Auto Page C3-RS-727A LCD User manual

1
C3-RS-727A LCD
PROFESSIONAL 2-WAY LCD REMOTE CAR
STARTER & ALARM SYSTEM
With
Built in Temperature sensor
And Two-way Serial Port Data Link
Compatible
Please see page 23 of this manual for more details
OPERATION MANUAL
Please register your product at:
www.autopageusa.com
THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY

2
TABLE OF CONTENTS:
LCD REMOTE TRANSMITTER:
ABATTERY REPLACEMENT 4
BTHE REMOTE LCD ICONS WITH FUNCTION 5
CPROGRAMMING OF THE LCD REMOTE TRANSMITTER
1. Screen Lamp ON
2. Power Save Mode
3. Clear The Flash Icon and Melody Sound
4. Stop The Melody Sound.
5. Button Lock
6. Vibration / Melody Mode
7. Enable / Disable Bi Sound While Pressing Button:
8. Low Battery Indication.
9. Set Up Fixed Count Down Timer
10. Out Of The Range Check
7
7
7
7
7
8
8
8
8
8
DCLOCK & TIMER SETTING
1. Clock Setting.
2. Alert Alarm Timer Setting
3. Count Down Timer Setting
4. Time Set-Up For “Daily Timer Start”
9
9
9
10
10
REMOTE TRANSMITTER OPERATION
A. REMOTE TRANSMITTER OPERATION 10
BLCD DISPLAY TRANSMITTER OPERATION 11
CLED DISPLAY 11
DCHIRP INDICATOR 11
EPARKING LIGHT 11
FALARM OPERATION CONDITION 11
GACTIVE ARMING –ARM & LOCK
Defective Sensor Reminder
Silent Arming / Disarming
Shock Sensor By-Pass
Hidden Alarm Function
12
12
12
12
12
HPASSIVE ARMING
Passive Arming with Passive Door Locking
Passive Arming By-Pass
12
12
12
IACTIVE DISARMING –UNLOCK & DISARM
TamperDisarming
Pathway Illumination
Two Steps Door Unlock
Automatic Re
-
Arm
13
13
13
13
13
JDISARMING WITHOUT A TRANSMITTER
Overrides the Alarm without Password Pin Code
Overrides the Alarm With Password Pin Code
13
13
14
KVALET MODE
EnterValetMode
Exit Valet Mode
14
14
14
LCAR LOCATOR 14

3
MPANIC FUNCTION 14
NTRIGGER THE SYSTEM
Clear The Trigger Icons and Melody Sound
Stop The Melody Sound Only
Noise Abatement Circuit
15
15
15
15
OANTI CAR-JACKING
Active Anti Car Jacking
Passive Anti Car Jacking
Trigger The Anti Car Jacking Mode
Override The System To Turn Off Anti Car Jacking
16
16
16
16
16
PSYSTEM’S TRIGGER CHECK 16
QSYSTEM’S STATUS CHECK 16
RDRIVER PAGING (OPTION) 16
SDOME LIGHT CONVENIENCE DELAY & SUPERVISION 17
TIGNITION CONTROL THE DOOR LOCK/UNLOCK 17
UTRUNK RELEASE (CHANNEL 3) OUTPUT 17
VCHANNEL 4 TIMER CONTROL OUTPUT 17
WPOWER ON MEMORY 18
XSECOND VEHICLE SECURITY SYSTEM OPERATION
Programming2nd car transmitter
For Standard Remote Transmitter
For 2-Way LCD Display Transmitter
18
18
18
18
REMOTE START OPERATION:
ATO REMOTE START THE VEHICLE
SafeStart (Childsafetymode) 19
BTO OPERATE VEHICLE WHILE RUNNING ON REMOTE START 19
CTEMPORARY STOP FEATURE 19
DTURBO CHARGE MODE 19
ETIMER / TEMPERATURE START
3(2)Hours Timer Start With Temperature-Control Off
3(2)Hours Timer Start With Temperature-Control
Daily Timer Start
Exit the Timer Start
20
20
20
20
20
FTEMPERATURE CHECK 21
GTO TURN OFF THE REMOTE START 21
HSHUT-DOWN INPUT FOR REMOTE STARTER 21
IDISABLING THE REMOTE START SYSTEM 21
Congratulations on your purchase of the RS727A LCD remote start vehicle security
system. We sincerely hope the purchase of the RS727A remote start security system
gives peace of mind to you.
The RS727A LCD is a state-of-the-arttwo-way communication system. Please take
the time to read over this manual to thoroughly familiarize your self with the many
features and options of the RS727A.

4
Auto Page, Inc. has over 25 years of experience in the vehicle security industry in the
United States and is a wholly owned subsidiary of Iwata Electric Co., of Tokyo, Japan.
Iwata has been an industry leader for over 50 years, establishing a reputation for
ingenuity in its engineering capability and innovative communication products. Auto
Page and Iwata maintain a long tradition of providing the best value to their customers.
TRANSMITTERS
The RS727A comes with two transmitters. The XT72LCD is a 2-way transmitter and
receiver, also referred to as a transceiver. The XT-65 is a mini-size 1-way transmitter.
Both operate on the AM band with a code-rolling feature that will prevent any illegal use
of a code-grabber attempting to record and steal the codes of your transmitter.
CHANGING THE BATTERY IN YOUR TRANSMITTERS
XT-73LCD: This transmitter uses a standard 1.5-volt AAA battery. Information on
changing the battery can be found on page 5 of this manual.
XT-65: This transmitter uses one (1) 3-volt lithium ion battery (#CR2032) that is
placed with the (+) side facing upward. To replace the battery, you will need to use a
small flat blade screwdriver and a small Philips screwdriver. Remove the small
Philips head screw. Then locate the small notch on the lower right side of the
transmitter case next to the key ring. Using the flat blade screwdriver, carefully pry the
top case from the bottom case. It should snap apart after breaking the seal. Before
removing the battery note the direction of the positive (+) terminal. Place the new
battery in exactly the same manner, being careful not to bend or damage the contact
terminal. Snap the cases back together and then test the transmitter to insure it arms
and disarms the alarm. Reinstall the Philips screw to finalize the battery replacement.
XT-65 Extended Range Sliding Cover remote
CR2032 3-Volt Battery

5
WARNINGS:
As with any product that performs automatic functions, there are certain safety
precautions that you must practice and be aware of.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or garage.
5. Always apply the parking brake and lock the vehicle as you exit the vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is corrected.
8. The use and operations of this system is the sole responsibility of the operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle running on
public streets.
10. It isnot safe to remote start the vehicle if the vehicle is parked on a steep incline.
LCD REMOTE CONTROL TRANSMITTER:
Note: If the system is interfered by stronger radio
frequency around, sources of high voltage electric
power or such Obstacles like tall buildings and so
on, the transmission range may get shorter as the
system uses low out put powered frequency.

6
A. BATTERY REPLACEMENT:
A 1.5V type AAA Alkaline battery powers the
Remote Transmitter. When the power of the
battery weakens a iconshall be
displayed on the LCD screen. When the old
battery is replaced to new one, there will be
beep sounds indicate the power is up and the
clock on the LCD screen returns to AM12:00
after displaying all the icons.
Correct the time by pressing for 3
s
econds before using (See Timer Setting).
Note : Press the button two times when the battery compartment is
empty, then insert the new battery
B. THE REMOTE LCD ICONS WITH FUNCTION:
DoorLock Your vehicle doors are
locked
Door Unlock Your vehicle doors are
unlocked and the system is
Disarmed
Armed Mode
Your vehicle is in armed
mode Valet Mode
All the function shall be
temporarily on hold.
RemoteTransmission
You are transmitting the
signal to control unit In –Range Indicator
You
r are within range of the
remote control
Door Open Warning
Doors are illegally opened
(Zone 3)
Trunk/Hood Trigger
Trunk or Hood is illegally
opened (Zone 2)
Shock Sensor Trigger
Trigger on Shock Sensor
(Zone 4)
Warn Away trigger
Trigger on Shock Sensor
(Zone1)
Engine Starting
Your vehicle engine
starting by remote control
Engine Running
Your vehicle's engine is
running
Timer Control Start
Start the Engine
automatically at the same
time next day or every
3
-
hour.
Temperature Monitor
Indoor temperature of your
vehicle
Time Monitor
Alert Alarm You have set morning call
alarm
Count Down Timer
Reminder when time is up
for parking
Power Save Mode
Save the battery power

7
Vibration Mode
Remote Control vibrates
when the system is
triggered
Button Lock
Disable the transmission
function temporarily
Driver paging
Someone is paging you in
front of your vehicle
Low Battery
You have to replace the
battery of remote control.
C. PROGRAMMING OF THE LCD REMOTE TRANSMITTER:
Transmitter Button Description Operation
(1 second) LCD screen lamp turns on for 5
seconds. Press and hold for 1 second 1 melody sound to confirm enters.
(3 seconds) Timer Programming Mode. Press and hold for 3 seconds
2-melody sounds to confirm enter.
(5 seconds) Power Save Mode Press and hold for 5 seconds
1 melody sound to confirm enters
--Clear the Flash Icon and Melody Sound on the LCD
ScreenTransmitter Press within 3 seconds
-(2-second) ButtonLock ( )enable /
disable
Press within 3 seconds and Hold
button for 2 seconds
-(2-second) Melody / Vibration ( )
Mode
Press within 3 seconds and Hold
button for 2 seconds
-(2-second)
Program Count Down Timer
( ) (10-Minute / 20M / 30 M
/1Hour /1.5H / 2.0H)
Press within 3 seconds cycling
*leave the buttons starting count
down then flashes
-(2-second) Enable / Disable Bi Sound(Bi)
While Pressing Button Press within 3 seconds and Hold
button for 2 seconds
1. Screen Lamp ON: Press and hold the button one second, one melody will
sound and the LCD screen lamp will turn on for 5 seconds.
2. Power Save Mode:While in the power save mode, the
LCD remote transmitter uses “0” current to save the
battery power.
Entry:Press & hold the button for 5 seconds, one
melody will sound and the icon on the LCD
screen indicates entry of the “power save mode”.
Exit: Press any button of the LCD remote transmitter to

8
exit the “Power Save Mode”.
3. Clear the Flash Icon and Melody Sound:Pressing the button 3 times
within 3 seconds will clear the flash icon and the melody sound on the LCD screen
transmitter.
4. Stop The Trigger Melody Sound: While triggering the alarm the LCD screen
will alert the user through a melody sound and a flashing trigger icon. Press any
button on the LCD remote transmitter to stop melody soundonly.
5. Button Lock:This is useful if you want to disable the
transmission function of the remote control temporarily to
prevent from any inadvertent pressing of buttons by others.
Press the button first, within 3 seconds press and hold
()button for 2 secondsto activateor cancelthe button
lock function, the icon will displayed on the LCD screen to
show the LCD remote transmitter is on “Button Lock”
6. Vibration / Melody Mode:
This
is useful when you are in a noisy place and it is difficult to
hear the beep sound from the remote control. In this mode,
the remote control vibrates itself if your security system is
triggered.
Press the button first, within 3 seconds press and hold
( )button for 2 seconds to select the mode of vibration
or melody, the icon will displayedon the LCD screen to
show the LCD remote transmitter is on vibration mode.
7. Enable / Disable Bi Sound While Pressing Button:
It has a short “bi” sound while pressing the button of the LCD screen transmitter
If you want mute the “bi” sound mute always while press button. Pressthe
button first, within 3 seconds press and hold the (Bi) button for 2 seconds to
disable the “bi” sound.
8. Low Battery Indication:
When the power of the battery weakens, it has two short “bi” sound and flash
icon while pressing the button of the LCD screen transmitter.
9. Set Up Fixed Count Down Timer:
1. Press the button first, within 3 seconds press and hold the ()button
for 2 seconds, the LCD screen will show the icon and timer (i.e. 0:10),

9
2. Press the ()button again showing next order time on the screen (ie.0:
20), press them again (ie.0: 30)…and so on.
3. After the timer is set the countdown beginswhen the iconflashes
Note: 1.The count down period is fixed as 10 minutes, 20 minutes, 30 minutes, 1
hour, 1.5 hours and 2 hours maximum.
a. When the count down timer shows 0:00 it means to turn off the timer.
b. Press button for real time indicationwhen the timer is counting down.
10. Out Of Range Indication:
The system will automatically check the range every 20 minutes after the unit is
armed.
1. If the user is within the range, the icon will display on the LCD screen.
2. If user is out of range, it has five short “bi” sounds and the icon will disappear on the
LCD screen.
D. CLOCK & TIMER SETTING:
Transmitter Button
Description
Press Transmitter Button
1Press & Hold
button for 3 seconds Clock Setting (Hour)
*Flash digit for adjusting for–and for +
Press buttononce Time setting (Minute)
*Flash digit for adjusting
for–and for +
2Press
button once.
Alert Alarm Time Setting (Hour)
*Flash digit for adjusting for–and for +
Press buttononce Alert Alarm Time Setting (Minute)
*Flash digit for adjusting for–and for +
Press buttononce Alert Alarm Setting ON / OFF for OFFand for
ON
3Press buttononce Count Down Timer Setting (Hour) *Flash digit for adjusting
(Max.19 hours 59 minutes)
for–and for +
Press buttononce Count down Timer Setting (Minute)
*Flash digit for adjusting for–and for +

10
Press buttononce Count down Timer Setting ON /
OFF for OFFand for
ON
4Press & hold the
button for 2 seconds. Daily Timer StartTimer Setting
Flash /icon and
“Hours” for adjusting for–and for +
EXIT: Press and hold the button for 2 seconds or leave it for 10 seconds, the
system will exit the programming mode.
1. Clock Setting: Example to AM10:30
1. Press & hold the button for 3 seconds,two-melodies will sound andthe
“Hours” digit flashes for adjusting.
2. Press the or button to decrease or increase the “Hour” digit until AM10:xx
3. Press the button once again then the “Minute” digit flashes for adjusting.
4. Press the or button to decrease or increase the “Minutes” digit until AM
10:30
5.Press the button for 2 seconds, one-melody will sound confirming exit of the
timer program mode.
2. Alert Alarm Timer Setting: Example to PM 6:30
1. Press & hold button for 3 seconds,two-melodies will sound and the
“Hours” digit flashes for adjusting.
2. Press button twice, the LCD screen will show the icon and the “Hours”
digit will flash for adjustment.
3. Press or button to decrease or increase the“Hour” digit until PM6:xx
4. Press button once again then the “Minutes” digit flashes for adjusting.
5. Press or button to decrease or increase the “Minutes” digit untilPM 6:30
6. Press button once again then icon flashes for alert alarm “ON / OFF”
setting
7. Press button to start the “Alert Alarm Timer”, and the “ON” icon will show on
the LCD screen. Press button to stop the “Alert Alarm Timer”, and the “OFF” icon
will appear on the LCD screen.
8.Press the button for 2 seconds,one-melody will soundconfirming exit of the
timerprogrammode.
3. Count Down Timer Setting: Example-Set the countdown timer at 2:30
1. Press & hold the buttonfor3 seconds,two-melodies will sound andthe
“Hours” digit will flash for adjustment.
2. Press the button 5 times, the LCD screen will show the icon and the
“Hours” digit flashes foradjustment.
3.Press or button to decrease or increase the “Hour” digit until2:xx.
4.Press the button once again then the “Minutes” digit will flash for adjusting.
5. Press or button to decrease or increase the “Minute” digit until2:30
6. Press the button once again then the icon flashes for the alert alarm
“ON / OFF” setting.
7. Press the button to start the count down timer, and the “ON” icon will appear
on the LCD screen.
Press the button to stop the count down timer, and the “OFF” icon will appear
on the LCD screen.
8.Press the button for 2 seconds, one-melody will soundto confirm exit of the

11
timer program mode.
Note:Maximum is 19 hours.
4.TimeSet-Up For “Daily Timer Start”: Example to AM 6:30
1. Press & hold the buttonfor3 seconds,two-melodies will sound andthe
“Hours” digit will flash for adjustment.
2. Press & hold the button for 2 seconds, the LCD screen will flash the /
icons and “Hours” digit for Hour set-up.
3. Press or button to decrease or increase the hour digit untilAM 6:00
4. Press the button once again then the minute digit will flash.
5. Press or button to decrease or increase the minutes digit until AM 6:30
6.Press the button for 2 seconds,one-melody will sound to confirm exit of the
timer program mode.
OPERATION:
A. REMOTE TRANSMITTER OPERATION:
Transmitter
Button System Function Remark
Lock Doors & Arm System
Panic function Press and Hold for 3 seconds
Car Locator Under armed mode
-
Arm and Delete The 2 Stage Shock Sensor Press twice within 3 seconds
-Arm System and Hidden Alarm Function Press within 3 seconds and Hold
button for 2 seconds
+ Silent Arming / Disarming Ignition in "off" position.
+ Active Anti Car-Jacking Mode Ignition in "on" position press and
hold for 2 seconds
Unlock Doors & Disarm System
-Two Steps Door Unlock & Disarm System Press twice within 3 seconds.
Trunk Release (Channel 3) Press and Hold for 2 seconds
-
Passive Arming By-pass While the system Disarmed.
Activate or Turn Off The Remote Start Press button once.
+Channel # 4 Timer Output (4)Optional
II
Switching code For 2nd Car Operation.For regularXT-65remote
transmitterOnly
B. LCD DISPLAY TRANSMITTER OPERATION ONLY:
Transmitter Button System Function Remark
-(C) System’s Trigger Record
Check Press within 3 seconds
-
-
(C) System’s Status Check Press within 3 seconds

12
-( ) Optional Driving Pager Press within 3 seconds
-( ) Monitor Indoor Temperature Press within 3 seconds
-( ) Daily Timer Start Press within 3 seconds
LCD screen lamp turns on for
5 seconds. Press and hold for 1 second
--Clear the Flash Icon and
Melody Sound on the LCD
Screen Transmitter Press within 3 seconds
-+ Switching code for 2nd / 1st
Car Operation Press within 3 seconds and Hold
and buttons together for 2
seconds
C. LED display:
LED Function LED Function
Off Disarmed Zone 1 / Warn-Away Trigger
Slow Flash Armed 2 flashes... pause Zone 2 / Trigger on Trunk/Hood
On (Solid) Valet Mode 3flashes…
Pause Zone 3 / Trigger on Door Switch
Pause On Password Lock-out 4flashes…
Pause Zone 4 / Trigger on Shock Sensor
5 flashes... pause Zone 5 / Trigger on Ignition
Switch
D. CHIRP INDICATORS: E. PARKING LIGHT:
Chirp Function Parking light Function
1 chirp Arm 1 flash Arm
2 chirps Disarm 2 flashes Disarm
3 chirps Defective Reminder3 flashes Disarm / Triggered
4 chirps Disarm / Triggered 12 flashes CarLocator
6 chirps Car Locator ConstantOn Under Remote Start
F. ALARM OPERATING CONDITION:
Siren / Horn Parking Light LED Doors Starter Dome Light
1.Arming 1 or 3 Chirps 1 Flash SlowFlash Locking Disable
2.Disarming 2 or 4 Chirps 2 or 3 Flashes Unlocking Turns on for 30
-second
3.Trigger Alarming Flashes SlowFlash Disable Flashes
4.Passive
Starter
Disable
FastFlash Disable
5.Panic
Alarming
Flashes
Flashe
s
6.Car-Jacking Alarming Flashes Disable Flashes
7. Car Locator 6 Chirps 12Flashes Locking
G. ACTIVE ARMING –LOCK & ARM:

13
1.Press button on the transmitter.
2.The siren will chirp once and parking light will flash once indicating that the
system is now armed. The vehicle’s doors will lock upon arming if interfaced with
the security system.
System Arm Door Ajar Trunk / Hood Ajar
Clear The Flash Icon:
Press the button 3
times within 3 seconds
will clear the flash icon
on
the LCD screen
transmitter.
DEFECTIVE SENSOR REMINDER: If the siren sounds 3 chirps, then you have left a
door, trunk, or hood lid ajar.
SILENT ARMING / DISARMING: Press the transmitter and buttons at the
same time will arm or disarm your security system, No chirp sound will be heard,
arm / disarm confirmation will be through the vehicles parking lights only.
SHOCK SENSOR BY-PASS: Pressing the button on the transmitter two times
within 3 seconds will arm the security system and by-pass the shock sensor. The
system will chirp one additional time to confirm the sensor bypass mode was
activated. The sensor bypass feature is programmed to activate for one arming
cycle only. The security system will return to normal operation during the next arming
cycle.
HIDDEN ALARM FUNCTION: Press the button first; within 3 seconds press the
button to activate the hidden alarm function. The security system will arm and with
“Hidden Alarm Function”. The siren / horn will be silenced even if the sensor is
triggered in the armedstatus. Alarm indication will only appear on the LCD.
H. PASSIVE ARMING
Active arming / disarming is controlled by your security system via the remote
transmitter. This security system is equipped with an optional Passive Arming
feature, which allows the security system to arm 30 seconds after the last door is
closed. Operation is as follows.
1. Turn the ignition to the “OFF” position and exit the vehicle.
2. After all entrances are closed, the security system LED will flash fast for 30
seconds. If you reopen any door / hood / trunk, the security system LED will stop
flashing. It will begin flashing again once all vehicle entrances are closed.
3. After 30-second timer has elapsed, the security system will automatically “ARM”.
The siren will chirp [1] time and the parking lights will flash [1] time.
PASSIVE ARMING WITH PASSIVE DOOR LOCKING
The vehicle doors will automatically lock after the passive arming cycle has been
completed.
PASSIVEARMINGBY-PASS: While the system is disarmed, Press the button twice,
the system will respond with [1] chirp and LED will turn “ON”. The security system will
remain in this temporary state for as long as you wish. To exit passive by-pass, press the
transmitter or buttonsand the system will return to normal status.
I. ACTIVE DISARMING –UNLOCK & DISARM:
1. Press buttononthetransmitter.

14
2. The siren will chirp twice and the parking lights will flash twice indicating that the security
system is now disarmed. The vehicle’s doors will unlock and the dome light will turn on
for 30 seconds upon disarming. (Note: Power door locks and dome light must be installed
with the security system.)
System Disarm Doors Trigger Trunk/Hood Trigger
Shock Sensor Trgr Ignition Trigger
Clear The Flash Icon:
Press the button 3 times within 3
seconds to clear the flash icon on the LCD
screen transmitter.
TAMPER DISARMING: If the alarm is triggered upon disarm, the system’s siren will
chirp 4 times, and the parking lights will flash 3 times.
PATHWAY ILLUMINATION: When receiving an unlock /disarm signal, this feature will
turn the parking lights “ON” for 30 seconds and for 10 seconds upon the lock signal.
TWO STEPS DOOR UNLOCK: This feature will independently unlock the driver’s door
only when disarming the security system. Pushing the button a second time
within 3 seconds will unlock the other doors.
AUTOMATIC RE-ARM: If this feature is selected, the security system will
automatically re-arm itself in 60 seconds after disarming with remote transmitter.
Automatic rearm will cancel if any door is opened before the 60 seconds timer has
elapsed.
J. DISARMING WITHOUT A TRANSMITTER
OVERRIDES THE ALARM WITHOUT PASSWORD PIN CODE:
(Factory Default Setting)
The Override function may be used if the remote transmitter is lost or inoperative.
1. Enter the vehicle andturn the ignition switch to 'ON’ position.
2. (Alarm will sound.)
3. Within 10 seconds push and release the valet switch. The alarm will stop
sounding and enter the disarm mode. You can now start and operate the vehicle
normally.
OVERRIDETHE ALARM WITH PASSWORD PIN CODE:
Unlike valet switch easily found, and defeated, this security system allows the
consumer to program a password pin code. Offering a higher level of security.
1. Enter the vehicle and turn the ignition switch to 'ON’ position. (Alarm will sound.)
2. Within 5 seconds, enter your chosen first digit code by pressing and releasing the
Valet Switch. (When finished above procedures, system's siren will stop alarming,
lights will stop flashing, but the vehicle can’t be started.)
3. Within 15 seconds of the last digit code enter (the 1st code), then turn the Ignition
Switch “OFF” and then “ON”.
4. Within 15 seconds, enter your chosen second digit code by pressing and

15
releasing the Valet Switch.
5. Turn the ignition switch “OFF” position. 4 Chirps from siren/horn and 3 flashes
from the parking lights will indicate the system has disarmed.
Note 1: You must override the alarm within 60 seconds. If not, the system will
automatically re-arm.
EXAMPLE: To Override The System With The Password Code 83,
1.Enter the vehicle and turn the ignition switch to the 'ON’ position.
(Alarm will sound.)
2.Within 5 seconds, Press and Release the Valet Switch 8 times, (When finished the
system's siren will stop alarming, lights stop flashing, but the vehicle can not be
started or driven away.)
3.Within 15 seconds of entering the last digit code enter (the 1st code), turn the Ignition
Switch “Off” and then “ON”.
4.Within 15 seconds, Press and Release the Valet Switch 3 times.
5.Turn the Ignition Switch to the “Off” position. 4 Chirps form siren/horn and 3 flashes
from the parking lights will indicate the system has disarmed.
K. VALET MODE:(System in Disarm or Valet mode)
The valet switch allows you to temporarily bypass all alarm function, eliminating the
need to hand your transmitter to parking attendants or garage mechanics. When the
system is in valet mode, all alarm functions and remote start functions are bypassed,
however, the remote panic feature and remote door locks will remain operational. To
use the valet mode, the system must first be disarmed either by using your remote
transmitter, or by operating the Manual Override sequence.
Enter Valet Mode:
1.
From the disarmed condition, turn
the ignition to the “ON” position.
2.
Push and hold the valet switch for 2
secondsunt
il the LED turns on. The
LED will remain “on” as long as the
system is in 'valet mode'.
Remote Door Lock Remote Door Unlock
Exit Valet Mode:
1.Return to normal operation, turn ignition 'on'.
2.Push and hold the valet switch for 2 seconds, The LED will turn off, indicating the
system has exited the valet mode.
L. CAR LOCATOR
Under the armed mode, press the
button to
activate the car locator function. The siren will chirp
6 times. The parking lights will flash 12 times
making it easier to locate your car.
M. PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger the alarm
in case of emergency.

16
1. Press and hold the button for 3 second. The alarm will immediately sound.
2. During panic mode, the normal function of this
transmitter button will be disabled. The transmitter and
buttons can be used to lock and unlock the door (if the
option is installed), however once the button is
pressed, the vehicle’s starter disable device, (where
installed) will be disengaged allowing the vehicle to start.
3. To stop the alarm, press and hold the transmitter or button on the
transmitter again for 3 seconds. Also, if any transmitter buttonsother than or
button is pressed and released, the panic mode will be turned off immediately.
4. If the button is not pressed, the alarm will automatically stop after 30 seconds.
N. TRIGGER THE SYSTEM
When armed, your vehicle is protected as follows:
1.Light impact will trigger the warn-away signal.
2.Heavy impacts / Doors open /(if installed) Hood open / (if installed) Trunk open /
Turning on the ignition key will trigger the programmed sequence.
The starter disable relay (if installed) prevents the vehicle’s starter from cranking.
The siren, horn, parking lights, and dome light will turn on alerting of an intrusion for
30 seconds. Then it will stop and automatic reset and re-arm. If the any one of the
sensors or detectors is still active, the alarm system will sound a maximum of 3
times of 30seconds cycles.
Trunk/Hood Trigger. Door Trigger Shock Sensor Trigger Ignition Trigger
Warn-away Trigger
CLEAR THE FLASH ICON AND MELODY SOUND: When the
alarm is triggered, the LCD screen will alert the user
through a melody sound and by flashing a trigger icon.
Press the button 3 times within 3 seconds to clear
the flash icon and stop the melody sound on the LCD
screen transmitter.
STOP THE MELODY SOUND ONLY: When the alarm is
triggered the LCD screen will alert the user through a
melody sound and a flashing trigger icon. Press any
button on the LCD remote transmitter to stop the melody
sound.
NOISE ABATEMENT CIRCUIT: Your system has a “Noise Abatement Circuit”. It
prevents annoying repetitive trigger sequences due to faulty door pin switches or
environmental conditions such as thunder, jackhammers airport noise, etc.
Here’s how “Noise Abatement Circuit” works: The alarm triggers five times. Each
time, the same sensor or switch has triggered the alarm; the “Noise Abatement
Circuit” will interpret this pattern of triggers as a false alarm. After the third trigger,
the “Noise Abatement Circuit” ignores, or bypasses, that sensor or switch until a
different sensor or switch is trigger.

17
“Noise Abatement Circuit” covers doors (Hood/Trunk) differently: If the alarm is
triggered by an open door for six full cycles, the doors will be bypassed until the
trigger ceases.
O. ANTI CAR-JACKING
Warning: If you don't need the car jacking function in this alarm system, be sure to
set car jacking feature “OFF”. This system is default setting all car jacking “OFF”.
ACTIVE ANTI CAR JACKING:
1.Press and hold the transmitter and buttonsat the same time for 2
seconds while the vehicle’s ignition is ON. The parking lights will turn on for 1.5
seconds to indicate entry.
2.Once the system is armed, if you are forced from the vehicle, the system will
trigger when the door is opened and closed while the ignition is “ON”.
PASSIVE ANTI CAR-JACKING:
It will operate as noted below:
1.Turn the ignition switch to the “ON” position and the system will arm.
2.Once the system is armed, if you are forced from the vehicle, the system will
trigger when the door is opened and closed while the ignition is “ON”.
TRIGGER THE ANTI CAR -JACKING MODE:
a). 50 seconds after the system has beer triggered. The siren will start chirping for
15 seconds.
b). During this 15 second period of chirping, you will be alerted to push the valet
switch once to turn off the car-jacking feature. If not, it will enter a second timer
for car jacking.
c). 65 seconds after the system has been triggered, the siren will start sounding
and the parking lights will start flashing.
d). 90 seconds after the system has been triggered,
1. The siren will sound and the parking lights will flash, and
2. The starter disable will activate to prevent the vehicle from starting.
3. It will remain active until the vehicle's battery power is exhausted.
OVERRIDE THE SYSTEM TO TURN OFF ANTI CAR-JACKING:
Turn the ignition switch from OFF to ON, and within 10 seconds push valet switch,
the siren will stop and the system disarmed
Note: If you use password pin code to double protect the vehicle security, you will
need to use it to completely disarm the system.
P. SYSTEM’S TRIGGER CHECK
Press the transmitter first, within 3 seconds press
(C)button. It will respond with one melody sound and
all trigger records will be immediately displayed on the
LCD screen.
Note: If it has no response,then you are out of range.

18
Q. SYSTEM’S STATUS CHECK
When you want to check the system’s present status
through the LCD screen, Press the transmitter
button twice. Within 3 seconds press the (C)button.
It will respond with one melody sound.
Note: If it has no response then you are out of range.
R. DRIVER PAGING
In the event that someone wants to page the driver of the parked vehicle.
In Car Driver Paging
With the ignition in the switched “off” condition, press and hold the valet switch for 2
seconds to page the driver. One chirp sound will be emitted from the vehicle and the
paging melody sound will continue sounding from your Remote LCD Transmitter
and the “ ” icon will flash on the LCD screen.
Out of Car Driver Paging (Optional Feature)
If someone tries to page you by tapping the paging (knock) sensor (OPTIONAL)
which is usually mounted on the bottom part of front window, the paging melody
sound continues sounding from you Remote LCD Transmitter and the “ ” icon
will flash on the LCD screen.
1. Press the transmitter button first, within 3 seconds
press ( )button to activate the out-of-car driver
pagingfunction. It will respond with chirps from the
vehicle, plus a melody will sound and the " " icon will
flash on the LCD screen to confirm the function is on.
2. When tapping the paging (knock) sensor, one chirp sound shall be emitted from
the siren/horn and the paging melody sound will continue sounding you’re your
Remote LCD Transmitter and the “ ” icon will flash on the LCD screen.
3. Turn on the ignition switch; OR press the button to arm the system; OR
press the button to disarm the system, the out-of-car driver paging function
will exit.
S. DOME LIGHT CONVENIENCE SUPERVISION (Optional Feature)
The alarm has a unique feature that will turn on your vehicle dome light as follows:
1.Upon disarming, the interior light will remain onfor 30 seconds.
2.If the vehicle is intruded, the interior light will flash for the same duration as the
siren.
Note: Turning on the ignition switch or arming the alarm will turn off the dome light.
T. IGNITION CONTROL DOOR LOCK/UNLOCK. (Programmable Feature)
If the vehicles door locks have been interfaced to the security system, the system
will automatically lock the vehicle's doors when the ignition is turned “ON” and /or
unlock the vehicle’s doors when the ignition is turned “OFF”. (Default is “OFF”)

19
U. CHANNEL 3 (TRUNK RELEASE) OUTPUT.
Press and hold
button on the transmitter for two seconds
to remote control the trunk release or other electric devices.
(If Installed as an Available Option)
V. CHANNEL 4 TIMER CONTROL OUTPUT
Press the transmitter (4)and (4) buttonsat the
same time to active Channel 4 function.Channel 4 is
user-programmable timer output. You may program the
built-in timer to send a ground signal for any time duration
from 1 second to 120 seconds. For instance, this timer
output may be used to turn on the headlight, power
window or sunroof. (Factory defaults setting at momentary
output.)
W. POWER ON MEMORY:
This security system is equipped with circuitry that will allow the unit to remember its
alarm state if the power is lost and then reconnected.
X. SECOND VEHICLE SECURITY OPERATION:
Your 5-button remote transmitter can be utilized to control a second vehicle security
system, To program the remote control transmitter to a second vehicle, follow the
instructions for Transmitter programming.
Programming the Transmitter to 2nd Car
Enter:
1. Turn the ignition key ON 3 times. (Finishing in the ON position)
2. Press valet switch2 times, holding in on the2nd push, you will hear a long siren
chirp. (Release the valet switch)
3. Press the shift button of the Car 2 transmitter.
* The standard transmitter (II) is shift button.
** LCD transmitter must be put in 2nd car mode to program for 2nd car. (See below)
4. Press the lock button on the transmitter; you will hear 1 siren chirp.
Turn OFF the ignition switch; you will hear 3 long siren chirps to confirm
programming and exit transmitter programming
*ForStandardRemoteTransmitter:
1. Prior to pushing any button on the transmitter. Press the Select II button first on
the transmitter.
2. Once II button is pressed the LED on the transmitter will illuminate for 3.5
seconds to indicate the second transmitter pin code has built-in.
3. While the LED is illuminated, press any button on the remote control transmitter
to control a second vehicle securitysystem.
** For 2-way LCD Display Transmitter:
2ndCar Operation:

20
1. Press first, within 3 seconds press and hold
and
buttons at the same time for 2 seconds.
Two beeping
sound and the “ ” icon will be displayed
on the LCD
screen to indicate the se
cond transceiver pin code is
programmed.
2. While the “ ”icon is displayed on the LCD screen,
you
canremote control
and communicate with a second vehicle
security system. It has two short “bi” sounds
while pressing
the button of the LCD screen transceiver.
Backto 1st Car Operation:
1. Press first, within 3 seconds press and hold
and
buttons at the same time for 2 seconds.One long
beeping sound and the “ ” timer icon will
be
displayed
on the LCD screen indicating the system is back
to the first transceiver pin code.
2. While the “ ”timer icon is displayed
on the LCD
screen, you can remote control
and communicate with the
first vehicle security system. It has one
short “bi” sound
while pressing the button of the LCD screen transceiver.
REMOTE START OPERATION:
A. TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
1.Press button once on the transmitter.
2. The parking light will activate to indicate the remote start
received the signal.
3. The engine will start in approximately 5 seconds.
4. Once the engine is running, after couple seconds the parking
lights will turn on and the climate controls will activate and adjust
the vehicle’s interior temperature to your preset setting. (While the
vehicle is running, the “minutes” digit on the LCD screen will flash
and the will indicate count down timer based on the 5, 10, 20 or 30
minute run time set up by your installation center.)
5. The vehicle will run for a programmable 5 to 30 minute cycle
before shutting down. (When the unit shuts off the count down timer
will turn off and the transmitter will play a melody.)
NOT E: The Remote Start Unit will not start the vehicle if any one of the
following conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3.The optional remote start enable toggle is switched to the “OFF”
position. (If installed)
Activate Remote
Start
Engine Running
