Digitus DS-55100-1 User manual

HDMI Extender Set,
Full HD, 50 m
Quick Installation Guide
DS-55100-1 Rev.3

2
Table of Contents
1. Introduction......................................................................... 3
2. Product Features ................................................................. 3
3. Package Content.................................................................. 4
4. Specification ........................................................................ 4
5. Penal Description................................................................. 4
6. Connection........................................................................... 6
7. Installation Requirements ................................................... 6
8. EDID Setting ......................................................................... 6

3
1. Introduction
The Digitus HDMI Extender Set, Full HD offers an extender
solution of up to 50 m for the highest demands. It is used to
transmit digital video and audio signals to a maximum length of
up to 50 m. The highest supported video resolution is 1080p /
60Hz. The transmitter unit features an EDID switch, which can be
used to regulate resolution and audio format of the output signal.
The transmitter also has an HDMI Loop Out Port, which allows
you to connect a local monitor. Thanks to PoC (Power over Cable)
support, it is only the transmitter unit that needs to be powered.
The package includes two bidirectional infrared units
(transmitter, receiver), which can be used for the remote control
of the connected input source.
2. Product Features
•Extends the maximum length for HDMI cable to up to 50 m
via a simple network cable
•Highest supported video resolution: 1080p / 60 Hz
•Supports CAT 6, CAT 6A, CAT 7 network cables
•EDID Switch - Allows you to set resolution and audio format
on the transmitter unit
•HDMI Loop Out - Allows you to connect a local monitor to
the transmitter unit
•Supports PoE (Power over Ethernet) - thus no power supply
is required for the receiver unit
•Supports uncompressed audio signals such as LPCM
•Compact size, simple use and installation

4
3. Package Content
•1x HDMI Extender transmitter unit
•1x HDMI Extender receiver unit
•1x Power supply unit: DC 5V/2A
•1x IR transmitter unit
•1x IR receiver unit
•1x Instruction manual
4. Specification
Support
HDCP 1.2a
Bandwidth
4.95 Gbps
Color depth
8 bits
Housing
Metal casing
Power supply unit
DC 5V/2A
Dimensions (1x unit)
L 7.2 x W 6.70 x H 2.3 cm
Color
black
5. Penal Description
Transmitter unit (TX)
①IR signal output to connect with blaster extension cable
②RJ45 signal output

5
③HDMI signal indicator led: it lights on all the time when
HDMI signal input, flashes when no signal input
④Reset button
⑤DC 5V power input
⑥HDMI signal output
⑦EDID switch
⑧HDMI signal input
Receiver unit (RX)
①DC 5V power input
②HDMI signal output
③IR signal input to connect with IR receiver extension cable
④LENGTH: for adjusting to the length of network cable
⑤RJ45 signal input
⑥RJ45 indicator led: it lights on all the time when HDMI
signal transmission, flashes when no signal transmission

6
6. Connection
1
DVD
4
HDMI EXTENDER RX
2
HDMI EXTENDER TX
5
HDMI OUT
3
CAT6/6A/7 Cable
6
HDMI display
7. Installation Requirements
1. HDMI source device (computer graphics card, DVD, PS3,
HD monitoring equipment etc.).
2. HDMI display device like SDTV, HDTV, and projector
with HDMI port.
3. UTP/STP CAT6/6A/7 cable, follow standard IEEE-568B.
8. EDID Setting
Switch Status
EDID information
switch 1
switch 2
switch 3
0
0
0
720P@60Hz 2.1CH
1
0
0
720P@60Hz 7.1CH
0
1
0
1080i@60Hz 2.1CH
1
1
0
1080i@60Hz 7.1CH
0
0
1
1080P@60Hz 2.1CH
1
0
1
1080P@60Hz 7.1CH

7
0 1 1
read and save the EDID of
the loop-out TV
1 1 1
Default EDID: 1080P 3D
2.1CH
1. Set the source device resolution to “Auto.” Don’t set any
specific resolution of the source device.
2. HDMI source device reads the EDID information of the
transmitter (TX) and then output the Relative HDMI signal
forma.
3. It needs to power on again or reset the transmitter unit
after re-setting EDID every time.
4. When connect a TV with loop-out HDMI port of
transmitter (TX), it can adjust EDID switch to read and
save this TV’s EDID information. When we use this
function, it should connect TV with transmitter first, and
then power on these devices, so that the EDID will be read
and saved successfully. At next time, even though do not
connect a TV into the loop-out HDMI Port, the source
device will output the saved EDID information last time.

8
