AUSTRALIAN MONITOR ERA User manual

&'ra Components Specification
The @,,ra Home Theatre amplifier is true to life re-
production of artistic power performance and natural
sound phenomena. Some of the outstanding features
of the &-t,r Home Theatre amplifier is super high en-
ergy linear power supply and intelligent protection cir-
cuitry to ensure the highest operational safety and qual-
ity sound reproduction. To meet the heavy demands of
the Home Theatre System the Australian Monitor engi-
neering team has chosen only the highest quality com-
ponents to produce an amplifier that delivers pure, re-
sponsive and powerful sonic quality, durability and reli-
ability.
The left and right speakers are true to life
sound reproduction delivering a crisp,
clear and accurate image across the en-
tire audio signal spectrum.
The High intelligibility level of the centre
speaker will put you face to face with the
actor's dialogue or singer's lyric. The bal-
ance energy distribution of the three front
speakers ensure that the voicing is not
swamped by an explosive sound track.
The Subwoofers are multi-chamber
bass enclosures delivering pure rich
most satisfying musical bass notes.
The bass response extends below your
hearing threshold levelto bring out the
quality of a commercial cinema or an
explosive movie sound track and the
feeling of thundering sound impact.
The dual subwoofer will bring you to
experience the real live performance
of musical concerts and will turn your
living room into a Jurassic Park, rec-
reating the sound of a living dinosaur
walking through your lounge room.
The 6,,ra Surround Speakers are of
classic dipole design creating a wall of
diffused sound image. As a result you
will not hear sound coming from the
speakers but you will hear the effect of
the ambience and moving sound
source. An intelligent approach the
Multi-cham ber &-t,:r surround sound
speaker s will move the sound wih your
moving picture.
6 GhannelAmplifier
Output PowerlGh 6 Ghannels driven
Continuous Power
<0.05% THD + Noise
into 8 ohm ........ .. 100W
Music Power
@1kHz,8 Ohm 10% duty cycle
into 8 ohm ........ .. 130W
Slew Rate @ 4 ohm 30V/ps
Cross Ta1k.......... . >90d8
Sensitivity lVrms
CMRR >8OdB
Voltage Gain......... 22dB
S/NA-wght............... 105d8
Distortion into Sohm
THD @ lk{z ...... 0.005%
Front Speakers
Design Type .........
Driver ....:...:.........
Frequency Response
@t2dB
Pattern
Sensitivity
1mpedance..............
Power Handling
Dimensions
HxWxD..........
Weight
Subwoofer Speaker
Design Type ........
Driver
Frequency Response
@+zoe
Sensitivity
1mpedance..............
Power Handling
Dimensions
HxWxD..........
Weight
Closed Box
dual 5" Driver
& dual 1" tweeter
80Hz-20kHzl
90deg horizontal
40 deg vertical
90dB@1W, lmetre
8 ohms nominal
300w
510x 220 x 255mm
1Okg
Band pass
12" driver
25Hz-120kHz
90dB@1W, lmetre
8 ohms nominal
400w
750x224x520mm
17kg
Rear Surround Speaker
Frequency Response
@ lzd9 90Hz-23kHz
Sensitivity
tmpedanc"...........:......:. :. .:.:
Power Handling
Dimensions
HxWxD..........
Weight
95dB @1W lmetre
4 ohms nominal
100w
155 x 430 x 280mm
7kg
