Austin Hughes CyberView Combo DB-15 KVM Series User manual

Combo KVM Installation Guide

KVMU
-
8 / KVMU
-
16
Combo DB
-
15 KVM
Package Content (only for rackmount KVM)
1 KVM switch x 1 pc
2 Screw M3.2 x 4.5mm x 4 pcs
3 Screw M4 x 10mm x 8 pcs
4 Bracket x 1 set
5 User manual x 1 pc
6 Power cord x 1 pc

KVMU-8 / KVMU-16
Connection
Combo DB-15 KVM
KVMU-8
KVMU-16

KVMU
-
8 / KVMU
-
16
Combo DB
-
15 KVM

KVMU
-
8 / KVMU
-
16
Combo DB
-
15 KVM
Cascade
Cascade up to 8 levels, 128 servers
Interconnection with Combo Cat6 KVM
Cascading multiple KVM by KVMCBC-6 cable.
KVMU-8
KVMU-16
KVMU-16
KVMU-8
KVM-CAT6-32
KVM-CAT6-16
KVMCBC-6

KVMU
-
8 / KVMU
-
16
Combo DB
-
15 KVM
Cascade
Cascade up to 8 levels, 128 servers
Interconnection with Combo Cat6 KVM
Cascading multiple KVM by KVMCBC-6 cable.
KVMU-16
KVMU-16
KVMU-16
KVMU-8
KVM-CAT6-32
KVM-CAT6-16
KVMCBC-6

Specifications
Combo DB
-
15 KVM
KVMU-8 / KVMU-16
KVM Port
Number of ports: 8 or 16
Connector: DB-15 combo connector
Connectivity: Combo 4-in-1 KVM cable, up to 6, 10 & 15 feet
Local Console
Graphic connector: 1 x DB-15 VGA
Resolution: Up to 1600 x 1200
Input device: 2 x USB type A for keyboard & mouse
Management
Multilingual OSD: English, France, German, Spanish, Italian, Russian, Simplified Chi
nese,
Japanese
Hotkey combination: Scroll-lock, Cap-lock, Num-lock, Alt, Ctrl & Win
Security: Password enable & disable, up to 8 users pro Þ le for port access
PC Selection: Front button, OSD menu & hotkey
Expansion: Up to 128 servers by 8-level cascade
Compatibility
Multi-platform: Mix PCs, SUNs, IBMs, HPs, DELLs Server
Support: Windows Vista / 2003 / XP / 2000, Linux, Netware, Unix
Power
Input: 100 or 240V AC at 50 or 60 Hz via IEC type cord OR
AC / DC power adapter 12V@3.3A (optional)
Option DC: 12V / 24V / 48V DC input
Consumption: Max. 48 Watt, Standby 5 Watt
Regulatory Approval: FCC, CE
Environmental
Operating: 0 to 50°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)
Product Information
Dimension (W x D x H): 446 x 180 x 44 mm / 17.6 x 7.1 x 1.73 inch
Net weight: 4 kg / 9 lb
Packing Information
Dimension (W x D x H): 510 x 400 x 77 mm / 20.1 x 15.7 x 3 inch
Gross weight: 7 kg / 15 lb

KVM Button
Combo KVM Usage
Power ON
Turn off all servers and KVM switches
Make sure all cables / connectors are properly connected
Recommend Power ON sequence is monitor, KVM switch Þ nally computer

Password
Combo KVM Usage

KVMOSD
Combo KVM Usage

KVM Hotkey
Combo KVM Usage

IP Setting Combo KVM Usage

IPSetting
Combo KVM Usage

Optional Accessories
Combo KVM Usage
1. Combo KVM cable
1.1 KVMCE-6 6 feet
1.2 KVMCE-10 10 feet
1.3 KVMCE-15 15 feet
2. Cat5 cable
2.1 KVMCU-3 3 feet
2.2 KVMCU-6 6 feet
2.3 KVMCU-10 10 feet
2.4 KVMCU-15 15 feet
2.5 KVMCU-33 33 feet
2.6 KVMCU-66 66 feet
3. Combo KVM cascade cable
3.1 KVMCBC-6 6 feet
4. DVI-USB Dongle
4.1 DG-100SD DVI-D
5. VGA-USB Dongle
5.1 DG-100S USB
6. VGA-PS/2 Dongle
6.1 DG-100 PS/2
7. Power cord
7.1 IEC power cord
7.2 NEMA 5-15 power cord (US)
7.3 BS 1363 power cord (UK) 7.4
CEE 7/4 power cord (German) 7.5
AS 3112 power cord (Australia)
