Auto Page CPX-2300 Installation and operating instructions

Car-Pro
By:
Professional Vehicle Security
CPX-2300
INSTALLATION & OPERATIONS
MANUAL
AUTOPAGE INC.
1815 West 205th Street Suite 101
Torrance, California 90501-1525
Main Office: 310-618-2002
Customer Service: 800-262-2527 Ext. 462
www.autopageusa.com
CPX-2300 WIRE DIAGRAM
H1: 10 PIN HARNESS
10AFuse
3AFuse
5.
Red
wire: to
constant battery +12v
7.
Black
wire:Groundtovehicle
8,Orange wire: 200 mA Ground output when arm
10.
White
wire: Parking light relay output
6.
Brown
wire: Positive output to siren
9.
Red/White
wire: Parking light relay power input
4.
Yellow
wire: To Ignition switch + 12V
3.
Green
wire: Negative door trigger input
2. Violet wire: Positive door trigger input
1. Blue wire: Instant trigger ground input
85
86
30
87a
87
T
o start solenoid
From ignition switch
12V
12V
To ignition
switch +12v
PROGRAMMING
A. TRANSMITTER CODE LEARNING:
Note: This security system will only retain the last 4 remote transmitters programmed. If the
transmitter memory is exceeded, the security system will start deleting transmitters from memory in
chronological order.
1. Disarm the system.
2. Open the Door and keep the door open
3. Turn the ignition key “ OFF / ON “ 6 times, keep at “ON” position at 6th time switching
4. Within 15 seconds press & hold any button for transmitter code learning, a long chirp confirm
transmitter programmed.
5. Apply steps 4 –5 to program 2nd, 3rd and 4th transmitter.
Exit:Turn the ignition off, 3 long chirps confirm exit.
B. FEATURE PROGRAMMING
1. Disarm the system.
2. Open the Door and keep the door open.
3. Turn the ignition key “ OFF / ON “ 3 times stay in on position. (3 chirps to confirm in
programming mode)
4. Within 15 seconds press button “ I + II “ to select the feature which you want to program. See
the features programming table below to select the desired features, which you want to
program. Note the number of siren chirps to confirm the selected feature(s).
5. Press the button “ I “ or “ II “ on the transmitter to enable or disable the specific feature.
6. Repeat steps 4 -5 for any other features you wish to program.
Number of pressing
button I + II & chirps Program feature Press button “ I “ / one long chirp
Factory Setting
Press button “ II “
/ Two long chirps
1
Time for door lock
0.9 sec. 3.5 sec.
2
Passive Door Lock
Disable Enable
3
Ignition lock
Enable Disable
4
Anti car
-jacking Disable Enable
5
Door Ajar Warning
Enable Disable
Exit:Turn the ignition off, or close the door, 3 long chirps confirm exit.
C. PASSWORD SETUP:
1. Disarm the system.
2. Open the Door and keep the door open
3. Turn the ignition key “ OFF / ON” 9 times for “New Password Pin Code Setting” and keep at
“ON” position at 9th time switching.
4. After 2-second pause, the siren will chirp 9 times to confirm entry.
5. Within 15 seconds, begin to enter your chosen 1 –9 digit by pressing and releasing the
transmitter button “I” from 1-9 times
6. Press button “ II ” to get out of password setup mode, corresponding to the newpasswordcode
report by siren chirp confirmation.
Note:Default setting of password code from the factory is “ 1”.
oooo
Blue (-) 200mA Unlock
Green (-) 200mA Lock
Car-Pro
CPX-2200
H1: 10 pin main harness
H2: 3-pin sensor harness
H3: 2-pin LED harness
H4: 3-pin door lock harness
Car–Pro
CPX
–
2300

CPX-2300 OPERATION MANUAL
TRANSMITTER OPERATION:
Transmitter Button Feature Remark
Button Arm / Door lock
–Button Arm and Delete Optional Sensor Press twice within 3
seconds.
Button Car Locator Under arm mode
Button for 3 seconds Panic Press & hold 3 seconds
Button Disarm & door unlock
Button for 2 seconds In or Out Active/Passive mode Press & hold 2 seconds
+Button Silent arm / disarm Under ignition off
+Button for 2 seconds Anti car-jacking Under ignition on
A. ACTIVE ARMING –LOCK & ARM:
1. Press button on transmitter.
2. The siren chirps once and parking lights flash once indicating the system is now armed. The
vehicle doors will lock upon arming when interfaced with the security system.
DOOR AJAR WARNING: When you arm the system and the siren chirps 3 times, it means you
have left a door or trunk, or hood lid ajar. You should check and find out the defective protecting
point.
SHOCK SENSOR / OPTIONAL SENSOR BY-PASS: Press button twice within 3 seconds to
arm the security system, by-pass shock sensor connected to 3-pin plug. The system will chirp one
additional time to confirm the sensor bypass mode was activated. The sensor bypass feature is
programmed to activate for one arming cycle only. The security system will return to the original
program setting for the next arming cycle.
SILENT ARMING / DISARMING: Press +button together to arm or disarm your security
system. No chirp sound will be heard; arm / disarm confirmation will be through the vehicle’s
parking lights only.
B. PASSIVE ARMING
This system is equipped with passive arming feature, which allows the system to arm itself in 30
seconds after the last door is closed; operation is as follows:
1. Turn ignition to OFF position and exit the vehicle
2. After all entrances are closed, the system will start counting and LED flashes for 30 sec., if you
re-open any door / trunk / hood the system will stop counting and the LED will stop flashing. It
will start re-counting again once all vehicles’ entrances are closed.
3. After 30 seconds has elapsed, the security system will automatically “ARM”. The siren will chirp
once and the parking lights will flash once.
REMOTE PASSIVE:
You can use the remote transmitter to both enter and to exit the passive mode, eliminating the
need to hand your transmitter to parking attendants or garage mechanics.
a). Press and release button for 2 seconds. The system will enter the passive mode. One
long chirp confirms entry to the passive mode.
b). Press and release button for 2 seconds. The system will exit the passive mode. Two long
chirps confirm exit of the passive mode.
PASSIVE DOOR LOCKING
The vehicle doors will automatically lock after passive arming cycle has been completed.
C. ACTIVE DISARMING –UNLOCK & DISARM:
Press button on the transmitter, the siren will chirp twice and parking lights will flash twice to
indicate the security system is now disarmed. The vehicle doors will unlock when interfaced with
the security system.
TAMPER DISARMING: If the alarm has been triggered, upon disarming the system, the siren will
chirp 4 times and the parking lights will flash 3 or 4 times.
AUTO RE-ARM:The security system will auto re-arm itself within 30 seconds after disarming by
remote transmitter. Auto re-arm will be canceled if any protected door has been opened before the
30 seconds timer has elapsed.
PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger the alarm in case of
emergency.
1.Under the arming mode press and hold button for over 3 seconds. The siren will sound and
the parking lights will flash.
To stop the panic mode press or button and the panic mode will turn off immediately.
If the button is not pressed, the alarm will automatically stop in 30 seconds.
D. TRIGGER THE SYSTEM
When the alarm system is armed, your vehicle is protected as follows:
1. Light impact will trigger the warn-away signal. A long chirp from siren.
2. Heavy impact / Door open / Hood open / Trunk open / Turning on the ignition switch; all will
trigger the programmed sequence.
For above (2) The siren and parking light will turn on, alerting of an intrusion for 30 seconds. Then
it will stop and automatic reset / re-arm. If any one of the sensors or detectors is still active, the
alarm system will sound a maximum of 3 times of 30 seconds cycles. The starter disable relay (if
installed) prevents the vehicle’s starter from cranking.
E. ANTI CAR -JACKING
Warning: If you don't need anti car-jacking function in this alarm system, be sure to set anti car-
jacking feature “DISABLE”. This system is default setting all anti car-jacking “ DISABLE ”.
1). With the Ignition “on”, press and hold +button on the transmitter for over 2 seconds.
The parking light will turn on for 2 seconds to indicate activation of anti car –jacking mode.
2). TRIGGER THE ANTI CAR -JACKING MODE:
3-timer circuits will function as follows:
First timer:
1. 50 seconds after the system has been triggered, the siren will start chirping for 15 seconds.
2. During this 15 seconds period of chirping, you will be alerted to press and hold +button on
the transmitter for over 2 seconds to turn off the anti car-jacking feature; parking lights will flash
twice and siren will chirp twice confirming success in turning off the anti car-jacking mode.
3. If not, it will enter the second timer of anti car-jacking feature
Second timer:
65 seconds after the system has been triggered. The siren start sounding and the parking lights
will start flashing.
Third timer:
90 seconds after the system has been triggered
a. The siren will continue sounding and the parking lights flashing, and
b. The starter disable will activate to prevent vehicle from starting.
c. It will remain active until the vehicle’s battery power exhausted.
F. DISARMING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost or inoperative.
1. Turn ignition switch to 'ON’ position and the LED will start flashing, indicating the system has
entered the password override mode.
Once the LED has flashed the same number of times as your password number, then turn the ignition
key “OFF”; the alarm will stop sounding and enter the disarm mode. You can now start and operate
the vehicle normally.
Example: If your programmed Password Code is “ 5 ” you would;
1. Turn the ignition switch to the 'ON’ position and the LED will start flashing, indicating the system
has entered the password override mode.
2. Wait until the LED flashes for the 5th time, then the turn ignition key OFF immediately.
The alarm will stop sounding and enter the disarm mode. You can now start and operate the
vehicle normally.
G. IGNITION CONTROL DOOR LOCK.
If the vehicles’ door locks have been interfaced to the security system, the system will
automatically lock the vehicle's door when the ignition “ON” and unlock vehicle’s door when
ignition “OFF”.
H. CAR LOCATOR
Under the armed mode press button to activate car locator,
siren will chirp 6 times and parking lights flash 12 times for
you to easily locate your car.
LED INDICATORS:
LED Function
Off Disarmed
Slow flash Armed
Fast flash Passive arming
CHIRP INDICATORS:
Chirp Function
1 chirps Arm
2 chirps Disarm
3 chirps Door ajar warming
4 chirps Disarm / shock sensor trigger
6 chirps Car locator
PARKING LIGHTS:
ALARM OPERATION CONDITIONS:
Parking light
Function
1 flash Arm
2 flashes Disarm
3 flashes Disarm / trigger on ignition or door
pin switch
4 flashes Disarm / trigger on shock sensor
12 flashes Car locator
Siren
Parking
Light
LED
Door
Starter
“CUT”
Arming 1 or 3
Chips 1 Flash Slow Flash Locking On
Disarming 2 or 4
Chirps 2 or 3 or 4
Flashes
Off or
Fast
Flash
Unlocking Off
Trigger Alarming
Flashes
Slow
Flash On
Panic Alarming
Flashes
Slow
Flash On
