User Manual
USB 2.0 HDMI Video Capturer
Model No. AA6232

FEATURES:
Connection and Operation:
1. Connection diagram
HDMI Input port
Connect to HDMI source with HDMI cable
USB2.0 Male Connector
Plug into USB port
Capturer
Video Player
HD camera
HDMI Cable
PC
Portable Equipment
Game Machine

2. PC hardware requirements
Hardware
Recommended Specifications
CPU
PC i5-3400 or above
NB i7-3537U 2.0GHZ or above
Memory
DDR3 4G or above
Graphics card
PC NVIDIA GT630 or above
NB NVIDIA GT735M or above
Hard disk
500G or above，SSD recommended
3. PC side system & software requirements
Type
Recommended version
Operating System
Windows XP/7/8/10
Andriod5.0 or above
MacOS 10 or above
Installation-free drive under normal conditions
Application
Support most video capture software, such as PotPlayer, VLC,
OBS, Amcap etc.
Note：The software copyright belongs to the third-party company. It is recommended to use licensed software.
4. Operation illustration
Operation Steps for video capture (Win7 and OBS for PC).
Ⅰ. Insert the capturer into the USB port of the PC, Check device identification in Control Panel \ Device Manager
\ Image Devices list.

Ⅱ. Open the OBS software and click the【+】button in the "Sources" control panel to add a video capture device.
Ⅲ. Select the capture device to preview the capture screen normally. Then click 【OK】.
HDSW0031M1

Ⅳ. Drag the red border to resize the capture screen.
Ⅴ. Click 【Settings】button on the lower right corner to enter the setting interface to set audio & video format,
picture quality, output etc. After setting, click 【Start Recording】button.

SPECIFICATIONS:
Model No.
HDCN0051M1
Model name
HD-Video Capturer
Input ports
HDMI1.4 x1
Output ports
USB2.0 x1
HDMI input resolution
3840x2160@30Hz or 4096x2160@24Hz Max
Support 3840x2160@60Hz YUV420
Input color space
RGB、YUV444、YUV422、YUV420
Video output resolution
1920x1080@30Hz Max
Video output format
YUV or JPEG
Audio format
LPCM2.0/32~192KHz/16~24Bit
Input cable length
AWG 26 HDMI standard cable ≤10m
Power supply mode
USB power supply
Max working current
280mA
Working temperature range
-5 ~ +40℃
Working humidity range
5 to 85%RH（No Condensation）
Storage temperature
-15 to 55℃
Storage humidity
5 ~95%RH(No Condensation)
Size
67*26*13 (mm)
Weight
22g
Accessories
Manual x1
