased and replaced by the factory’s default settings.
UP/DOWN ADJUST “MENU”:EXIT
Restore Setting
Language
Color Mode
English
Normal
Time Zone
Clock
UP/DOWN ADJUST “MENU”:EXIT
Day Saving Time
OSD Duration
Sleep Timer
30 Sec
Off
Eastern
Off
----/--/-- --:--

E
15
TV CHANNEL SETTING
1. Press the TV MENU button.
2. Use the or button to select TV CHANNEL
SETTING.
3. Use the or button to select the options
(Antenna / Auto Scan / Auto Scan Add CH
/ Channel Skip / Channel No. / Channel
Label).
4. Use the or button to make adjustment.
The screen will change to your selected mode
immediately. Press the TV MENU button to
return to the previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit the TV SETUP MENU and return to
the normal screen, press the EXIT button on
the remote control.
NOTE
Channel No. : 2-69 Channel for Air, 1-135
Channel for CATV.
TV SETUP
Channel Label: You may edit one label for each channel.
1. Select the Channel Label item and press the or button to go
into the channel label edit screen.
2. Use the or button to enter the number or letter.
3. Use the or button to move and edit for the next character.
4. After editting, press the DISPLAY button and the Channel &
Channel Label will be shown on the screen.
Antenna : Select “CATV” to receive cable signal. Select
“AIR” to receive air singal.
Auto Scan : Automatically search all channels for those
with adequate signal strength.
Auto Scan Add CH :The stored channels can not be cleared and
the Auto Scan Channels will be added.
Auto Scan Add CH
Channel Skip
Channel No.
Channel Label
UP/DOWN ADJUST “MENU”:EXIT
Antenna
Auto Scan
Air
If you has selected CATV in TV CHANNEL
SETTING, then you can select Cable System
(AUTO / STD / HRC / IRC) in the sub menu
as the picture shown.
Cable System
Start to Scan
Auto
UP/DOWN ADJUST “MENU”:EXIT
EDIT SELECT “MENU”:EXIT
123#
Channel Skip: You may switch ON/OFF the skip function of
each stored channel by selecting the channel
with / button (and using / button to
select page if the amount of stored channels in
more than 1 page), and followed with pressing
the ENTER button.
“ENTER”:SELECT
No. SkipProgram Name
2.0 Off
“MENU”:EXIT
3.0 Off

E
16
PLAYING A DISC
This owner’s manual explains the basic instructions of this unit. Some DVDs are produced with
limited operation during playback. For example, many DVDs do not allow users to skip government
warnings, or in some cases previews or other features. This is not a defect in the unit. Refer to the
instruction notes of discs.
“” may appear on the screen during operation. A “ ” means that the desired operation is not
permitted by the unit or disc.
PLAYING A DISC
1. Press the /ON button to turn on the unit.
2. Use the button to select “NO”, then press the ENTER
button.
(Only appears to the first time Power ON)
3. Use FUNCTION button repeatedly to select DVD mode,
then press the ENTER button.
See CUSTOMIZING THE FUNCTION SETTINGS before
proceeding to step 4.
4. Press the OPEN button to open the disc door.
5. Hold the disc by its sides and carefully press onto the central support of compartment with the
printed side facing towards you until you hear a “click”.
6. Push the disc door to close it.
It takes a short while for your unit to load the disc. After loading, the unit will automatically either
bring you to the main menu of DVD, or start playing the DVD. If the unit does not automatically start
playing the DVD, press the PLAY button.
PLAYING A PICTURE FILE DISC
This unit can play JPEG files recorded on a CD-R or CD-ROM disc.
1. Press the OPEN button to open the disc door.
2. Hold a JPEG file disc by its edge and gently push it onto the spindle with label side facing towards you
until you hear a “click”.
3. Push the disc door to close it.
4. The unit will load the disc and automatically display the contents of the disc on the screen, while also
beginning to play the picture file. These files will then be played back one by one.
5. Press the RETURN button to folder list.
6. Use the , , or button to view and select desired file, then press the ENTER button to confirm the
selected file.
NOTES
• You can press the PAUSE button to freeze the picture, and press the PLAY button to resume slide show.
• You can press the PREV or NEXT button to change the picture. Press the PREV button to view
the previous picture. Press the NEXT button to view to the next picture.
• You can press the ANGLE button to rotate direction of the picture by 90°.
PAUSING PLAYBACK (STILL MODE)
Press the PAUSE button. To resume normal playback, press the PLAY button. Each time you press
the PAUSE button, the picture advances one frame.
STOPPING PLAYBACK
Press the STOP button at the location where you want to interrupt playback. To resume playback at
the position where the disc was stopped, press the PLAY button.
SKIPPING TO A DIFFERENT TRACK
• Press the PREV button to skip to the start of the current/previous track.
• Press the NEXT button to skip to the next track.
• For an audio CD, use the number buttons on the remote control to go directly to the desired track number.
: SELECT
“ENTER” : CONFIRM
PROCEED WITH AUTO SCAN?
NO YES

E
17
PLAYING A DISC
FAST FORWARD / FAST REVERSE
1. Press the SEARCH or SEARCH button when a disc is playing.
• The disc begins a fast scan at two times normal (x2) speed.
• Fourspeeds areavailable. Eachtime theSEARCH buttonispressed,the speedof thefastscanchanges
2. Press the PLAY button when you have reached the desired point to resume playback at normal
speed.
AUDIO SELECTION (DVD)
On some discs, the sound is recorded in two or more formats. Follow the directions below to select the
type of playback.
1. While a disc is playing, press the AUDIO button to show the
current audio format number.
2. Press the AUDIO button repeatedly to select the desired audio format.
NOTES
• If only one audio format is recorded, the number does not change.
• About two seconds later, playback continues in the new audio format.
SUBTITLE SELECTION (DVD)
1. While a DVD is playing, press the SUBTITLE button to display the current language setting.
2. Press the SUBTITLE button repeatedly to select the desired subtitle language.
NOTES
• If only one language is recorded, the language does not change.
• About two seconds later, playback continues with the new subtitle you selected.
• The number of languages recorded differs depending on the disc.
• If no button is pressed within a few seconds, playback continues without changing the current subtitle.
• This function can only be used for discs on which subtitles have been recorded in multiple languages.
• On some DVDs, subtitles are activated from the main menu of the DVD. Press the DVD MENU button
to activate the main menu.
ANGLE SELECTION (DVD)
Some DVDs contain scenes which have been shot from a number of different angles. For these discs,
the same scene can be viewed from each of these different angles.
1. While you are playing a DVD with different angles
recorded,presstheANGLE button to view the number
of the current angle available.
2. Press the ANGLE button repeatedly to change the
scene to the next angle in those recorded.
• About two seconds later, playback continues from
the new angle you selected.
• If no button is pressed within 10 seconds, playback
continues without changing the current angle.
NOTES
• Thisfunctioncanonly be used for discs on which scenes shot frommultipleangleshavebeen recorded.
• If only one angle is recorded, “
1/1
” is displayed.
: 1/3ENG 6CH
D
: 2/3 ESP
:[3/3]
:[1/3] :[2/3]
: [ 2 / 3 ]
Sequence of angle shots
(Example)

E
18
SPECIAL FUNCTION
LOCATING A SPECIFIC TITLE (DVD)
If a DVD disc contains title numbers, you can locate a specific title by directly selecting its title
number.
1. In STOP mode, press the GOTO button.
2. Press the or button to highlight aspecific
field and press the corresponding number button(s) for the title you want.
3. Press the ENTER button to confirm. The unit will start playback about 3 second later.
LOCATING A SPECIFIC CHAPTER / TRACK
If you know the chapter / track number you want to play, you can locate a specific chapter / track by
directly selecting a chapter / track number.
1. Press the GOTO button to search for your
desired chapter / track.
2. Press the or button to highlight a chapter
/ track and press the corresponding number
button(s) for the chapter / track you want.
3. Press the ENTER button to confirm. The unit will start playback about 3 second later.
LOCATING A SPECIFIC TIME
You can move to a specific location by entering its corresponding time (hours, minutes, seconds)
1. Press the GOTO button.
2. Press the or button to highlight a time
andpress the correspondingnumberbutton(s)
for the setting point you want.
3. Press the ENTER button to confirm. The unit will start playback about 3 second later.
NOTES
• Some discs may not respond to this process.
• Thismethod of locating atitle/chapteris available onlyona DVD discthatcontainstitle/chapternumbers.
• Some scenes may not be located as precisely as you specified.
• This method for accessing specific locations is available only within the current title of the DVD disc.
DISPLAY
While the disc is playing, press the DISPLAY button
repeatedly to display information on operation status.
00:00:00
TRK 0 / 120
X
00:00:00
TT 00/34CH 0 /02900
0 :00:001
TT 00/21 CH 029/029
00:00:00
TT 0/21 CH 029/0290
Title Chapter Elapsed time
TT 1/21 CH 6/29 00:07:18
Audio Subtitle Angle
1/3 ENG 2/3 ESP
OFF
6D
TT 1/21 CH 11/29 -00:30:28
R
Title Remaining time
TT 1/21 CH 11/29 -01:00:28
T
Title Total time
Chapter
Chapter

E
19
REPEATPLAYBACK
You can play a specific title or chapter repeatedly.
(Title repeat, chapter repeat)
REPEATING A CHAPTER (DVD)
When you play the same chapter repeatedly.
1. While the DVD disc is playing, press the REPEAT button until the “REP : CHAPTER”indicator displays
on the screen. The current chapter is played repeatedly.
REPEATING A TITLE
When you play the same title repeatedly.
2. While the DVD disc is playing, press the REPEAT button until the “REP : TITLE”indicator displays on
the screen. The current title is played repeatedly.
To resume normal playback
3. While the DVD disc is playing, press the REPEAT button until the “REP : OFF”indicator displays on
the screen.
You can play a single track or an entire disc repeatedly.
REPEATING A SINGLE TRACK (CD)
You can play the same track repeatedly.
1. When the CD disc is playing, press the REPEAT button until the “REP : REP1” indicator displays on
the screen. The current track is played repeatedly.
REPEATING AN ENTIRE DISC
2. While the CD disc is playing, press the REPEAT button until the “REP : REP ALL” indicator displays
on the screen. The entire disc is played repeatedly.
To resume normal playback
3. Press the REPEAT button until the “REP : OFF” indicator display on the screen.
