Audioxtra Axis 2 Series User manual

SPECIFICATIONS
- 1/4” Full Colour CMOS Imaging Clip
- PC7070 Imaging Sensor
- Full Glass Lens
- 110° Wide Viewing Angle (Horizontal)
- 170° Wide Viewing Angle (Diagonal)
- PAL/NTSC (Switchable)
- Parking Guidelines (Selectable), Type, Height & Width (Adjustable)
- One Button Control of Image Orientation, Video Mode Select, Guideline Type,
Guideline Height & Guideline Width
- Mirror, Normal, Upside-Down Mirror, Upside-Down Normal Image Orientation (Switchable)
- 0.3 Lux Minimum Illumination
- IP67 Water/Dust Protection
- 12V DC Power Input
- Number Plate or In-Bumper Mounting
- RCA Connection
- Dimensions: 16.5mm x 23mm (D)
INCLUDED:
- Dual Mounting Heads (Butterfly and Bumper Fit)
- Installation Manual
- Installation Hardware
- Metal Hole Saw for Bumper Fit Installation
- 6m Video Cable (RCA M)
2WARRANTY
YEAR
SYSTEM CAMERA PARKING
GUIDELINES
IP67
WEATHER
PROOF
SWITCHABLE
12 V

CAR REARVIEW CAMERA
GENERAL:
After installation, the rear view system will automatically activate when reverse
gear is selected. This can provide a clear image for the driver and protect children,
pedestrians etc from injury. Also your vehicle will avoid costly repairs from dents
and other damage when parking.
CAMERA:
The DUAL HEAD system included with your purchase allows for exible installation
options, either surface mount (eg number plate or boot lid) or stealth insert mount
(eg bumper).
The RCA video cable simply connects with most aftermarket LCD monitors.
CAUTION:
Protective lm (if attached) should be removed from camera before operation.
Carefully check the +/- wiring sequence during installation.
Ensure safety when installing wires near the fuel tank
INSTALLATION:
1) Determine installation location (usually the centre-rear of vehicle).
a) Buttery Type - Mount on surface using double-sided tape or screws
b) Insert Type - Carefully drill hole (hole saw supplied) in bumper & insert camera
2) Connect RED cable to 12V+ power cable of Reversing Light circuit.
3) Connect BLACK cable to ground.
4) Connect signal extension cable.
5) Connect RCA (YELLOW) video cable to LCD monitor.

CAR REARVIEW CAMERA
CAMERA ASSEMBLY OPTIONS:
The C20 System is supplied with Dual Mounting Heads: Wing/Buttery or Bumper Fit.
1-click, enter with/without guide line switching mode:
THE FOLLOWING MODES MUST BE OPERATED UNDER THE MODE WITH GUIDE LINE,
operate to enter any mode you want 3 secinds afetr the previous mode.
2-quick-continuous click, enter Mirror/Non-mirror switching mode;
3-quick-continuous click, enter PAL/NTSC switching mode:
4-quick-continuous click, enter GUIDE LineType selecting mode:
5-quick-continuous click, enter GUIDE Line Width adjusting mode:
6-quick-continuous click, enter GUIDE Line Height adjusting mode.
CABLE CONNECTIONS:
See wiring diagram below:
Camera
GND
+12V
(Red Cable connect to rear lamp positive)
F
F
M
M
Monitor
+
One-Button
Control
Monitor Trigger Wire
(Please insulate if not used)
Selectable - Guidelines, PAL/NTSC & Normal/Mirror Image
Dual Mounting Heads
+
+ +
+
Butterfly
Bumper
