Aus Electronics Direct HDEX0021M1 User manual

200m HDMI Wireless Extender
1
USER MANUAL
REMARK
Manufacturer does not make any commitment to update the information contained herein.
HDEX0021M2(1 to Multiple)
Model No: HDEX0021M1(1 to 1)

Contains a transmitter (TX) and a receiver (RX). The HDMI signal over
wireless transmission from the transmitter to the receiver
One TX can be paired with multiple (up to 4PCS) RX
The TX support one HDMI loop output, for local screen monitor
Support HDMI resolution: 480P~1080P@50/60Hz and SVGA~WUXGA
Use the internationally accepted 5G ISM frequency band, high transmission
rate and strong anti-interference capability
Using an external dual - gain antennas. Full HD 1080p transmits up to 200
meters wireless in open space.( May be affected by the use environment)
Extends wide-band infrared remote to control source device from display side
Support OSD, for informed of device status
Simple Plug and Play, no software installation required
Supports both panel settings and Web Configuration Interface, Simple and
easy to use
2
INTRODUCTION
FEATURES ：
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
The products are designed to make you'rE a/V device use more convenient,
comfortable, productive and cost-efficient.
This product will let the user experience of transmitting the HD content by
wireless. The HDMI sources over wireless kit extends high-definition video and
audio to any HDTV displays up to 100 meters away.The extender follows the
TCP / IP standard Wireless Transport Protocol, so it has high transmission rate
and strong anti-interference capability. It also supports HDMI mirror output and
infrared remote control extension. The HDMI Wireless Extender is widely
applicable to office presentation, lecture, education, conference, family
entertainments etc.
Our devices offer solutions for noise, space and security concerns, data center
control, information distribution, conference room presentation, school and
corporate training environments.

3
PACKAGE CONTENTS:
1. HDMI Wireless Transmitter 1pcs
2. HDMI Wireless Receiver 1~4pcs (optional)
3. IR Transmitter cable 1pcs
4. IR Receiver cable 1~4pcs
5. User manual 1pcs
6. DC power adapter 2~5pcs
FEATURES OF THE INTERFACE:
Transmitter (TX)
FIG.1 TX Front Panel View FIG.2 TX Rear Panel View
Receiver (RX)
FIG.3 RX Front Panel View FIG.4 RX Rear Panel View

1.
2.
3.
4.
5.
6.
Connect one HDMI cable from the DVD/BD player into the HDMI input port of
the HDMI wireless TX.
Connect one HDMI cable from TV/Monitor into the HDMI output port of the
HDMI wireless RX.
Connect the IR Transmitter cable to the HDMI wireless TX and the IR
Transmitter cable must face to the control target device.
7In the case of multiple RX, all RX are connected in the same way.
Connect IR Receiver cable to the HDMI wireless RX.
Connect 5V power supplies to the TX&RX, the POWER indicator will be lit at
this moment.
The device will automatically connect after power on. The STATUS indicator
of TX and RX will be lit when the connection is successful. If the HDMI input or
output signal is normal, the HDMI indicator light will be lit also. The STATUS
indicator flashes continuously during normal transmission.
4
HDMI IN: HDMI INPUT
HDMI OUT: HDMI OUTPUT
DC5V: 5V DC in jack
FIG.5 connection diagram
POWER: Power indicator
STATUS: System status indicator
HDMI: HDMI input/output status indicator
CHANNEL: Wireless channel switch key
HIGH-LOW: Rate selector switch
IR OUT&RESET: Insert IR transmitter cable & Factory Reset Button
IR IN&RESET: Insert IR receiver cable & Factory Reset Button
OPERATIONG AND CONNECTION:

5
1.
Panel key operation instructions:
2.
3. Restore Factory Setting: To press the button for lasting three seconds, then
the HDMI Status Led Light will flash for three times and restart, it shows that
Restore Factory Set is successful.
Select transmission rate: When the rate switch is selected at "HIGH," the
product works in high rate mode, the RX has the best picture quality. If the
rate switch is selected at "LOW", the product works in low rate mode, the RX
has the best working distance at the moment.
Change Wireless channel: Press the “CHANNEL” key on the front panel of
TX to cyclic switch the multiple wireless channels. If the product works
unsteadily or pictures not fluent, You can try a different working channel.
Multi_HDMI_Wireless, Enter the default password: 00000000.
1. Connect 5V power supplies to the transmitter and all receivers, and let
them be connected.
2. Turn on the WLAN of the mobile phone / PC，search and connect SSID：
The Factory Reset Button is located at the bottom of the Hole of the IR IN/OUT.
It is able to work under power on status. To use one long and narrow insulated
stick (like toothpick) to insert the hole end to press the button.
Note: You must to restore factory set at transmitter and all receivers before
they can be reused.
Web settings:
To prevent the interference caused by the same frequency device, the Wireless
HDMI Extender support to set up the , transmit channel andSSID by the WEB.
For safety, the user should change the SSDI and the password at the first log in.
Please follow the below steps:
3. Modify the IP address type of the mobile phone / PC to Auto. When you
select static type, you must be set the IP in 192.168.1. xxx address segment
range, e.g. 192.168.1.100.
4. Open the browser and scan the QR code or enter “192.168.1.10” in the
address bar to enter the configuration page.. As shown below:

6
6. If you have an error in setting or forgot the password, you can restore
factory setting.
5. Enter the default login password: admin, click “Login” open the Settings
Interface. If you want to modify the login password, please click on the
" Modify ", after modified click "save" to save and exit. Restore factory
settings when click "reset".

7
SPECIFICATIONS: HDEX0021M1
HDMI resolution ......................................................up to 1080P@50/60Hz
HDMI Audio Format..................................................LPCM2.0/48KHz/16Bit
HDMI Max bandwidth.....................................................................225MHz
HDMI Max baud rate....................................................................6.75Gbps
Input/Output TMDS signal.........................................0.5~1.5Volts p-p(TTL)
Input/Output DDC signal....................................................5Volts p-p (TTL)
HDMI output cable distance...................İ12m AWG26 HDMI standard cable
Antenna type..............................................External dual 3dBi gain antenna
Wireless standard.............................................................. IEEE 802.11a/n
Wireless Band...................................................................5GHz ISM Band
Max Data rates...........................................................2T2R up to 300Mbps
Transmit Output Power（IPEX）........................................................20dBm Max
Transmission distance.......................................up to 200m (in open space)
IR Carrier frequency...................................................................20-60KHz
TX/RX Max working current...................................................................1A
Power adapter format Input............... AC 100V～240V 50HZ/60Hz, DC5V/2A
Operating Temperature range....................................................-5 to +45ć
Storage Temperature range..................................................... -20 to +60ć
Operating Humidity range..........................10 to 90%RH (No Condensation)
Storage Humidity range...............................5 to 95%RH (No Condensation)
Case Dimension (L x W x H).......................................127.5x127.5x25 (mm)
Weight.............................................................................TX163g/RX160g
Notes:
Pls use the machine as the instruction listed to keep the long use lifetime of the
machine.
1. The machine should be placed at the spot far from the Damp,
High-Temperature, Dusty, Erosive, and oxidative environment.
2. All parts will be free from the strong shake, hit, fall.
3. Touching the power adaptor with the wet hands is prohibited.
4. Pls hold the power adaptor head and do not pull the power cord when cut off
from the socket.
5. Pls turn the power off when the machines not used for long time.
6. Pls do not open the cover and do not touch the inside parts.
7. Pls use the original factory power adaptor.

No. Problem DescriptionSolutions
FAQ:
Before power on, pls check the connection line carefully. And make sure that
all interfaces are normally connected. The common trouble shooting way
shows below:
1No display
1. Check the TV is on and has been connected
with the machine.
2. Please check the TX power supply
3. Make sure the TV is working regularly
Display
2“Connecting” channel
4. Pls reset or turn off the power restart
1. Please check the RX power supply
2. Please check the WEB are set correctly
3. Co-channel interference. Pls select a new
2.
output normal.
1. Check the signal source is power on and
3.
Display
3
1.
“No signal” Check the signal source output resolution.
Make sure the HDMI cable is properly
connected
2.
channel
Transmission
3. Co-channel interference. Pls select a new
4distance is short
Please adjust the angle of the antenna or
adjust the placement
Concrete walls, Brick, Wallpaper, Metal,
Bulletproof glass willshorten the signal
cover range or cause big signal loss.
5Screen not fluent
1. Please adjust the angle of the antenna or
adjust the placement
2. Co-channel interference. Pls select a new
channel
Can't find
8
the SSID
1. Please check the RX and TX power supply
2. Please check whether the Phone/PC
supports 5G band
3. Factory default or turn off the power restart
Can't login to
6
7theWeb settings
interface
1. Please check the RX and TX power supply
2. Please check the IP type of mobile phone/PC
is Auto
3. Please check the IP is in 192.168.1. XXX
address range
4. Please try Login again after changed a browser
