Automatic Technology MegaCode User manual

MegaCode® Receiver
Multi-Frequency Four Channel Receiver
INSTALLATION INSTRUCTIONS | OWNERS COPY
Featuring TrioCode™Technology
10:05:12 STD MON
OFF OFF OFF OFF
Part # 13291 (Manual) v1.01

2MegaCode® Receiver Owner Installation Instructions
MegaCode® Receiver
Four Channel Multi-Frequency Receiver
Features 4
Operating Controls 6
Menu Structure 8
Initial Electrical Installation 9
Coding Transmitters 9
Transmitter Management 11
Code Operation (Location Empty) 12
Code Operation (Location Used) 12
Delete Operation 12
Edit Operation 12
Copy Operation 13
Remote Code Set Procedure 13
Parameter Viewing And Editing 14
Menus 2 Output One Setup 15
Menu 2.1: Output Pulse Time 15
Menu 2.2: Pulse Time Units 15
Menu 2.3: Flash On Time 15
Menu 2.4: Flash Off Time 15
Menu 2.5 Complete Flash Sequence 15
Menu 2.6: Output One Inverted 15
Menu 2.7: Trigger 1 Input 15
Menu 2.8: Trigger 1 Input Contact 15
Menu 2.9: Disable 1 Input Contact 15
Menus 3 Output Two Setup 15
Menu 3.1: Output Pulse Time 15
Menu 3.2: Pulse Time Units 15
Menu 3.3: Flash On Time 15
Menu 3.4: Flash Off Time 15
Menu 3.5 Complete Flash Sequence 15
Menu 3.6: Output Two Inverted 16
Menu 3.7: Trigger 2 Input 16
Menu 3.8: Trigger 2 Input Contact 16
Menu 3.9: Disable 2 Input Contact 16
Menus 4 Output Three Setup 16
Menu 4.1: Output Pulse Time 16
Menu 4.2: Pulse Time Units 16
Menu 4.3: Flash On Time 16
Menu 4.4: Flash Off Time 16
Menu 4.5 Complete Flash Sequence 16
Menu 4.6: Output Three Inverted 16
Menu 4.7: Trigger 3 Input 16
Menu 4.8: Trigger 3 Input Contact 16
Menu 4.9: Disable 3 Input Contact 16
Menus 5 Output Four Setup 17

Owner Installation Instructions MegaCode® Receiver 3
Menu 5.1: Output Pulse Time 17
Menu 5.2: Pulse Time Units 17
Menu 5.3: Flash On Time 17
Menu 5.4: Flash Off Time 17
Menu 5.5 Complete Flash Sequence 17
Menu 5.6: Output Four Inverted 17
Menu 5.7: Trigger 4 Input 17
Menu 5.8: Trigger 4 Input Contact 17
Menu 5.9: Disable 4 Input Contact 17
Menu 6 Operating Modes 17
Menu 6.1: Default Tx Button 1 Function 17
Menu 6.2: Default Tx Button 2 Function 17
Menu 6.3: Default Tx Button 3 Function 17
Menu 6.4: Default Tx Button 4 Function 17
Menu 6.5: Remote Code 17
Menu 6.6: Activity Report 17
Menu 6.7: Activity Report ID 17
Menu 6.8: Vacation 17
Menu 6.9: Password Protection 18
Menu 6.10: Tx# Grouping 18
Menu 7 Time Clock 18
Time Clock Operation 18
Time Clock Settings 18
Menu 7.1 Set Time/date 18
Menu 7.2 View Programs 18
Menu 7.3 Settings 19
Menu 7.3.1 Run Programs 19
Menu 7.3.2 Disable 4 Input 19
Menu 7.3.3 Disable 4 Input Contact 19
Menu 7.3.4 Daylight Saving Time Adjust 19
Menu 8 Diagnostics Tools 19
Menu 8.1 Test Inputs 19
Menu 8.2 Test Tx’ers 19
Menu 8.3 Display History 20
Menu 8.4 Memory Usage 20
Menu 8.5 Console Test 20
Menu 9 Memory Tools 20
Menu 9.1 Clr Control 20
Menu 9.2 Clr Tx’ers 20
System Specifications 21
Warranty 22

4MegaCode® Receiver Owner Installation Instructions
Multiple Modes Of Control
The solid state relay outputs of the MegaCode® receiver can be controlled by
remote control transmitters, wired inputs and a programmable time clock. Each
output can be configured to be a steady state or flashing output
TrioCode™ Code Hopping Technology
Every time a TrioCode™ transmitter is used, a new security code is randomly
generated from over 4.29 billion possibilities. This greatly enhances the security
of the system and makes “code grabbing” a thing of the past.
These transmitters also overcome interference issues by simultaneously sending a
signal over three slightly different frequencies. Even if two of the three signals are
jammed, the system will still work.
Programmable Time Clock
The Time Clock can be used to override transmitter and trigger input control at various
times of the day on a weekly basis. An output can be forced on, forced off or released
for transmitter or trigger input control. The Time Clock has 32 programs which select the
output to be controlled and the time and days of the week it is to be activated.
Console
Incorporated into the MegaCode® receiver is a simple to use console which consists of several
buttons and a display. With the addition of the console, facilities which were only available on previous
receivers using an additional hand held programmer are now available as standard via a simple menu system.
Features include editing transmitter storage and names, setting various parameters, and performing system
diagnostics.
Security Code Store
The MegaCode® receiver uses state of the art technology in storing your selected transmitter security codes.
Up to 511 different transmitters can be stored in the memory with the facility to assign an 11 character ID
label to each transmitter.
Features
Thank you for purchasing the Automatic Technology
MegaCode® Receiver. Designed by our renowned
engineers to suit garage doors and gate openers, the
MegaCode® Receiver will provide years of smart,
simple & secure convenience to your home.

Owner Installation Instructions MegaCode® Receiver 5
Transmitter Management Flexibility
Whenever a large number of transmitters are used, managing those transmitter
effectively is of great importance. The MegaCode® receiver provides many
features which enhance transmitter management. Transmitters can be listed
by store location, group number, serial number or I.D label. Tools are available
which allow transmitters to be Replaced, Deleted and Edited. A quick
transmitter code set feature is provided which allows the button functions
of an existing transmitter to be copied to all transmitters to be coded. This
feature allows many transmitters to be coded without the need for the installer
to touch any console buttons during the coding process.
Status Indication
The status of the receiver outputs and the last event are displayed whenever the
main screen is shown. Information provided includes; the status of each output,
the last transmitter or input that was activated, the last output affected, the time
remaining before an output timer expires etc.
Password Protection
All operating parameters and transmitter storage can be protected from being changed
by unauthorised personnel by an optional password protection feature.
Vacation mode
A handheld transmitter can be programmed to lock and unlock all other transmitters that have been
programmed into the openers’ memory. The vacation mode can be used when the door is left idle for long
periods of time.

6MegaCode® Receiver Owner Installation Instructions
Operating Controls
AC/DC Power Supply Input 12 to 24 AC/DC power supply input terminal.
Output One (1) normally open contacts of the solid state relay output can be controlled by remote
control transmitters, wired inputs and a programmable time clock.
Output Two (2) normally open contacts of the solid state relay output can be controlled by remote
control transmitters, wired inputs and a programmable time clock.
Output Three (3) normally open contacts of the solid state relay output can be controlled by remote
control transmitters, wired inputs and a programmable time clock.
Output Four (4) normally open contacts of the solid state relay output can be controlled by remote
control transmitters, wired inputs and a programmable time clock.
Trigger Input One (1) the output one (1) can also be controlled via trigger one (1) independently. The
trigger input can be programmed to activate its output similar to a transmitter button.
Trigger Input Two (2) the output two (2) can also be controlled via trigger two (2) independently. The
trigger input can be programmed to activate its output similar to a transmitter button.
Trigger Input Three (3) the output three (3) can also be controlled via trigger three (3) independently.
The trigger input can be programmed to activate its output similar to a transmitter button.
Trigger Input Four (4) the output four (4) can also be controlled via trigger four (4) independently. The
trigger input can be programmed to activate its output similar to a transmitter button.
Disable Input One (1) activation of this input will disable Output One (1)
Disable Input Two (2) activation of this input will disable Output Two (2)
Disable Input Three (3) activation of this input will disable Output Three (3)
Disable Input Four (4) activation of this input will disable Output Four (4)
AC/DC Power Supply plug pack Input 12 to 24 AC/DC power supply input
Antenna connector
Clock Battery
Prog Input is used to connect the Automatic Technology Handheld Programmer for editing control and
receiver functions, accessing diagnostic tools, and activating special features and operating modes.
01 02
03 04
05 06
07 08
09 10
11 12
1413
15 16
17 18
19 20
21 22
23 24
25 26
27
28
29
30

Owner Installation Instructions MegaCode® Receiver 7
0806 070502 03 0401
1816 171512 13 1411 2624 252320 21 2219
1009
28
29
30
27

8MegaCode® Receiver Owner Installation Instructions
Menu Structure
Menu 8
Diagnostics
Menu 9
Memory tools
Menu 1
Code
transmitter
Menu 2
Output 1 Setup
Menu 3
Output 2 Setup
Main Screen
Code/edit
transmitter
procedure.
See page 9
See page 15
Menu 9.1
CLR control?
Menu 9.2
CLR Tx’ers?
Memory reset/clear see page 20
Menu 8.1
Test inputs
Menu 8.2
Test tx’ers
Menu 8.3
Display history
Menu 8.5
Console test
Menu 8.4
Memory Usage
Control input
status display.
See page 19
Transmitter
testing
See page 19
Event history
display
See page 20 See page 20
Memory usage
See page 20
NOTES 1. Press PREV/NEXT buttons to move Left/Right. 2. Press OPEN/CLOSE buttons to change setting. 3. Press SET button to save changes. 4. Press EXIT to return to MENU without saving changes. Note: System will automatically return to the main screen after 30 secs if a menu screen is displayed and no buttons are pressed.
Menu 5
Output 4 Setup
Menu 6
Operating
Modes
Menu 7
Time Clock
Menu 4
Output 3 Setup
See page 15
See page 17
See page 16 See page 17 See page 18

Owner Installation Instructions MegaCode® Receiver 9
1
fig
2
fig
MEGA CODE RM01
Firmware 1.01
00:00:80 STD ---
OFF OFF OFF OFF
Receiver Supply
The MegaCode® receiver is designed to be powered
from 12V - 24VAC/DC. A suitable 12VDC plug pack also
can be used to power up the MegaCode® receiver.
Wiring Outputs
Each output is able to switch up to 40VAC/DC @
100mA. Each output consists of a solid state relay with
normally open (selectable to N/C) contacts. No internal
connections exist to the relay contacts so it may be
treated as a simple switch.
Wiring Inputs And Powering Up The Receiver
Each input is operated by a simple switch contact. Do
not apply any voltage to the inputs. The Trigger inputs
are normally open (selectable to N/C) inputs. After re-
checking all wiring, apply power to the receiver. The
receiver will go through a startup sequence displaying
the startup screen which indicates the receiver type and
firmware version (Fig. 1). After a short delay the main
screen will be displayed. This will show the current time
and day of the week on the top line. The bottom line
will show the output status starting with Output 1 on
the left through to Output 4 on the right (Fig. 2). Make
sure the time and day are set correctly.
Initial Electrical Installation
Coding Transmitters
The MegaCode® receiver can store up to five hundred
and eleven (511) transmitters in its memory. Each
transmitter can be allocated an alpha-numeric ID label up
to eleven (11) characters in length and each button can
be assigned to any channel. The settings for a transmitter
are represented in (Fig. 3). It shows the transmitter’s
store number, ID label or serial number and the functions
assigned to each of its four buttons. To toggle between
ID/SN display, press UP/DOWN with the cursor on the
ID/SN indicator.
Brand Of Transmitters
The first memory location sets the type of transmitters
which can be stored into the memory of the receiver.
It either can be Automatic Technology TrioCode™ or
B&D Tri-Tran™ transmitters. For example, if the first
transmitter stored is TrioCode™, then the rest of the
transmitters can only be the TrioCode™ type and mixing
of TrioCode™, Tri-Tran™ is not possible. The deletion of
all stored transmitter codes from the receivers memory
will allow you to choose either TrioCode™ or Tri-Tran™
transmitters again.
3
fig
I.D label/Serial number
Output 1 function
Store number
ID/SN display indicator
12 ID NAME/SN
M_1 T_4 PR_3 S_1
Output 2 function
Output 3 function
Output 4 function

10 MegaCode® Receiver Owner Installation Instructions
Coding Transmitters
Any button of the transmitter can be assigned to
any output on the MegaCode® receiver. To code a
transmitter button:
Navigating to “Code Transmitter” menu
1. Press NEXT to navigate to the Menu 1 (Fig. 4).
2. Press SET to enter code set procedure.
Storing transmitter code
1. Receiver will prompt to press one of the transmitter’s
buttons.
2. Press the transmitter button you wish to operate the
receiver (e.g. button 1) (Fig. 5).
3. Press the same transmitter button again as prompted
by display (Fig. 6).
Selecting function of the button
The receiver will now show the transmitter’s record, with
a cursor on the field for the button being coded (Fig. 7).
Use UP/DOWN to select the function for the button.
Available functions are:
M_# (Mimic)
P_# (Pulse)
PR# (Pulse/Reset)
T_# (Toggle)
S_# (Set)
R_# (Reset)
VAC (Vacation)
−−− (OFF)
Where # is the output Number 1,2,3,4
Press SET to save the settings (Fig. 8) or EXIT to abort
without saving.
Editing the store location
This feature is only available when coding the first
button of a new transmitter.
1. Press NEXT or PREV to move cursor over Store No.
2. Press UP or DOWN to select new Store No (Fig. 9).
3. Press SET to Confirm or NEXT/PREV to move to next
field.
This is useful when managing transmitters using
a scheme which ties the store location to the
transmitter’s owner.
Returning to main screen
The “Code Transmitter” menu will now be shown.
Press EXIT to return to the main screen and test the
transmitter.
5
fig
MENU 1
Code Transmitter
PR E S S
6
fig
7
fig
8
fig
2 ID[ No Name ]
M_1 --- --- ---
PRESS
2 ID[ No Name ]
M_∆--- --- ---
PRESS
Press Tx'er
Again!
PRESS
4
fig
Press Tx'er
Button! LIST—›
PRESS
∆ID[ No Name ]
M_1 --- --- ---
PRESS
9
fig

Owner Installation Instructions MegaCode® Receiver 11
Transmitter Management
MENU 1
Code Transmitter
PR E S S
10
fig
Press Tx’er
Button! LIST—»
PRESS
11
fig
12
fig
13
fig
Press Tx'er
Again! VIEW—»
PRESS
The MegaCode® provides a transmitter listing facility
which enables the User to find a transmitter location
within memory. Once located a stored transmitter can
be replaced, deleted, edited, copied or, if the location
is empty, a new transmitter can be coded.
Method 1 - Go to the start of the list
Accessing the list menu
1. Press NEXT to navigate to Menu 1.
2. Press SET to enter the transmitter edit procedure
(Fig. 10).
3. Press NEXT to enter the transmitter list and edit
mode (Fig. 11). This is used if the transmitter is not
available.
Method 2 - Use transmitter to go direct to list
Accessing the list menu
1. Press NEXT to navigate to Menu 1.
2. Press SET to enter the transmitter edit procedure
(Fig. 10).
3. Press transmitter once (Fig. 12).
4. Press NEXT to view transmitter parameters (Fig. 13).
This is used for quick navigation if the transmitter is
available. The transmitter details will be shown (Fig.
14).
NOTE: “VIEW>” will not be shown if the transmitter is
not stored.
Once the list is displayed it can be sorted by stored
number, ID Label or Serial Number. Use NEXT or PREV
button to select sorting method.
NOTE: When sorting by ID label or S/N, only stored
transmitter locations are displayed.
Navigating the list
1. Press UP or DOWN buttons to navigate through the
list (Fig. 15).
2. Press SET to display menu of available functions.
NOTE: Holding a button down will step through the
list faster.
14
fig
51∆ID T SMITH
M_3 T_4 R_1 S_2
Press Tx'er
Button! LIST—›
PRESS
31∆ID T SMITH
P_1 --- R_1 T_2
PRESS
15
fig

12 MegaCode® Receiver Owner Installation Instructions
Transmitter Management
16
fig
18
fig
19
fig
17
fig
Selecting an Operation
Press NEXT or PREV to cycle through the four menu
options (Fig. 16-19). Press EXIT to return to the list.
Press SET to execute the menu’s operation.
Menu 1.1 Code Operation (location empty)
If the code operation is selected on an empty
transmitter location, the code transmitter procedure
will be initiated with the transmitter being saved in
the selected location. This is useful when managing
transmitters using a scheme which ties the store
location to the transmitter’s owner.
Menu 1.1 Code Operation (location used)
If the code operation is selected for a location
that already contains a transmitter, then the code
transmitter procedure will be initiated and the new
transmitter will replace the existing one. Note that the
button functions and name of the existing transmitter
will be transferred to the new transmitter. This
procedure is of great convenience when replacing
a lost transmitter.
Menu 1.2 Delete Operation
The delete operation is used to remove a transmitter
from memory along with the name and button function
settings.
Menu 1.3 Edit Operation
The edit operation displays the transmitter record for
editing purposes.
Editing The Button Function Fields
Select the desired field by using NEXT or PREV to
move the cursor.
Use UP and DOWN to change the displayed
value. When the correct setting has been made
repeat step i (above) to select the next field to
edit. The example (Fig. 19) shows editing the
function of transmitter number 510 assigned to
the Output 1.
Available functions:
M_# (Mimic)
P_# (Pulse)
PR# (Pulse/Reset)
T_# (Toggle)
S_# (Set)
R_# (Reset)
VAC (Vacation)
−−− (OFF)
Where # is the output number M_1,M_2, M_3,M_4
Press SET to save the settings (Fig. 8) or EXIT to abort
without saving.
i.
ii.
MENU 1.1
Code Tx# 312
MENU 1.2
Delete Tx# 312
MENU 1.3
Edit Tx# 312
510 ID[ No Name]
M_∆T_4 R_1 S_2

Owner Installation Instructions MegaCode® Receiver 13
Editing A Character Field
Select the desired field by using NEXT or PREV to
move the cursor.
Use UP and DOWN to change the displayed
value. When the correct setting has been made
repeat step i (above) to select the next field to
edit. The example (Fig. 20) shows editing the
function of transmitter number 510 assigned
to the Output 1. When a change is made, the
bottom line of the display will show a list of available
characters to choose from with the current value
indicated at the cursor position (Fig. 20). When the
correct character has been selected, repeat STEP 2
to select the next field to edit.
Menu 1.4 Copy Operation
The copy operation is used to code multiple transmitters
with the same button function as that of the selected
transmitter.
Exiting The List
To exit the transmitter list simply press EXIT to return
to the code.
i.
ii.
510 IDA
456789 ∆BCDEFGHI
PRESS
Remote Code Set Procedure
If a TrioCode™ transmitter is already coded into
the MegaCode® receiver, additional TrioCode™
transmitters can be coded without being in direct
contact with the MegaCode® receiver.
NOTE: Only the function of the existing transmitter
button can be assigned to new transmitter. Take into
account that there is a time-out facility for security
reasons. This feature is only available with TrioCode™
transmitters
1. Selecting the function to be coded
Using the existing transmitter, operate the
MegaCode® receiver’s output with the transmitter
button which has the function to be coded (Fig. 21)
(e.g. Button 1 has been coded with the M_1 function
assigned).
3. Activate remote code set mode
Using a small pin, press and hold through the Coding
Hole of the existing transmitter for two seconds (Fig.
22).
4. Code new transmitter button
Within 10 seconds, press the button on the new
transmitter you wish to code for 2 seconds (Fig. 23).
5. Confirm transmitter button to be coded
Press the same button again (within 10 seconds) for
confirmation.
PRESS
Existing
transmitter
Existing
transmitter
21
fig
22
fig
20
fig

14 MegaCode® Receiver Owner Installation Instructions
Remote Code Set Procedure
New
transmitter
PRESS
23
fig
Viewing And Editing Parameters
This section illustrates how to locate, view and adjust
parameters.
Locating parameters
Refer to MENU STRUCTURE on Page 8. Locate the
required parameter and note the MENU number. The
example used in (Fig. 24) displays “1: Output Pulse
Time”
Changing setting
1. Press NEXT/PREV to navigate to the required menu.
2. Press SET to show the sub-menu.
3. Press NEXT/PREV to go to required sub-menu.
4. Press SET to enter edit mode.
5. Press UP/DOWN to change the parameter setting
(Fig. 25). Holding the button down causes the
parameter’s value to change rapidly. The longer the
button is held, the faster the value changes.
6. Press SET to SAVE setting.
Reload default Value
1. Press NEXT/PREV buttons to display LOAD
DEFAULT screen.
2. Press SET to load the default value.
Return to menu
If the parameter’s value is not to be changed, press
EXIT to return to the sub menu. Press EXIT again to
return to the MAIN SCREEN.
24
fig
1: Output Pulse
Time 1.0
25
fig
1: Output Pulse
Time 1.0
Parameter name
Parameter
value
Displays next
parameter
in list
Parameter number in list
Enter Edit
Mode
Displays previous
parameter in list
Returns back to menu Enter Edit Mode
View Mode (No cursor)
Edit Mode (Cursor shown)
Increase
value
Displays “Load
Default?” screen,
giving option of
loading default value Exits back to View Mode
with no changes made
Decrease
value
Saves new
value and exits
back to View
Mode
Displays “Load
Default?” screen,
giving option of
loading default
value
Cursor shown
6. Test operation
The new transmitter button should now function
identically to the existing transmitter.
NOTE: When a transmitter is remote coded, its ID
label is set to that of the existing transmitter. If the
existing transmitter does not have an ID label assigned,
then the ID label of the new transmitter is set to: R/C
Tx ###, where ### is the existing transmitters store
number. This ensures that the originator of any remote
coded transmitter can be identified.

Owner Installation Instructions MegaCode® Receiver 15
Menu 2. Output One Setup
The output setup parameters in Menu 2 is used to configure Output One.
Menu 2.1: Output Pulse Time
This parameter sets the duration of the output pulse time. The output pulse time is used only for pulse
functions. The time is adjustable from 0.1 to 99.9 units.
Menu 2.2: Pulse Time Units
This parameter sets the units used for the output time settings. The options are Sec, Min or Hrs.
Menu 2.3: Flash On Time & Menu 2.4: Flash Off Time
A flash on an output is created by repeatedly turning the output on and off. The Flash On Time sets the
duration of the on phase while the Flash Off Time sets the duration of the off phase. For a steady output state
which does not flash, set the Flash On Time = 0.0s. The Flash Off Time is not used for steady state outputs.
Menu 2.5: Complete Flash Sequence
Turning this parameter on will allow the flash cycle to complete if the output is turned off during the flash cycle.
Menu 2.6: Output One Inverted
Output One is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 2.7: Trigger One Input
Output One can also be controlled via independent Trigger One input. The trigger input can be programmed to
activate its output similar to a transmitter button.
Menu 2.8: Trigger One Input Contact
Trigger One input is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 2.9: Disable One Input Contact
This input can be used to disable the output in software regardless of the state of the transmitters, wired inputs
or time clock.The disable input is normally configured for N/O operation. This parameter allows its operation to be
changed to N/C.
Menu 3 Output Two Setup
Menu 3. Output Two Setup
The output setup parameters in Menu 3 is used to configure Output Two.
Menu 3.1: Output Pulse Time
This parameter sets the duration of the output pulse time. The output pulse time is used only for pulse
functions. The time is adjustable from 0.1 to 99.9 units.
Menu 3.2: Pulse Time Units
This parameter sets the units used for the output time settings. The options are Sec, Min or Hrs.
Menu 3.3: Flash On Time & Menu 3.4: Flash Off Time
A flash on an output is created by repeatedly turning the output on and off. The Flash On Time sets the
duration of the on phase while the Flash Off Time sets the duration of the off phase. For a steady output state
which does not flash, set the Flash On Time = 0.0s. The Flash Off Time is not used for steady state outputs.
Menu 3.5: Complete Flash Sequence
Turning this parameter on will allow the flash cycle to complete if the output is turned off during the flash cycle.
Menu 2 Output One Setup

16 MegaCode® Receiver Owner Installation Instructions
Menu 3.6: Output Two Inverted
Output Two is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 3.7: Trigger Two Input
Output Two can also be controlled via independent Trigger One input. The trigger input can be programmed to
activate its output similar to a transmitter button.
Menu 3.8: Trigger Two Input Contact
Trigger Two input is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 3.9: Disable Two Input Contact
This input can be used to disable the output in software regardless of the state of the transmitters , wired
inputs or time clock. The disable input is normally configured for N/O operation. This parameter allows its operation
to be changed to N/C.
Menu 4 Output Three Setup
Menu 4. Output Three Setup
The output setup parameters in Menu 4 is used to configure Output Three.
Menu 4.1: Output Pulse Time
This parameter sets the duration of the output pulse time. The output pulse time is used only for pulse
functions. The time is adjustable from 0.1 to 99.9 units.
Menu 4.2: Pulse Time Units
This parameter sets the units used for the output time settings. The options are Sec, Min or Hrs.
Menu 4.3: Flash On Time & Menu 3.4: Flash Off Time
A flash on an output is created by repeatedly turning the output on and off. The Flash On Time sets the
duration of the on phase while the Flash Off Time sets the duration of the off phase. For a steady output state
which does not flash, set the Flash On Time = 0.0s. The Flash Off Time is not used for steady state outputs.
Menu 4.5: Complete Flash Sequence
Turning this parameter on will allow the flash cycle to complete if the output is turned off during the flash cycle.
Menu 4.6: Output Three Inverted
Output Three is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 4.7: Trigger Three Input
Output Three can also be controlled via independent Trigger Three input. The trigger input can be programmed to
activate its output similar to a transmitter button.
Menu 4.8: Trigger Three Input Contact
Trigger Three input is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 4.9: Disable Three Input Contact
This input can be used to disable the output in software regardless of the state of the transmitters , wired
inputs or time clock. The disable input is normally configured for N/O operation. This parameter allows its operation
to be changed to N/C.

Owner Installation Instructions MegaCode® Receiver 17
Menu 5. Output Four Setup
The output setup parameters in Menu 5 is used to configure Output Four.
Menu 5.1: Output Pulse Time
This parameter sets the duration of the output pulse time. The output pulse time is used only for pulse
functions. The time is adjustable from 0.1 to 99.9 units.
Menu 5.2: Pulse Time Units
This parameter sets the units used for the output time settings. The options are Sec, Min or Hrs.
Menu 5.3: Flash On Time & Menu 3.4: Flash Off Time
A flash on an output is created by repeatedly turning the output on and off. The Flash On Time sets the
duration of the on phase while the Flash Off Time sets the duration of the off phase. For a steady output state
which does not flash, set the Flash On Time = 0.0s. The Flash Off Time is not used for steady state outputs.
Menu 5.5: Complete Flash Sequence
Turning this parameter on will allow the flash cycle to complete if the output is turned off during the flash cycle.
Menu 5.6: Output Four Inverted
Output Four is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 5.7: Trigger Four Input
Output Four can also be controlled via independent Trigger Four input. The trigger input can be programmed to
activate its output similar to a transmitter button.
Menu 5.8: Trigger Four Input Contact
Trigger Four input is configured for N/O operation. This parameter allows its operation to be changed to N/C.
Menu 5.9: Disable Four Input Contact
This input can be used to disable the output in software regardless of the state of the transmitters , wired
inputs or time clock. The disable input is normally configured for N/O operation. This parameter allows its operation
to be changed to N/C.
Menu 6 Operating Modes
Menu 6.1-4 Default Tx B1-4 Functions
These parameter are used to set the default output function offered when coding a transmitter button.
Menu 6.5 Remote Code
The receiver supports the Remote Code Set feature. This parameter can be used to disable the feature for
security or transmitter management reasons.
Menu 6.6 Activity Reports
This parameter enables activity report outputs. Contact Automatic Technology for more details.
Menu 6.7 Activity Report ID
This parameter sets the ID of the controller that is sent with the activity report. Contact Automatic Technology
for more details.
Menu 6.8 Vacation Mode
Vacation mode can be turned on or off using this parameter.
Menu 5 Output Four Setup

18 MegaCode® Receiver Owner Installation Instructions
Menu 6.9 Password Protection
The password feature enables all parameters and configuration settings to be protected unless a password is
entered. When this feature is turned on, the user is requested to enter a password to be used. The password
protection feature has a timeout that expires after 60 seconds of inactivity. Alternatively the User may log out
manually by pressing EXIT when the main screen is displayed.
Menu 6.10 Transmitter # Grouping
The transmitter store number display format can be changed to show a grouped format. When grouping is
selected, instead of displaying the store location as a number between 1 and 511, it is displayed as ##$ where
## is the group number and $ is a character a,b,c,d,e,f,g or h which indicates the group member.
Menu 7 Time Clock
The MegaCode® receiver provides a programmable Time Clock which can be used to control its outputs on a
timed basis at various times of the week. This section details the Time Clock operation and configuration.
Time Clock Operation
The Time Clock consists of a 7 day clock and storage for 32 programs . The clock is powered by its own battery
and therefore does not lose time when the MegaCode® receiver is turned off. Each Time Clock program
defines the time of the day and the days of the week it is to run and the output function to be executed. Any
combination of the days of the week can be selected.
The output actions available are:
S_# Output# is SET on, Transmitter and wired triggers are ignored.
R_# Output# is RESET off, Transmitter and wired triggers are ignored.
RX# Output# is released for transmitter and wired trigger access. The output state is not changed.
--- Not used
Note that the most recent program that applies to an output remains active until a new program takes effect.
The program is not just executed at the programmed time but from the programmed time until another
program takes over. This also means that each output’s state is correctly restored after power failure, Vacation
Mode and output disabling. If a Time Clock program does not have a day selected then it can not executed. If
a Time Clock program is taking control of an output (function = S_# or R_#), then this status is displayed on the
MAIN SCREEN in the output field as #S or #R where # is the program number.
Time Clock Settings
The Time Clock settings are accessed by selecting the Time Clock Menu 7. Press SET to enter the menu and
then PREV or NEXT to navigate through the options.
Menu 7.1 Set Time/date
This is where the current time, date and day are displayed and set. Note the time is in a 24 hour format and
the day of the week is not automatically set with the date. To change the settings simply press UP or DOWN
to display the cursor and then move to the field to be changed using the NEXT / PREV buttons. Then press UP/
DOWN to change the setting and then press the SET or EXIT buttons to save.
Menu 7.2 View Programs
Select this menu to display or edit the Time Clock
programs. When selected, program number 1 is
displayed and the cursor is shown on the program
number field. The other fields shown include the
function, time and days of operation. The example
in Fig. 26 shows that output 1 will be SET on at 6pm
on Mondays, Tuesdays, Wednesdays, Thursdays and
Fridays. Use the UP / DOWN buttons to scroll though
the other programs. To edit a program, simply press
the NEXT / PREV buttons to move the cursor onto
the required field and press the UP/DOWN button to
change the value. To save the program settings, press
SET or to exit without saving press EXIT.
P#01 S_1
18:00:00 MTWTF--
26
fig

Owner Installation Instructions MegaCode® Receiver 19
Menu 8 Diagnostic Tools
The controller provides several diagnostic tools from
within the Diagnostics Menu 8. This section details the
function of each tool and its use.
Navigating to Diagnostics Menu
1. Press PREV to navigate Menu 8 (Fig. 27).
2. Press SET to display the menu of available functions.
3. Press PREV or NEXT to cycle through the diagnostic
tool.
4. Press SET to select.
Menu 8.1 Test inputs
This tool is used to view the state of the control inputs.
When selected, a screen is displayed (Fig. 28) which
indicates the state of disable and trigger inputs. If the
number of the input is shown then that input is active.
For normal operation all inputs should be inactive
when idle. When finished press EXIT. The example in
Fig. 28 shows the status shown when Trigger 4 input
is active.
Menu 8.2 Test tx’ers
This tool is used to test receiver/transmitter
functionality. When selected, a screen is displayed
which prompts for a transmitter button to be pressed
(Fig. 29) and whether ID or serial numbers are to be
displayed.
The opener will then beep each time a transmission
is received. If the transmitter button is stored in the
controller memory and has a function assigned to
it, a second screen will be displayed that shows the
transmitter details along with the button pressed
(Fig. 30). The example shows the case when transmitter
number 3 is activated by button 1. Note ID is selected
for display.
MENU 8
Diagnostics
PRESS
29
fig
DISABLE: ....
TRIGGER: ...4
28
fig
PRESS TX’ER!
<—/—> Shows ID/SN
27
fig
Menu 7.3 Settings
This menu is used to adjust the Time Clock according to the daylight saving period.
Menu 7.3.1 Run Programs
This parameter allows the User to halt or run the timer programs.
Menu 7.3.2 Disable 4 Input
This input can be used as a daylight saving time adjuster. When activated, it will add the amount of time
selected in Menu 7.3.4 to the Time Clock.
Menu 7.3 .3 Disable 4 Input Contact
Disable four (4) input is configured for N/O operation. This parameter allows its operation to be changed to N/C
Menu 7.3 .4 Daylight Saving Time Adjust
The amount of time to add to the time clock at start of daylight saving period is selected here. The options are:
0, 30, 90, 120 minutes
3 IDAB SMITH
›ON OFF OFF OFF
PRESS
30
fig

20 MegaCode® Receiver Owner Installation Instructions
The Memory Tools accessed from within Menu 9 (Fig.
33) are used to clear the controller’s. memory. Once
selected, the PREV or NEXT buttons can be used
to view the Memory Tool options. To execute the
displayed option simply press SET.
Menu 9.1 Clr control
This option will clear the MegaCode® receivers
memory and reload the factory set defaults for
parameters.
Menu 9.2 Clr tx’ers
This option will clear the transmitter storage memory.
Menu 9 Memory Tools
MENU 9
Memory Tools
33
fig
31
fig
32
fig
Used = 15
Free = 496
3 F= M_1
Event# 64
Menu 8.3 Display history
The MegaCode® keeps a record of the last 64 events
that have taken place. The events include outputs
turning off & on and by what cause, power failures etc.
When this tool is selected, a screen displays the last
event that occurred. The NEXT and PREV buttons can
be used to view each event. The “EVENT#” field shows
the sequence of the events, with 64 being the first and 1
being the last. The example (Fig. 31) shows that the last
event was “output 1 was triggered by the transmitter #
3”. When finished viewing the events, simply press EXIT.
Menu 8.4 Memory usage
This tool displays the number of transmitter store
location used and the number free (Fig. 32).
Menu 8.5 Console Test
This tool allows to test the console buttons and the
beeper.
